Nokia E66 User manual

E66 User Guide
Issue 1.0

DECLARATION OF CONFORMITY
Hereby, NOKIA CORPORATION declares that this RM-343 product is in compliance with the essential requirements
and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://
www.nokia.com/phones/declaration_of_conformity/.
© 2008 Nokia. All rights reserved.
Nokia, Nokia Connecting People, Nokia Original Enhancements logos, Eseries, E66, and Visual Radio are trademarks or registered trademarks of Nokia
Corporation. Nokia tune is a sound mark of Nokia Corporation. Other product and company names mentioned herein may be trademarks or tradenames
of their respective owners.
Reproduction, transfer, distribution, or storage of part or all of the contents in this document in any form without the prior written permission of Nokia
is prohibited.
US Patent No 5818437 and other pending patents. T9 text input software Copyright © 1997-2008. Tegic Communications, Inc. All rights reserved.
This product includes software licensed from Symbian Software Ltd ©1998-2008. Symbian and Symbian OS are trademarks of Symbian
Ltd.
Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.
Portions of the Nokia Maps software are ©1996-2008 The FreeType Project. All rights reserved.
This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which
has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in
connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information,
including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http://www.mpegla.com.
Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this
document without prior notice.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, UNDER NO CIRCUMSTANCES SHALL NOKIA OR ANY OF ITS LICENSORS BE RESPONSIBLE FOR ANY
LOSS OF DATA OR INCOME OR ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES HOWSOEVER CAUSED.

THE CONTENTS OF THIS DOCUMENT ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAW, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS DOCUMENT. NOKIA RESERVES THE RIGHT TO REVISE THIS DOCUMENT OR WITHDRAW IT AT ANY TIME
WITHOUT PRIOR NOTICE.
Reverse engineering of any software in the Nokia device is prohibited to the extent permitted by applicable law. Insofar as this user guide contains
any limitations on Nokia's representations, warranties, damages and liabilities, such limitations shall likewise limit any representations, warranties,
damages and liabilities of Nokia's licensors.
The availability of particular products and applications and services for these products may vary by region. Please check with your Nokia dealer for
details, and availability of language options.
Export controls
This device may contain commodities, technology or software subject to export laws and regulations from the US and other countries. Diversion
contrary to law is prohibited.
FCC/INDUSTRY CANADA NOTICE
Your device may cause TV or radio interference (for example, when using a telephone in close proximity to receiving equipment). The FCC or Industry
Canada can require you to stop using your telephone if such interference cannot be eliminated. If you require assistance, contact your local service
facility. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or
modifications not expressly approved by Nokia could void the user's authority to operate this equipment.
Issue 1.0

Contents
Safety.........................................................10
About your device.........................................................10
Network services...........................................................11
Battery removing..........................................................12
E66 in brief.................................................13
Key features...................................................................13
Keys and parts...............................................................14
Key moves......................................................................15
Automatic display rotation.......................................15
Silence the device.......................................................16
Scroll key lights...........................................................16
Slide function..............................................................16
Set up your device......................................18
Insert the SIM card and battery...................................18
Charge the battery........................................................19
Insert the memory card................................................19
Eject the memory card..................................................20
Connect the headset.....................................................20
Attach the wrist strap...................................................21
Antennas........................................................................21
Get started.................................................22
First start-up..................................................................22
Welcome........................................................................22
Settings wizard.............................................................23
Home screen..................................................................23
Menu...............................................................................24
Switch.............................................................................25
Transfer content between devices...........................25
View transfer log........................................................25
Synchronise, retrieve, and send data.......................26
Common actions in several applications....................26
Display indicators..........................................................27
Volume control..............................................................28
Memory..........................................................................29
Free memory...............................................................29
Memory card...............................................................29
MicroSDHC.................................................................29
Use a memory card..................................................29
Write text.......................................................................30
Traditional text input.................................................30
Predictive text input..................................................31
Change the writing language...................................31
Further information......................................................31
New from Eseries.......................................33
Access tasks quickly......................................................33
Home screen..................................................................33
Navigate in the home screen....................................33
Work on the home screen.........................................34
Switch home screens.................................................34
One-touch keys..............................................................34
Contents

