Nokia 6230i - Cell Phone 32 MB User manual

1
Nokia 6230i User Guide
xxxxxxx
Issue 1

2
LEGAL INFORMATION
DECLARATION OF CONFORMITY
We, NOKIA CORPORATION declare under our sole responsibility that the product RM-72 is in
conformity with the provisions of the following Council Directive: 1999/5/EC.
A copy of the Declaration of Conformity can be found from
http://www.nokia.com/phones/declaration_of_conformity/.
PART NO. XXXXXXXX, ISSUE NO. 1
Copyright © 2005 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document
in any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia 6230i, Nokia Connecting People, Xpress-on, and Pop-Port are trademarks or
registered trademarks of Nokia Corporation. Other product and company names mentioned
herein may be trademarks or tradenames of their respective owners.
US Patent No 5818437 and other pending patents. T9 text input software
Copyright © 1999-2005. Tegic Communications, Inc. All rights reserved.
Nokia tune is a sound mark of Nokia Corporation.
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Includes RSA BSAFE cryptographic or security protocol software from RSA Security.
Java is a trademark of Sun Microsystems, Inc.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and
non-commercial use in connection with information which has been encoded in compliance
with the MPEG-4 Visual Standard by a consumer engaged in a personal and non-commercial
activity and (ii) for use in connection with MPEG-4 video provided by a licensed video
provider. No license is granted or shall be implied for any other use. Additional information
including that relating to promotional, internal and commercial uses may be obtained from
MPEG LA, LLC. See <http://www.mpegla.com>.
The information contained in this user guide was written for the Nokia 6230i product. Nokia
operates a policy of continuous development. Nokia reserves the right to make changes and
improvements to any of the products described in this document without prior notice.

3
UNDER NO CIRCUMSTANCES SHALL NOKIA BE RESPONSIBLE FOR ANY LOSS OF DATA OR
INCOME OR ANY SPECIAL, INCIDENTAL, AND CONSEQUENTIAL OR INDIRECT DAMAGES
HOWSOEVER CAUSED. THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS." EXCEPT
AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO
THE ACCURACY AND RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE
RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME WITHOUT PRIOR NOTICE.
EXPORT CONTROLS
This device may contain commodities, technology, or software subject to export laws and
regulations from the U.S. and other countries. Diversion contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close
proximity to receiving equipment). The FCC or Industry Canada can require you to stop using
your telephone if such interference cannot be eliminated. If you require assistance, contact
your local service facility. This device complies with part 15 of the FCC rules. Operation is
subject to the condition that this device does not cause harmful interference.

4

Contents
5
Contents
Contents ................................. 4
For your safety....................... 6
General information .............. 9
Phone functions.................................. 9
Access codes ........................................ 9
Security code.................................... 9
PIN and codes ............................... 10
PUK and PUK2 codes................... 10
Barring password ......................... 10
Wallet code.................................... 10
Configuration settings ................... 11
Nokia support on the Web............ 11
1. Get started....................... 12
Install the SIM card and battery. 12
Charge the battery.......................... 13
Switch the phone on and off ....... 13
Normal operating position............ 14
Change the covers........................... 15
Install a multimedia card .............. 16
2. Your phone ...................... 17
Keys and connectors....................... 17
Standby mode................................... 18
Power saving ................................. 18
Indicators........................................ 19
Shortcuts in the standby mode 20
Keypad lock (Keyguard) ................. 20
3. Call functions.................. 22
Make a call........................................ 22
Speed dialing................................. 22
Answer or reject an incoming call 22
Call waiting.................................... 23
Options during a call ...................... 23
Write text .......................................... 24
Settings for writing text ............ 24
Predictive text input ................... 25

