Nokia E7-00 User Guide
Issue 3.0

Contents
Safety 5
Get started 6
Keys and parts 6
Change the volume of a call, song, or
video 10
Lock or unlock the keys and screen 10
Flashlight 11
Insert or remove the SIM card 11
Charge your phone 12
Antenna locations 14
Headset 15
Switch the phone on or off 15
Use your phone for the first time 16
Nokia account 16
Copy contacts or pictures from your
old phone 17
Access codes 18
Use the user guide in your phone 19
Install Nokia Ovi Suite on your
computer 19
Basic use 19
Touch screen actions 19
Use shortcuts 21
Switch between open applications 22
Write text 23
Keyboard shortcuts 27
Display indicators 28
Set the notification light to blink for
missed calls or messages 30
Search your phone and the internet 30
Use your phone offline 30
Prolong battery life 31
Customization and Nokia Store 32
Profiles 32
Change your theme 34
Home screen 34
Organize your applications 37
Nokia Store 37
Telephone 40
Call a phone number 40
Search for a contact 40
Call a contact 40
Make a video call 41
Make a conference call 42
Call the numbers you use the most 43
Make calls over the internet 43
Call the last dialed number 44
Record a phone conversation 44
Turn to silence 44
View your missed calls 45
Call your voice mailbox 45
Forward calls to your voice mailbox or
another phone number 45
Prevent making or receiving calls 46
Allow calls only to certain numbers 47
Video sharing 47
Contacts 49
About Contacts 49
Save phone numbers and mail
addresses 49
Save a number from a received call or
message 50
Contact your most important people
quickly 50
Add a picture for a contact 50
Set a ringtone for a contact 51
Send your contact information using
My Card 51
Create a contact group 51
Send a message to a group of
people 52
Copy contacts from the SIM card to
your phone 52
Back up your contacts to Nokia
Services 52
2Contents

Messaging 53
About Messaging 53
Send a message 53
Send an audio message 54
Read a received message 54
View a conversation 55
Listen to a text message 55
Change the language 56
Mail 56
About Mail 56
Get a free mail account from Nokia 57
Add a mailbox 57
Read a received mail 57
Send mail 58
Respond to a meeting request 58
Open mail from the home screen 59
Internet 59
About the web browser 59
Browse the web 59
Add a bookmark 60
Subscribe to a web feed 60
Unreadable characters while
browsing the web 61
Social networks 61
About Social 61
See your friends' status updates in
one view 62
Post your status to social networking
services 62
Link your online friends to their
contact information 62
See your friends' status updates on
the home screen 62
Upload a picture or video to a service 63
Share your location in your status
update 63
Contact a friend from a social
networking service 64
Add an event to your phone calendar 64
Camera 64
About the camera 64
Take a picture 64
Save location information to your
pictures and videos 65
Take a picture in the dark 66
Picture and video tips 66
Record a video 66
Send a picture or video 67
Share a picture or video directly from
the camera 67
Your pictures and videos 68
Gallery 68
Edit the pictures you have taken 71
Video editor 71
Print a picture you have taken 72
View pictures and videos on a TV 73
Connect your phone to your home
theater 73
Videos and TV 75
Videos 75
Music and audio 76
Music player 76
About Nokia Music 78
Protected content 79
Record sounds 79
FM radio 79
Maps 81
About Maps 81
Find and view locations 82
Navigate to your destination 87
Save and share places 91
Report incorrect map information 94
Time management 94
Clock 94
Calendar 97
Contents 3

