Nokia 3555 User manual

Service Manual
RM-257; RM-270; RM-277 (Nokia 3555)
Mobile Terminal
Part No: (Issue 1)
Nokia Customer Care
COMPANY CONFIDENTIAL
Copyright © 2007 Nokia. All rights reserved.

Amendment Record Sheet
Amendment No Date Inserted By Comments
Issue 1 08/2007 MHa
RM-257; RM-270; RM-277
Amendment Record Sheet
Page ii COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Copyright
Copyright © 2007 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form
without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of Nokia
Corporation. Other product and company names mentioned herein may be trademarks or tradenames of
their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental,
consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no warranties of
any kind, either express or implied, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this
document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.
RM-257; RM-270; RM-277
Copyright
Issue 1 COMPANY CONFIDENTIAL Page iii
Copyright © 2007 Nokia. All rights reserved.

Warnings and cautions
Warnings
• IF THE DEVICE CAN BE INSTALLED IN A VEHICLE, CARE MUST BE TAKEN ON INSTALLATION IN VEHICLES FITTED
WITH ELECTRONIC ENGINE MANAGEMENT SYSTEMS AND ANTI-SKID BRAKING SYSTEMS. UNDER CERTAIN FAULT
CONDITIONS, EMITTED RF ENERGY CAN AFFECT THEIR OPERATION. IF NECESSARY, CONSULT THE VEHICLE DEALER/
MANUFACTURER TO DETERMINE THE IMMUNITY OF VEHICLE ELECTRONIC SYSTEMS TO RF ENERGY.
•THE PRODUCT MUST NOT BE OPERATED IN AREAS LIKELY TO CONTAIN POTENTIALLY EXPLOSIVE ATMOSPHERES,
FOR EXAMPLE, PETROL STATIONS (SERVICE STATIONS), BLASTING AREAS ETC.
• OPERATION OF ANY RADIO TRANSMITTING EQUIPMENT, INCLUDING CELLULAR TELEPHONES, MAY INTERFERE
WITH THE FUNCTIONALITY OF INADEQUATELY PROTECTED MEDICAL DEVICES. CONSULT A PHYSICIAN OR THE
MANUFACTURER OF THE MEDICAL DEVICE IF YOU HAVE ANY QUESTIONS. OTHER ELECTRONIC EQUIPMENT MAY
ALSO BE SUBJECT TO INTERFERENCE.
• BEFORE MAKING ANY TEST CONNECTIONS, MAKE SURE YOU HAVE SWITCHED OFF ALL EQUIPMENT.
Cautions
• Servicing and alignment must be undertaken by qualified personnel only.
• Ensure all work is carried out at an anti-static workstation and that an anti-static wrist strap is worn.
• Ensure solder, wire, or foreign matter does not enter the telephone as damage may result.
• Use only approved components as specified in the parts list.
• Ensure all components, modules, screws and insulators are correctly re-fitted after servicing and
alignment.
• Ensure all cables and wires are repositioned correctly.
•Never test a mobile phone WCDMA transmitter with full Tx power, if there is no possibility to perform the
measurements in a good performance RF-shielded room. Even low power WCDMA transmitters may disturb
nearby WCDMA networks and cause problems to 3G cellular phone communication in a wide area.
• During testing never activate the GSM or WCDMA transmitter without a proper antenna load, otherwise
GSM or WCDMA PA may be damaged.
RM-257; RM-270; RM-277
Warnings and cautions
Page iv COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

For your safety
QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries. Do not connect incompatible products.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user’s guide for detailed safety instructions. Do not connect
incompatible products.
RM-257; RM-270; RM-277
For your safety
Issue 1 COMPANY CONFIDENTIAL Page v
Copyright © 2007 Nokia. All rights reserved.

