Nokia 6131/6133 User Guide
FCC Draft
Issue 1

DRAFT
DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION, declares that this product RM-115 is in compliance with the
essential requirements and other relevant provisions of Directive 1999/5/EC.
A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/.
The crossed-out wheeled bin means that within the European Union the product
must be taken to separate collection at the product end-of life. This applies to
your device but also to any enhancements marked with this symbol. Do not
dispose of these products as unsorted municipal waste.
Copyright © 2006 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia, Visual Radio, Nokia Connecting People, Xpress-on, XpressPrint, and Pop-Port are
trademarks or registered trademarks of Nokia Corporation. Other product and company
names mentioned herein may be trademarks or tradenames of their respective owners.
Nokia tune is a sound mark of Nokia Corporation.
US Patent No 5818437 and other pending patents. T9 text input software Copyright (C)
1997-2006. Tegic Communications, Inc. All rights reserved.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
noncommercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information
including that relating to promotional, internal and commercial uses may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com>.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products described in this document without prior
notice.
0434

DRAFT
This Nokia device complies with Directive 2002/95/EC on the restriction of the use of certain
hazardous substances in electrical and electronic equipment.
Under no circumstances shall Nokia be responsible for any loss of data or income or any
special, incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided "as is". Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region. Please check with the Nokia dealer
nearest to you.
This device may contain commodities, technology or software subject to export laws and
regulations from the US and other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC or Industry Canada can require you to stop using
your telephone if such interference cannot be eliminated. If you require assistance, contact
your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation. Any changes or modifications not expressly approved by Nokia
could void the user's authority to operate this equipment.
FCC Draft/Issue 1

4
DRAFT
Contents
For your safety.......................... 7
General information.............. 10
Overview of functions........................ 10
Access codes......................................... 10
Configuration settings service ........ 11
Download content .............................. 12
Nokia support....................................... 12
1. Get started ......................... 13
Install SIM card and battery............ 13
Insert a microSD card ........................ 14
Remove the microSD card................ 14
Charge the battery.............................. 14
Open and close the phone................ 15
Switch the phone on and off........... 15
Antenna ................................................. 16
Phone strap........................................... 16
2. Your phone......................... 17
Keys and parts...................................... 17
Standby mode ...................................... 18
Keypad lock (keyguard) ..................... 21
Functions without a SIM card......... 21
3. Call functions..................... 22
Make a call ........................................... 22
Answer or reject a call....................... 23
Options during a call.......................... 24
4. Write text........................... 25
Predictive text input .......................... 25
Traditional text input......................... 26
5. Navigate the menus .......... 27
6. Messaging .......................... 28
Text messages (SMS).......................... 28
SIM messages....................................... 29
Multimedia messages (MMS).......... 30
Memory full.......................................... 32
Folders.................................................... 32
Postcards ............................................... 33
Flash messages .................................... 34
Nokia Xpress audio messaging........ 34
E-mail application .............................. 35
Instant messaging............................... 38
Voice messages.................................... 43
Info messages ...................................... 43
Service commands.............................. 43
Delete messages.................................. 44
Message settings................................. 44
7. Contacts.............................. 48
Search for a contact .......................... 48
Save names and phone numbers.... 48
Save details........................................... 48
Copy or move contacts...................... 49
Edit contact details ............................ 49
Synchronize all .................................... 49
Delete contacts.................................... 49
My presence ......................................... 50
Subscribed names ............................... 51
Business cards...................................... 52
Settings.................................................. 52
Groups.................................................... 53
Speed dials............................................ 53
Info, service, and my numbers ........ 53
8. Call log................................ 54
Positioning information .................... 54
9. Settings ............................. 55
Profiles ................................................... 55
Themes ................................................... 55
Tones....................................................... 55
Main display ......................................... 56
Mini display .......................................... 57
Time and date ...................................... 57

