NoiseKen LSS-F03 Series User manual

INSTRUCTIONMANUAL
LIGHTNINGSURGESIMULATOR
MODEL LSS-F03 SERIES
NOISE LABORATORY CO., LTD.
The 1.04 edition
AEE00567-00E-0E

NOTICE
•The contents of this instruction manual (the “Manual”) are subject to change
without prior notice.
•No part of the Manual may be reproduced or distributed, in any form or by any
means, without the authorization of Noise Laboratory Co., Ltd. (the “Company”).
•The contents of the Manual have been thoroughly examined. However, if you find
any problems, misprints, or missing information, please feel free to contact our
sales agent who you purchased our product from.
•The Company assumes no responsibility for any loss or damage resulting from
improper usage, failure to follow the Manual, or any repair or modifications of this
product undertaken by a third party other than the Company or the agent
authorized by the Company.
• The Company assumes no responsibility for any loss or damage resulting from
remodeling or conversion solely undertaken by the user.
• Please note that the Company cannot be held responsible for any consequences
arising from the use of this product.

1
Only well-trained EMC technicians (electric technicians) are
allowed to use the Unit.
The Unit may cause a fatal wound. Carefully handle it. And it may radiate
electromagnetic noise which exceeds the regulation value. Take applicable
countermeasures such as faraday cage, shield room, etc. as the need arises.
The Unit should be used only for EMC testing described in
this manual.
Using it for other purposes may result in a fatal or serious accident.
A person who has a pacemaker on should not operate the
Unit and also should not enter the area where it is operating.
It may result in a fatal or serious accident.
The Unit cannot be used in an explosive area, fire prohibited
area, etc.
Use of the Unit in such an area is liable to cause combustion or ignition.
1. IMPORTANT SAFETY PRECAUTIONS
The following instructions are very important for safe handling of the lightening surge
simulator LSS-F03 series (hereinafter “the Unit”). They must be kept strictly to prevent
users of the Unit from receiving harm or damage through using the Unit. Read them
carefully before use.
A number of safety recommendations are listed in the later chapter
"BASIC SAFETY PRECAUTIONS". Be sure to read them before test
environment settings, connecting relating equipment and testing.

2
2. CHECK PACKAGE CONTENTS
Before using the instrument, check whether the included accessories are
complete according to the following list.
A B C D
E F G H
I J K L
A
： AC cable--------------------------------------------------------------------------------------------- 1
B ： Surge output cable (1.8m) （ MODEL ： 05-00137A alligator clip ） --------------- 2
C ： Line output cable (1.8m) （ MODEL ： 05-00138A M6 ） ----------------------------- 3(A1/C1)
5(A3/C3)
D ： FG cable (2m) （ MODEL ： 05-00070A M6 － M6 ） ----------------------------------- 1
E ： Coaxial cable for monitoring (1m) （ MODEL ： 02-00128A BNC － BNC ） ------ 1
F ： Interlock connector-------------------------------------------------------------------------------- 1
G ： High voltage connector cap （ MODEL ： 05-00060A ） --------------------------------- 5(A1/C1)
7(A3/C3)
H ： Telecom line output cable (1m) （ MODEL ： 05-00061A ／ 05-00065A ） ---------- 5(C1/C3)
I ： Coupling arrestor unit (for coupling) （ MODEL ： 08-00016A ） ----------------------- 4(C1/C3)
J ： Arrestor unit (For input protection) （ MODEL ： 08-00012A ） ------------------------ 4(C1/C3)
K
： Accessory bag------------------------------------------------------------------------------------- 1
L ： Instruction manual--------------------------------------------------------------------------------- 1

3
3. APPLICATION FORM FOR INSTRUCTION MANUAL
We place an order for an instruction manual.
Model: LSS-F03
Serial No.:
Applicant:
Company name:
Address:
Department:
Person in charge:
Tel No.:
Fax No.
Cut off this page “APPLICATION FORM FOR INSTRUCTION
MANUAL” from this volume and keep it for future use with
care.
When an INSTRUCTION MANUAL is required, fill in the above Application Form and
mail or fax it to the following sales department of our company.
To: Noise Laboratory Co., Ltd.
1-4-4 Chiyoda, Chuo-ku, Sagamihara City,
Kanagawa Pref., 252-0237 Japan
Tel: [phone] Fax: [phone]
Cut
line

Memorandum
4

5
4. PREFACE
4-1. Preface
We thank you very much for your purchase of our Lightening Surge Simulator LSS-F03
series (hereinafter “the Unit”). This instruction manual (“the Manual”) contains how to use
the Unit and other important information. In order to obtain the highest performance from
the Unit, thoroughly understand the contents of the Manual and use as ready reference
for operation.
 The Manual was prepared so that any person who can observe the prescribed instruction
method and operating precautions may safely handle and fully utilize the Unit.
 Keep the Manual by your side or other proper location so that it may be readily available
when using the Unit.
4-2. Feature
Conforming to IEC61000-4-5 (Edition 3.0 / 2014)
 Generating combination wave surge of 1.2/50 µ s and 10/700 µ s prescribed by IEC 61000-4-5
(Edition 3 / 2014).
Combination waves mean output of 1.2/50 µ s or 10/700 µ s voltage surge waveform with the
surge output unit opened (load: more than 10k Ω ) and output of 8/20 µ s or 5/320 µ s current
surge waveform with the output unit short-circuited.
 Testing high voltage and great electric current (voltage surge: 15kV, current surge: 7500A).
The surge generating circuit adopts a floating output system recommended by IEC
61000-4-5 (Edition 3 / 2014).
 Capable to conduct surge injection test to power supply lines with the CDN (Coupling and
Decoupling Network) for EUT which is equipped as standard equipment. The AC/DC line
injection part adopts a circuit system conforming to IEC 61000-4-5 (Edition 3 / 2014).
 Capable to conduct surge injection test to TELECOM lines with the incorporated CDN for the
symmetrical interconnection lines (C1 / C3 model).
User-friendly LCD Control Panel
 The operation panel adopts a color LCD touch panel for pursuing high visibility.
 Capableof variouskindsofsetupwithsimpletouchpanel.
 Employspushbuttonsfor handling safety-relatedoperationsuchasSTART/STOP.
Various Functions Broaden Horizons of Test
 Preset test conditions which are prescribed on the standard in the “standard test” mode.
 Capable to set test conditions as you like in the “manual test” mode.
 “Sweep” function enable automatic step-by-step change of test parameters.
 Capable to save your test conditions.
 Remote control is available with optical communication (optional).
 Capable to set upper limit of voltage setup (6kV).

6