Care and maintenance
This product is of superior design and craftsmanship and should be treated with care. The suggestions below
will help you to fulfil any warranty obligations and to enjoy this product for many years.
• Keep the phone and all its parts and accessories out of the reach of small children.
•Keep the phone dry. Precipitation, humidity and all types of liquids or moisture can contain minerals that
will corrode electronic circuits.
• Do not use or store the phone in dusty, dirty areas. Its moving parts can be damaged.
•Do not store the phone in hot areas. High temperatures can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
• Do not store the phone in cold areas. When it warms up (to its normal temperature), moisture can form
inside, which may damage electronic circuit boards.
• Do not drop, knock or shake the phone. Rough handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone.
• Do not paint the phone. Paint can clog the moving parts and prevent proper operation.
• Use only the supplied or an approved replacement antenna. Unauthorised antennas, modifications or
attachments could damage the phone and may violate regulations governing radio devices.
All of the above suggestions apply equally to the product, battery, charger or any accessory.
RM-257; RM-270; RM-277
Care and maintenance
Page vi COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

ESD protection
Nokia requires that service points have sufficient ESD protection (against static electricity) when servicing
the phone.
Any product of which the covers are removed must be handled with ESD protection. The SIM card can be
replaced without ESD protection if the product is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be damaged by static electricity
discharge.
All ESD sensitive parts must be packed in metallized protective bags during shipping and handling outside
any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product components must be done under
ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD Protected Area.
For more information and local requirements about ESD protection and ESD Protected Area, contact your local
Nokia After Market Services representative.
RM-257; RM-270; RM-277
ESD protection
Issue 1 COMPANY CONFIDENTIAL Page vii
Copyright © 2007 Nokia. All rights reserved.

Battery information
Note: A new battery's full performance is achieved only after two or three complete charge and
discharge cycles!
The battery can be charged and discharged hundreds of times but it will eventually wear out. When the
operating time (talk-time and standby time) is noticeably shorter than normal, it is time to buy a new battery.
Use only batteries approved by the phone manufacturer and recharge the battery only with the chargers
approved by the manufacturer. Unplug the charger when not in use. Do not leave the battery connected to
a charger for longer than a week, since overcharging may shorten its lifetime. If left unused a fully charged
battery will discharge itself over time.
Temperature extremes can affect the ability of your battery to charge.
For good operation times with Li-Ion batteries, discharge the battery from time to time by leaving the product
switched on until it turns itself off (or by using the battery discharge facility of any approved accessory
available for the product). Do not attempt to discharge the battery by any other means.
Use the battery only for its intended purpose.
Never use any charger or battery which is damaged.
Do not short-circuit the battery. Accidental short-circuiting can occur when a metallic object (coin, clip or
pen) causes direct connection of the + and - terminals of the battery (metal strips on the battery) for example
when you carry a spare battery in your pocket or purse. Short-circuiting the terminals may damage the battery
or the connecting object.
Leaving the battery in hot or cold places, such as in a closed car in summer or winter conditions, will reduce
the capacity and lifetime of the battery. Always try to keep the battery between 15°C and 25°C (59°F and 77°
F). A phone with a hot or cold battery may temporarily not work, even when the battery is fully charged.
Batteries' performance is particularly limited in temperatures well below freezing.
Do not dispose of batteries in a fire!
Dispose of batteries according to local regulations (e.g. recycling). Do not dispose as household waste.
RM-257; RM-270; RM-277
Battery information
Page viii COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Company Policy
Our policy is of continuous development; details of all technical modifications will be included with service
bulletins.
While every endeavour has been made to ensure the accuracy of this document, some errors may exist. If
any errors are found by the reader, NOKIA MOBILE PHONES Business Group should be notified in writing/e-
mail.
Please state:
• Title of the Document + Issue Number/Date of publication
• Latest Amendment Number (if applicable)
• Page(s) and/or Figure(s) in error
Please send to:
NOKIA CORPORATION
Nokia Mobile Phones Business Group
Nokia Customer Care
PO Box 86
FIN-24101 SALO
Finland
E-mail: [email protected]
RM-257; RM-270; RM-277
Company Policy
Issue 1 COMPANY CONFIDENTIAL Page ix
Copyright © 2007 Nokia. All rights reserved.