Home key....................................................................35
Contacts key................................................................35
Calendar key................................................................35
E-mail key....................................................................35
Nokia Calendar for Eseries............................................35
Calendar views............................................................35
View calendar information........................................36
Create calendar entries..............................................36
Calendar settings........................................................37
Nokia Contacts for Eseries............................................37
Add contacts...............................................................37
Contact groups............................................................37
Search for contacts.....................................................38
Manage contacts directories.....................................38
Add ringing tones for contacts.................................38
Change contacts settings...........................................38
Multitasking...................................................................38
Personalisation..........................................40
Profiles...........................................................................40
Select ringing tones......................................................40
Customise profiles.........................................................41
Personalise the home screen.......................................41
Change the display theme............................................42
Download a theme........................................................42
3-D ringing tones..........................................................42
Media..........................................................44
Camera...........................................................................44
Capture an image.......................................................44
Scenes..........................................................................44
Capture images in a sequence..................................45
View captured image.................................................45
Record videos.............................................................45
Play a video clip..........................................................46
Image settings............................................................46
Video settings.............................................................46
Nokia Podcasting..........................................................47
Play and manage podcasts........................................47
Directories...................................................................47
Search podcasts..........................................................48
Podcasting settings....................................................48
Music player...................................................................48
Play a song or a podcast episode.............................49
Playlists.......................................................................49
Nokia Music Store ......................................................49
Transfer music from PC..............................................50
Transfer with Windows Media Player......................50
Preset frequency settings..........................................51
Share online...................................................................51
Share images online..................................................51
Recorder.........................................................................51
Record a sound clip....................................................52
Play a recording..........................................................52
Recorder settings.......................................................52
Gallery............................................................................52
Work with media files and folders...........................52
View images................................................................53
Manage image files....................................................53
RealPlayer......................................................................53
Play video clips and stream links..............................54
Send audio files and video clips...............................54
Contents
Contents

View information about a media clip......................54
RealPlayer settings.....................................................55
Flash player....................................................................55
Manage flash files.......................................................55
Radio..............................................................................55
Listen to the radio......................................................55
View visual content....................................................56
Saved stations.............................................................56
Radio settings.............................................................56
Internet......................................................58
Web................................................................................58
Connection security....................................................58
Browse the web..........................................................59
Bookmarks..................................................................59
Clear the cache............................................................59
Feeds and blogs..........................................................59
End a connection........................................................60
Web settings...............................................................60
Browse the intranet .....................................................60
Download!......................................................................60
Manage items.............................................................61
Subscriptions..............................................................61
Download! search.......................................................61
Purchase history.........................................................61
Download! settings....................................................61
Internet access points..................................................62
Set up an internet access point for packet data
(GPRS)..........................................................................62
Advanced internet access point settings for packet
data (GPRS)..................................................................62
Set up an access point for WLAN manually..............63
Advanced access point settings for WLAN...............64
Connect PC to web.........................................................64
Messaging..................................................65
Messaging folders.........................................................65
Organise messages.......................................................66
Message reader.............................................................66
Speech............................................................................66
Edit the voice properties ..........................................66
E-mail messages............................................................67
Set up your e-mail......................................................67
Connect to a remote mailbox....................................68
Read and reply to e-mail...........................................68
Write and send e-mail...............................................69
Delete messages.........................................................69
Subfolders in your remote e-mail.............................69
Text messages...............................................................70
Write and send text messages..................................70
Sending options for text messages..........................70
Text messages on the SIM card.................................70
View picture messages..............................................71
Forward picture messages........................................71
Multimedia messages...................................................71
Create and send multimedia messages...................72
Receive and reply to multimedia messages............72
Create presentations..................................................73
View presentations....................................................73
View and save multimedia attachments.................74
Forward a multimedia message...............................74
Send a sound clip.......................................................74
Contents
Contents

