Nokia X3-00 User Guide
Issue 1.0

Contents
Safety 4
Get started 5
Keys and parts 5
Insert the SIM card and battery 6
Insert and remove the memory
card 7
Charge the battery 8
GSM antenna 8
Accessories 9
Switch it on 10
About your device 10
Network services 10
Access codes 11
Switch the device on and off 12
Standby mode 12
Navigate the menus 14
Lock the keys 15
Functions without a SIM card 15
Flight profile 15
Support and updates 16
Support 16
My Nokia 17
Download content 17
Software updates using your PC 17
Software updates over the air 18
Restore factory settings 18
Make it your device 19
Basic settings 19
Personalise your phone 21
Connect 24
Network provider services 27
Stay in touch 29
Make calls 29
Text and messages 32
Mail and Instant Messaging 37
Image and video 43
Capture images 43
Record video clips 43
Camera and video settings 43
Gallery 44
Print images 45
Memory card 45
Entertainment 46
Listen to music 46
Web 51
Games and applications 53
Maps 55
Download maps 55
Maps and GPS 56
2Contents
© 2009 Nokia. All rights reserved.2

Extra services 57
Organise 58
Manage contacts 58
Business cards 59
Date and time 59
Alarm clock 60
Calendar 60
To-do list 60
Notes 61
Calculator 61
Countdown timer 61
Stopwatch 61
Green tips 62
Save energy 62
Recycle 63
Learn more 63
Nokia original accessories 63
Practical rules about accessories 64
Battery 64
Digital rights management 65
Third-party applications 65
Battery 65
Battery and charger information 65
Nokia battery authentication
guidelines 66
Care and maintenance 67
Recycle 68
Additional safety information 68
Magnets and magnetic fields 68
Small children 68
Operating environment 68
Medical devices 68
Vehicles 69
Potentially explosive
environments 69
Emergency calls 69
Certification information (SAR) 70
Index 71
Contents 3
© 2009 Nokia. All rights reserved. 3

Safety
Read these simple guidelines. Not
following them may be dangerous or
illegal. Read the complete user guide for
further information.
SWITCH ON SAFELY
Do not switch the device on
when wireless phone use is
prohibited or when it may
cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always
keep your hands free to
operate the vehicle while
driving. Your first
consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be
susceptible to interference,
which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions.
Switch the device off in
aircraft, near medical
equipment, fuel, chemicals,
or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may
install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved
accessories and batteries. Do
not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-
resistant. Keep it dry.
4Safety
© 2009 Nokia. All rights reserved.4

Get started
Get to know your phone, insert the
battery, SIM card, and memory card, and
learn some important information
about your phone.
Keys and parts
1Earpiece
2Music key: skip/rewind
3Music key: play/pause
4Music key: skip/forward
5Left and right selection key
6Call key
7Microphone
8Display
9Navi™ key (scroll key)
10 End/Power key
11 Keypad
12 Loudspeaker
13 Loudspeaker
14 Nokia AV Connector (3.5 mm)
15 Charger connector
16 Micro USB cable connector
17 Volume keys
18 Capture key
Get started 5
© 2009 Nokia. All rights reserved. 5

19 Camera lens
20 Memory card slot
21 Wrist strap eyelet
Insert the SIM card and battery
Note: Switch off the power and
disconnect the charger and any other
device before removing the covers.
Avoid touching electronic components
while changing the covers. Always store
and use the device with the covers
attached.
The SIM card and its contacts can be
easily damaged by scratches or
bending, so be careful when handling,
inserting, or removing the card.
1 Open the back cover, and remove it.
Remove the battery.
2 Open the SIM card holder. Insert the
SIM card into the holder with the
bevelled corner facing down and
the contact surface area facing
toward the contacts of the device.
Close the SIM card holder.
3 Line up the battery contacts, and
insert the battery. Replace the back
cover.
6Getstarted
© 2009 Nokia. All rights reserved.6

