Nokia 6175i User manual

1
FCC DRAFTFCC DRAFT
Nokia 6175i User Guide

2
FCC DRAFT
Part No. 9250401, Issue No. 1
Copyright ©2006 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Pop-Port, and the Nokia Original Enhancements logos are
trademarks or registered trademarks of Nokia Corporation. Other company and product
names mentioned herein may be trademarks or trade names of their respective owners.
US Patent No 5818437 and other pending patents. T9 text input software Copyright
©1999-2006. Tegic Communications, Inc. All rights reserved.
Bluetooth wireless technology is a registered trademark of Bluetooth SIG, Inc.
Includes RSA BSAFE cryptographic or security protocol software from
RSA Security.
Java is a trademark of Sun Microsystems, Inc.
Nokia operates a policy of continuous development. Nokia reserves the right to make
changes and improvements to any of the products descrived in this document without prior
notice.
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT
AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO
THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE
RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
The availability of particular products may vary by region. Check with the Nokia dealer
nearest you. This device may contain commodities, technology, or software subject to export
laws and regulations from the U.S. and other countries. Diversion contrary to law is
prohibited.
Copyright protections may prevent some images, music (including ringing tones), and the
content from being copied, modified, transferred, or forwarded.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC or Industry Canada can require you to stop using
your telephone if such interference cannot be eliminated. If you require assistance, contact
your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including interference that may
cause undesired operation. Any changes or modifications not expressly approved by Nokia
could void the user’s authority to operate this equipment.

Contents
3
FCC DRAFTFCC DRAFT
Contents
Phone at a glance ..................................................................................................................9
Set up your phone ............................................................................................................... 15
Text entry ............................................................................................................................... 21
Messaging .............................................................................................................................24
Log ........................................................................................................................................... 40
Contacts ................................................................................................................................. 43
Gallery..................................................................................................................................... 52
Media ...................................................................................................................................... 54
Settings .................................................................................................................................. 65
Organizer................................................................................................................................ 90
Mobile web......................................................................................................................... 102
Extras ................................................................................................................................... 105
Push to talk .........................................................................................................................106
PC connectivity ..................................................................................................................108
Enhancements ................................................................................................................... 109
Battery information ..........................................................................................................111
Index .....................................................................................................................................120

For your safety
4
FCC DRAFT
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
Switch on safely
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
Road safety comes first
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
Interference
All wireless phones may be susceptible to interference, which could
affect performance.
Switch off in hospitals
Follow any restrictions. Switch the phone off near medical
equipment.
Switch off in aircraft
Follow any restrictions. Wireless devices can cause interference in
aircraft.
Switch off when refueling
Do not use the phone at a refueling point. Do not use near fuel or
chemicals.
Switch off near blasting
Follow any restrictions. Do not use the phone where blasting is in
progress.
Use sensibly
Use only in the normal position as explained in the product
documentation. Do not touch the antenna unnecessarily.
Qualified service
Only qualified personnel may install or repair this product.

For your safety
5
FCC DRAFTFCC DRAFT
Enhancements and batteries
Use only approved enhancements and batteries. Do not connect
incompatible products.
Water-resistance
Your phone is not water-resistant. Keep it dry.
Back-up copies
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
Connecting to other devices
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
Emergency calls
Ensure the phone is switched on and in service. Press the end key as
many times as needed to clear the display and return to the start
screen. Enter the emergency number, then press the call key. Give
your location. Do not end the call until given permission to do so.
■About your device
The wireless device described in this guide is approved for use on the CDMA 800
and 1900, AMPS 800, and GPS networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect privacy and
legitimate rights of others.
When taking and using images or video clips, obey all laws and respect local
customs as well as privacy and legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features in this device depend on features in the wireless network to
function. These network services may not be available on all networks or you may
have to make specific arrangements with your service provider before you can

For your safety
6
FCC DRAFT
utilize network services. Your service provider may need to give you additional
instructions for their use and explain what charges will apply. Some networks
may have limitations that affect how you can use network services. For instance,
some networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, they will not appear on your device menu. Your
device may also have been specially configured. This configuration may include
changes in menu names, menu order, and icons. Contact your service provider for
more information.
This device supports WAP 2.0 protocols (HTTP and SSL) that run on TCP/IP
protocols. Some features of this device, such as Mobile web, require network
support for these technologies.
■Shared memory
The following features in this device may share memory: Messaging, Contacts,
Gallery, Organizer, and Extras. Use of one or more of these features may reduce
the memory available for the remaining features sharing memory. For example,
saving many photos to the Gallery may use all of the available memory. Your
device may display a message that the memory is full when you try to use a
shared memory feature. In this case, delete some of the information or entries
stored in the shared memory features before continuing. Some of the features,
such as Messaging and Contacts, may have a certain amount of memory specially
allotted to them in addition to the memory shared with other features.

