Nokia 1661 User manual

Nokia 1661 User Guide
9214163
Issue 1

© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, and Navi are trademarks or registered trademarks of Nokia Corporation. Nokia
tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be
trademarks or tradenames of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2008. Tegic
Communications, Inc. All rights reserved.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements
to any of the products described in this document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS
LICENSORS BE RESPONSIBLE FOR ANY LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER CAUSED.
THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES
OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY
OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY
TIME WITHOUT PRIOR NOTICE.
The availability of particular products and applications and services for these products may vary by region.
Please check with your Nokia dealer for details, and availability of language options.
Export controls
This device may contain commodities, technology or software subject to export laws and regulations from the
US and other countries. Diversion contrary to law is prohibited.
FCC NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to
receiving equipment). The FCC can require you to stop using your telephone if such interference cannot be
eliminated. If you require assistance, contact your local service facility. This device complies with part 15 of the
FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. Any changes or modifications not expressly approved by Nokia could void the user's
authority to operate this equipment.
9214163/Issue 1 EN-US

Contents
Safety........................................4
1. General information.............5
About your device..................................5
Network services....................................5
Nokia support and contact
information............................................6
2. Get started............................6
Insert the SIM card and battery............6
Remove the SIM card.............................7
Charge the battery.................................7
Switch on and off...................................7
3. Your phone...........................8
Keys and parts........................................8
Main features..........................................8
Make and answer a call.........................9
Loudspeaker...........................................9
Write text..............................................10
Text modes and text input...............10
Message................................................11
Contacts................................................11
Multi-phonebook.................................11
Flashlight..............................................12
Accessories.............................13
Battery....................................13
Battery and charger
information..........................................13
Nokia battery authentication
guidelines.............................................14
Authenticate hologram....................15
What if your battery is not
authentic?..........................................15
Care and maintenance............16
Disposal.................................................17
Additional safety
information............................17
Small children.......................................17
Operating environment.......................17
Medical devices....................................18
Implanted medical devices..............18
Hearing aids.......................................19
Vehicles.................................................19
Potentially explosive
environments.......................................19
Emergency calls....................................20
Certification information (SAR)..........21

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle
while driving. Your first consideration while driving should be road
safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
© 2008 Nokia. All rights reserved.4

1. General information
About your device
The wireless device described in this guide is approved for use on the GSM 850 and
1900 MHz networks. Contact your service provider for more information about
networks.
When using the features in this device, obey all laws and respect local customs,
privacy and legitimate rights of others, including copyrights.
Copyright protection may prevent some images, music, and other content from
being copied, modified, or transferred.
Warning: To use any features in this device, other than the alarm clock, the
device must be switched on. Do not switch the device on when wireless device use
may cause interference or danger.
Remember to make back-up copies or keep a written record of all important
information stored in your device.
Network services
To use the device you must have service from a wireless service provider. Many of
the features require special network features. These features are not available on
all networks; other networks may require that you make specific arrangements with
your service provider before you can use the network services. Using network
services involves transmission of data. Check with your service provider for details
about fees in your home network and when roaming on other networks. Your
service provider can give you instructions and explain what charges will apply. Some
networks may have limitations that affect how you can use network services. For
instance, some networks may not support all language-dependent characters and
services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, these features will not appear on your device menu.
Your device may also have a special configuration such as changes in menu names,
menu order, and icons. Contact your service provider for more information.
© 2008 Nokia. All rights reserved. 5

Nokia support and contact information
Check www.nokia.com/support or your local Nokia Web site for the latest version
of this guide, additional information, downloads, and services related to your Nokia
product.
On the website, you can get information on the use of Nokia products and services.
If you need to contact customer service, check the list of local Nokia contact centers
at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia service center at
www.nokia.com/repair.
2. Get started
Insert the SIM card and battery
This phone is intended for use with the BL-4C battery.
Always switch the device off and disconnect the charger before removing the
battery.
1. Slide the back cover downwards (1), and remove it.
2. Lift the battery, and remove it (2).
3. Insert the SIM card (3). Ensure that the gold-coloured contact area is facing down
and the bevelled corner of the SIM card is slid in next.
4. Replace the battery and back cover (4, 5).
© 2008 Nokia. All rights reserved.6