5
DRAFT
My shortcuts......................................... 58
Connectivity.......................................... 59
Call........................................................... 65
Phone ...................................................... 66
Enhancements ...................................... 66
Configuration........................................ 67
Security .................................................. 68
Phone software updates.................... 69
Restore factory settings..................... 70
10. Operator menu ................ 70
11. Gallery.............................. 71
Print images.......................................... 71
Memory card......................................... 71
12. Media ............................... 73
Camera ................................................... 73
Media player ......................................... 74
Music player.......................................... 75
Radio ....................................................... 76
Voice recorder....................................... 78
Equalizer................................................. 78
Stereo widening................................... 79
13. Organizer.......................... 80
Alarm clock............................................ 80
Calendar................................................. 80
To-do list................................................ 81
Notes....................................................... 82
Calculator .............................................. 82
Countdown timer ................................ 83
Stopwatch ............................................. 83
14. Push to talk ..................... 84
Push to talk channels......................... 84
Switch PTT on and off ........................ 86
Make and receive a PTT call ............. 86
Callback requests................................. 88
Add a one-to-one contact................ 89
PTT settings ........................................... 89
Configuration settings ....................... 90
Web ......................................................... 90
15. Applications ..................... 91
Launch a game..................................... 91
Launch an application........................ 91
Some application options ................. 91
Download an application .................. 92
Presenter ................................................ 92
16. SIM services ..................... 94
17. Web................................... 95
Set up browsing ................................... 95
Connect to a service ........................... 95
Browse pages........................................ 96
Bookmarks ............................................. 97
Appearance settings ........................... 97
Security settings .................................. 98
Download settings .............................. 99
Service inbox ........................................ 99
Cache memory................................... 100
Browser security ............................... 100
18. PC connectivity............. 102
Nokia PC Suite................................... 102
EGPRS, HSCSD, and CSD................. 102
Data communication applications 102
19. Battery information...... 103
Charging and discharging.............. 103
Nokia battery authentication ....... 104
20. Technical Information .. 106
Care and maintenance ........ 107
Additional safety
information.......................... 108
APPENDIX ............................ 112
Index..................................... 121

Contents
6
DRAFT

For your safety
7
DRAFT
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in
aircraft.
SWITCH OFF WHEN REFUELLING
Do not use the phone at a refuelling point. Do not use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Do not use the phone where blasting is in
progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.

For your safety
8
DRAFT
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the end key as
many times as needed to clear the display and return to the start
screen. Enter the emergency number, then press the call key. Give
your location. Do not end the call until given permission to do so.
■About your device
The wireless device described in this guide is approved for use on the EGSM 850,
900, 1800 and 1900 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect the privacy and
legitimate rights of others.
When taking and using images or video clips, obey all laws and respect local
customs as well as privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features in this device depend on features in the wireless network to
function. These network services may not be available on all networks or you may
have to make specific arrangements with your service provider before you can
utilize network services. Your service provider may need to give you additional
instructions for their use and explain what charges will apply. Some networks
may have limitations that affect how you can use network services. For instance,
some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, they will not appear on your device menu. Your

For your safety
9
DRAFT
device may also have been specially configured for your network provider. This
configuration may include changes in menu names, menu order and icons.
Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as multimedia messaging (MMS),
browsing, e-mail application, instant messaging, presence enhanced contacts,
remote synchronization, and content downloading using the browser or MMS,
require network support for these technologies.
■Shared memory
The following features in this device may share memory: gallery, contacts, text
messages, multimedia messages, and instant messages, e-mail, calendar, to-do
notes, JavaTM games and applications, and note application. Use of one or more of
these features may reduce the memory available for the remaining features
sharing memory. For example, saving many Java applications may use all of the
available memory. Your device may display a message that the memory is full
when you try to use a shared memory feature. In this case, delete some of the
information or entries stored in the shared memory features before continuing.
Some of the features, such as text messages, may have a certain amount of
memory specially allotted to them in addition to the memory shared with other
features.
■Enhancements
A few practical rules about accessories and enhancements
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement, grasp
and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted and
are operating properly.
• Installation of any complex car enhancements must be made by qualified
personnel only.