Sending options for multimedia messages.............74
Instant messaging........................................................75
Define IM settings.......................................................75
Start a conversation...................................................76
IM groups....................................................................76
Block users..................................................................77
IM application settings..............................................77
Special message types..................................................78
Service messages........................................................78
Send service commands............................................78
Cell broadcast................................................................78
Messaging settings.......................................................79
Text message settings...............................................79
Multimedia message settings...................................80
E-mail account settings.............................................80
Connection settings.................................................81
User settings............................................................81
Retrieval settings.....................................................81
Automatic retrieval settings...................................82
Service message settings..........................................82
Cell broadcast settings...............................................82
Other settings.............................................................82
Phone.........................................................84
Voice calls.......................................................................84
Answer a call...............................................................84
Make a call...................................................................84
Make a conference call...............................................85
Fax calls.......................................................................85
Video calls......................................................................86
Make a video call........................................................86
Share a video..............................................................86
Receive a video sharing invitation...........................87
Net calls..........................................................................87
Create a net call profile..............................................87
Connect to the net call service..................................88
Make net calls.............................................................88
Net call service settings.............................................89
Speed dialling................................................................89
Call divert.......................................................................89
Call barring.....................................................................90
Bar net calls...................................................................90
Send DTMF tones...........................................................91
Voice mail......................................................................91
Voice aid.........................................................................91
Voice commands...........................................................92
Make a call...................................................................92
Launch an application................................................93
Change profiles...........................................................93
Voice command settings...........................................93
Push to talk....................................................................93
PTT settings................................................................94
Log in to PTT service..................................................94
Make a PTT call...........................................................94
Created PTT calls.........................................................94
Manage PTT contacts.................................................95
Create a PTT channel..................................................95
Exit PTT........................................................................95
Log..................................................................................95
Call and data registers...............................................95
Monitor all communications.....................................96
Call and send messages from Log.............................96
Contents
Contents

Log settings................................................................96
Travelling...................................................97
About GPS and satellite signals...................................97
Positioning settings......................................................98
Maps...............................................................................98
About Maps.................................................................99
Move on a map...........................................................99
Display indicators.....................................................100
Find locations...........................................................100
Plan a route..............................................................100
Walk to your destination.........................................101
Drive to your destination........................................101
Traffic information...................................................102
Travel guides............................................................102
GPS data.......................................................................102
Use GPS data.............................................................103
Landmarks...................................................................103
Create a landmark....................................................103
Edit landmarks..........................................................104
Landmark categories...............................................104
Receive landmarks...................................................104
Nokia Office Tools....................................106
Active notes.................................................................106
Create and edit notes...............................................106
Settings for Active notes.........................................106
Calculator.....................................................................107
File manager................................................................107
Quickoffice...................................................................108
Work with files.........................................................108
Converter.....................................................................108
Convert measurements...........................................108
Set base currency and exchange rate....................108
Zip manager................................................................109
PDF reader...................................................................109
Printing........................................................................109
Print files ..................................................................109
Printing options.......................................................110
Printer settings.........................................................110
Clock.............................................................................110
Alarm clock................................................................111
World clock...............................................................111
Clock settings............................................................111
Notes............................................................................111
Write and send notes...............................................111
Nokia Wireless Keyboard...........................................112
Connectivity.............................................113
Fast downloading.......................................................113
Nokia PC Suite..............................................................113
Data cable....................................................................113
Infrared........................................................................114
Bluetooth.....................................................................115
About Bluetooth.......................................................115
Send and receive data with Bluetooth..................115
Pair devices...............................................................116
Security tips..............................................................117
SIM access profile........................................................117
Wireless LAN................................................................118
WLAN connections...................................................118
See WLAN availability..............................................119
Contents
Contents