Remove the SIM card
Press the release spring (1), and slide out the SIM card (2).
Charge the battery
1. Connect the charger to a wall outlet.
2. Connect the charger to the phone. The battery indicator bar
starts scrolling. When the battery is fully charged, the bar stops
scrolling.
Tip: To save energy, unplug the charger when the battery is fully charged.
If the battery is completely discharged, it may take a few minutes before the
charging indicator appears on the display or before any calls can be made.
Switch on and off
Press and hold the end key.
Use the phone only in its normal operating position.
Your device may have internal and external antennas. As with any
radio transmitting device, avoid touching the antenna area
unnecessarily while the antenna is transmitting or receiving. Contact
with such an antenna affects the communication quality and may cause the device
to operate at a higher power level than otherwise needed and may reduce the
battery life.
© 2008 Nokia. All rights reserved. 7

3. Your phone
Keys and parts
1Flashlight
2Wrist strap eyelet
3Earpiece
4Display
5Selection keys
6Navi™ key; hereafter referred
to as scroll key
7Call key
8End/Power key
9Keypad
10 Charger connector
11 Headset connector
12 Microphone
Main features
Select Menu and from the following:
●Messages — to create, send, open, and manage messages
●Contacts — to save and access names and phone numbers on the SIM card or
in the device memory
●Call log — to view the log of missed, received, and dialled calls
© 2008 Nokia. All rights reserved.8

●Clock — to set the time for the alarm
●Radio — to define radio settings
●Reminders — to manage reminders
●Games — to define game settings, or play installed games
●Extras — to access applications, such as the calculator, converter, spreadsheet,
countdown timer, calendar, and stopwatch
●SIM services — to use additional services, if supported by your SIM card
Select Menu > Settings and from the following:
●Tone settings — to select ringing tones, and adjust volume settings
●Display settings — to select the theme, color scheme, and screen saver
●Profiles — to select and customize profiles
●Time settings — to define time and format settings
●Call settings — to activate call forwarding, automatic redial, and call waiting
●Phone settings — to set the device language, define keyguard settings, and
create a welcome note
●Cost settings — to define call timer, call summary, and fixed dialling settings
●Security settings — to set the PIN and security codes
●Right selection key settings — to set a shortcut key for a function
●Restore factory set. — to restore settings to their default values
Make and answer a call
To make a call, enter the phone number, including the country code and area code,
if necessary, and press the call key. To increase or decrease the volume of the
earpiece or headset during the phone call, scroll right or left.
To answer an incoming call, press the call key. To reject the call without answering,
press the end key.
Loudspeaker
If available, to use the loudspeaker or earpiece of the phone during a call, you may
select Loudsp. or Hands..
© 2008 Nokia. All rights reserved. 9

Warning: Do not hold the device near your ear when the loudspeaker is in
use, because the volume may be extremely loud.
Write text
Text modes and text input
You can enter text using traditional text input or predictive text input .
To use traditional text input, press the key repeatedly until the letter appears.
To set predictive text input on when writing, select Options > Predictive text and
the desired language; to set it off, select Options > Predictive text > Prediction
off.
When using predictive text input, press each key once for a single letter. If the
displayed word is the one you want, press 0, and start writing the next word.
To change the word, press *repeatedly until the word you want appears.
If ? is displayed after the word, the word is not in the dictionary.
To add the word to the dictionary, select Spell, enter the word (using traditional
text input), and select OK.
Tips for writing text:
To add a space, press 0.
To quickly change the text input method, press #repeatedly, and check the indicator
at the top of the display.
To add a number, press and hold the desired number key.
To get a list of special characters when using traditional text input, press *; when
using predictive text input, press and hold *.
To undo the clearing of a message in the editing window, select Options > Undo
clear.
© 2008 Nokia. All rights reserved.10