General information
10
DRAFT
General information
■Overview of functions
Your phone provides many functions that are practical for daily use,
such as a text and multimedia messaging, a calendar, a clock, an alarm
clock, a radio, a music player, and a built-in camera. Your phone also
supports the following functions:
• Plug and play online service to get the configuration settings. See
“Plug and play service,”p. 16, and “Configuration settings service,”
p. 11.
• Push to talk. See “Push to talk,” p. 84.
• A microSD memory card to extend the memory capacity of the
phone. See “Insert a microSD card,” p. 14 and “Memory card,” p. 71.
• Active standby. See “Active standby,” p. 18.
• Audio messaging. See “Nokia Xpress audio messaging,” p. 34.
• Instant messaging. See “Instant messaging,” p. 38.
• E-mail application. See “E-mail application,” p. 35.
• Enhanced voice dialing. See “Enhanced voice dialing,” p. 22 and
“Voice commands,” p. 59.
• Presence-enhanced contacts. See “My presence,” p. 50.
• Java 2 Platform, Micro Edition (J2METM). See “Applications,” p. 91.
■Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against
unauthorized use. The preset code is 12345. To change the code, and to
set the phone to request the code, see “Security,” p. 68.

General information
11
DRAFT
PIN codes
The personal identification number (PIN) code and the universal
personal identification number (UPIN) code (4 to 8 digits) help to
protect your SIM card against unauthorized use. See “Security,” p. 68.
The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is
required for some functions.
The module PIN is required to access the information in the security
module. See “Security module,” p. 100.
The signing PIN is required for the digital signature. See “Digital
signature,” p. 101.
PUK codes
The personal unblocking key (PUK) code and the universal personal
unblocking key (UPUK) code (8 digits) is required to change a blocked
PIN code and UPIN code, respectively. The PUK2 code (8 digits) is
required to change a blocked PIN2 code. If the codes are not supplied
with the SIM card, contact your local service provider for the codes.
Barring password
The barring password (4 digits) is required when using the Call barring
service. See “Security,” p. 68.
■Configuration settings service
To use some of the network services, such as mobile Internet services,
MMS, Nokia Xpress audio messaging, or remote Internet server
synchronization, your phone needs the correct configuration settings.
You may be able to receive the settings directly as a configuration
message. After receiving the settings you need to save them on your
phone. The service provider may provide a PIN that is needed to save the
settings. For more information on availability, contact your network
operator, service provider, nearest authorized Nokia dealer, or visit the
support area on the Nokia Web site, www.nokia.com/support.
When you have received the settings as a configuration message, and
the settings are not automatically saved and activated, Configuration
settings received is displayed.

General information
12
DRAFT
To save the settings, select Show > Save. If the phone requests Enter
settings' PIN:, enter the PIN code for the settings, and select OK. To
receive the PIN code, contact the service provider that supplies the
settings. If no settings are saved yet, these settings are saved and set as
default configuration settings. Otherwise, the phone asks Activate saved
configuration settings?.
To discard the received settings, select Exit or Show > Discard.
■Download content
You may be able to download new content (for example, themes) to the
phone (network service). Select the download function (for example, in
the Gallery menu). To access the download function, see the respective
menu descriptions.
You may also be able to download updates of phone software (network
service). See “Phone,” p. 66, Phone updates.
For the availability of different services, pricing, and tariffs, contact your
service provider.
Important: Use only services that you trust and that offer adequate
security and protection against harmful software.
■Nokia support
Check www.nokia.com/support or your local Nokia Web site for the
latest version of this guide, additional information, downloads, and
services related to your Nokia product.
On the Web site, you can get information on the use of Nokia products
and services. If you need to contact customer service, check the list of
local Nokia Care contact centers at www.nokia.com/customerservice.
For maintenance services, check your nearest Nokia service center at
www.nokia.com/repair.