Contents
6
Traditional text input .................. 25
Tips for writing text..................... 26
4. Navigate the menus ........ 28
Access a menu function................. 28
5. Menu functions ............... 29
Messages............................................ 29
Text messages (SMS)................... 29
Flash messages.............................. 31
Multimedia messages (MMS).... 32
Multimedia messages memory
full..................................................... 35
Folders ............................................. 35
Instant message (IM)................... 35
E-mail messages........................... 41
Voice messages ............................. 43
Info messages................................ 44
Service commands ....................... 44
Delete messages ........................... 44
Message settings.......................... 44
Contacts.............................................. 47
Search for a contact.................... 47
Save names and phone numbers.. 48
Save multiple numbers, text items,
or an image .................................... 48
Copy contacts................................ 49
Edit the contact details .............. 49
Delete contacts or contact details. 49
My presence................................... 49
Subscribed names......................... 51
Send and receive a business card. 53
Speed dials ..................................... 53
Voice dialing .................................. 54
Other functions in Contacts...... 55
Call register ....................................... 55
Recent calls lists........................... 56
Counters and timers .................... 56
Positioning information.............. 56
Settings.............................................. 56
Profiles............................................. 56
Themes............................................. 57
Tone settings.................................. 57

Contents
7
Display settings ............................ 57
Time and date settings ............... 58
My shortcuts ................................. 58
Connectivity................................... 59
Call settings................................... 62
Phone settings .............................. 63
Enhancement settings ................ 63
Configuration settings................ 64
Security settings........................... 65
Restore factory settings............. 66
Operator menu ................................. 66
Gallery................................................. 66
Media (Menu 6) ............................... 68
Camera............................................ 68
Media player.................................. 68
Music player .................................. 69
Radio................................................ 70
Voice recorder ............................... 72
Media equalizer............................ 73
Push to talk ....................................... 73
PTT menu ........................................ 74
Connect and disconnect ............ 74
Make and receive a PTT call...... 74
Callback requests ......................... 76
Add a one-to-one contact ........ 77
Create and set up groups........... 77
PTT settings.................................... 79
Organizer............................................ 80
Alarm clock .................................... 80
Calendar.......................................... 80
To-do list ........................................ 81
Notes ............................................... 81
Wallet.............................................. 82
Synchronization............................ 85
Applications ...................................... 87
Games.............................................. 87
Collection ....................................... 87
Calculator....................................... 89
Countdown timer......................... 90
Stopwatch...................................... 90
Web ..................................................... 91
Basic steps to access and use

Contents
8
services............................................ 91
Set up browsing............................ 92
Connect to a service.................... 92
Browse pages................................. 92
Appearance settings .................... 94
Cookies ............................................ 95
Scripts over secure connection. 95
Bookmarks ...................................... 95
Download files............................... 96
Service inbox.................................. 96
Cache memory............................... 97
Browser security ........................... 97
SIM services....................................... 99
6. PC connectivity.............. 100
PC Suite ........................................... 100
EGPRS, HSCSD, and CSD.......... 101
Data communication applications 101
7. Battery information....... 102
Charging and Discharging.......... 102
Nokia Battery Authentication Guidelines (for batteries with Nokia Hologram
labels)
((DRAFT - to be defined if needed for Matrix2)) 102
Technical information.................. 105
Nokia One-Year Limited Warranty 106
Patent information....................... 109
Care and maintenance ...... 111
Additional safety information 112

For your safety
9
For your safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH ON SAFELY
Do not switch the phone on when wireless phone use is prohibited or
when it may cause interference or danger.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the
vehicle while driving. Your first consideration while driving should be
road safety.
INTERFERENCE
All wireless phones may be susceptible to interference, which could
affect performance.
SWITCH OFF IN HOSPITALS
Follow any restrictions. Switch the phone off near medical
equipment.
SWITCH OFF IN AIRCRAFT
Follow any restrictions. Wireless devices can cause interference in
aircraft.
SWITCH OFF WHEN REFUELLING
Don’t use the phone at a refuelling point. Don’t use near fuel or
chemicals.
SWITCH OFF NEAR BLASTING
Follow any restrictions. Don’t use the phone where blasting is in
progress.
USE SENSIBLY
Use only in the normal position as explained in the product
documentation. Don’t touch the antenna unnecessarily.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and batteries. Do not connect
incompatible products.