Message
The message services can only be used if they are supported by your network or
service provider.
Your device supports text messages beyond the limit for a single message. Longer
messages are sent as two or more messages. Your service provider may charge
accordingly. Characters with accents or other marks, and characters from some
language options, take up more space, and limit the number of characters that can
be sent in a single message.
1. Select Menu > Messages > Create message.
2. Write the message. The message length indicator shows how many characters
you can enter in the message. For example, 10/2 means that you can still add
10 characters for the text to be sent as two separate text messages.
3. To send the message, select Options > Send, enter the recipient's phone
number or select it from Contacts, and select OK.
To delete all read messages or all the messages in a folder, select Menu >
Messages > Delete messages > All read or the desired folder.
Contacts
You can save names and phone numbers in the phone and SIM card memory. The
contacts list can contain up to 500 contacts, stored in the phone memory.
To search for a contact, scroll down in the standby mode, and enter the first letters
of the name. Scroll to the desired contact.
1. To save names and phone numbers to the contacts list, select Menu >
Contacts > Add name.
2. To copy names and phone numbers all at once or one by one between the phone
and SIM card memory, select Menu > Contacts > Copy.
Multi-phonebook
Your phone supports up to five separate phonebooks for multiple users. When the
multi-phonebook is activated, only the contacts in the active phonebook are visible.
© 2008 Nokia. All rights reserved. 11

To activate the multi-phonebook, select Menu > Contacts > Settings > Multi-
Phonebook > Phonebook style > Multi-Phonebook.
To activate a phonebook, select Menu > Contacts > Settings > Multi-
Phonebook > Current phonebook and the desired phonebook or Shared
contacts.
A contact can belong to one or several phonebooks. The contacts in Shared
contacts are accessible from all phonebooks. To assign a contact to one or several
phonebooks, select Menu > Contacts > Settings > Multi-Phonebook >
Manage contacts. Scroll to the desired contact, and select it. Mark the phonebooks
in which you want to save the contact, and select Done > Yes.
To rename the phonebooks, select Menu > Contacts > Settings > Multi-
Phonebook > Rename phonebooks and the desired phonebook.
Flashlight
To switch the flashlight on or off, select Menu > Extras > Flashlight > On or
Off.
© 2008 Nokia. All rights reserved.12

Accessories
Warning: Use only batteries, chargers, and accessories approved by Nokia
for use with this particular model. The use of any other types may invalidate any
approval or warranty, and may be dangerous.
For availability of approved accessories, please check with your dealer. When you
disconnect the power cord of any accessory, grasp and pull the plug, not the cord.
Battery
Battery and charger information
Your device is powered by a rechargeable battery. The battery intended for use with
this device is BL-4C. Nokia may make additional battery models available for this
device. This device is intended for use when supplied with power from the following
chargers: AC-3. The exact charger model number may vary depending on the type
of plug. The plug variant is identified by one of the following: E, EB, X, AR, U, A, C, or
UB.
The battery can be charged and discharged hundreds of times, but it will eventually
wear out. When the talk and standby times are noticeably shorter than normal,
replace the battery. Use only Nokia approved batteries, and recharge your battery
only with Nokia approved chargers designated for this device. Use of an unapproved
battery or charger may present a risk of fire, explosion, leakage, or other hazard.
If a battery is being used for the first time or if the battery has not been used for a
prolonged period, it may be necessary to connect the charger, then disconnect and
reconnect it to begin charging the battery. If the battery is completely discharged,
it may take several minutes before the charging indicator appears on the display or
before any calls can be made.
Always switch the device off and disconnect the charger before removing the
battery.
Unplug the charger from the electrical plug and the device when not in use. Do not
leave a fully charged battery connected to a charger, since overcharging may
© 2008 Nokia. All rights reserved. 13

shorten its lifetime. If left unused, a fully charged battery will lose its charge over
time.
Always try to keep the battery between 15°C and 25°C (59°F and 77°F). Extreme
temperatures reduce the capacity and lifetime of the battery. A device with a hot
or cold battery may not work temporarily. Battery performance is particularly
limited in temperatures well below freezing.
Do not short-circuit the battery. Accidental short-circuiting can occur when a
metallic object such as a coin, clip, or pen causes direct connection of the positive
(+) and negative (-) terminals of the battery. (These look like metal strips on the
battery.) This might happen, for example, when you carry a spare battery in your
pocket or purse. Short-circuiting the terminals may damage the battery or the
connecting object.
Do not dispose of batteries in a fire as they may explode. Batteries may also explode
if damaged. Dispose of batteries according to local regulations. Please recycle when
possible. Do not dispose as household waste.
Do not dismantle, cut, open, crush, bend, deform, puncture, or shred cells or
batteries. In the event of a battery leak, do not allow the liquid to come in contact
with the skin or eyes. In the event of such a leak, flush your skin or eyes immediately
with water, or seek medical help.
Do not modify, remanufacture, attempt to insert foreign objects into the battery,
or immerse or expose it to water or other liquids.
Improper battery use may result in a fire, explosion, or other hazard. If the device
or battery is dropped, especially on a hard surface, and you believe the battery has
been damaged, take it to a service center for inspection before continuing to use
it.
Use the battery only for its intended purpose. Never use any charger or battery that
is damaged. Keep your battery out of the reach of small children.
Nokia battery authentication guidelines
Always use original Nokia batteries for your safety. To check that you are getting
an original Nokia battery, purchase it from a Nokia authorized service center or
dealer, and inspect the hologram label using the following steps:
© 2008 Nokia. All rights reserved.14