Get started
13
DRAFT
1. Get started
■Install SIM card and battery
Always switch the device off and disconnect the charger before removing the
battery.
Keep all SIM cards out of the reach of small children.
For availability and information on using SIM card services, contact your SIM
card vendor. This may be the service provider, network operator, or other vendor.
This device is intended for use with BL-4C battery. Always use original
Nokia batteries. See “Nokia battery authentication,” p. 104.
The SIM card and its contacts can easily be damaged by scratches or
bending, so be careful when handling, inserting, or removing the card.
To remove the back
cover of the phone,
press sightly (1) and
slide the cover (2).
Remove the battery as
shown (3).
Open the SIM card
holder (4). and insert
the SIM card properly
into the holder (5).
Close the SIM card
holder (6).
Replace the battery (7).
Slide the back cover
into its place (8, 9).

Get started
14
DRAFT
■Insert a microSD card
Keep all microSD memory cards out of the reach of small children.
1. Remove the back cover of the phone.
2. Insert the card into the microSD card
slot with the golden contact surface
facing down, and press it until it locks
into place.
3. Close the back cover of the phone.
Use only compatible microSD cards with this device. Other memory cards, such as
Reduced Size MultiMedia cards, do not fit in the microSD card slot and are not
compatible with this device. Using an incompatible memory card may damage
the memory card as well as the device, and data stored on the incompatible card
may be corrupted.
Use only microSD cards approved by Nokia for use with this device. Nokia utilizes
the approved industry standards for memory cards but not all other brands may
function correctly or be fully compatible with this device.
■Remove the microSD card
Important: Do not remove the microSD card in the middle of an
operation when the card is being accessed. Removing the card in the
middle of an operation may damage the memory card as well as the
device, and data stored on the card may be corrupted.
You can remove or replace the microSD card during phone operation
without switching the phone off.
1. Make sure that no application is currently accessing the micro SD
memory card.
2. Remove the back cover of the phone.
3. Press the microSD card slightly in to release the locking.
4. Remove the microSD card from the slot.
■Charge the battery
Check the model number of any charger before use with this device. This device is
intended for use when supplied with power from an AC-3 or AC-4 charger.

Get started
15
DRAFT
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
For availability of approved enhancements, please check with your dealer. When
you disconnect the power cord of any enhancement, grasp and pull the plug, not
the cord.
1. Connect the charger to a wall socket.
2. Connect the lead from the charger to the socket
on the bottom of your phone.
If the battery is completely discharged, it may take a
few minutes before the charging indicator appears
on the display or before any calls can be made.
The charging time depends on the charger used. Charging a BL-4C
battery with the AC-3 charger takes approximately 2 hours and
20 minutes while the phone is in the standby mode.
■Open and close the phone
To open the phone press the fold
release button (1). The fold opens
automatically (2).
To close the phone turn the fold
manually in its closed position.
To switch off a tone that sounds
when you open and close the
phone, see “Tones,” p. 55.
■Switch the phone on and off
Warning: Do not switch the phone on when wireless phone use is
prohibited or when it may cause interference or danger.
To switch the phone on or off, press and hold the power key. See “Keys
and parts,” p. 17. If the phone asks for a PIN or a UPIN code, enter the
code (displayed as ****), and select OK.

Get started
16
DRAFT
Set the time, time zone, and date
Enter the local time, select the time zone of your location in terms of the
time difference with respect to Greenwich Mean Time (GMT), and enter
the date. See “Time and date,” p. 57.
Plug and play service
When you switch on your phone for the first time, and the phone is in
the standby mode, you are asked to get the configuration settings from
your service provider (network service). Confirm or decline the query.
See "Connect to serv. support," p. 68, and “Configuration settings
service,” p. 11.
■Antenna
Your device has an internal antenna.
Note: As with any other radio
transmitting device, do not touch
the antenna unnecessarily when the
device is switched on. Contact with
the antenna affects call quality and
may cause the device to operate at a
higher power level than otherwise
needed. Avoiding contact with the
antenna area when operating the
device optimizes the antenna
performance and the battery life.
■Phone strap
Thread the strap through the eyelet of the
phone as shown in the picture and tighten it.

