Nokia 002G846 User manual

Nokia 2630 User’s Guide
9203192_2630_en_apac_v1.1_web.fm Page -13 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that
this RM-298 product is in compliance with
the essential requirements and other relevant
provisions of Directive 1999/5/EC. A copy of
the Declaration of Conformity can be found at
http://www.nokia.com/phones/
declaration_of_conformity/.
© 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution, or storage of part or all of the
contents in this document in any form without the prior written
permission of Nokia is prohibited.
Nokia, Nokia Connecting People, Xpress-on, Navi, and Visual Radio are
trademarks or registered trademarks of Nokia Corporation. Nokia tune is a
sound mark of Nokia Corporation. Other product and company names
mentioned herein may be trademarks or tradenames of their respective
owners.
US Patent No 5818437 and other pending patents. T9 text input software
Copyright © 1997-2007. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol
software from RSA Security.
Java and all Java-based marks are trademarks or registered
trademarks of Sun Microsystems, Inc.
0434
i
9203192_2630_en_apac_v1.1_web.fm Page -11 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

This product is licensed under the MPEG-4 Visual Patent Portfolio License
(i) for personal and noncommercial use in connection with information
which has been encoded in compliance with the MPEG-4 Visual Standard
by a consumer engaged in a personal and noncommercial activity and
(ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use.
Additional information, including that related to promotional, internal,
and commercial uses, may be obtained from MPEG LA, LLC.
See <http://www.mpegla.com>.
Nokia operates a policy of ongoing development. Nokia reserves the right
to make changes and improvements to any of the products described in
this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO
CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE
RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER
CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED “AS IS”. EXCEPT AS
REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE
THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR
NOTICE.
ii
9203192_2630_en_apac_v1.1_web.fm Page -10 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

The availability of particular products and applications and services for
these products may vary by region. Please check with your Nokia dealer
for details, and availability of language options.
This device may contain commodities, technology or software subject to
export laws and regulations from the US and other countries.
Diversion contrary to law is prohibited.
The third-party applications provided with your device may have been
created and may be owned by persons or entities not affiliated with or
related to Nokia. Nokia does not own the copyrights or intellectual
property rights to the third-party applications. As such, Nokia does not
take any responsibility for end-user support, functionality of the
applications, or the information in the applications or these materials.
Nokia does not provide any warranty for the third-party applications.
BY USING THE APPLICATIONS YOU ACKNOWLEDGE THAT THE
APPLICATIONS ARE PROVIDED AS IS WITHOUT WARRANTY OF ANY KIND,
EXPRESS OR IMPLIED, TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW. YOU FURTHER ACKNOWLEDGE THAT NEITHER NOKIA
NOR ITS AFFILIATES MAKE ANY REPRESENTATIONS OR WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO WARRANTIES OF
TITLE, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
OR THAT THE APPLICATIONS WILL NOT INFRINGE ANY THIRD-PARTY
PATENTS, COPYRIGHTS, TRADEMARKS, OR OTHER RIGHTS.
iii
9203192_2630_en_apac_v1.1_web.fm Page -9 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Contents
For your safety.................. vi
About your device ..................ix
Network services......................x
General information ....... xii
Access codes ......................... xii
1. Get started ................... 1
Install the SIM card and
battery ....................................... 1
Remove the SIM card ............ 3
Charge the battery ................. 4
Normal operating position... 5
2. Your phone................... 6
Keys and parts ......................... 6
Switch the phone on or off . 8
Standby mode.......................... 8
Keypad lock .............................. 9
3. Call functions............. 10
Make and answer a call..... 10
Loudspeaker .......................... 10
4. Write text................... 11
5. Menu functions.......... 12
Messaging .............................. 12
Contacts.................................. 20
Log............................................ 21
Settings................................... 22
Operator menu...................... 32
Gallery ..................................... 32
Media....................................... 33
Organiser ................................ 36
Applications........................... 38
Web.......................................... 39
SIM services........................... 42
6. Battery information... 43
Charging and discharging.. 43
Nokia battery authentication
guidelines ............................... 45
7. Genuine
Enhancements ................. 48
Battery..................................... 49
Nokia Bluetooth Headset
(BH-100)................................. 50
iv
9203192_2630_en_apac_v1.1_web.fm Page -8 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Nokia Wireless Plug-in Car
Handsfree (HF-33W) .......... 50
Nokia Carrying Case
(CP-153)................................. 50
Care and maintenance.... 51
Additional safety
information...................... 53
Small children ...................... 53
Operating environment ..... 53
Medical devices ................... 54
Vehicles .................................. 55
Potentially explosive
environments........................ 57
Emergency calls ................... 58
Certification information
(SAR) ....................................... 59
Index................................. 61
v
9203192_2630_en_apac_v1.1_web.fm Page -7 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