Insert and remove the memory card
Use only compatible microSD cards
approved by Nokia for use with this
device. Nokia uses approved industry
standards for memory cards, but some
brands may not be fully compatible with
this device. Incompatible cards may
damage the card and the device and
corrupt data stored on the card.
Your device supports microSD cards
with a capacity of up to 8 GB. The size of
a single file must not exceed 2 GB.
Insert the memory card
1 Open the cover of the memory card
slot.
2 Insert the card into the memory
card slot with the contact surface
facing down, and press until it locks
into place.
3 Close the cover of the memory card
slot.
Remove the memory card
Important: Do not remove the memory
card during an operation when the card
is being accessed. Doing so may damage
the memory card and the device, and
corrupt data stored on the card.
You can remove or replace the memory
card without switching the device off.
1 Ensure that no application is
currently accessing the memory
card.
2 Open the cover of the memory card
slot.
3 Press the memory card slightly in to
release the lock, and remove the
card.
Get started 7
© 2009 Nokia. All rights reserved. 7

Charge the battery
Your battery has been partially charged
at the factory. If the device indicates a
low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full
charge, disconnect the charger from
the device, then from the wall
outlet.
You can also charge the battery with a
USB cable with power from a computer.
1 Connect the USB cable to a USB port
of a computer and to your device.
2 When the battery is fully charged,
disconnect the USB cable.
You do not need to charge the battery
for a specific length of time, and you can
use the device while it is charging. If the
battery is completely discharged, it may
take several minutes before the
charging indicator appears on the
display or before any calls can be made.
Charging the device while listening to
the radio may affect the quality of
reception.
GSM antenna
Your device may have internal and
external antennas. Avoid touching the
antenna area unnecessarily while the
antenna is transmitting or receiving.
Contact with antennas affects the
communication quality and may cause
a higher power level during operation
and may reduce the battery life.
8Getstarted
© 2009 Nokia. All rights reserved.8

The figure shows the GSM antenna area
marked in grey.
Accessories
Connect a USB cable
Open the cover of the USB connector,
and connect the USB cable to the device.
Headset
Warning:
When you use the headset, your ability
to hear outside sounds may be affected.
Do not use the headset where it can
endanger your safety.
When connecting any external device or
any headset, other than those approved
by Nokia for use with this device, to the
Nokia AV Connector, pay special
attention to volume levels.
Do not connect products that create an
output signal as this may cause damage
to the device. Do not connect any
voltage source to the Nokia AV
Connector.
Strap
Thread a strap as shown in the picture
and tighten it.
Get started 9
© 2009 Nokia. All rights reserved. 9

Switch it on
Learn how to switch on your phone, and
how to use the basic functions.
About your device
The wireless device described in this
guide is approved for use on the GSM
850, 900, 1800, and 1900 MHz
networks. Contact your service provider
for more information about networks.
Your device may have preinstalled
bookmarks and links for third-party
internet sites and may allow you to
access third-party sites. These are not
affiliated with Nokia, and Nokia does
not endorse or assume liability for
them. If you access such sites, take
precautions for security or content.
Warning:
To use any features in this device, other
than the alarm clock, the device must be
switched on. Do not switch the device
on when wireless device use may cause
interference or danger.
When using this device, obey all laws
and respect local customs, privacy and
legitimate rights of others, including
copyrights. Copyright protection may
prevent some images, music, and other
content from being copied, modified, or
transferred.
Make back-up copies or keep a written
record of all important information
stored in your device.
When connecting to any other device,
read its user guide for detailed safety
instructions. Do not connect
incompatible products.
The images in this guide may differ from
your device display.
Refer to the user guide for other
important information about your
device.
Network services
To use the device you must have service
from a wireless service provider. Some
features are not available on all
networks; other features may require
that you make specific arrangements
with your service provider to use them.
Network services involve transmission
of data. Check with your service provider
for details about fees in your home
network and when roaming on other
10 Switch it on
© 2009 Nokia. All rights reserved.10