WLAN wizard............................................................119
Modem.........................................................................120
Connection manager..................................................121
View and end active connections...........................121
Search for WLAN.......................................................121
Security and data management..............122
Lock the device............................................................122
Memory card security.................................................122
Encryption....................................................................123
Encrypt device memory or memory card...............123
Decrypt device memory or memory card..............123
Fixed dialling...............................................................124
Certificate manager....................................................124
View certificate details............................................125
Certificate trust settings..........................................125
Security modules.........................................................126
View and edit security modules.............................126
Back up data................................................................126
Remote configuration................................................126
Application manager..................................................127
Install applications...................................................128
Installation settings.................................................128
Java security settings...............................................129
Activation keys............................................................130
Use activation keys..................................................130
Data synchronisation..................................................131
Create a synchronisation profile.............................131
Select applications to synchronise.........................131
Synchronisation connection settings.....................132
Mobile VPN...................................................................132
Manage VPN..............................................................133
Create VPN access points.........................................133
Use a VPN connection in an application................133
Barcode reader............................................................134
Settings....................................................135
General settings..........................................................135
Personalisation settings..........................................135
Display settings.....................................................135
Standby mode settings.........................................136
Tone settings.........................................................136
Language settings.................................................137
Notification light...................................................137
Settings for One-touch keys.................................137
Date and time settings............................................137
Slide settings............................................................137
Enhancement settings.............................................138
Common enhancement settings..........................138
E-mail key settings...................................................138
Security settings.......................................................138
Device and SIM card security................................138
Restore original settings.........................................139
Telephone settings.....................................................139
Call settings...............................................................139
Network settings......................................................140
Connection settings....................................................140
Access points............................................................141
Packet data (GPRS) settings....................................141
WLAN settings..........................................................141
Advanced WLAN settings.........................................142
WLAN security settings............................................142
Contents
Contents

WEP security settings...............................................142
WEP key settings......................................................142
802.1x security settings..........................................143
WPA security settings..............................................143
Wireless LAN plugins................................................143
EAP plug-ins...........................................................144
Use EAP plug-ins....................................................144
Session initiation protocol (SIP) settings..............144
Edit SIP profiles........................................................144
Edit SIP proxy servers...............................................145
Edit registration servers..........................................145
Net call settings........................................................145
Configuration settings.............................................145
Restrict packet data.................................................146
Application settings....................................................146
Shortcuts..................................................147
General shortcuts........................................................147
Glossary....................................................149
Nokia original enhancements.................153
Battery..........................................................................153
Troubleshooting......................................154
Battery and charger information.............157
Battery and charger information..............................157
Nokia battery authentication guidelines.................158
Authenticate hologram...........................................159
What if your battery is not authentic?...................159
Care and maintenance.............................160
Additional safety information.................162
Small children..............................................................162
Operating environment..............................................162
Medical devices...........................................................162
Implanted medical devices.....................................162
Hearing aids..............................................................163
Vehicles........................................................................163
Potentially explosive environments.........................164
Emergency calls...........................................................164
CERTIFICATION INFORMATION (SAR)...........................165
MANUFACTURER’S LIMITED WARRANTY......166
Warranty period..........................................................166
How to get warranty service.....................................167
What is not covered?..................................................167
Other important notices.............................................168
Limitation of Nokia's liability....................................169
Statutory obligations..................................................169
Index........................................................171
Contents
Contents

Safety
Read these simple guidelines. Not following them may
be dangerous or illegal. Read the complete user guide
for further information.
SWITCH ON SAFELY
Do not switch the device on when wireless
phone use is prohibited or when it may
cause interference or danger.
INTERFERENCE
All wireless devices may be susceptible to
interference, which could affect
performance.
SWITCH OFF IN RESTRICTED AREAS
Follow any restrictions. Switch the device off
in aircraft, near medical equipment, fuel,
chemicals, or blasting areas.
QUALIFIED SERVICE
Only qualified personnel may install or
repair this product.
ENHANCEMENTS AND BATTERIES
Use only approved enhancements and
batteries. Do not connect incompatible
products.
WATER-RESISTANCE
Your device is not water-resistant. Keep it
dry.
About your device
The wireless device described in this guide is approved
for use on the (E)GSM 850, 900, 1800, and 1900
networks, and UMTS 900/2100 HSDPA networks.
Contact your service provider for more information
about networks.
When using the features in this device, obey all laws
and respect local customs, privacy and legitimate
rights of others, including copyrights.
Copyright protection may prevent some images, music,
and other content from being copied, modified, or
transferred.
10
Safety