Your phone
17
DRAFT
2. Your phone
■Keys and parts
1Earpiece
2Main display
3Left and right selection keys
4Middle selection key
5Call key
6Keypad
7Infrared window
8Fold release button
94-way navigation key
10 End key
11 Loudspeaker
12 Phone strap eyelet
13 Pop-PortTM connector flap
14 Charger connector
15 Camera lens
16 Volume keys (Volume up = PTT key)
17 Mini display
18 Camera key
19 Power key
Connector flap
To connect enhancements, open the Pop-PortTM
connector flap.

Your phone
18
DRAFT
■Standby mode
When the phone is ready for use, and you have not entered any
characters, the phone is in the standby mode.
Main display
1Signal strength of the cellular network
2Battery charge status
3Indicators
4Name of the network or the operator logo
5Clock
6Main screen
7Function of the left selection key is Go to
or a shortcut to another function.
See “Left selection key,”p. 58.
8Function of the middle selection key is Menu
9Function of the right selection key is Names or
a shortcut to another function. See “Right selection key,” p. 58.
Operator variants may have an operator-specific name to access an
operator-specific Web site.
Active standby
In the active standby mode there is a list of selected phone features and
information on the screen that you can directly access in the standby
mode. To switch on the mode, select Menu > Settings > Main display >
Standby mode settings >Active standby > My active standby. In the
standby mode, scroll up or down to activate the navigation in the list. To
start the feature, select Select; or to display the information, select
View. Left and right arrows at the beginning and end of a line indicate
that further information is available by scrolling left or right. To end the
active standby navigation mode, select Exit.

Your phone
19
DRAFT
To organize and change the active standby mode, activate the
navigation mode, and select Options > Active standby > My active
standby > Options and the following options:
Personalise — Assign or change phone features in the standby mode.
Organise — Move the position of features in the standby mode.
Enabling active standby — Select keys to activate the standby
navigation mode. To change the settings, see “Standby mode settings,”
p. 56.
To switch off the active standby mode select Options > Active
standby > Off; or select Menu > Settings > Main display > Standby
mode settings >Active standby > Off.
Shortcuts in the standby mode
• To access the list of dialed numbers, press the call key once. Scroll to
the number or name that you want; and to call the number, press the
call key.
• To open the web browser, press and hold 0.
• To call your voice mailbox, press and hold 1.
• Use the navigation key as a shortcut. See “My shortcuts,” p. 58.
• Press the camera key to start the camera (still photo).
• In camera mode press the volume keys to zoom in or out.
• Press a volume key to mute the ringing tone of an incoming call
when the phone is closed.
• Press the power key to access the profiles menu on the main display.
Indicators
You have unread messages in the Inbox folder.
You have unsent, canceled or failed messages in the Outbox
folder.
The phone registered a missed call.

Your phone
20
DRAFT
, Your phone is connected to the instant messaging service, and
the availability status is online or offline.
You received one or several instant messages, and you are
connected to the instant messaging service.
The keypad is locked.
The phone does not ring for an incoming call or text message.
The alarm clock is set to On.
The countdown timer is running.
The stopwatch is running in the background.
, The phone is registered to the GPRS or EGPRS network.
, A GPRS or EGPRS connection is established.
, The GPRS or EGPRS connection is suspended (on hold), for
example, if there is an incoming or outgoing call during an
EGPRS dial-up connection.
A Bluetooth connection is active.
,Push to talk connection is active or suspended. See “Push to
talk,” p. 84.
If you have two phone lines, the second phone line is selected.
All incoming calls are diverted to another number.
The loudspeaker is activated, or the music stand is connected to
the phone.
Calls are limited to a closed user group.
The timed profile is selected.
, , , or
A headset, hands-free, loopset, or music stand enhancement is
connected to the phone.
