Nokia C5–03 User Guide
Issue 2.3

Contents
Safety 5
Battery removing 5
Get started 6
Insert the SIM card and battery 6
Insert a memory card 8
Remove the memory card 9
Charge the battery 10
Keys and parts 11
Switch the device on 12
Lock the keys and touch screen 12
Home screen 12
Access the menu 14
Touch screen actions 14
Change the ringing tone 15
Nokia services 15
About Nokia Store 16
Your device 16
Phone setup 16
Settings wizard 17
Copy content from your old device 17
Display indicators 18
Contacts bar 19
Antenna locations 19
Offline profile 20
Shortcuts 20
Volume and loudspeaker control 21
Sensor settings and display rotation 21
Remote lock 21
Headset 22
Attach a wrist strap 22
Make calls 23
Calls 23
During a call 23
Voice mailbox 24
Answer or reject a call 24
Make a conference call 25
Speed dial a phone number 25
Call waiting 26
Voice dialling 26
Log 27
Write text 29
Virtual keyboard 29
Handwriting 30
Enter text with the virtual keypad 31
Touch input settings 32
Contacts 33
Save phone numbers and mail
addresses 33
Manage names and numbers 33
Assign default numbers and
addresses 34
Ringing tones, images, and call text
for contacts 34
Copy contacts 35
SIM services 35
Messaging 36
Messaging main view 36
Write and send messages 37
Receive messages 38
Multimedia messages 38
Data, settings, and web service
messages 39
Set up e-mail 39
Mailbox 40
Mail for Exchange 42
View messages on a SIM card 43
Service commands 43
Messaging settings 43
Personalise your device 45
Change the look of your device 45
Profiles 46
Music folder 46
Music player 46
2Contents

Ovi Music 48
Nokia Podcasting 49
Radio 50
Camera 51
Activate the camera 51
Image capture 51
Video recording 54
Gallery 54
View and organise files 54
View images and videos 55
Organise images and videos 56
Share online 56
About Share online 56
Subscribe to an online sharing
service 56
Manage your accounts 57
Create a post 57
Post files from Gallery 57
Nokia Video Centre 58
View and download videos 58
Video feeds 59
My videos 60
Copy your videos between your
phone and computer 60
Video centre settings 60
Internet 61
About the web browser 61
Browse the web 61
Add a bookmark 62
Subscribe to a web feed 62
Unreadable characters while
browsing the web 62
Positioning (GPS) 62
About GPS 63
About assisted GPS (A-GPS) 63
Hold your device correctly 63
Tips on creating a GPS connection 64
Position requests 65
Landmarks 65
GPS data 65
Positioning settings 66
Maps 66
Maps overview 66
View your location and the map 67
Map view 68
Change the look of the map 69
Download and update maps 69
About positioning methods 70
Find a location 71
View location details 71
Save or view a place or route 72
Send a place to a friend 72
Check in 73
Synchronise your Favourites 73
Get voice guidance 74
Use the compass 75
Drive to your destination 75
Navigation view 77
Get traffic and safety information 77
Walk to your destination 78
Plan a route 78
Connectivity 80
Data connections and access points 80
Network settings 80
Wireless LAN 81
Access points 83
View your active data connections 86
Synchronisation 87
Bluetooth connectivity 87
Transfer data using a USB cable 91
PC connections 91
Administrative settings 92
Search 93
About Search 93
Start a search 93
Contents 3

Other applications 94
Clock 94
Calendar 95
File manager 96
Application manager 97
RealPlayer 99
Recorder 100
Write a note 101
Make a calculation 101
Converter 101
Dictionary 102
Settings 102
Phone settings 102
Call settings 107
Find help 109
In-device help 109
Support 109
Update phone software and
applications using your phone 110
Update phone software using your
PC 110
Settings 110
Access codes 110
Prolong battery life 111
Increase available memory 112
Nokia original accessories 113
Practical rules about accessories 113
Battery 113
Product and safety information 114
Index 120
4Contents

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further info, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for
long periods. Exercise caution when holding your device near your ear while
the loudspeaker is in use.
Battery removing
Switch the device off and disconnect the charger before removing the battery.
Safety 5