For your safety
10
WATER-RESISTANCE
Your phone is not water-resistant. Keep it dry.
BACK-UP COPIES
Remember to make back-up copies or keep a written record of all
important information stored in your phone.
CONNECTING TO OTHER DEVICES
When connecting to any other device, read its user guide for detailed
safety instructions. Do not connect incompatible products.
EMERGENCY CALLS
Ensure the phone is switched on and in service. Press the End key as
many times as needed to clear the display and return to the start
screen. Enter the emergency number, then press the Call key. Give
your location. Do not end the call until given permission to do so.
■About your device
The wireless device described in this guide is approved for use on the EGSM 900,
and GSM 1800 and 1900 networks. Contact your service provider for more
information about networks.
When using the features in this device, obey all laws and respect privacy and
legitimate rights of others.
Warning: To use any features in this device, other than the alarm clock,
the device must be switched on. Do not switch the device on when
wireless device use may cause interference or danger.
■Network services
To use the phone you must have service from a wireless service provider. Many of
the features in this device depend on features in the wireless network to
function. These network services may not be available on all networks or you may
have to make specific arrangements with your service provider before you can
utilize network services. Your service provider may need to give you additional
instructions for their use and explain what charges will apply. Some networks
may have limitations that affect how you can use network nervices. Some
networks may not support all language-dependent characters and services.
Your service provider may have requested that certain features be disabled or not
activated in your device. If so, they will not appear on your device menu. Your
device may also have been specially configured for your network provider. This

For your safety
11
configuration may include changes in menu names, menu order, and icons.
Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP AND SSL) that run on TCP/IP
protocols. Some features of this device, such as multimedia messaging (MMS),
browsing, e-mail application, instant messaging, presence-enhanced contacts,
remote synchronization, and content downloading using the browser or MMS,
require network support for these technologies.
■Shared memory
The following features in this device may share memory: contacts, text and
instant messages, e-mails, voice tags, SMS distribution lists, calendar, to-do
notes, Java™ games, Java applications, and note applications. Use of one or more
of these features may reduce the memory available for the remaining features
sharing memory. For example, saving many Java applications may use all of the
available memory. Your device may display a message that the memory is full
when you try to use a shared memory feature. In this case, delete some of the
information or entries stored in the shared memory features before continuing.
Some of the features, such as Java applications, may have a certain amount of
memory specially allotted to them in addition to the memory shared with other
features.
Gallery files share a different memory, for further information see "Gallery,"
page 65.
■Enhancements
A few practical rules about accessories and enhancements.
• Keep all accessories and enhancements out of the reach of small children.
• When you disconnect the power cord of any accessory or enhancement, grasp
and pull the plug, not the cord.
• Check regularly that enhancements installed in a vehicle are mounted and
are operating properly.
• Installation of any complex car enhancements must be made by qualified
personnel only.

General information
12
General information
■Phone functions
The Nokia 6230i phone provides many functions that are practical for daily use,
such as a calendar, clock, alarm clock, radio, music player, and built-in camera.
You can personalize your phone with Nokia Xpress-on™ color covers. Your phone
also supports the following functions:
• Enhanced data rates for GSM evolution (EDGE), see "EGPRS," page 60.
• Extensible hypertext markup language (XHTML) browser, see "Web," page 88.
• E-mail application, see "E-mail," page 41.
• Instant messaging, see "Instant messaging," page 36.
• Presence-enhanced contacts, see "My presence," page 49.
• Push to talk (PTT), see "Push to talk," page 72.
• J2METM (Java 2 Platform Micro Edition), see "Applications," page 84.
• Bluetooth technology, see "Bluetooth wireless technology," page 58.
• Multimedia card to extend the memory capacity of your phone to store
images and video clips.
■Access codes
Security code
The security code (5 to 10 digits) helps to protect your phone against
unauthorized use. The preset code is 12345. Change the code, and keep the new
code secret in a safe place separate from your phone. To change the code, and to
set the phone to request the code, see "Security settings," page 64.
If you enter an incorrect security code five times in succession, the phone ignores
further entries of the code. Wait for 5 minutes, and enter the code again.
PIN, PIN2, module PIN, and signing PIN codes
The PIN (personal identification number) code (4 to 8 digits) helps to protect your
SIM card against unauthorized use. The PIN code is usually supplied with the SIM