Your device supports several methods of connectivity.
Like computers, your device may be exposed to viruses
and other harmful content. Exercise caution with
messages, connectivity requests, browsing, and
downloads. Only install and use services and other
software from trustworthy sources that offer adequate
security and protection against harmful software, such
as applications that are Symbian Signed or have passed
the Java Verified™ testing. Consider installing antivirus
and other security software on your device and any
connected computer.
Your device may have preinstalled bookmarks and links
for third-party internet sites. You may also access other
third-party sites through your device. Third-party sites
are not affiliated with Nokia, and Nokia does not
endorse or assume liability for them. If you choose to
access such sites, you should take precautions for
security or content.
Warning: To use any features in this device, other
than the alarm clock, the device must be switched on.
Do not switch the device on when wireless device use
may cause interference or danger.
The office applications support common features of
Microsoft Word, PowerPoint, and Excel (Microsoft Office
2000, XP, and 2003). Not all file formats can be viewed
or modified.
Remember to make back-up copies or keep a written
record of all important information stored in your
device.
When connecting to any other device, read its user
guide for detailed safety instructions. Do not connect
incompatible products.
The images in this guide may differ from your device
display.
Network services
To use the phone you must have service from a wireless
service provider. Many of the features require special
network features. These features are not available on
all networks; other networks may require that you
make specific arrangements with your service provider
before you can use the network services. Your service
provider can give you instructions and explain what
charges will apply. Some networks may have
limitations that affect how you can use network
services. For instance, some networks may not support
all language-dependent characters and services.
Your service provider may have requested that certain
features be disabled or not activated in your device. If
so, these features will not appear on your device menu.
Your device may also have a special configuration such
as changes in menu names, menu order, and icons.
Contact your service provider for more information.
This device supports WAP 2.0 protocols (HTTP and SSL)
that run on TCP/IP protocols. Some features of this
device, such as e-mail, browsing, and multimedia
Safety
11
Safety

messaging (MMS), require network support for these
technologies.
Battery removing
Always switch the device off and disconnect the
charger before removing the battery.
Safety
12
Safety

E66 in brief
Model number: Nokia E66-1 (RM-343).
Hereinafter referred to as Nokia E66.
Key features
Your new Eseries device helps you manage your
business and personal information in and out of office.
Some of the key features are highlighted here:
Switch from business to personal mode.
Browse the internet, find blogs and receive
news feeds with Web.
Listen to music with Music player.
Get podcasts to your device with Podcasting.
Add new applications to your device with
Download!
Find points of interest with Maps.
Access your e-mail while on the move.
Stay up-to-date and plan your meetings with
Calendar.
Manage your business partners and free time
friends with the new Contacts application.
Make calls using voice over IP services with
Internet tel..
Connect to WLAN with WLAN wiz..
View documents, spreadsheets, and
presentations with Quickoffice.
13
E66 in brief

Keys and parts
1— Power key
2— Earpiece
3— Light sensor
4— Selection key. Press the selection key to perform
the function shown above it on the display.
5— Call key
6— Press the key for a few seconds to switch on
Bluetooth connectivity. When writing text, press the
key and select More symbols to access special
characters.
7— Microphone
8— Camera (video calls only)
9— Navi™ scroll key, hereafter referred to as the scroll
key. Press the scroll key to enter a selection, to scroll
left, right, up, and down on the display. A long press
left, right, up, or down accelerates the scrolling.
10 — End key. Press the end key to reject a call, end
active calls and held calls, and with a long keypress, end
data connections.
11 — Backspace key. Press the key to delete items.
12 — Shift key. When writing text, press and hold the
key and select the text with the scroll key. Press this
key for a few seconds to toggle between the Silent and
General profiles.
13 — Charger connector
E66 in brief
14
E66 in brief