networks. Your service provider can
explain what charges will apply.
Your service provider may have
requested that certain features be
disabled or not activated in your device.
If so, these features will not appear on
your device menu. Your device may also
have customized items such as menu
names, menu order, and icons.
Access codes
To set how your phone uses the access
codes and security settings, select
Menu > Settings > Security > Access
codes.
•The security code helps to protect
your phone against unauthorised
use. The preset code is 12345. You
can change the code and set the
phone to request the code. Some
operations require the security
code regardless of the settings, for
example if you want to restore the
factory settings. Keep the code
secret and in a safe place separate
from your phone. If you forget the
code and your phone is locked, your
phone will require service and
additional charges may apply. For
more information, contact a Nokia
Care point or your phone dealer.
•The PIN (UPIN) code, supplied with
the SIM (USIM) card, helps to protect
the card against unauthorised use.
•The PIN2 (UPIN2) code, supplied
with some SIM (USIM) cards, is
required to access certain services.
•PUK (UPUK) and PUK2 (UPUK2) codes
may be supplied with the SIM (USIM)
card. If you enter the PIN code
incorrectly three times in
succession, you are asked for the
PUK code. If the codes are not
supplied, contact your service
provider.
•The barring password is required
when using the call barring service
to restrict calls to and from your
phone (network service).
•To view or change the security
module settings for the browser,
select Menu > Settings >
Security > Security module sett..
Switch it on 11
© 2009 Nokia. All rights reserved. 11

Switch the device on and off
Switch on and off
Press and hold the power key.
Enter the PIN code
If requested , enter the code PIN code
(displayed as ****).
Set the time and date
If requested, enter the date, the local
time, and the time zone and the
daylight saving time of your location.
When you switch on your device for the
first time, you may be prompted to get
the configuration settings from your
service provider (network service). For
more information, contact your service
provider.
Standby mode
When the phone is ready for use, and
you have not entered any characters,
the phone is in the standby mode.
Display
1Signal strength of the cellular
network
2Battery charge status
3Indicators
4Clock
5Name of the network or the
operator logo
12 Switch it on
© 2009 Nokia. All rights reserved.12

6Date (only if the Home screen is
deactivated)
7Display
8Function of the left selection key
9Function of the Navi key (scroll key)
10 Function of the right selection key
You may change the function of the left
and right selection key. See " Left and
right selection keys ", p. 22.
Home screen
The home screen displays a list of
selected features and information that
you can directly access.
Select Menu > Settings > Display >
Home screen.
Activate the home screen
Select Home screen mode.
Organise and personalise the home
screen
Select Personalise view.
Select a key to activate the home
screen
Select Home screen key.
Navigate in the home screen
Scroll up or down to navigate in the list,
and select Select, View, or Edit. The
arrows indicate that further
information is available.
Stop navigating
Select Exit.
Shortcuts
When your device is in the standby or
home screen mode, you can use the
following shortcuts.
List missed, received, and dialled
calls
Press the call key. To make a call, scroll
to the number or name, and press the
call key.
Start the web browser
Press and hold 0.
Call the voice mailbox
Press and hold 1.
Use other keys as shortcuts
See "Dialling shortcuts", p. 30.
Switch it on 13
© 2009 Nokia. All rights reserved. 13

Indicators
You have unread messages.
You have unsent, cancelled, or
failed messages.
The keypad is locked.
The device does not ring for
incoming calls or text
messages.
An alarm is set.
/ The device is registered to the
GPRS or EGPRS network.
/ A GPRS or EGPRS connection is
open.
/ The GPRS or EGPRS connection is
suspended (on hold).
Bluetooth connectivity is
activated.
A GPS signal is available
(external GPS antenna
necessary).
No GPS signal available
(external GPS antenna
necessary).
If you have two phone lines, the
second line is in use.
All incoming calls are diverted
to another number.
Calls are limited to a closed user
group.
The currently active profile is
timed.
A headset is connected to the
device.
The device is connected to
another device using a USB data
cable.
Navigate the menus
The phone offers you an extensive range
of functions that are grouped into
menus.
1 To access the menu, select Menu.
2 Scroll through the menu, and select
an option (for example, Settings).
3 If the selected menu contains
further submenus, select one (for
example, Call).
4 Select the setting of your choice.
5 To return to the previous menu
level, select Back.
To exit the menu, select Exit.
To change the menu view, select
Options > Main menu view. Scroll
right, and select from the available
options.
To rearrange the menu, select
Options > Organise. Scroll to the menu
14 Switch it on
© 2009 Nokia. All rights reserved.14