For your safety
Read these simple guidelines. Not following them may be
dangerous or illegal. Read the complete user guide for further
information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone
use is prohibited or when it may cause interference
or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to
operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the device off near
medical equipment.
vi
9203192_2630_en_apac_v1.1_web.fm Page -6 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause
interference in aircraft.
SWITCH OFF WHEN REFUELING
Do not use the device at a refueling point. Do not
use near fuel or chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the device where
blasting is in progress.
USE SENSIBLY
Use only in the positions as explained in the product
documentation. Do not touch the antenna areas
unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this
product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries.
Do not connect incompatible products.
vii
9203192_2630_en_apac_v1.1_web.fm Page -5 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written
record of all important information stored in your
device.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user
guide for detailed safety instructions. Do not
connect incompatible products.
EMERGENCY CALLS
Ensure the phone function of the device is switched
on and in service. Press the end key as many times as
needed to clear the display and return to the
standby mode. Enter the emergency number,
then press the call key. Give your location. Do not
end the call until given permission to do so.
viii
9203192_2630_en_apac_v1.1_web.fm Page -4 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

■About your device
The wireless device described in this guide is approved for use on
GSM 900 and 1800 networks. Contact your service provider for
more information about networks.
When using the features in this device, obey all laws and respect
local customs, privacy and legitimate rights of others, including
copyrights.
Copyright protections may prevent some images, music
(including ringing tones), and other content from being copied,
modified, transferred, or forwarded.
Warning: To use any features in this device, other than
the alarm clock, the device must be switched on.
Do not switch the device on when wireless device use
may cause interference or danger.
ix
9203192_2630_en_apac_v1.1_web.fm Page -3 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

■Network services
To use the phone you must have service from a wireless service
provider. Many of the features require special network features.
These features are not available on all networks; other networks
may require that you make specific arrangements with your
service provider before you can use the network services.
Your service provider can give you instructions and explain what
charges will apply. Some networks may have limitations that
affect how you can use network services. For instance, some
networks may not support all language-dependent characters
and services.
Your service provider may have requested that certain features
be disabled or not activated in your device. If so, these features
will not appear on your device menu. Your device may also have
a special configuration such as changes in menu names,
menu order, and icons. Contact your service provider for more
information.
x
9203192_2630_en_apac_v1.1_web.fm Page -2 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

This device supports WAP 2.0 protocols (HTTP and SSL) that run
on TCP/IP protocols. Some features of this device, such as
multimedia messaging service (MMS), remote synchronization,
and accessing internet with the browser, require network
support for these technologies.
xi
9203192_2630_en_apac_v1.1_web.fm Page -1 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