Get started
Insert the SIM card and battery
Safe removal. Always switch the device off and disconnect the charger before
removing the battery.
Important: This device is designed to be used with a standard SIM card (see figure)
only. Use of incompatible SIM cards may damage the card or the device, and may
corrupt data stored on the card. Please consult your mobile operator for the use of
a SIM card that has a mini-UICC cutout.
A SIM card may be already inserted in the device. If not, do the following:
1 Remove the back cover.
2 Remove the battery, if inserted.
3 Slide the SIM card holder, to unlock it.
6 Get started

4 Lift the SIM card holder up.
5 Make sure the contact area of the SIM card is facing toward the device, and slide
the SIM card into the SIM card holder.
6 Lower the SIM card holder into place. Slide the SIM card holder, to lock it.
7 Line up the battery contacts, and insert the battery.
Get started 7

8 To replace the cover, direct the top locking catches toward their slots, and press
down until the cover locks into place.
If the SIM card is not properly in place, the device can only be used in the offline profile.
Insert a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.
1 Remove the back cover.
8 Get started

2 Make sure the contact area of a compatible memory card is facing down, and
insert the card into the memory card slot.
3 Push the card in, until it clicks into place.
4 Replace the back cover.
Remove the memory card
Important: Do not remove the memory card when an app is using it. Doing so may
damage the memory card and the device and corrupt data stored on the card.
1 If the device is switched on, before you remove the card, press the power key,
and select Remove memory card.
2WhenRemove memory card? Some applications will be closed. is displayed,
select Yes.
Get started 9

3 When Remove memory card and press 'OK' is displayed, remove the back cover
of the device, and push the card in, until you hear a click.
4 Pull out the memory card, and replace the back cover. If the device is switched
on, select OK.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your device for the first time. If the device indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the device.
3 When the device indicates a full charge, disconnect the charger from the device,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the device while it is charging. If the battery is completely discharged, it may take
several minutes before the charging indicator appears on the display or before any
calls can be made.
Tip: Disconnect the charger from the wall outlet when the charger is not in use. A
charger that is connected to the outlet consumes power even when it is not connected
to the device.
USB charging
You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly,
and it may take a long time for charging to start and the device to start functioning.
1 Use a compatible USB data cable to connect your device to a compatible USB
device.
Depending on the type of the device that is used for charging, it may take a while
for charging to start.
2 If the device is switched on, select the appropriate USB mode.
10 Get started

Only connect your device to products that have USB-IF logo.
Keys and parts
1Wrist strap hole
2Nokia AV connector (3.5 mm)
3Micro USB connector
4Volume/Zoom key
5Lock key
6Earpiece
7Touch screen
8Call key
9Menu key
10 End/power key
11 Camera lens
12 Loudspeaker
13 Charger connector
14 Microphone
Get started 11

Switch the device on
1 Press and hold the power key.
2 If the device asks for a PIN code or lock code, enter it, and select OK. To delete
a number, select . The factory setting for the lock code is 12345.
3 Select your location. If you accidentally select the wrong location, select Back.
4 Enter the date and time. When using the 12-hour time format, to switch between
a.m. and p.m., select any number.
Lock the keys and touch screen
To lock the touch screen and the keys, press the lock key on the side of the device.
To unlock, press the lock key on the side of the device, and select the unlock icon on
the screen.
When the touch screen and keys are locked, the touch screen is switched off and the
keys are inactive.
The screen and keys may be locked automatically after a period of inactivity.
To change the settings for automatic screen and key locking, select Menu > Settings
and Phone > Phone mgmt. > Auto. keyguard > Keypad autolock period.
Home screen
The home screen is your starting point where you can collect all your important
contacts or application shortcuts.
12 Get started