Successful completion of the steps is not a total assurance of the authenticity of the
battery. If you have any reason to believe that your battery is not an authentic,
original Nokia battery, you should refrain from using it, and take it to the nearest
Nokia authorized service center or dealer for assistance. If authenticity cannot be
verified, return the battery to the place of purchase.
Authenticate hologram
1. When you look at the hologram on the label, you should see
the Nokia connecting hands symbol from one angle and the
Nokia Original Enhancements logo when looking from
another angle.
2. When you angle the hologram left, right, down and up, you
should see 1, 2, 3 and 4 dots on each side respectively.
What if your battery is not authentic?
If you cannot confirm that your Nokia battery with the hologram on the label is an
authentic Nokia battery, please do not use the battery. Take it to the nearest Nokia
authorized service center or dealer for assistance. The use of a battery that is not
approved by Nokia may be dangerous and may result in poor performance and
damage to your device and its accessories. It may also invalidate any approval or
warranty applying to the device.
For additional information, refer to the warranty and reference leaflet included with
your Nokia device.
© 2008 Nokia. All rights reserved. 15

Care and maintenance
Your device is a product of superior design and craftsmanship and should be treated
with care. The following suggestions will help you protect your warranty coverage.
●Keep the device dry. Precipitation, humidity, and all types of liquids or moisture
can contain minerals that will corrode electronic circuits. If your device does get
wet, remove the battery, and allow the device to dry completely before replacing
it.
●Do not use or store the device in dusty, dirty areas. Its moving parts and electronic
components can be damaged.
●Do not store the device in hot areas. High temperatures can shorten the life of
electronic devices, damage batteries, and warp or melt certain plastics.
●Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic circuit
boards.
●Do not attempt to open the device other than as instructed in this guide.
●Do not drop, knock, or shake the device. Rough handling can break internal circuit
boards and fine mechanics.
●Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the
device.
●Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
●Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the device and may
violate regulations governing radio devices.
●Use chargers indoors.
●Always create a backup of data you want to keep, such as contacts and calendar
notes.
●To reset the device from time to time for optimum performance, power off the
device and remove the battery.
© 2008 Nokia. All rights reserved.16

These suggestions apply equally to your device, battery, charger, or any
enhancement. If any device is not working properly, take it to the nearest
authorized service facility for service.
Disposal
The crossed-out wheeled-bin symbol on your product, literature, or packaging
reminds you that all electrical and electronic products, batteries, and
accumulators must be taken to separate collection at the end of their working
life. This requirement applies to the European Union and other locations
where separate collection systems are available. Do not dispose of these products
as unsorted municipal waste.
By returning the products to collection you help prevent uncontrolled waste
disposal and promote the reuse of material resources. More detailed information is
available from the product retailer, local waste authorities, national producer
responsibility organizations, or your local Nokia representative. For the product Eco-
Declaration or instructions for returning your obsolete product, go to country-
specific information at www.nokia.com.
Additional safety information
Small children
Your device and its accessories may contain small parts. Keep them out of the reach
of small children.
Operating environment
This device meets RF exposure guidelines when used either in the normal use
position against the ear or when positioned at least 2.2 centimetres (7/8 inch) away
from the body. When a carry case, belt clip, or holder is used for body-worn
operation, it should not contain metal and should position the device the above-
stated distance from your body.
To transmit data files or messages, this device requires a quality connection to the
network. In some cases, transmission of data files or messages may be delayed until
© 2008 Nokia. All rights reserved. 17