Welcome
7
FCC DRAFTFCC DRAFT
Welcome
Congratulations on your purchase of the Nokia 6175i mobile phone. Your phone
provides many functions which are practical for daily use, such as a handsfree
loudspeaker, camera, music player, video recorder, and more. Your phone can also
connect to a PC, laptop, or other device using a USB data cable or Bluetooth
wireless technology.
■Register your phone
Make sure to register your phone at www.warranty.nokiausa.com or call
1-888-NOKIA-2U (1-888-665-4228) so that we can serve your needs better if
you need to call a customer center or have your phone repaired.
■Getting help
Find your phone label
If you need help, the Nokia Care Contact
Center is available for assistance. Before
calling, we recommend that you write down
the following information and have it
available:
• Electronic Serial Number (ESN) or Mobile
Equipment Identity (MEID), depending on
your service provider
• Your zip code (only in the US)
The ESN or MEID is found on the type label, which is located beneath the battery
on the back of the phone. See "Remove the back cover," p. 15 and "Remove the
battery," p. 15.
Check www.nokia.com/support or your local Nokia Web site for the latest
version of this guide, additional information, downloads, and services related to
your Nokia product.

Welcome
8
FCC DRAFT
Accessibility solutions
Nokia is committed to making mobile phones easy to use for all individuals,
including those with disabilities. For more information visit the Web site at
www.nokiaaccessibility.com.

Phone at a glance
9
FCC DRAFTFCC DRAFT
1. Phone at a glance
■Keys and parts
Front view
Earpiece (1) Mini-USB port (7)
Display (2) Microphone (8)
Center selection key (3) Keypad (9)
Right selection key (4) Call key (10)
End/power key (5) Left selection key (11)
Charger port (6) Scroll key (12)

Phone at a glance
10
FCC DRAFT
Side view
■Standby mode
Depending on your wireless service provider and the model number of your
phone, some or all of the following selection keys may appear in the standby
mode.
The standby mode indicates your phone is
idle.
Battery level (1)—A filled-in battery indicates
more power.
Names or network operator menu (2)—Press
the right selection key to select this option.
Go to (3)—Press the left selection key to select
this option.
Menu (4)—Press the center selection key to
select this option.
Signal strength (5)—More bars indicate a stronger network signal.
Retractable antenna (1) Volume keys (6)
2.5 mm stereo headset port (2) Push-to-talk key (7)
Camera key (3) Camera flash (8)
Back cover removal key (4) Camera lens (9)
Self-portrait mirror (5)
1
2
3
4
5
6
7
8
9
Go to Names
Menu
5
4
1
2
3

Phone at a glance
11
FCC DRAFTFCC DRAFT
■Quick keys (shortcuts)
Depending on your wireless service provider and the model number of your
phone, some or all of the following scroll key shortcuts may be available.
In the standby mode, the four-way scroll and center selection keys instantly take
you to frequently-accessed menus:
Scroll up key—Go to the contacts list or network operator menu.
Scroll right key—View the calendar.
Scroll down key—Go to the contacts list.
Scroll left key—Create a text message.
Center selection key—Displays available applications or selects highlighted
menus and submenus.
■Indicators and icons
To identify the icons on your phone, select Menu > Settings > Phone details >
Icon details.
■Phone menus
Phone features are grouped according to function and are accessed through the
main menus. Each main menu contains submenus and lists from which you can
select or view items and customize your phone features. To access these menus
and submenus, use the scroll method or use a shortcut.
Some features may not be available, depending on your network. For more
information, contact your wireless provider.
Scroll method
1. Select Menu using the center selection key. Scroll through
the main menu using the scroll key.
On the right side of the screen, a scroll bar is displayed with
a tab that moves up or down as you move through the
menus. This provides a visual representation of your current
position in the menu structure.
2. When you arrive at a menu, press Select (the center selection key) to enter
submenus.

