Nokia X2-02 User manual

Nokia X2-02 User Guide
Issue 1.1

Contents
Safety 4
Your phone in brief 5
Your dual SIM phone 5
Keys and parts 5
Get started 7
Insert a SIM card and battery 7
Insert a second SIM card 7
Insert a memory card 8
Charge the battery 9
Switch the phone on or off 10
GSM antenna 10
Connect a headset 11
Attach a strap 11
Basic use 11
Support 11
Access codes 12
Set which SIM card to use 12
Lock the keys 13
Copy contacts or pictures from your
old phone 13
Use your phone without a SIM card 14
Calls 14
Make a call 14
View your missed calls 14
Call the last dialled number 15
Divert calls to your voice mailbox or
another phone number 15
Contacts 15
Save a name and phone number 15
Use speed dial 16
Send your contact information 16
Write text 16
Switch between text input modes 16
Write using traditional text input 17
Messaging 17
Send a message 17
Save an attachment 18
Listen to voice messages 19
Send an audio message 19
Connectivity 19
Bluetooth 19
USB data cable 22
Clock 22
Change the time and date 22
Alarm clock 22
Pictures and videos 23
Take a picture 23
Record a video 23
Send a picture or video 24
Organise files 24
Music and audio 24
Media player 24
FM radio 26
Play via radio 27
Web 28
About the web browser 28
Browse the web 28
Fit a web page to your phone display 29
Add a bookmark 29
Clear your browsing history 30
Phone management 30
Update phone software using your
phone 30
Update phone software using your
PC 31
Restore original settings 31
Back up your pictures and other
content to a memory card 31
2Contents

Nokia original accessories 32
Practical rules about accessories 32
Battery 32
Protect the environment 33
Save energy 33
Recycle 33
Product and safety information 33
Index 50
Contents 3

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for
use with this device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near
your ear when the loudspeaker is in use.
4Safety

Your phone in brief
Your dual SIM phone
You can insert two SIM cards.
Some benefits of a dual SIM phone
•You can make savings when you use services from different service providers.
•Use one phone number for personal calls and another for work, but carry only
one phone.
•Avoid network coverage variation between service providers.
Both SIM cards are available at the same time when the phone is not being used, but
while one SIM card is active, for example, making a call, sending or receiving a
message, or transferring data, the other is unavailable.
If there is no SIM card in the internal SIM card holder, you can only make emergency
calls.
Some features and operator services are only available when using the SIM card in
the internal SIM card holder.
A GPRS connection cannot be open in the background. If an application is using a GPRS
connection, and you return to the home screen or switch to another application,
menu, or other view, the connection is automatically closed.
Keys and parts
1Display
2Selection keys
3Navi™ key (scroll key)
4Call key
Your phone in brief 5

5Keypad
6End/Power key
7Earpiece
8Camera lens
9Loudspeaker
10 Media key
11 Memory card slot
12 Wrist strap hole
13 SIM card slot (SIM 2)
14 Volume down key
15 Volume up key
16 Headset connector/Nokia AV connector (3.5 mm)
17 Micro-USB connector
18 Charger connector
Media key functions
•To open the media player or radio, on the home screen, press and hold the media
key. The last used application opens.
•If the media player or radio is already open in the background, press the media
key.
6 Your phone in brief

Get started
Insert a SIM card and battery
This phone is intended for use with a BL-5C battery. Always use original Nokia
batteries.
If you only have one SIM card, insert the card into the internal SIM card holder.
1 Place your finger in the recess at the bottom of the phone, and carefully lift and
remove the back cover (1).
2 If the battery is inserted, lift it out.
3 Open the SIM card holder (2), and insert the SIM card (3). Make sure the contact
area of the card is facing down.
4
Line up the contacts of the battery and the battery compartment, and insert the
battery (4). To replace the back cover, direct the top locking catches toward their
slots (5), and press down until the cover locks into place (6).
Insert a second SIM card
Have a second SIM card, but want to keep using your main SIM card? You can insert
or remove a second SIM card without switching the phone off.
Get started 7

1 Open the cover of the external SIM card slot (1), marked with .
2 Insert the SIM card (2). Make sure the contact area of the card is facing up. Push
the card in, until it locks into place. Close the cover (3).
Insert a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.
Your phone supports memory cards with a capacity of up to 32 GB.
8 Get started

1 Open the memory card slot cover (1, 2).
2 Make sure the contact area of the card is facing up. Push the card in, until it locks
into place (3).
3Closethecover.
Remove the memory card
Important: Do not remove the memory card when an application is using it.
Doing so may damage the memory card and the device and corrupt data stored on
the card.
You can remove or replace the memory card without switching the phone off.
1 Open the memory card slot cover.
2 Push the card in, until it is released, and pull the card out.
3Closethecover.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time. If the phone indicates a low
charge, do the following:
1 Connect the charger to a wall outlet.
2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the charger from the phone,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.
Get started 9

If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Switch the phone on or off
Press and hold the power key .
You may be prompted to get the configuration settings from your network service
provider. For more information on this network service, contact your network service
provider.
GSM antenna
The figure shows the GSM antenna area marked in grey.
10 Get started
