Nokia 1661 User manual

Nokia 1661 User Guide
9213794
Issue 2

Contents
Safety 3
Get started 4
Insert the SIM card and battery 4
Remove the SIM card 4
Charge the battery 4
Switch on and off 5
Your phone 5
Keys and parts 5
Main features 6
Make and answer a call 6
Write text 7
Message 8
Contacts 8
Multi-phonebook 9
Radio 9
Turn the flashlight on or off 10
General information 11
Accessories 11
Battery 11
Battery and charger information 11
Nokia battery authentication
guidelines 12
Taking care of your device 12
Recycle 13
Additional safety information 13
Small children 13
Operating environment 13
Medical devices 13
Vehicles 13
Potentially explosive environments 14
Emergency calls 14
Certification information (SAR) 14
2Contents
© 2009 Nokia. All rights reserved.2

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is prohibited or when
it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
Safety 3
© 2009 Nokia. All rights reserved. 3

Get started
Insert the SIM card and battery
This phone is intended for use with the BL-4C battery.
Safe removal. Always switch the device off and disconnect the charger before removing
the battery.
1 Slide the back cover downwards (1), and remove it.
2 Lift the battery, and remove it (2).
3 Insert the SIM card (3). Ensure that the gold-coloured contact area is facing down
and the bevelled corner of the SIM card is slid in next.
4 Replace the battery and back cover (4, 5).
Remove the SIM card
Press the release spring (1), and slide out the SIM card (2).
Charge the battery
Your battery has been partially charged at the factory. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
4Getstarted
© 2009 Nokia. All rights reserved.4

3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
Tip: To save energy, unplug the charger when the battery is fully charged.
You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging. If the battery is completely discharged, it may take several
minutes before the charging indicator appears on the display or before any calls can be
made.
Switch on and off
Press and hold the end key.
Use the phone only in its normal operating position.
Your device may have internal and external antennas. Avoid touching the antenna area
unnecessarily while the antenna is transmitting or receiving. Contact with antennas
affects the communication quality and may cause a higher power level during operation
and may reduce the battery life.
Your phone
Keys and parts
1Flashlight
2Wrist strap eyelet
3Earpiece
4Display
5Selection keys
6Navi™ key; hereafter referred
to as scroll key
7Call key
8End/Power key
Your phone 5
© 2009 Nokia. All rights reserved. 5

9Keypad
10 Charger connector
11 Headset connector
12 Microphone
Do not connect products that create an output signal as this may cause damage to the
device. Do not connect any voltage source to the Nokia AV Connector.
When connecting any external device or any headset, other than those approved by
Nokia for use with this device,to the Nokia AV Connector, pay special attention to volume
levels.
Main features
Select Menu and from the following:
Messages — to create, send, open, and manage messages
Contacts — to save names and phone numbers in the SIM card and phone memory
Call log — to access phone numbers of missed, received, and dialled calls
Settings — to set up various features of your phone
Clock — to set the time for the alarm
Radio — to manage radio features
Reminders — to manage reminders
Games — to set up game effects or play the games installed in your phone
Extras — to access various applications, such as the calculator or flashlight
SIM services — to use additional services, if supported by your SIM card
Make and answer a call
Make a call
Enter the phone number, including the country code and area code, if necessary, and
press the call key.
Answer a call
Press the call key.
End or reject a call
Press the end key.
6 Your phone
© 2009 Nokia. All rights reserved.6

Use the loudspeaker or earpiece
During a call, select Loudsp. or Hands..
Adjust the volume
During a call, scroll left or right to adjust the volume of the earpiece or headset.
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
Write text
Use traditional text input
Press a key repeatedly until the desired letter is displayed.
Activate predictive text input
Select Options > Predictive text and the desired language.
Deactivate predictive text input
Select Options > Predictive text > Prediction off.
When using predictive text input, press each key once for a single letter. If the desired
word is displayed, press 0, and start writing the next word. If ? is displayed after the
word, the word is not in the dictionary.
Change a word
Press *repeatedly until the desired word is displayed.
Add a word
Select Spell, enter the word using traditional text input, and select OK.
Add a space
Press 0.
Change text input method
Press #repeatedly, and check the indicator at the top of the display.
Add a number
Press and hold the desired number key.
Your phone 7
© 2009 Nokia. All rights reserved. 7

Add a special character
Press *when using traditional text input; press and hold *when using predictive text
input.
Undo clearing of a message
Select Options > Undo clear.
Message
The message services can only be used if they are supported by your service provider.
Your device supports text messages beyond the limit for a single message. Longer
messages are sent as two or more messages. Your service provider may charge
accordingly. Characters with accents, other marks, or some language options take more
space, and limit the number of characters that can be sent in a single message.
Write and send a message
1 Select Menu > Messages > Create message.
2 Write the message. The message length indicator shows how many characters you
can enter in the message.
3 Select Options > Send, enter the recipient's phone number or select it from the
contacts list, and select OK.
Delete messages
Select Menu > Messages > Delete messages > All read or the desired folder.
Contacts
You can save names and phone numbers in the phone and SIM card memory. The
contacts list can contain up to 500 contacts, stored in the phone memory.
Search for a contact
Scroll down in the standby mode, enter the first characters or letters of the name, and
scroll to the desired contact.
Save contacts to the contacts list
Select Menu > Contacts > Add name.
Copy contacts between the phone and SIM card memory
Select Menu > Contacts > Copy.
8 Your phone
© 2009 Nokia. All rights reserved.8

Multi-phonebook
Your phone supports up to five separate phonebooks for multiple users. When the multi-
phonebook is activated, only the contacts in the active phonebook are visible.
A contact can belong to one or several phonebooks. The contacts in Shared contacts are
accessible from all phonebooks.
Select Menu > Contacts > Settings > Multi-Phonebook and the appropriate options.
Activate the multi-phonebook
Select Phonebook style > Multi-Phonebook.
Activate a phonebook
Select Current phonebook and the desired phonebook or Shared contacts.
Assign a contact to one or more phonebooks
Select Manage contacts and the desired contact.
Rename a phonebook
Select Rename phonebooks and the desired phonebook.
Radio
The FM radio depends on an antenna other than the wireless device antenna. A
compatible headset or accessory needs to be attached to the device for the FM radio to
function properly.
To open the radio, select Menu > Radio, or press and hold *.
Select from the following:
Turn off — Close the radio.
Save channel — Save an active channel.
Auto-tuning — Tune radio channels automatically. To start automatic tuning, scroll
up or down.
Manual tuning — Tune radio channels manually. To change the frequency, scroll up
or down.
Set frequency — Enter the desired frequency.
Delete channel — Delete a saved channel.
Rename — Rename a saved channel.
Clock radio — Manage clock radio features.
Loudspeaker or Headset — Listen to the radio using the loudspeaker or a headset.
Your phone 9
© 2009 Nokia. All rights reserved. 9

To adjust the volume of the radio, scroll left or right.
Warning:
Continuous exposure to high volume may damage your hearing. Listen to music at a
moderate level, and do not hold the device near your ear when the loudspeaker is in
use.
Turn the flashlight on or off
Select Menu > Extras > Flashlight.
10 Your phone
© 2009 Nokia. All rights reserved.10