RM-257; RM-270; RM-277
Company Policy
(This page left intentionally blank.)
Page x COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Nokia 3555 Service Manual Structure
1 General information
2 Service Tools and Service Concepts
3 BB Troubleshooting and Manual Tuning Guide
4 RF troubleshooting
5 System Module
Glossary
RM-257; RM-270; RM-277
Nokia 3555 Service Manual Structure
Issue 1 COMPANY CONFIDENTIAL Page xi
Copyright © 2007 Nokia. All rights reserved.

RM-257; RM-270; RM-277
Nokia 3555 Service Manual Structure
(This page left intentionally blank.)
Page xii COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

1 — General information
Nokia Customer Care
Issue 1 COMPANY CONFIDENTIAL Page 1 –1
Copyright © 2007 Nokia. All rights reserved.

RM-257; RM-270; RM-277
General information
(This page left intentionally blank.)
Page 1 –2 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Table of Contents
Product selection....................................................................................................................................................1–5
Phone features .......................................................................................................................................................1–5
Accessories..............................................................................................................................................................1–7
Technical specifications.........................................................................................................................................1–8
General specifications.......................................................................................................................................1–8
Battery endurance.............................................................................................................................................1–8
Environmental conditions ................................................................................................................................1–8
Electrical characteristics ...................................................................................................................................1–9
Main RF characteristics for GSM850/900/1800/1900 and WCDMA IV (1700) phones (RM-257).................1–9
Main RF characteristics for GSM850/900/1800/1900 and WCDMA V (850) and WCDMA I (2100) phones
(RM-270)................................................................................................................................................ 1–10
Main RF characteristics for GSM850/900/1800/1900 and WCDMA V (850) and WCDMA II (1900) phones
(RM-277)................................................................................................................................................ 1–11
List of Tables
Table 1 Battery and chargers ................................................................................................................................1–7
Table 2 Car accessories ..........................................................................................................................................1–7
Table 3 Headsets ....................................................................................................................................................1–7
Table 4 Data ............................................................................................................................................................1–8
Table 5 Memory cards............................................................................................................................................1–8
Table 6 Normal and extreme voltages.................................................................................................................1–9
List of Figures
Figure 1 RM-257/270/277 phone..........................................................................................................................1–5
RM-257; RM-270; RM-277
General information
Issue 1 COMPANY CONFIDENTIAL Page 1 –3
Copyright © 2007 Nokia. All rights reserved.

RM-257; RM-270; RM-277
General information
(This page left intentionally blank.)
Page 1 –4 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

Product selection
RM-257/270/277 is a GSM/WCDMA handportable phone. RM-257 supports GSM850/900/1800/1900 and
WCDMA1700 bands, RM-270 GSM850/900/1800/1900 and WCDMA850/2100 bands and RM-277
GSM850/900/1800/1900 and WCDMA850/1900 bands.
Figure 1 RM-257/270/277 phone
Phone features
Hardware characteristics
• EDGE Rel. 4: MSC 32 (RX+TX 5+3, class B&C and DTM)
• GPRS: MSC 32 (RX+TX 5+3, class B&C and DTM)
• Speech codec support for FR, EFR, AMR
• 30MB user memory and (empty) MicroSD card slot
• Douglas 5 UI on primary display, fold 2 UI on secondary display
• 1.8” 128x160 pixel, 262k color primary TFT display
• 1” 96x68 pixel BW FSTN secondary display
• VGA camera with 4x digital zoom, portrait mode
• Bluetooth version 2.0 supporting SAP (SIM Access Profile), OPP (Object Push Profile), FTP (File Transfer
Profile), DUN (Dial-up Networking Profile), HSP (Headset Profile), HFP (Hands-Free Profile), SDP (Service
Discovery Application Profile), GAP (Generic Access Profile), SPP (Serial Port Profile), GOEP (Generic Object
Exchange Profile), A2DP profile for stereo headset
• Micro USB
• Nokia 2.5 mm A/V connector
• Nokia Dynamo power connector
• 5-way, two soft keys, send and end keys
• Side volume keys with the zoom functionality
RM-257; RM-270; RM-277
General information
Issue 1 COMPANY CONFIDENTIAL Page 1 –5
Copyright © 2007 Nokia. All rights reserved.

