Nokia 130 User manual

Issue 1.1
EN
User Guide
Nokia 130

2
© 2016 HMD Global. All rights reserved.
User Guide
Nokia 130
Contents
For your safety 3
Get started 4
Keys and parts 4
Insert the SIM and memory card and
battery 4
Charge the battery 6
Lock or unlock the keys 6
Basics 8
Explore your phone 8
Change the volume 9
Change the wallpaper 9
Set the ringtone 9
Write text 10
Use predictive text 10
People & messaging 11
Make a call 11
Save a name and phone number 11
Send and receive messages 11
Entertainment 12
Listen to music 12
Listen to the radio 12
Play a video 12
Office 13
Set an alarm 13
Add a calendar reminder 13
Change the time and date13
Phone management 14
Share your content using Slam 14
Copy content between your phone and
computer 14
Remove private content from your phone 14
Access codes 15
Product and safety info 16

3
© 2016 HMD Global. All rights reserved.
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by HMD Global for use with
this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the loudspeaker is in use.

4
© 2016 HMD Global. All rights reserved.
Get started
Get started with the basics, and have your phone up and running in no time.
Keys and parts
Explore the keys and parts of your new phone.
1 Charger connector
2 Headset connector (3.5mm)
3 Scroll key
4 End/Power key
5 Microphone
6 Call key
7 Selection keys
8 Earpiece
9 Flashlight
10 Loudspeaker
11 Antenna area
Avoid touching the antenna area while the
antenna is in use. Contact with antennas affects the communication quality and may reduce battery
life due to higher power level during operation.
Do not connect to products that create an output signal, as this may damage the device. Do not
connect any voltage source to the audio connector. If you connect an external device or headset,
other than those approved for use with this device, to the audio connector, pay special attention to
volume levels.
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable, may
be sold separately.
Note: You can set the phone to ask for a security code. The pre-set code is 12345, but you can
change it to protect your privacy and personal data. Note, however, that when you change the
code, you need to remember the new code, as HMD Global is not able to open or bypass it.
Insert the SIM and memory card and battery
Learn how to insert the battery and SIM and memory cards.
Important: This device is designed to be used with a standard SIM card (see figure) only. Use of
incompatible SIM cards may damage the card or the device, and may corrupt data stored on the
card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout.

5
© 2016 HMD Global. All rights reserved.
Use only compatible memory cards approved for use with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
1. Press the back cover with your thumb, carefully lift the bottom edge of the back cover with your
fingers, and remove the cover.
2. If the battery is in the phone, lift it out.
3. Slide the SIM in with the contact area face down.
4. Push the memory card into the memory card slot.
5. Line up the battery contacts, and put the battery in.

6
© 2016 HMD Global. All rights reserved.
6. Replace the back cover.
Remove the SIM card
Open the back cover, remove the battery, press the release spring, and slide the SIM out.
Remove the memory card
Open the back cover, remove the battery, and pull the memory card out.
Switch your phone on
Press and hold the power key.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it before you
can use your phone.
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the
wall outlet.
If the battery is completely discharged, it may take up to 20 minutes before the charging indicator
is displayed.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while
charging the device. The efficiency of USB charging power varies significantly, and it may take
a long time for charging to start and the device to start functioning.
Make sure your computer is switched on.
Lock or unlock the keys
To avoid accidentally pressing the keys, use keypad lock.
1. Quickly press .

7
© 2016 HMD Global. All rights reserved.
2. Select Lock.
Unlock the keypad
Press , and select Unlock.
Lock

8
© 2016 HMD Global. All rights reserved.
Basics
Learn how to get the most out of your new phone.
Explore your phone
Explore your phone with a simple key press.
See the apps and features of your phone
Press Menu.
Go to an app or feature
Press the scroll key up, down, left, or right.
Open an app or select a feature
Press Select.
Go back to the previous view
Press Back.
Menu
Sele ct
Back

9
© 2016 HMD Global. All rights reserved.
Go back to the home screen
Press .
Switch the flashlight on
On the home screen, quickly press the scroll key up twice.
To switch the flashlight off, press up once.
Do not shine the light in anyone’s eyes.
Change the volume
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the
volume to your liking.
Scroll left or right to change the volume during a call or when listening to the radio.
Change the wallpaper
You can change the background of your home screen to your liking.
1. Select Menu > Settings > Display settings > Wallpaper.
2. Select a wallpaper.
Set the ringtone
Set a ringtone for your phone.
1. Select Menu > Settings > Tone settings.
2. Select Ringing tone.
Go to Menu Music

10
© 2016 HMD Global. All rights reserved.
3. Pick a ringtone, and select OK.
Write text
Writing with the keypad is easy and fun.
Press a key repeatedly until the letter is shown.
Type in a space
Press 0.
Type in a special character or punctuation mark
Press *.
Switch between character cases
Press # repeatedly.
Type in a number
Press and hold a number key.
Use predictive text
To speed up your writing, your phone can guess what you are starting to write. Predictive text is based
on a built-in dictionary. This feature is not available for all languages.
1. Select Opt. > Dictionary and the language.
2. Start writing a word. When the word you want is shown, press 0.
Change a word
Press * repeatedly until the word you want is shown.
Add a new word to the dictionary
If the word you want isn't in the dictionary, write the word, press * repeatedly to skip all unwanted
words, select Spell, and write the word.
Switch between predictive and traditional text
Press # repeatedly.
Switch predictive text off
Select Opt. > Dictionary > Dictionary off.
