Nokia 2720 fold User manual

Nokia 2720 fold User Guide
9216121
Issue 1
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Contents
Safety 5
1. Get started 7
Insert SIM card and battery 7
Charge the battery 8
Antenna 9
Headset 10
Magnets and magnetic fields 10
Keys and parts 11
Switch on and off 12
Standby mode 13
Volume key functions when the
fold is closed 14
Keypad lock 14
Functions without a SIM card 15
Applications running in
background 16
2. General information 16
About your device 16
Network services 17
Shared memory 18
Access codes 18
Support 19
3. Calls 20
Make and answer a call 20
Loudspeaker 21
Dialling shortcuts 22
4. Write text 22
Text modes 22
Traditional text input 23
Predictive text input 24
5. Navigate the menus 25
6. Messaging 25
2Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Text and multimedia
messages 25
E-mail 28
Flash messages 30
Nokia Xpress audio messages 30
Instant messaging 31
Voice messages 31
Message settings 32
7. Contacts 33
8. Call log 35
9. Settings 35
Profiles 35
Tones 36
Display 36
Date and time 36
Shortcuts 37
Synchronisation and backup 38
Connectivity 38
Call and phone 41
Accessories 43
Configuration 43
Restore factory settings 44
10. Operator menu 45
11. Gallery 45
12. Media 47
Camera and video 47
FM radio 49
Voice recorder 50
Music player 51
13. Applications 53
14. Organiser 54
Alarm clock 54
Contents 3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Calendar and to-do list 56
15. Web or Internet 57
Connect to a web service 57
16. SIM services 58
17. Green tips 58
Save energy 59
Recycle 59
Learn more 60
Accessories 61
Battery 61
Battery and charger
information 61
Nokia battery authentication
guidelines 62
Taking care of your device 64
Recycle 65
Additional safety
information 65
Small children 65
Operating environment 65
Medical devices 65
Vehicles 66
Potentially explosive
environments 67
Emergency calls 67
Certification information
(SAR) 68
Index 70
4Contents
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Safety
Read these simple guidelines. Not following them may be dangerous or
illegal. Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless phone use is
prohibited or when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving
should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which
could affect performance.
Safety 5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off in aircraft, near
medical equipment, fuel, chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect
incompatible products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it dry.
6Safety
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

1. Get started
Insert SIM card and battery
Safe removal. Always switch the device off and disconnect the charger
before removing the battery.
The SIM card and its contacts can be easily damaged by scratches or
bending, so be careful when handling, inserting, or removing the card.
1 Press and slide the back cover towards the bottom of the phone, and
remove it (1).
2 Remove the battery (2).
Get started 7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

3 Open the SIM card holder (3), insertthe SIM card with the contact surface
facing down (4), and close the holder (5).
4 Insert the battery (6), and replace the back cover (7).
Charge the battery
Your battery has been partially charged at the factory. If the device indicates
a low charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from
the device, then from the wall outlet.
8Getstarted
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

You do not need to charge the battery for a specific length of time, and you
can use the device while it is charging. If the battery is completely
discharged, it may take several minutes before the charging indicator
appears on the display or before any calls can be made.
Antenna
Your device may have internal and external antennas. Avoid touching the
antenna area unnecessarily while the antenna is transmitting or receiving.
Contact with antennas affects the communication quality and may cause a
higher power level during operation and may reduce the battery life.
The figure shows the antenna area marked in grey.
Get started 9
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Headset
Warning:
When you use the headset, your ability to hear outside sounds may be
affected. Do not use the headset where it can endanger your safety.
When connecting any external device or any headset, other than those
approved by Nokia for use with this device, to the Nokia AV Connector, pay
special attention to volume levels.
Do not connect products that create an output signal as this may cause
damage to the device. Do not connect any voltage source to the Nokia AV
Connector.
Magnets and magnetic fields
Keep your device away from magnets or magnetic fields.
10 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Keys and parts
1End/Power key
2Right selection key
3Earpiece
4Main display
5Left selection key
6Navi™ key; hereafter referred to
as scroll key
7Call key
8Keypad
Get started 11
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

