Nokia 220 Dual SIM User manual

User Guide
Nokia 220 Dual SIM
RM-969
Issue 1.0 EN RM-969

Contents
Safety 3
Get started 4
Keys and parts 4
Insert SIM, battery, and memory card 4
Charge the battery 6
Lock or unlock the keys 6
Set which SIM card to use 7
Forward calls between your 2 SIMs 7
Change the volume 8
Basics 9
Explore your phone 9
Write text 10
Use predictive text 10
Set the ringtone 11
People & messaging 12
Make a call 12
Save a name and phone number 12
Send and receive messages 12
Get social 12
Internet 14
Browse the web 14
Camera 15
Take a photo 15
Record a video 15
Share a photo or video 15
Entertainment 16
Listen to music 16
Listen to the radio 16
Find and save a radio station 16
Phone management & connectivity 17
Copy content between your phone and
computer 17
Access codes 17
Product and safety information 19
User Guide
Nokia 220 Dual SIM
© 2014 Nokia. All rights reserved.
2

Safety
Read these simple guidelines. Not following them may be dangerous or illegal.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may cause interference
or danger, for example, in aircraft, in hospitals or near medical equipment, fuel, chemicals, or
blasting areas. Obey all instructions in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first
consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
BATTERIES, CHARGERS, AND OTHER ACCESSORIES
Use only batteries, chargers, and other accessories approved by Nokia for use with this device.
Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
To prevent possible hearing damage, do not listen at high volume levels for long periods.
Exercise caution when holding your device near your ear while the loudspeaker is in use.
© 2014 Nokia. All rights reserved.
3

Get started
Get to grips with the basics, and have your phone up and running in no time.
Keys and parts
Explore the keys and parts of your new phone.
1 Charger connector
2Flashlight
3 Headset connector (3.5 mm)
4 Screen
5 Scroll key
6End/Powerkey
7Microphone
8Keypad
9 Call key
10 Selection keys
11 Earpiece
12 Camera lens. Before using the camera,
remove the protective tape from the lens.
13 Antenna area
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power level during operation.
Do not connect products that create an output signal, as this may damage the device. Do not connect
any voltage source to the audio connector. If you connect an external device or headset, other than
those approved for use with this device, to the audio connector, pay special attention to volume
levels.
Some of the accessories mentioned in this user guide may be sold separately.
Insert SIM, battery, and memory card
Learn how to insert the battery and SIM and memory cards.
Important: This device is designed to be used with a standard SIM card (see figure) only. Use of
incompatible SIM cards may damage the card or the device, and may corrupt data stored on the
card. Please consult your mobile operator for the use of a SIM card that has a mini-UICC cutout.
Use only compatible memory cards approved for use with this device. Incompatible cards may
damage the card and the device and corrupt data stored on the card.
© 2014 Nokia. All rights reserved.
4

Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store and
use the device with any covers attached.
1. Place your thumb on the Nokia logo, and pull the top corners one at a time to separate the back
cover from the phone.
2. Place your fingers at the top middle of the back cover, and with your thumb on the Nokia logo,
remove the cover.
3. If the battery is in the phone, lift it out.
4. Slide the SIM into the holder with the contact area face down. To insert a second SIM, slide it into
the other holder.
5. Line up the battery contacts, and put the battery in.
6. Insert the memory card into the memory card slot. Push the memory card in until it locks into place.
© 2014 Nokia. All rights reserved.
5

Important: Do not remove the memory card when an app is using it. Doing so may damage the
memory card and the device and corrupt data stored on the card.
7. Replace the back cover.
Remove the memory card
Pull the memory card out.
Switch on your phone
Press and hold the power key.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge it before you
can use your phone.
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done, unplug the charger from the phone, then from the
wall outlet.
If the battery is completely discharged, it may take several minutes before the charging indicator is
displayed or before any calls can be made.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred while
charging the device. The efficiency of USB charging power varies significantly, and it may take
a long time for charging to start and the device to start functioning.
Make sure your computer is switched on.
Lock or unlock the keys
To avoid accidentally pressing the keys, use keypad lock.
1. Quickly press .
© 2014 Nokia. All rights reserved.
6

2. Select Lock.
Lock
Unlock the keypad
Press , and select Unlock.
Set which SIM card to use
If you have 2 SIM cards in your phone, you can select which one you want to use.
1. Select Menu > Settings > Connectivity > Dual SIM.
2. To choose which SIM to use for calls, select Call, switch Always ask to Off, and select Preferred
SIM.
3. To choose which SIM to use for messages, select Messaging, switch Always ask to Off, and select
Preferred SIM.
4. To choose which SIM to use for mobile data, switch Mobile data connection to On, and select
Mobile data > Preferred SIM.
Forward calls between your 2 SIMs
Get the most out of your 2 SIM cards. If you forward your calls between your SIMs, when someone
calls you on one SIM while you’re having a call on the other, you can manage your calls from both SIMs
just like with only one SIM.
Make sure you have 2 SIM cards inserted in your phone.
1. Select Menu > Smart Dual SIM.
2. Switch Call forwarding to On.
3. To set the numbers of your SIMs, select SIM numbers, and type in the numbers of both your SIMs.
4. Depending on how you want to forward the calls when one of your SIMs is out of reach or busy,
select Between two SIMs, From SIM1 to SIM2, or From SIM2 to SIM1.
Tip: To check if your calls are being forwarded, select Check status.
© 2014 Nokia. All rights reserved.
7

Change the volume
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change the
volume to your liking.
Scroll up or down to change the volume during a call or when listening to the radio.
© 2014 Nokia. All rights reserved.
8

Basics
Learn how to get the most out of your new phone.
Explore your phone
Explore your phone with a simple key press.
See the apps and features of your phone
Press Menu.
Menu
Go to an app or feature
Press the scroll key up, down, left, or right.
Open an app or select a feature
Press Choose.
Choose
Go back to the previous view
Press Back.
Back
© 2014 Nokia. All rights reserved.
9

Go back to the home screen
Press .
Switch the flashlight on
On the home screen, quickly press the scroll key up twice.
Menu Camera
To switch the flashlight off, press up once.
Do not shine the light in anyone’s eyes.
Write text
Writing with the keypad is easy and fun.
Press a key repeatedly until the letter is shown.
Type in a space
Press 0.
Type in a special character or punctuation mark
Press *.
Switch between character cases
Press #repeatedly.
Type in a number
Press and hold a number key.
Use predictive text
To speed up your writing, your phone can guess what you are starting to write. Predictive text is based
on a built-in dictionary. This feature is not available for all languages.
1. Select Options > Dictionary and the language.
2. Start writing a word. When the word you want is shown, press 0.
Change a word
Press *repeatedly until the word you want is shown.
© 2014 Nokia. All rights reserved.
10