General information
■Access codes
The security code helps to protect your phone against
unauthorized use. You can create and change a code, and set the
phone to request the code.
The PIN code supplied with the SIM card, protects the card
against unauthorized use. The PIN2 code supplied with some
SIM cards, is required to access certain services. If you enter the
PIN or PIN2 code incorrectly three times in succession, you are
asked for the PUK or PUK2 code. If you do not have them,
contact your local service provider.
The module PIN is required to access the information in the
security module of your SIM card. The signing PIN may be
required for the digital signature. The barring password is
required when using the call barring service.
Select Menu > Settings > Security to set how your phone uses
the access codes and security settings.
xii
9203192_2630_en_apac_v1.1_web.fm Page 0 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Get started
1
1. Get started
■Install the SIM card and battery
For availability and information on using SIM card services,
contact your SIM card vendor. This may be the service provider
or other vendor.
Note: Always switch off the power and disconnect the
charger and any other device before removing the
cover. Avoid touching electronic components while
changing the cover. Always store and use the device
with the cover attached.
1. Push the side release buttons (one on each side of the cover)
(1) to release the back cover (2), and lift it from the phone.
9203192_2630_en_apac_v1.1_web.fm Page 1 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Get started
2
2. Insert the SIM card (3). Ensure that the gold-colored contact
area faces down and the beveled corner of the SIM card is
slided in first.
3. Insert the battery into the battery slot (4). Ensure that the
contacts on the top of the battery are facing the connectors
in the phone.
4. To replace the back cover, position the bottom first, then
press the top of the cover down (5) until it clicks into place.
9203192_2630_en_apac_v1.1_web.fm Page 2 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Get started
3
■Remove the SIM card
1. Follow step 1 of “Install the SIM card and battery” to remove
the back cover.
2. Lift the battery out by the groove at the top (1).
3. With the finger grip, carefully slide the SIM card holder
out (2).
4. Carefully slide out the SIM card from the holder (3).
5. Slide the SIM card holder closed (4).
9203192_2630_en_apac_v1.1_web.fm Page 3 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Get started
4
6. Follow step 3 and 4 of “Install the SIM card and battery” to
replace the battery and the back cover.
■Charge the battery
Warning: Use only batteries, chargers, and
enhancements approved by Nokia for use with this
particular model. The use of any other types may
invalidate any approval or warranty, and may be
dangerous.
Check the model number of any charger before use with this
device. This device is intended for use when supplied with power
from the AC-3 charger.
This device is intended for use with the BL-4B or BL-4BA battery.
For availability of approved enhancements, please check with
your dealer. When you disconnect the power cord of any
enhancement, grasp and pull the plug, not the cord.
1. Connect the charger to a wall outlet.
2. Connect the charger to the phone as
shown.
9203192_2630_en_apac_v1.1_web.fm Page 4 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Get started
5
■Normal operating position
Your device has an internal antenna.
Note: As with any radio
transmitting device, avoid touching
an antenna unnecessarily when the
antenna is in use. For example, avoid
touching the cellular antenna
during a phone call. Contact with a transmitting or
receiving antenna affects the quality of the radio
communication, may cause the device to operate at a
higher power level than otherwise needed, and may
reduce the battery life.
9203192_2630_en_apac_v1.1_web.fm Page 5 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Your phone
6
2. Your phone
■Keys and parts
• Earpiece (1)
• Display (2)
• Left selection key (3)
• Right selection key (4)
• Call key (5)
• End key and power key (6)
• Keypad (7)
• Navi™ key (hereinafter
scroll key) (8)
• Wrist strap eyelet (9)
• Camera lens (10)
• Loudspeaker (11)
• Microphone (12)
9203192_2630_en_apac_v1.1_web.fm Page 6 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.

Your phone
7
• Headset connector (13)
• Charger connector (14)
• Battery cover release
button (15)
• Camera key (16)
Some special key functions
are as follows:
• Press the camera key to activate the camera;
• Press and hold the camera key to activate the video;
• Press and hold *to activate the FM radio;
• Press and hold #to activate silent mode.
Note: Do not touch this
connector as it is intended for
use by authorized service
personnel only.
Warning: The scroll key in this device may contain
nickel. Continuous exposure to nickel on the skin may
lead to a nickel allergy.
9203192_2630_en_apac_v1.1_web.fm Page 7 Monday, November 19, 2007 4:18 PM
Copyright © 2007 Nokia. All rights reserved.