General information
13
card. Set the phone to request the PIN code each time the phone is switched on.
See "Security settings," page 64.
The PIN2 code (4 to 8 digits) may be supplied with the SIM card and is required to
access some functions, such as call counters.
The module PIN is required to access the information in the security module. See
"Security module," page 93. The module PIN is supplied with the SIM card if the
SIM card has a security module in it.
The signing PIN is required for the digital signature. See "Digital signature,"
page 95. The signing PIN is supplied with the SIM card if the SIM card has a
security module in it.
If you enter an incorrect PIN code three times in succession, the phone may
display PIN blocked or PIN code blocked and ask you to enter the PUK code.
PUK, and PUK2 codes
The PUK (personal unblocking key) code (8 digits) is required to change a blocked
PIN code. The PUK2 code (8 digits) is required to change a blocked PIN2 code.
If the codes are not supplied with the SIM card, contact your local service
provider for the codes.
Barring password
The barring password (4 digits) is required with the Call barring service. See
"Security settings," page 64. You can obtain the password from your service
provider.
Wallet code
The wallet code (4 to 10 digits) is required to access the wallet services. If you
enter an incorrect wallet code three times in succession, the wallet application is
blocked for 5 minutes. If you give three more incorrect entries, the time doubles.
See "Wallet," page 79.
■Configuration settings
Before you use multimedia messaging, instant messaging, presence, push to talk,
e-mail application, synchronization, streaming, and the browser, you must have
the proper configuration settings on your phone. You may receive the settings
directly as a configuration message, which you save to your phone. For more

General information
14
information on availability, contact your network operator, service provider, or
nearest authorized Nokia dealer.
When you have received the settings as a configuration message, and the
settings are not automatically saved and activated, Configuration sett. received is
displayed.
To save received settings, select Show > Save. If the phone requests Enter
settings’ PIN:, enter the PIN code for the settings, and select OK. To receive the
PIN code, contact the service provider that supplies the settings.
If no settings are saved yet, these settings are saved and set as default
configuration settings. Otherwise, the phone asks Activate saved configuration
settings?.
To discard the received settings, select Show > Discard.
■Nokia support on the Web
Check www.nokia.com/support or your local Nokia Web site for the latest version
of this guide, additional information, downloads, and services related to your
Nokia product.

Get started
15
1. Get started
■Install the SIM card and battery
Always switch the device off and disconnect the charger before removing the
battery.
Keep all SIM cards out of the reach of small children. For availability and
information on using SIM card services, contact your SIM card vendor. This may
be the service provider, network operator, or other vendor.
This device is intended for use with the BL-5C battery.
The SIM card and its contacts can easily be damaged by scratches or bending, so
be careful when handling, inserting, or removing the card.
To remove the back cover of the phone, do the following:
1. With the back of the phone facing you, push
the back cover release button (1).
2. Slide the back cover to remove it from the
phone (2).
3. To remove the battery, lift
it as shown (3).
4. To release the SIM card
holder, gently pull the
locking clip of the card
holder, and open it (4).
5. Insert the SIM card into
the SIM card holder (5).
Make sure that the SIM
card is properly inserted
and that the golden
contact area on the card
is facing downwards.

