Nokia Asha 202 User manual

Nokia 202 User Guide
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
Issue 1.1EN

Keys and parts
6
7
8
9
1 Headset connector (3.5 mm)
2 Micro-USB connector
3 Charger connector
4Earpiece
5End/Powerkey
6Keypad
7Microphone
8 Call key
9 Screen
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

10 11
14
15 12
13
10 Loudspeaker
11 Camera lens. Before using the
camera, remove the protective
tape from the lens.
12 Volume keys
13 Key lock button
14 Antenna area (highlighted). See
1 in "Feature specific
instructions".
15 SIM card slot (SIM 2). See 6.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert a SIM card and battery
Switch the phone off, then remove
the back cover.
1
If the battery is in the phone, lift it
out.
2
Open the holder, then put the SIM in
with the contact area face down. See
4.
3
Line up the battery contacts, then
push the battery in.
4
Press the back cover down until it
locks into place.
5
To switch on, press and hold until
the phone vibrates.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert or remove a second SIM card
Open the external SIM slot marked
with . See 7.
1
Put the SIM in with the contact area
face down.
2
Push the card in until it locks into
place. Close the cover.
3
To remove the card, open the SIM
slot.
4
Push the SIM in until it's free.
5
Pull the SIM out.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Insert a memory card
Switch the phone off, then remove
the back cover.
1
If the battery is in the phone, lift it
out.
2
Slide the memory card holder
towards the bottom of the phone.
3
Lift the holder.
4
Put a compatible memory card in with
the contact area face down.
5
Lower the holder.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Slide the holder to its original
position.
7
Line up the battery contacts, then
push the battery in.
8
Press the back cover down until it
locks into place. See 2.
9
Charge the battery
Plug the charger into a wall outlet.
1
Connect the charger to the phone.
2
Battery full? Unplug from the phone,
then from the wall outlet.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Lock or unlock the keys
and screen
Lock the keys and screen when not
using your phone.
Press the key lock button.
1
Explore your phone
NamesMenu
Go to
To see the features and apps in your
phone, press Menu.
1
Back
To go back to the previous view, press
Back.
2
Exit
To go back to the home screen, press
.
3
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Options
Tap an app or other item to open it.
4
Go to Menu Names
Tap and hold an item to see more
options.
5
Options
To swipe, steadily slide your finger to
the desired direction.
6
Options
To scroll, slide your finger quickly up
or down, then lift your finger. See
3.
7
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Swipe to open applications
Go to Menu
Open your favourite app with a single
swipe on the home screen.
Back Options
Select Menu > Settings.
1
Back Back
Go to
Display
Ton e s
My shortcuts
Left selection key
Right selection key
Names
Swipe gesture
Date and time
Select My shortcuts > Swipe
gesture.
2
Back
Camera
Change outg.
Back
Call divert
Fav o urit e s
Countd. timer
Apps and games
Create message
Select which app to open when you
swipe left.
3
Back
Mail
Back
Log
Create message
Meeting
Message inbox
Make a to-do
Apps and games
Select which app to open when you
swipe right.
4
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Copy content from your old phone
Easily get your contacts, calendar,
and other stuff to your new phone.
Back
Switch Bluetooth on in both phones.
1
Back Options
Select Menu > Settings.
2
Back Back
Date and time
My shortcuts
Restore backup
Connectivity
Create backupSync & backup
Phone switch
Sync with
server
Select Sync & backup > Phone
switch.
3
Back
Synchronise
Copy from this
Copy to this
Contacts
Calendar
Text messages
Multimedia msg.
Notes
Done
Options
Select Copy to this and what you want
to copy, then select Done.
4
New search
Nokia XX
Back
Options
Select your old phone from the list of
found devices.
5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Clear
OK
Options
123
Enter passcode:
*****
If asked, create a one-time passcode
(such as 123), then select OK.
6
No Yes
123456
Does code match with
code on other device?
Check that the codes match on both
phones.
7
Follow the instructions on both
phones.
8
Set which SIM card to use
Set which SIM to use for calls or the
internet connection.
Back Options
Select Menu > SIM mgr..
1
Back
SIM1
SIM2
(no selections)
(no selections)
Info
Always used
Ask every time
To decide every time which SIM to
use, select Ask every time.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Back Done
SIM2
(no selections)
Always us ed
Ask every time
SIM1
(no selections)
Info
Call
Text messages
Multimedia msgs.
Mobile data
Select SIM1 or SIM2 to set which SIM
to use for which connection.
3
Back Back
Always us ed
Ask every time
SIM1
(no selections)
Info
SIM2
Always used
Ask every time
SIM1
(no selections)
SIM2
(no selections)
Rename
To rename a SIM, select and hold the
card, then select Rename.
4
Clear
OK
Options
abc
Ask ever
y
time
Rename SIM:
******
Write a name, then select OK.
5
Indicators
/ — You have unread
messages sent to SIM1 or SIM2.
— You have unread messages
sent to SIM1 and SIM2.
/ — You have unsent,
cancelled, or failed messages from
SIM1 or SIM2.
— You have unsent, cancelled, or
failed messages from SIM1 and SIM2.
— The touch screen and keys
are locked.
— The phone doesn't ring when
somebody calls or sends a message.
— An alarm is set.
/ — The phone is connected to
a GPRS or EGPRS network using SIM1.
/ — A GPRS or EGPRS
connection from SIM1 is open.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