Interactive display elements
To open the clock application, tap the clock (1).
To open calendar or change profiles in the home screen, tap the date or the profile
name (2).
To view or modify connectivity settings ( ), to see the available wireless LANs if
WLAN scanning is enabled, or to view missed events, tap the top right corner (3).
To make a phone call, select (4), or, if the contacts bar is active, select
Telephone.
To open Contacts, select (5), or, if the contacts bar is active, select Contacts.
To open the main menu, press the menu key (6).
Start using the contacts bar
To add a contact to the contacts bar, in the home screen, select and a contact,
and follow the displayed instructions.
Contacts need to be saved in the phone memory.
To add a new contact to your contacts list, select > Options > New contact, and
follow the displayed instructions.
Contacts added from the contacts bar are always saved to the phone memory.
Get started 13

Change the home screen theme
To change the home screen theme or the shortcuts, select Menu > Settings and
Personal > Home screen.
Access the menu
To access the menu, press the menu key.
To open an application or folder in the menu, select the item.
Touch screen actions
Open an application or other screen element
Tap the application or element once.
To view the options available for the opened item, select Options or, if available,
select an icon from a toolbar.
Access functions quickly
Tap and hold the item. A pop-up menu with available options opens. For example, to
send an image, tap and hold the image, and from the pop-up menu, select the
appropriate option.
Tip: To see the options available for an opened item, such as an image or a video clip,
tap the screen.
Select
In this user documentation, opening applications or items by tapping them is called
"selecting". If you need to select several items in a sequence, the menu items to select
are separated by arrows.
For example, to select Options > Help, tap Options, and then tap Help.
Drag an item
Tap and hold the item, and slide your finger across the screen. The item follows your
finger.
To scroll up or down on a web page, drag the page with your finger.
Swipe
Place a finger on the screen, and steadily slide your finger in the desired direction.
14 Get started

When viewing an image, to view the next or previous image, swipe the image left or
right, respectively.
Scroll
To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.
Place your finger on the screen, slide it quickly up or down the screen, then lift your
finger. The content of the screen scrolls with the speed and direction it had at the
moment of release. To select an item from a scrolling list and to stop the movement,
tap the item.
Tip: To view a brief description of an icon, place your finger on the icon. Descriptions
are not available for all icons.
Touch screen backlight
The touch screen backlight is turned off after a period of inactivity. To turn the screen
backlight on, tap the screen.
If the touch screen and keys are locked, tapping the screen does not turn the screen
backlight on.
Change the ringing tone
Select Menu > Settings and Personal > Profiles.
You can use profiles to set and customise the ringing tones, message alert tones, and
other tones for different events, environments, or caller groups.
To personalise a profile, go to the profile, and select Personalise.
Nokia services
With Nokia services, you can find new places and services, and stay in touch with your
friends. You can do, for example, the following:
•Download games, applications, videos, and ringtones to your phone
Get started 15

•Find your way with free walk and drive navigation, plan trips, and view locations
on a map
•Get a free Nokia Mail account
•Get music
Some items are free of charge, others you may need to pay for.
The available services may also vary by country or region, and not all languages are
supported.
To use Nokia services, you need a Nokia account. When you access a service on your
phone, you are prompted to create an account.
For more information, go to www.nokia.com/support.
About Nokia Store
You can download mobile games, applications, videos, pictures, themes, and
ringtones to your phone. Some items are free of charge; others you need to pay for
with your credit card or on your phone bill. The availability of payment methods
depends on your country of residence and your network service provider. Nokia Store
offers content that is compatible with your phone and relevant to your tastes and
location.
Select Menu. To learn more about Nokia Store, go to www.nokia.com/support.
Your device
Phone setup
With the Phone setup application, you can do the following, for example:
•Define the regional settings, such as the language of the phone.
•Copy data from your old phone.
•Personalise your phone.
•Set up your mail accounts.
•Sign up for the My Nokia service to receive free tips, tricks, and support for your
Nokia phone. You will also receive notifications when new software updates are
available for your phone.
•Start using Nokia services.
When you switch on your phone for the first time, the Phone setup application opens.
To open the application later, select Menu > Applications > Tools > Phone setup.
16 Your device