Office 100
Quickoffice 100
Read PDF documents 101
Calculator 102
Write notes 102
Translate words 102
Open or create zip files 103
Chat with your colleagues 103
Connectivity 103
Internet connections 103
Wireless LAN 104
Bluetooth 106
USB data cable 109
VPN connections 111
Close a network connection 111
Phone management 112
Keep your phone software and
applications up to date 112
Manage files 113
Free up phone memory 115
Manage applications 116
Synchronize content 116
Copy contacts or pictures between
phones 118
Protect your device 118
Find more help 120
Support 120
Troubleshooting 120
If your phone stops responding 120
Restore original settings 120
What to do when the memory is full?121
Message indicator blinking 121
A contact appears twice in the
contacts list 121
Unreadable characters while
browsing the web 121
Prepare your phone for recycling 121
Protect the environment 122
Save energy 122
Recycle 122
Product and safety information 123
Index 129
4Contents

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when cell phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The front cover of the device is made of glass. This glass can break if the
device is dropped on a hard surface or receives a substantial impact. If the
glass breaks, do not touch the glass parts of the device or attempt to
remove the broken glass from the device. Stop using the device until the
glass is replaced by qualified service personnel.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near
your ear when the loudspeaker is in use.
Safety 5

Get started
Keys and parts
Top
1Nokia AV connector (3.5 mm)
2Power key
3HDMI™ connector
4Charging indicator light
5Micro USB connector
Front
1Earpiece
2Light sensor
3Menu key
4Front camera
6 Get started

Back
1Camera flash
2Back camera
3Loudspeaker
4Microphone
Sides
1Key lock switch/Flashlight key
2SIM card slot
3Volume/Zoom key
4Camera key
Get started 7

Bottom
1Microphone
Keyboard
Your phone has a full keyboard. To open the keyboard, lift the touch screen up. The
display rotates automatically from portrait to landscape when you open the keyboard.
1Function key. To insert special characters printed at the top of keys, press
the function key, and then press the corresponding key. To enter several special
characters in a row, press the function key twice. To return to normal mode, press
the function key.
2Shift key. To switch between the upper and lower case modes, press the shift
key twice. To enter a single upper case letter in lower case mode, or a single lower
case letter in upper case mode, press the shift key, and then press the desired
alphabet key.
8 Get started

3Sym key. To insert special characters not shown on the keyboard, press the sym
key, and select the desired character. To change the writing language, press and
hold the shift key, and then press the sym key, and select the desired language.
4Space key
5Backspace key. To delete a character, press the backspace key. To delete
several characters, press and hold the backspace key.
Insert a variation of a letter
You can insert, for example, letters with accents. To insert á, press and hold the sym
key, and then press Arepeatedly, until the desired letter is displayed. The order and
availability of letters depends on the selected writing language.
Insert a number or special character that is printed at the top of a key
Press and hold the desired key.
HDMI adapter
Share your favorite pictures and high-definition videos, and browse the web directly
on your TV. Connect the adapter to your phone, and then connect any compatible
HDMI cable (available separately), to see it all on the big screen.
USB OTG adapter
Connect the USB On-The-Go (OTG) adapter to browse a compatible USB memory stick
or drive. You can then copy your pictures, videos, documents, and other content
between your phone and the external memory. It's an easy way to back up your
essential files.
Get started 9

Change the volume of a call, song, or video
Use the volume key.
You can change the volume during a call or when an application is active.
The built-in loudspeaker allows you to speak and listen from a short distance without
having to hold the phone to your ear.
Activate or deactivate the loudspeaker during a call
Select or .
Lock or unlock the keys and screen
To avoid accidentally making a call when your phone is in your pocket or bag, lock the
keys and screen of your phone.
Slide the key lock switch.
Tip: To unlock, you can also press the menu key, and select Unlock.
Set the keys and screen to lock automatically
1Select > Settings and Phone > Display > Screen/keylock time-out.
10 Get started