Phone at a glance
12
FCC DRAFT
Select Back from the submenu level to return to the previous menu.
Press the end key to return to the standby mode from any menu or submenu.
Main menu display
You can control whether your phone main menu is displayed as a list or grid.
Select Menu > Options > Main menu view > List or Grid.
If supported by your wireless service provider, you can also change the order of
menus in your main menu.
Select Menu > Options > Organize. Scroll to a menu, and select Move. Scroll to a
new location, and select OK. You can repeat this procedure to customize your
main menu.
Select Done > Yes to save the changes.
In-phone help
Many features have brief descriptions (help text) that can be viewed on the
display. To view these descriptions, scroll to a feature, and wait for about
15 seconds. Scroll down to view all of the description, or select Back to exit.
To view the descriptions, you must activate help text.
Select Menu > Settings > Phone > Help text activation and an option.
■Security settings
The security feature protects your device from unauthorized outgoing calls or
denies access to the stored information with a lock or security code. The lock
code is a four-digit number, while the security code is a five-digit number. By
default, the security feature uses the lock code (defaulted to the last four digits
of your phone number), instead of the security code.
You must enter your lock code to access the Security menu.
To access the Security menu, do the following:
1. Select Menu > Settings > Security.
2. Enter the lock code, and select OK. See "Security," p. 79.
Depending on your wireless service provider, the preset lock code may be
1234 or 0000 instead of the last four digits of your phone number. If none of
these work, contact your wireless service provider for more help.

Phone at a glance
13
FCC DRAFTFCC DRAFT
To enter the lock code to restore the factory settings, do the following:
1. Select Menu > Settings > Restore settings.
2. Enter the lock code, and select OK.
Depending on your wireless service provider, your phone may ask for the
security code (defaulted to 12345 or 00000) instead of the lock code.
If you enter the wrong lock code five times in succession, your phone will not
accept your current lock code for 5 minutes. This occurs even if when you power
down the phone between incorrect attempts.
■Go to functions
The Go to menu allows you to change the function of the left selection key on
your phone so that your most frequently used functions can be quickly accessed
from the Go to menu.
Select options
1. Select Go to > Options > Select options.
2. Scroll to the options you want to add.
3. Select Mark to add an option or Unmark to remove an option.
4. Select Done when you have added all desired options.
5. Select Yes to save the changes.
6. Select Go to to display a list of the options that you selected in step 3.
Organize functions
Select Go to > Options > Organize. Scroll to an option, and select Move. Scroll to
move the option to a new location, and select OK. You can repeat this procedure
to customize your Go to menu.
Select Done > Yes to save the changes.

Set up your phone
14
FCC DRAFT
2. Set up your phone
■Antenna
Your device has an external antenna. Extend the
antenna fully.
Hold the device as you would any other telephone
with the antenna area pointed up and over your
shoulder.
Note: As with any other radio transmitting device, do not touch the
antenna unnecessarily when the device is switched on.
Contact with the antenna affects call quality and may cause the device
to operate at a higher power level than otherwise needed. Avoiding
contact with the antenna area when operating the device optimizes the
antenna performance and the battery life.
■Battery
Always switch off the power and disconnect the charger and any other device
before removing the battery. Avoid touching electronic components while
changing the covers. Always store and use the device with the covers attached.
Prolonged, continuous use of your device may increase the device temperature.
The increased temperature is a normal function of this product and does not pose
a safety concern for you or the device. If the temperature is uncomfortable to
you, use a headset or allow your device to return to room temperature before
your next call.

Set up your phone
15
FCC DRAFTFCC DRAFT
Remove the back cover
1. With the back of the phone facing you, press
down and hold the back cover latch.
2. Slide the back cover toward the bottom of
the phone, lift up, and remove.
Remove the battery
After you have removed the back cover, insert
your finger into the finger grip, and lift the
battery from its compartment.
UIM (CDMA SIM) card slot
Your phone has a UIM card slot built into the mechanics. However, the UIM is not
functional in this phone model. Avoid placing anything into the UIM card slot.
Replace the battery
1. Insert the battery, gold-colored contact
end first, into the battery slot.
2. Push down on the other end of the
battery to snap the battery into place.
Replace the back cover
1. Set the back cover on the phone with
the cover tabs aligned with the slots in
the phone.
2. Press the back cover latch down and
slide the back cover toward the top of
phone.
3. Ensure the back cover latch is secure.

Set up your phone
16
FCC DRAFT
Charge the battery
1. Plug the charger transformer into
a standard wall outlet.
2. Insert the charger output plug (1)
into the round jack at the bottom
end of the phone.
If necessary, you can use a CA-44
adapter cable (2) to connect a
charger and the phone.
After a few seconds, the battery indicator on the display scrolls. If the battery
is completely discharged, it may take a few minutes before the charging
indicator appears on the display or before any calls can be made.
■Switch your phone on or off
1. To switch your phone on or off, press and hold the
end key for at least three seconds.
2. Enter the lock code, if necessary, and select OK.
■Connect the headset
A compatible headset, such as the Nokia
HS-9 or HS-49 models, may be purchased
with your phone or separately as an
enhancement. See "Enhancements," p. 79.
1. Move the headset port cover down to
reveal the 2.5 mm stereo headset port.
2. Plug a compatible headset into the
headset port to allow handsfree
operation.
3. Position the headset on your ear.
With the headset connected, you can make, answer, and end calls as usual.