Get started
16
6. Close the SIM card holder (6), and press it until it snaps into position.
7. Replace the battery (7).
Always use original
Nokia batteries. See
"Nokia battery
authentication
guidelines," page 99.
8. Slide the back cover into
place (8).
■Charge the battery
Warning: Use only batteries, chargers, and enhancements approved by
Nokia for use with this particular model. The use of any other types may
invalidate any approval or warranty, and may be dangerous.
Check the model number of any charger before use with this device. Use this
device with ACP-7, ACP-8, ACP-12, and LCH-12 chargers.
For availability of approved enhancements, please check with your dealer.
1. Connect the charger to a wall socket.
2. Connect the lead from the charger to the
socket on the bottom of your phone.
If the battery is completely discharged, it may
take a few minutes before the charging
indicator appears on the display or before any
calls can be made.
The charging time depends on the charger and the battery used. Charging a
BL-5C battery with the ACP-12 charger takes approximately 1 hour and
30 minutes while the phone is in the standby mode.
■Switch the phone on and off
Warning: Do not switch the phone on when wireless phone use is
prohibited or when it may cause interference or danger.

Get started
17
Press and hold the power key as shown.
If the phone asks for a PIN code, enter the code (for example,
displayed as ****), and select OK.
■Normal operating position
Use the phone only in its normal operating position.
Your device has an internal antenna.
Note: As with any other radio
transmitting device, do not touch the antenna unnecessarily when the
device is switched on. Contact with the antenna affects call quality and
may cause the device to operate at a higher power level than otherwise
needed. Avoiding contact with the antenna area when operating the
device optimizes the antenna performance and the battery life.

Get started
18
■Change the covers
Note: Always switch off the power and disconnect the charger and any
other device before removing the covers. Avoid touching electronic
components while changing the covers. Always store and use the
device with the covers attached.
1. Remove the back cover from the phone. See step 1 and 2 in "Install the SIM
card and battery," page 15.
2. Beginning at the top of the phone,
gently pull the front cover away
from the phone (1), and detach
the front cover (2).
3. To remove the key mat from the
front cover, press it gently out (3).
4. Place the key mat in the new front
cover (4).
5. Press the key mat gently in (5).
6. To replace the front cover, press it gently on the phone,
beginning from the bottom (6).
7. Replace the back cover of the phone. See step 8 in "Install
the SIM card and battery," page 15.

Get started
19
■Install a multimedia card
Use only compatible multimedia cards (MMC) with this device. Other memory
cards, such as secure digital (SD) cards, do not fit in the MMC card slot and are
not compatible with this device. Using an incompatible memory card may
damage the memory card as well as the device, and data stored on the
incompatible card may be corrupted.
You can use a multimedia card to extend the memory of Gallery. See "Gallery,"
page 65.
1. Remove the back cover and battery from the phone. See "Install the SIM card
and battery," page 15.
2. Place the multimedia
card in the card holder.
Make sure that the
multimedia card is
properly inserted and
that the golden contact
area on the card is
facing downwards.
3. Replace the battery and back cover of the phone. See step 7 and 8 in "Install
the SIM card and battery," page 15.

Your phone
20
2. Your phone
■Keys and connectors
Power key (1)
Earpiece (2)
Volume keys (3)—Hold the volume down key
to make a push to talk call. See "Make and
receive a PTT call,"page 73.
Loudspeaker (4)
Left selection key, middle selection key, and
right selection key (5)—The function of these
keys depends on the guiding text shown on
the display above the keys.
4-way navigation key (6)—Scroll up, down,
left, and right.
Call key—Dials a phone number and answers
a call (7).
End key—Ends an active call. Exits from any
function (8).
Number keys—Enters numbers and characters (9).
The *and #keys are used for various purposes in different functions.
Charger connector (10)
Pop-PortTM connector used for enhancements such
as headsets and the data cable (11).
Infrared (IR) port (12)