2 Define the length of time after which the keys and screen are locked
automatically.
Flashlight
The camera flash can be used as a flashlight. To switch the flashlight on or off, slide
and hold the key lock switch for two seconds.
Do not shine the flashlight in anyone's eyes.
Insert or remove the SIM card
Do not attach any stickers to your SIM card.
Important: This device is designed to be used with a standard SIM card (see figure)
only. Use of incompatible SIM cards may damage the card or the device, and may
corrupt data stored on the card. Please consult your mobile operator for the use of
a SIM card that has a mini-UICC cutout.
Insert the SIM card
1 Switch the phone off, and remove the SIM card holder from the phone.
2 Turn the SIM card holder over.
3 Make sure the contact area is facing up, and insert the SIM card into the SIM card
holder.
Get started 11

4 Turn the SIM card holder over, and insert it back into the phone.
Remove the SIM card
1 Switch the phone off, and remove the SIM card holder from the phone.
2 Turn the SIM card holder over.
3 Remove the SIM card.
4 Turn the SIM card holder over, and insert it back into the phone.
Charge your phone
About the battery
Your phone has an internal, nonremovable, rechargeable battery. Use only Nokia
approved chargers designated for this phone. You can also use a compatible USB data
cable to charge your phone.
Do not attempt to remove the battery from the device. To replace the battery, take
the device to your nearest authorized service facility.
Authorized retail points may also offer a battery replacement service.
Important: Only qualified personnel or an authorized service facility should
replace the battery. Unauthorized battery replacement may invalidate your warranty.
12 Get started

When your phone is low on power, power save mode is activated. You may not be able
to edit the settings of certain applications. To deactivate power save mode, press the
power key , and select Deactivate power saving.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time.
If the phone indicates a low charge, do the following:
1
2
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging.
If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
Get started 13

If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Charge the battery over USB
Battery low, but you don't have a charger with you? You can use a compatible USB
cable to connect your phone to a compatible device, such as a computer.
You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly,
and it may take a long time for charging to start and the device to start functioning.
You can use your phone while it's charging.
To avoid breaking the charger connector, be careful when connecting or
disconnecting the charger cable.
Antenna locations
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.
14 Get started

The antenna area is highlighted.
Headset
You can connect a compatible headset or compatible headphones to your phone.
Do not connect products that create an output signal, as this may damage the device.
Do not connect any voltage source to the Nokia AV connector. If you connect an
external device or headset, other than those approved by Nokia for use with this
device, to the Nokia AV connector, pay special attention to volume levels.
Switch the phone on or off
Switch on
Press and hold the power key until the phone vibrates.
Switch off
Press and hold the power key .
Get started 15

Use your phone for the first time
Your phone guides you through the initial setup when you insert your SIM card and
switch your phone on for the first time. To use Nokia services, create a Nokia account.
You can also copy your contacts and other content from your previous phone. You
can also subscribe to the My Nokia service, to receive helpful tips and tricks on how
to make the most of your phone.
To start an action, select . To skip an action, select .
To create a Nokia account, you need an internet connection. For information about
possible costs, contact your network service provider. If you can't connect to the
internet, you can create an account later.
If you already have a Nokia account, enter your username and password, and select
.
Tip: Forgotten your password? You can request it to be sent to you in a mail or text
message.
Use the Phone switch application to copy your content, such as:
•Contacts
•Messages
•Pictures and videos
•Personal settings
When you set up your mail account, you can set your inbox to be displayed on your
home screen, so you can easily check your mail.
If you need to make an emergency call during the setup phase, press the menu key.
Nokia account
When you switch on your phone for the first time, your phone guides you through
creating a Nokia account.
With your Nokia account, you can, for example:
16 Get started