Settings wizard
With Settings wizard, you can define e-mail and connection settings. The availability
of the items in Settings wizard depends on the features of the device, SIM card,
service provider, and the data in the Settings wizard database.
Select Menu > Applications > Tools > Sett. wizard.
To get the best results when using Settings wizard, keep your SIM card inserted in
the device. If the SIM card is not inserted, follow the instructions on the display.
Select from the following:
Operator — Define the operator-specific settings, such as MMS, internet, WAP, and
streaming settings.
E-mail setup — Set up a POP, IMAP, or Mail for Exchange account.
The settings available for editing may vary.
Copy content from your old device
Want to move important information from your old device and start using your new
device quickly? Use Switch to move or copy, for example, contacts, calendar entries,
and pictures to your new device free of charge.
Select Menu > Applications > Tools > Switch.
If your old Nokia device does not have the Switch application, your new device sends
it in a message. Open the message in the old device, and follow the instructions.
1 Select the connection type you want to use to transfer the data, and connect the
devices. Both devices must support the selected connection type.
2 On your device, select the content you want to transfer from the other device.
Your device 17

Display indicators
General indicators
Your phone keys and touch screen are locked.
Your phone alerts silently for incoming calls or messages.
You have set a clock alarm.
You are using a timed profile.
Call indicators
Someone has tried to call you.
You have set your phone to divert incoming calls to another number (network
service).
Your phone is ready for an internet call.
You have an ongoing data call (network service).
Messaging indicators
You have unread messages. If the indicator is blinking, the SIM card memory
for messages may be full.
You have messages waiting to be sent in the Outbox folder.
Network indicators
Your phone is connected to a GSM network (network service).
Your phone is connected to a 3G network (network service).
High-speed downlink packet access (HSDPA) / high-speed uplink packet
access (HSUPA) (network service) in the 3G network is activated.
You have a GPRS packet data connection (network service). indicates that
the connection is on hold and that a connection is being established.
You have an EGPRS packet data connection (network service). indicates that
the connection is on hold and that a connection is being established.
You have a 3G packet data connection (network service). indicates that the
connection is suspended and that a connection is being established.
You have a high-speed downlink packet access (HSDPA) connection (network
service). indicates that the connection is suspended and that a
connection is being established.
A WLAN connection is available (network service). indicates that the
connection is encrypted and that the connection is not encrypted.
18 Your device

Connectivity indicators
Bluetooth is active. indicates that your phone is sending data. If the
indicator is blinking, your phone is trying to connect to another device.
You have connected a USB cable to your phone.
GPS is active.
Your phone is synchronising.
You have connected a compatible headset to your phone.
You have connected a compatible text phone to your phone.
Contacts bar
To add a contact to the home screen, on the home screen, select > Options >
New contact, and follow the instructions.
To communicate with a contact, select the contact and from the following:
— Call the contact.
— Send a message to the contact.
— Refresh the contact's web feeds.
To view past communication events with a contact, select the contact. To view the
details of a communication event, select the event.
To close the view, select .
Antenna locations
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.
GPS antenna
Your device 19

Cellular antenna Bluetooth and WLAN
antenna
Offline profile
The offline profile lets you use the device without connecting to the wireless cellular
network. When the offline profile is active, you can use your device without a SIM card.
Activate the offline profile
Press the power key briefly, and select Offline.
When you activate the offline profile, the connection to the cellular network is closed.
All radio frequency signals to and from the device to the cellular network are
prevented. If you try to send messages using the cellular network, they are placed in
the Outbox folder to be sent later.
Important: In the offline profile you cannot make or receive any calls, or use other
features that require cellular network coverage. You may be able to call the official
emergency number programmed into your device.To make calls, you must first
change to another profile.
When you have activated the offline profile, you can still use a wireless LAN (WLAN),
for example, to read your e-mail or browse on the internet. You can also use Bluetooth
connectivity while in the offline profile. Remember to comply with any applicable
safety requirements when establishing and using WLAN or Bluetooth connections.
Shortcuts
To switch between open applications, press and hold the menu key.
Leaving applications running in the background increases the demand on battery
power and reduces the battery life.
To change the profile, press the power key, and select a profile.
To call your voice mailbox (network service), in the dialler, tap and hold 1.
To open a list of last dialled numbers, in the home screen, press the call key.
To use voice commands, in the home screen, press and hold the call key.
20 Your device