9Camera lens
10 Headset connector/Nokia AV
Connector (2.5 mm)
11 Wrist strap eyelet
12 Loudspeaker
13 Charger connector
14 Volume keys
15 Cover display
Switch on and off
Press and hold the power key.
12 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Standby mode
When the phone is ready for use, and you have not entered any characters,
the phone is in the standby mode.
1Network signal strength
2Battery charge level
3Network name or operator logo
4Functions of selection keys
The left selection key, Go to, allows you to access the functions in your
personal shortcut list. When viewing the list, select Options > Select
options to view the available functions, or select Options > Organise to
arrange the functions in your shortcut list.
Get started 13
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Volume key functions when the fold is closed
Activate the cover display
Press a volume key.
Adjust the volume
Use the volume keys when the cover display is activated.
Mute the ringing tone of an incoming call
Press a volume key.
Reject an incoming call
Press and hold a volume key.
Keypad lock
Lock the keypad
Select Menu, and press *within 3.5 seconds to lock the keypad.
14 Get started
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Unlock the keypad
Select Unlock, and press *within 1.5 seconds. If the security keyguard is
activated, enter the security code when requested.
Set automatic keypad lock
Select Menu > Settings > Phone > Automatic keyguard > On, and set
the length of time, after which the keypad locks.
Answer a call when the keypad is locked
Press the call key. When you end or reject the call, the keypad locks
automatically.
When the device or keypad is locked, calls may be possible to the official
emergency number programmed into your device.
Functions without a SIM card
Some functions of your phone may be used without inserting a SIM card,
such as Organiser functions and games. Some functions appear dimmed in
the menus and cannot be used.
Get started 15
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Applications running in background
Leaving applications running in the background increases the demand on
battery power and reduces the battery life.
2. General information
About your device
The wireless device described in this guide is approved for use on the GSM
850 and 1900 MHz networks. Contact your service provider for more
information about networks.
Your device may have preinstalled bookmarks and links for third-party
internet sites and may allow you to access third-party sites. These are not
affiliated with Nokia, and Nokia does not endorse or assume liability for
them. If you access such sites, take precautions for security or content.
Warning:
To use any features in this device, other than the alarm clock, the device
must be switched on. Do not switch the device on when wireless device use
may cause interference or danger.
16 General information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

When using this device, obey all laws and respect local customs, privacy
and legitimate rights of others, including copyrights. Copyright protection
may prevent some images, music, and other content from being copied,
modified, or transferred.
Make back-up copies or keep a written record of all important information
stored in your device.
When connecting to any other device, read its user guide for detailed safety
instructions. Do not connect incompatible products.
The images in this guide may differ from your device display.
Refer to the user guide for other important information about your device.
Network services
To use the device you must have service from a wireless service provider.
Some features are not available on all networks; other features may require
that you make specific arrangements with your service provider to use
them. Network services involve transmission of data. Check with your
service provider for details about fees in your home network and when
roaming on other networks. Your service provider can explain what charges
General information 17
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

will apply. Some networks may have limitations that affect how you can
use some features of this device requiring network support such as support
for specific technologies like WAP 2.0 protocols (HTTP and SSL) that run on
TCP/IP protocols and language-dependent characters.
Your service provider may have requested that certain features be disabled
or not activated in your device. If so, these features will not appear on your
device menu. Your device may also have customized items such as menu
names, menu order, and icons.
Shared memory
The following features in this device may share memory: multimedia
messaging (MMS), e-mail application, instant messaging. Use of one or
more of these features may reduce the memory available for the remaining
features. If your device displays a message that the memory is full, delete
some of the information stored in the shared memory.
Access codes
The security code helps to protect your phone against unauthorised use.
The preset code is 12345. You can create and change the code, and set the
phone to request the code. Keep the code secret and in a safe place separate
18 General information
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

from your phone. If you forget the code and your phone is locked, your
phone will require service and additional charges may apply. For more
information, contact a Nokia Care point or your phone dealer.
The PIN code supplied with the SIM card protects the card against
unauthorised use. The PIN2 code supplied with some SIM cards is required
to access certain services. If you enter the PIN or PIN2 code incorrectly three
times in succession, you are asked for the PUK or PUK2 code. If you do not
have them, contact your service provider.
The module PIN is required to access the information in the security module
of your SIM card. The signing PIN may be required for the digital signature.
The barring password is required when using the call barring service.
To set how your phone uses the access codes and security settings, select
Menu > Settings > Security.
Support
When you want to learn more about how to use your product or you are
unsure how your device should function, see the user guide or see the
support pages at www.nokia.com/support or your local Nokia website, or
with a mobile device, www.nokia.mobi/support.
General information 19
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

If this does not resolve your issue, do the following:
•Restart the device: switch off the device, and remove the battery. After
about a minute, replace the battery, and switch on the device.
•Restore the original factory settings as explained in the user guide.
If the issue remains unsolved, contact Nokia for repair options. See
www.nokia.com/repair, or in Latin America, www.nokia-
latinoamerica.com/centrosdeservicio. Before sending your device for
repair, always back up the data in your device.
3. Calls
Make and answer a call
Make a call
Enter the phone number, including the country and area code if necessary,
and press the call key.
Answer an incoming call
Press the call key.
20 Calls
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
