THE SOFT BUTTON
USER GUIDE
Control all your smart home
with The Soft Button.
Approvals and certications
Contact
After sales
Manufacturer and importer:
NodOn, 121 rue des Hêtres
45590 St CYR EN VAL (FRANCE)
NodOn®is an ID-RF SAS trademark.
www.nodon.fr section “support” • suppor[email protected]
For user guides in other languages, please visit
www.nodon.fr/notices
Hereby, ID-RF SAS declares that this radio
equipment is conform to the RED directive
2014/53/UE. The integral text of the EU declaration
of conformity is available at the following online
address: www.nodon.fr ”support” section.
This product is conform to EnOcean®radio protocol.
The presence of this symbol on a product
indicates that this one is conform to the European
directive 2012/19/UE. Find out more about the
provisions in force in your region regarding the
separate collection of electrical and electronical
devices. Respect the local rules and do not
throw out the product with common domestic
wastes. The correct rejection of ancient products
allows to preserve the environment and health.
Use cautions
• Do not swallow
• Not suitable for children under 3 years
Reference: TSB-2-2-01
Cozy White

Use
Pairing
Quickmove®compatibility
Features
3 types of presses:
Battery change
Single
press Long
press
Double
press
Shockproof
The Soft Button has a
silicone case, allowing it to
withstand shocks.
Waterproof IP67
The Soft Button is waterproof
to immersion, up to 1 meter.
Magnetic
The Soft Button has an
embedded magnet to
be fixed on any metallic
surface: fridge, heater,
lamp, etc.
For an optimum range of the signal up to 30 meters,
take out the remote from its metallic support.
Metallic sticker support included
Take out the plastic lm and place the
metallic sticker support at the desired
location.
To pair your Soft Button to your
compatible home automation gateway
or device, do 5 consecutive short
presses.
Proceed to the battery CR2032 change following
the diagram below.
The Soft Button is Quickmove®compatible for
wireless pairing (NFC scan or QR Code) with
the smartphone app of your home automation
gateway (please refer to your gateway user guide
for more details).
Find the list of compatible devices on nodon.fr/en/tsb-2-2-01
Technical specications
• Power source: battery CR2032
• Battery lifetime: 7 years
• Protection factor: IP67
• Operational temperature: from -10°C to 50°C
• Center radio frequency: 868.3 MHz
• Occupied frequency band: 868.0 to 868.6 MHz
• RF power Max: +3dBm
• Range: 20-30 meters indoor
• EEP (EnOcean® Prole): D2-03-0A
• Warranty: 2 years