item to be moved, and select Move.
Scroll to where you want to move the
menu item, and select OK. To save the
change, select Done > Yes.
Lock the keys
Lock the keypad to prevent accidental
keypresses.
Lock the keypad
Select Menu, and press *within 3.5
seconds.
Unlock the keypad
Select Unlock, and press *within 1.5
seconds. If requested, enter the lock
code.
Answer a call when the keypad is
locked
Press the call key. When you end or
reject a call, the keypad locks
automatically.
Further features are Automatic
keyguard and Security keyguard. See
"Phone settings", p. 19.
When the device or keypad is locked,
calls may be possible to the official
emergency number programmed into
your device.
Functions without a SIM card
Some functions of your phone may be
used without inserting a SIM card, such
as Organiser functions and games.
Some functions appear dimmed in the
menus and cannot be used.
Flight profile
Use the Flight profile in radio sensitive
environments to deactivate all radio
frequency functions. You still have
access to offline games, the calendar,
and phone numbers. When the Flight
profile is active, is displayed.
Activate the Flight profile
Select Menu > Settings > Profiles >
Flight > Activate or Personalise.
Deactivate the Flight profile
Select any other profile.
Switch it on 15
© 2009 Nokia. All rights reserved. 15

Warning:
With the Flight profile you cannot make
or receive any calls, including
emergency calls, or use other features
that require network coverage. To make
calls, you must first activate the phone
function by changing profiles. If the
device has been locked, enter the lock
code.
If you need to make an emergency call
while the device is locked and in the
Flight profile, you may be also able to
enter an official emergency number
programmed in your device in the lock
code field and select 'Call'. The device
will confirm that you are about to exit
Flight profile to start an emergency call.
Support and updates
Nokia helps you in many ways to gain
the most benefit from your device.
You can find the model number of your
device on the back cover.
Support
When you want to learn more about
how to use your product or you are
unsure how your device should
function, see the user guide or see the
support pages at www.nokia.com/
support or your local Nokia website, or
with a mobile device,
www.nokia.mobi/support.
If this does not resolve your issue, do
one of the following:
•Restart the device: switch off the
device, and remove the battery.
After about a minute, replace the
battery, and switch on the device.
•Restore the original factory settings
as explained in the user guide.
•Update your device software
regularly for optimum performance
and possible new features, as
explained in the user guide.
16 Support and updates
© 2009 Nokia. All rights reserved.16

If your issue remains unsolved, contact
Nokia for repair options. See
www.nokia-asia.com/repair. Before
sending your device for repair, always
back up the data in your device.
My Nokia
Receive free tips, tricks, and support for
your Nokia phone, plus free trial
content, interactive demonstrations, a
personalised web page, and news about
the latest Nokia products and services.
Get the most out of your Nokia phone
and register at My Nokia today! For more
information and availability in your
region, see www.nokia.com/mynokia.
Download content
You may be able to download new
content (for example, themes) to your
phone (network service).
Important: Use only services that you
trust and that offer adequate security
and protection against harmful
software.
For the availability of different services
and pricing, contact your service
provider.
Software updates using your PC
Nokia Software Updater is a PC
application that enables you to update
your device software. To update your
device software, you need a compatible
PC, broadband internet access, and a
compatible USB data cable to connect
your device to the PC.
To get more information, to check the
release notes for the latest software
versions, and to download the Nokia
Software Updater application, see
www.nokia-asia.com/softwareupdate
or your local Nokia website.
To update the device software, do the
following:
1 Download and install the Nokia
Software Updater application to
your PC.
2 Connect your device to the PC using
a USB data cable, and select PC
Suite.
3 Open the Nokia Software Updater
application. The Nokia Software
Updater application guides you to
back up your files, update the
software, and restore your files.
Support and updates 17
© 2009 Nokia. All rights reserved. 17