Set up your phone
17
FCC DRAFTFCC DRAFT
Warning: When you use the headset, your ability to hear outside sounds
may be affected. Do not use the headset where it can endanger your
safety.
■Make calls
Call using the keypad
1. Enter the phone number (including the area code), and press the call key.
To delete a character to the left of the cursor, select Clear.
2. To end the call, press the end key. To cancel the call attempt, select End call.
Call a stored contact
See "Contacts," p. 42.
Call the last dialed number
1. Press the call key to display the last 30 numbers dialed.
2. Scroll to the number or name you wish to redial, and press the call key.
Make a conference call
Conference calling is a network service that allows you to take part in a
conference call with two other participants.
1. Make a call to the first participant.
2. With the first participant on the line, select Options > Add new call.
3. Enter the phone number of the second participant; or, to retrieve a number
from your contacts, select Search and the number you want to call.
4. Press the call key. The first participant is put on hold.
5. When the second participant answers, press the call key to connect the calls.
6. To end the conference call, select Options > End all calls, or press the end key.
■Answer calls
You can answer a call when the keypad is locked. When you end or reject the call,
the keypad automatically relocks. See "Keyguard," p. 19.

Set up your phone
18
FCC DRAFT
Answer or silence an incoming call
To answer the call, press the call key or select Answer.
To reject the call, press the end key.
Select Silence to mute the ringing tone. Select Dismiss or do nothing, and the call
is eventually forwarded to voice mail.
If your phone is set to Silent in the Profiles menu, select Dismiss, and the call is
forwarded to voice mail.
Adjust the earpiece volume
Press the up or down arrow on the volume key to adjust the volume of the
earpiece.
When adjusting the volume, a bar chart appears on the display indicating the
volume level.
Mute the phone
To mute your phone during a call, select Mute; to unmute the phone, select
Unmute. When the phone is muted, you can hear the caller but the caller cannot
hear you.
In-call options
Many of the options that you can use during a call are network services. Check
with your wireless service provider for more information.
During a call, select Options and one of the following:
Loudsp. or Normal—Activate or deactivate the loudspeaker while in a call. The
loudspeaker is deactivated automatically when a call or a call attempt ends or
when certain enhancements are connected.
Warning: Do not hold the device near your ear when the loudspeaker is
in use because the volume may be extremely loud.
Add new call—Initiate a conference call. See "Make a conference call," p. 17 for
information.
Save—Save a number entered during a call.
Add to contact—Add a number entered during a call to a contact in your list.
End all calls—Disconnect from all active calls.

Set up your phone
19
FCC DRAFTFCC DRAFT
Send touch tones—Enter the numbers, and select Tones to send the numbers as
tones.
Contacts—View the contacts list.
Menu—View the phone menu.
■Send business cards
You can send a business card to a compatible phone or other handheld device.
1. Scroll down to display your list of contacts.
2. Select the contact to which you want to send a business card, and select
Details.
3. Scroll to the phone number for the contact, and select Options > Send bus.
card > Via multimedia, Via text message, or Via Bluetooth.
4. Select Primary number or All details.
5. Enter the number for your recipient, or select Search to retrieve a number
from your contacts; select OK.
If you selected Via Bluetooth > All details, select a Bluetooth device. The
business card is sent to the device.
■Keyguard
With the keyguard, you can lock the keypad to prevent keys from accidental
keypresses. If the keypad is locked, it unlocks when you receive a call. After the
call, the lock automatically reactivates.
When the keyguard is on, calls may be possible to the official emergency number
programmed into your device.
To lock the keypad when the phone is open, select Menu, and press *within two
seconds.
To unlock the keypad when the phone is open, select Unlock, and press *within
two seconds.

Text entry
20
FCC DRAFT
3. Text entry
You can use two methods for entering text and numbers: standard mode and
predictive text mode.
■Standard mode
Standard mode is the only way to enter text in the contacts list and to rename
caller groups.
Text (Abc) and numbers (123)
• Press a key once to insert the first letter on the key, twice for the second
letter, and so on. If you pause briefly, the last letter on the display is accepted
and your phone awaits the next entry.
• Press 0to enter a space and accept a completed word.
• Press 1as many times as necessary to scroll through a list of commonly used
characters.
• Press and hold *to display a complete list of special characters.
• Press #multiple times to turn predictive text on and off, or to change the
capitalization mode. See "Predictive text mode," p. 21 and "Change case and
mode," p. 22.
• Press and hold #to switch to the number mode. After you type a number,
press and hold #again to return to text mode.
Change language
To change the language, do the following:
1. Press and hold #.
2. In Editor settings, select Writing language and the new language.
The phone returns to the message entry screen, and you can compose in the new
language.