1— Volume up key
2— Voice key. Press the voice key to mute and unmute
the active call. This key is also used in the Voice
commands and Push to talk applications.
3— Volume down key
4— Capture key
5— Release button
6— Headset connector
7— Micro-USB port
8— Infrared port
1— Home key
2— Contacts key
3
— E-mail key
4
— Calendar key
Key moves
Your device rotates the display automatically when you
move it and responds to tapping and turning. Scroll key
lights notify you of events, and the slide enables
answering and ending calls and locking the keypad.
Automatic display rotation
In all applications, the screen rotates automatically
from portrait to landscape when you turn the device to
the left. For example, if you are browsing the web and
turn the device to the left, the image rotates
accordingly and changes to full screen. To display the
control and status panes, press either selection key.
The image changes to full screen in RealPlayer,
browser, and image viewer.
E66 in brief
15
E66 in brief

To turn off the automatic display rotation or changing
to full screen, select Menu > Tools > Settings >
General > Personalisation > Display > Display
rotation or Turn to full view.
Silence the device
To set calendar and clock alarms to snooze and to
silence incoming calls, turn the device face down.
You can also silence the device by tapping it twice. To
turn on silencing by tapping, select Menu > Tools >
Settings > General > Personalisation > Tones >
Tap to silence > On.
To turn off silencing by tapping or
turning, select Menu > Tools >
Settings > General >
Personalisation > Tones > Tap
to silence or Turn to silence.
Scroll key lights
When you receive a message or miss a call, the scroll
key starts blinking to indicate the event. When the
display light turns off, the scroll key starts blinking
slowly.
To set the length of time for blinking for missed events
or to select of which events you want to be notified,
select Menu > Tools > Settings > General >
Personalisation > Notification light.
To turn off slow blinking, select Menu > Tools >
Profiles and a profile. Select Personalise >
Breathing light.
Slide function
When the device or keypad is locked, calls may be
possible to the official emergency number
programmed into your device.
E66 in brief
16
E66 in brief

To open or close the full-size keypad, push the slide up
or down.
To lock the keypad, close the slide. To unlock
the keypad, open the slide.
Tip: To unlock the keypad without
opening the slide, press the left and
then the right selection key.
To answer a call, open the slide. To end the
call, close the slide, unless you have a headset
connected to the device, or you select
Options before closing the keypad.
To change the slide settings, select Menu > Tools >
Settings > General > Slide handling.
The keypad of your device locks automatically to
prevent the keys from being accidentally pressed. To
change the period after which the keypad is locked,
select Menu > Tools > Settings > General >
Security > Phone and SIM card > Keypad autolock
period.
E66 in brief
17
E66 in brief

Set up your device
Set up your E66 following these instructions.
Insert the SIM card and
battery
1. With the back of the device facing you, press the
release buttons (1) and slide the back cover off (2).
2. If the battery is inserted, lift the battery in the
direction of the arrow to remove it.
3. Insert the SIM card. Make sure that the contact area
on the card is facing the connectors on the device
and that the bevelled corner is facing the top of the
device.
4. Insert the battery. Align the contacts of the battery
with the corresponding connectors on the battery
compartment and insert in the direction of the
arrow.
18
Set up your device

5. Slide the back cover back to place.
Charge the battery
1. Connect a compatible charger to a wall outlet.
2. Connect the power
cord to the device. If
the battery is
completely
discharged, it may
take a while before
the charging indicator
starts scrolling.
3. When the battery is
fully charged, disconnect the charger from the
device, then from the wall outlet.
Your battery has been precharged at the factory, but
the charging levels may vary. To reach the full
operation time, charge the battery until it has been
fully charged according to the battery level indicator.
Tip: If you have old compatible Nokia chargers,
you can use them with the Nokia E66 by
attaching the CA-44 charger adapter to the old
charger. The adapter is available as a separate
enhancement.
Insert the memory
card
Use a memory card to save the memory on your device.
You can also back up information from your device to
the memory card.
Set up your device
19
Set up your device