Software updates over the air
Your service provider may send phone
software updates over the air directly to
your phone (network service). This
option may not be available, depending
on your phone.
Downloading software updates may
involve the transmission of large
amounts of data (network service).
Make sure that the device battery has
enough power, or connect the charger
before starting the update.
Warning:
If you install a software update, you
cannot use the device, even to make
emergency calls, until the installation is
completed and the device is restarted.
Be sure to back up data before accepting
installation of an update.
Software update settings
This option may not be available,
depending on your phone.
To allow or disallow software and
configuration updates, select Menu >
Settings > Configuration > Device
manager sett. > Serv. softw.
updates.
Request a software update
1 Select Menu > Settings >
Phone > Phone updates to
request available software updates
from your service provider.
2 Select Current softw. details to
display the current software version
and check whether an update is
needed.
3 Select Downl. phone softw. to
download and install a software
update. Follow the instructions on
the display.
4 If the installation was cancelled
after the download, select Install
softw. update to start the
installation.
The software update may take several
minutes. If there are problems with the
installation, contact your service
provider.
Restore factory settings
To restore the phone back to factory
settings, select Menu > Settings >
Rest. factory sett. and from the
following:
18 Support and updates
© 2009 Nokia. All rights reserved.18

Restore settings only — Reset all
preference settings without deleting
any personal data.
Restore all — Reset all preference
settings and delete all personal data,
such as contacts, messages, media files,
and activation keys.
Make it your device
Set up your device, personalise it, and
connect it in several ways.
Basic settings
Phone settings
Select Menu > Settings and Phone.
Select from the following:
Language settings — To set the
language of your device, select Phone
language and a language. To set the
language of your device according to
the information on the SIM card, select
Phone language > Automatic.
Memory status — View the memory
consumption.
Automatic keyguard — The keypad is
locked automatically after a preset time
delay when the device is in the standby
mode or home screen and no function
has been used.
Security keyguard — Set the device to
request the security code to unlock the
keypad.
Voice recognition — Set up voice
commands, or start voice recognition
training.
Make it your device 19
© 2009 Nokia. All rights reserved. 19

Flight query — Set the device to
prompt for the Flight profile when you
switch the device on. In the Flight
profile, all radio connections are closed.
Phone updates — Allow software
updates from your service provider
(network service). The available options
may vary.
Operator selection — Manually select
which network to use.
Help text activation — Set the device
to display help text.
Start-up tone — Play a tone when you
switch the device on.
Confirm SIM actions — Access
additional network services from your
SIM card. This option may not be
available, depending on your SIM card.
Security settings
Select Menu > Settings and Security.
When security features that restrict calls
are in use (such as call barring, closed
user group, and fixed dialling), calls may
be possible to the official emergency
number programmed into your device.
Call barring and call diverting cannot be
active at the same time.
Select from the following:
PIN code request or UPIN code
request — Set the device to request for
the PIN or UPIN code every time the
device is switched on. Some SIM cards
do not allow the code request to be
deactivated.
Call barring service — Restrict
incoming calls to and outgoing calls
from your device (network service). A
barring password is required.
Fixed dialling — Restrict your
outgoing calls to selected phone
numbers if supported by your SIM card.
When fixed dialling is activated, GPRS
connections are not possible except
while sending text messages over a
GPRS connection. In this case, the
recipient’s phone number and the
message centre number must be
included in the fixed dialling list.
Closed user group — Define a group of
people whom you can call and who can
call you (network service).
Security level — To request the
security code whenever a new SIM card
is inserted into the device, select
Phone.
20 Make it your device
© 2009 Nokia. All rights reserved.20