• Music Player
• MicroSD card slot
• Internal vibra and antenna
• M3&T3 HAC compliance (for RM-257 only)
UI Features
• New Series 40 UI
• Active stand-by
• "My Fav" (for RM-257 only)
Bearers supported
• UMTS, GSM/EGSM, EGPRS/GPRS Rel.4
• CSD for browsing and as data modem
Applications/service enablers
• Video streaming and recording in QCIF
• XHTML browsing over TCP/IP
• SAIC/DARP
• Theme (wallpapers, icons, colors)
• Music Player supporting MP3, MP4, AAC, eAAC+ and Windows Media Player
• PIM (Calendar & Contacts)
• Nokia Xpress audio messaging (AMS)
• Nokia PoC (for RM-270/277 only)
• Flight mode
• OMA DRM 2.0 (Digital Right Management)
• OMA MMS 1.2, MMS Conformance 3.0, AMR and SMIL
• OMA Client Provisioning v1.1
• Java&APIs MIDP2.0, JSR139 (CLDC1.1), JSR75 (file connection and PIM), JSR135, JSR184 (3D), JSR82 (BT)
• 3GPP H.263 playback+streaming and MPEG4 video and playback
• Video, MP3, AAC, eAAC+ and 64 polyphonic ringing tones
• WAP 2.0, XHTML browser over HTTP/TCP/IP stack
• SyncML (local and remote)
• Nokia E-mail client with attachment (for RM-270/277 only)
• OZ IM/E-mail client (for RM-257 only)
• Nokia PC Suite
Services
• OTA download of ringing tones, themes, wallpapers
• Download/upload images and video sequences
• FOTA – Firmware update over the air
• Plug and play services
• IM (AOL, ICQ, Yahoo, MSN)
RM-257; RM-270; RM-277
General information
Page 1 –6 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.

• SIM access profile in BT
• HAC (for RM-257 only)
Accessories
Sales package contents
• RM-257/270/277 phone
• Battery BL-5C
• Standard Charger AC-3
• Headset HS-40 (for RM-257 only)
• User Guide
Table 1 Battery and chargers
Type Name
AC-3 Compact charger
AC-4 Travel performance charger
AC-5 Travel performance charger
BL-5C Battery 1020 mAh Li-Ion
Table 2 Car accessories
Type Name
HF-6W Wireless plug-in handsfree
HF-9W Wireless plug-in handsfree
CK-20W Wireless carkit
Table 3 Headsets
Type Name
HS-40 Wired headset
HS-47 Wired headset
BH-601 Wireless headset
BH-602 Wireless headset
BH-800 Wireless headset
BH-900 Wireless headset
HS-21W Wireless headset
BH-600 Wireless headset
BH-200 Wireless headset
BH-201 Wireless headset
HS-36W Wireless headset
RM-257; RM-270; RM-277
General information
Issue 1 COMPANY CONFIDENTIAL Page 1 –7
Copyright © 2007 Nokia. All rights reserved.

Table 4 Data
Type Name
CA-101 Micro USB data cable
Table 5 Memory cards
Type Name
MU-37 Memory card
MU-27 Memory card
MU-28 Memory card
MU-22 Memory card
Technical specifications
General specifications
Unit Dimension (mm) Weight (g) Volume (cc)
RM-257/270/277
transceiver with BL-5C
1020 mAh Li-Ion battery
pack
99.6 x 44.3 x 20.5 94 71.3
Battery endurance
Battery Talk time Standby time
BL-5C 1020 mAh Li-ion GSM: up to 3h20min
WCDMA: up to 3h
GSM: up to 270h
WCDMA: up to 270h
Note: Variation in operation times will occur depending on SIM card, network settings and usage.
Talk time is increased by up to 30% if half rate is active, and reduced by 5% if enhanced full rate is
active.
Environmental conditions
Temperature
Temperature range Min oCMax oC
Operational (all specs met) -5 +55
Functional (reduced
performance)
-30 +70
Storage -30 +85
The HW module complies with the SPR4 Operating Conditions.
RM-257; RM-270; RM-277
General information
Page 1 –8 COMPANY CONFIDENTIAL Issue 1
Copyright © 2007 Nokia. All rights reserved.