/ — The GPRS or EGPRS
connection from SIM1 is on hold.
— Bluetooth is on.
/ — All incoming calls to
SIM1 or SIM2 are forwarded to
another number.
— All incoming calls to SIM1 and
SIM2 are forwarded to another
number.
— The profile inuse is timed. After
a set amount of time, the phone
changes back to the previously used
profile.
— A headset is connected to the
phone.
— The phone is connected to a
device, such as a PC, with a USB cable.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Make or answer a call
Call your friend. See 17.
Clear
Options
23456789
01
Save
Type in the phone number, then press
.
1
Back
SIM2
SIM1
Call using:
If asked, select which SIM to use.
2
Contact
In call
0123456789
Options
Mute Loudsp.
To end the call, press .
3
Options Silence
Incoming call
9876543210
SIM1
When your phone rings, press to
answer. See 18.
4
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

View your missed calls
View
1 missed call
Mike
On the home screen, select View. See
5.
1
Mike
Tod a y, 14:29
0123456789
Today, 14:29
Send message
Call
Back
Back
Options
To call back, select the number, then
press .
2
Options Exit Back
Names
Add new
Log
Synchronise all
Tip: To view missed calls later, select
Menu > Contacts > Log.
Change the volume
Is the volume too loud during a call or
when listening to the radio?
Use the volume keys.
1
Better.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Save a name and phone number
Add new contacts to your phone.
Back Options
Select Menu > Contacts.
1
Back
Names
Add new
Log
Synchronise all
Select Add new.
2
Clear
OK
123
Number:
9876543210
Type in the phone number, then
select OK.
3
Clear
OK
Options
abc
First name:
Jim
Write the first name, then select OK.
4
Clear
Save
Jim Brown
Done
Options
abc
Last name:
Brown
Send message
Call
Send mail
Write the last name, then select
Save > Done.
5
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Back Back
Dad
Mum
Names
Add new
Log
Synchronise all
Jim Brown
Options
Anna
To edit details, select Names and a
contact.
6
Back Back
Options
Add detail
View conversat.
Add image
Delete contact
Jim Brown
Send message
Call
Send mail
Select Options > Add detail.
7
Send a message
HiMike!
Keep in touch with people through
messages. See 9.
Back Options
Select Menu > Messaging.
1
Back
Options
Inbox
Conversations
Sent items
Create message
Select Create message.
2
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Hi Anna, how are you?
Continue
Write your message and select
Continue.
3
Back
Options
Recently used
Number or mail
Log
123
Contacts
Mum
To add a recipient, select Contacts.
4
Back
Options
Mum
Recently used
Log
Contacts
Number or mail
231
To type in a number or mail address,
select Number or mail.
5
Back Back
Hi Anna, how are you?
Options
abc abc
Edit text
Save as draft
More
Insert object
Tip: To add an attachment, select
Options > Insert object. See 10,
11, 12.
Send
To:
Anna
Hi Anna, how are you?
Your message:
Image:
Select Send. If asked, select which
SIM to use.
6
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black

Write text
Press a key repeatedly until the letter
is shown.
To type in a punctuation mark, press
1repeatedly.
To type in a special character, press
*, then select the character.
To switch between character cases,
press #.
To use number mode, press and hold
#, then select Number mode. To go
back to letter mode, press and hold
#.
If you want to quickly type in a single
number, just press and hold the
number key.
To switch predictive text on or off,
select Options > Prediction >
Prediction on or Prediction off. Not
all languages are supported.
To change the writing language,
select Options > Writing language.
Cyan
Cyan
Magenta
Magenta
Yellow
Yellow
Black
Black