such a connection is available. Ensure the above separation distance instructions
are followed until the transmission is completed.
Parts of the device are magnetic. Metallic materials may be attracted to the device.
Do not place credit cards or other magnetic storage media near the device, because
information stored on them may be erased.
Medical devices
Operation of any radio transmitting equipment, including wireless phones, may
interfere with the functionality of inadequately protected medical devices. Consult
a physician or the manufacturer of the medical device to determine if they are
adequately shielded from external RF energy or if you have any questions. Switch
off your device in health care facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities may be using equipment
that could be sensitive to external RF energy.
Implanted medical devices
Manufacturers of medical devices recommend that a minimum separation of 15.3
centimeters (6 inches) should be maintained between a wireless device and an
implanted medical device, such as a pacemaker or implanted cardioverter
defibrillator, to avoid potential interference with the medical device. Persons who
have such devices should:
●Always keep the wireless device more than 15.3 centimeters (6 inches) from the
medical device when the wireless device is turned on.
●Not carry the wireless device in a breast pocket.
●Hold the wireless device to the ear opposite the medical device to minimize the
potential for interference.
●Turn the wireless device off immediately if there is any reason to suspect that
interference is taking place.
●Read and follow the directions from the manufacturer of their implanted medical
device.
If you have any questions about using your wireless device with an implanted
medical device, consult your health care provider.
© 2008 Nokia. All rights reserved.18

Hearing aids
Some digital wireless devices may interfere with some hearing aids. If interference
occurs, consult your service provider.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic
systems in motor vehicles such as electronic fuel injection systems, electronic
antiskid (antilock) braking systems, electronic speed control systems, and air bag
systems. For more information, check with the manufacturer, or its representative,
of your vehicle or any equipment that has been added.
Only qualified personnel should service the device or install the device in a vehicle.
Faulty installation or service may be dangerous and may invalidate any warranty
that may apply to the device. Check regularly that all wireless device equipment in
your vehicle is mounted and operating properly. Do not store or carry flammable
liquids, gases, or explosive materials in the same compartment as the device, its
parts, or accessories. For vehicles equipped with an air bag, remember that air bags
inflate with great force. Do not place objects, including installed or portable wireless
equipment in the area over the air bag or in the air bag deployment area. If in-
vehicle wireless equipment is improperly installed and the air bag inflates, serious
injury could result.
Using your device while flying in aircraft is prohibited. Switch off your device before
boarding an aircraft. The use of wireless teledevices in an aircraft may be dangerous
to the operation of the aircraft, disrupt the wireless telephone network, and may
be illegal.
Potentially explosive environments
Switch off your device when in any area with a potentially explosive atmosphere,
and obey all signs and instructions. Potentially explosive atmospheres include areas
where you would normally be advised to turn off your vehicle engine. Sparks in such
areas could cause an explosion or fire resulting in bodily injury or even death. Switch
off the device at refueling points such as near gas pumps at service stations. Observe
restrictions on the use of radio equipment in fuel depots, storage, and distribution
areas; chemical plants; or where blasting operations are in progress. Areas with a
© 2008 Nokia. All rights reserved. 19

potentially explosive atmosphere are often, but not always, clearly marked. They
include below deck on boats, chemical transfer or storage facilities and areas where
the air contains chemicals or particles such as grain, dust, or metal powders. You
should check with the manufacturers of vehicles using liquefied petroleum gas
(such as propane or butane) to determine if this device can be safely used in their
vicinity.
Emergency calls
Important: This device operates using radio signals, wireless networks,
landline networks, and user-programmed functions. If your device supports voice
calls over the internet (internet calls), activate both the internet calls and the cellular
phone. The device will attempt to make emergency calls over both the cellular
networks and through your internet call provider if both are activated. Connections
in all conditions cannot be guaranteed. You should never rely solely on any wireless
device for essential communications like medical emergencies.
To make an emergency call:
1. If the device is not on, switch it on. Check for adequate signal strength.
Depending on your device, you may also need to complete the following:
●Insert a SIM card if your device uses one.
●Remove certain call restrictions you have activated in your device.
●Change your profile from offline or flight profile mode to an active profile.
2. Press the end key as many times as needed to clear the display and ready the
device for calls.
3. Enter the official emergency number for your present location. Emergency
numbers vary by location.
4. Press the call key.
When making an emergency call, give all the necessary information as accurately
as possible. Your wireless device may be the only means of communication at the
scene of an accident. Do not end the call until given permission to do so.
© 2008 Nokia. All rights reserved.20