•Access all Nokia services with a single username and password, both on your
phone and a compatible computer
•Download content from Nokia services
•Save details about your phone model and contact information. You can also add
your payment card details.
•Save your important walking and driving routes to Nokia Maps
To learn more about Nokia accounts and Nokia services, go to www.nokia.com/
support.
To create a Nokia account later, use your phone to access a Nokia service, and you
are prompted to create an account.
Copy contacts or pictures from your old phone
Want to copy important information from your previous compatible Nokia phone and
start using your new phone quickly? Use the Phone switch application to copy, for
example, contacts, calendar entries, and pictures to your new phone, free of charge.
Your previous Nokia phone needs to support Bluetooth.
Select > Settings > Connectivity > Data transfer > Phone switch, and follow the
displayed instructions on both phones.
If the other phone requires a passcode, enter the passcode. The passcode, which you
can define yourself, must be entered in both phones. The passcode in some phones
is fixed. For details, see the user guide of the phone. The passcode is valid only for
the current connection.
If your previous Nokia phone does not have the Phone switch application, your new
phone sends it in a message using Bluetooth. To install the application, open the
message in your previous phone, and follow the instructions.
Get started 17

Access codes
PIN or PIN2 code
(4-8 digits)
These protect your SIM card against unauthorized use or are
required to access some features.
You can set your phone to ask for the PIN code when you switch
it on.
If not supplied with your SIM card or you forget the codes,
contact your service provider.
If you enter the code incorrectly three times in a row, you need
to unblock the code with the PUK or PUK2 code.
PUK or PUK2 code
(8 digits)
These are required to unblock a PIN or PIN2 code.
If not supplied with your SIM card, contact your service
provider.
IMEI number
(15 digits)
This is used to identify valid phones in the network. The
number can also be used to block, for example, stolen
phones.You may also need to give the number to Nokia Care
services.
To view your IMEI number, dial *#06#.
Lock code (security
code)
(min. 4 digits or
characters)
This helps you protect your phone against unauthorized use.
You can set your phone to ask for the lock code that you
define.
Keep the code secret and in a safe place, separate from your
phone.
If you forget the code and your phone is locked, your phone
will require service. Additional charges may apply, and all the
personal data in your phone may be deleted.
For more information, contact a Nokia Care point or your
phone dealer.
The personal unblocking key (PUK) code and the universal personal unblocking key
(UPUK) code (8 digits) are required to change a blocked PIN code and UPIN code,
respectively. The PUK2 code (8 digits) is required to change a blocked PIN2 code.
These codes are not supplied with the SIM card. Contact your local service provider
for the codes.
18 Get started

Use the user guide in your phone
Your phone has a built-in user guide. It's always with you, available when needed.
Select > User guide.
Open the user guide from an application
Select > User guide. This is not available for every application.
Search the user guide
When the user guide is open, select > Search, and enter a letter or a word in the
search field.
Open an application from the user guide
Select the application link in a topic.
To switch back to the user guide, press and hold the menu key, swipe left or right,
and select the user guide.
Links to related topics may be at the end of instructions.
Tip: You also receive text messages and pop-up tips that give useful information
about using your phone. To view the tips later, select > My Nokia.
Install Nokia Ovi Suite on your computer
With the Nokia Ovi Suite PC application, you can manage content on your phone, and
keep it in sync with your compatible computer. You can also update your phone with
the latest software, and download maps.
A connection to the internet may be needed. For information about data costs,
contact your service provider.
Download the latest version of Nokia Ovi Suite from www.nokia.com/support to your
computer.
The latest version of Nokia Ovi Suite is called Nokia Suite.
To learn more about Nokia Ovi Suite, and to check which operating systems Nokia Ovi
Suite works with, go to www.nokia.com/support.
Basic use
Touch screen actions
To interact with the user interface, tap or tap and hold the touch screen.
Install Nokia Ovi Suite on your computer 19

Important: Avoid scratching the touch screen. Never use an actual pen, pencil, or
other sharp object on the touch screen.
Open an application or other screen element
Tap the application or element.
Access functions quickly
Tap and hold the item. A pop-up menu with available options opens.
Example: To send an image or delete an alarm, tap and hold the image or alarm, and
from the pop-up menu, select the appropriate option.
Drag an item
Tap and hold the item, and slide your finger across the screen.
Example: You can drag items on the home screen.
Swipe
Place a finger on the screen, and steadily slide your finger in the desired direction.
20 Basic use
