Nokia TA-1188 Specification sheet

1. Insert the SIM and memory
card
1. With the phone facing down, put your fingernail
in the slot on the side of the phone, bend the back
cover open, and remove it.
2. Slide the nano-SIM in slot 1 with the contact area
face down. If you have a second SIM, slide it in slot
2.
Use only original nano-SIM cards. Use of incompati-
ble SIM cards may damage the card or the device,
and may corrupt data stored on the card.
3. If you have a microSD memory card, slide the
card in the memory card slot.
Use only compatible memory cards approved for
use with this device. Incompatible cards may dam-
age the card and the device and corrupt data stored
on the card.
Important: Do not remove the memory card
when an app is using it. Doing so may damage the
memory card and the device and corrupt data
stored on the card.
Note: Switch the device off and disconnect the
charger and any other device before removing any
covers. Avoid touching electronic components while
changing any covers. Always store and use the
device with any covers attached.
Both SIM cards are available at the same time when
the device is not being used, but while one SIM card
is active, for example, making a call, the other may
be unavailable.
Tip: To remove the SIM card, slide the lever to the
left.
2. Charge the battery and switch the
phone on
Plug a compatible charger into a wall outlet, and
connect the cable to your phone. Your phone sup-
ports the USB micro-B cable. You can also charge
your phone from a computer with a USB cable, but
it may take a longer time.
If the battery is completely discharged, it may take
several minutes before the charging indicator is dis-
played.
To switch your phone on, press and hold the power
key until the phone vibrates. The phone guides you
through the setup.
For an online user guide and troubleshooting help,
go to www.nokia.com/mobile-support.
Get Started
Nokia X
TA-1188/TA-1191 EN
Camera
Flash
Google Assistant/
Google Search key*
Microphone
USB connector
Front
camera Earpiece
Volume keys
Power/Lock key
*Google Assistant is available in selected
markets and languages. Where not
available, Google Assistant is replaced by
Google Search.
Loudspeaker

Product and safety info
Important: For important info on the safe use of your device and
battery, read the Product and safety info booklet before you take
your device into use.
You can only use your device on the GSM 850, 900, 1800, 1900;
WCDMA 1, 5, 8; LTE 1, 3, 5, 7, 8, 20, 28, 38, 40, 41 (2535-2655 MHz)
networks.
You need a subscription with a service provider.
Important: 4G/LTE might not be supported by your network
service provider or by the service provider you are using when
traveling. In these cases, you may not be able to make or receive
calls, send or receive messages or use mobile data connections. To
make sure your device works seamlessly when full 4G/LTE service is
not available, it is recommended that you change the highest
connection speed from 4G to 3G. To do this, on the home screen, tap
Settings > Network & Internet > Mobile network > Advanced, and
switch Preferred network type to 3G.
For more info, contact your network service provider.
Maximum transmit power
Charge your device with the CH-51E (EU plug)/ CH-51X (UK plug)/ CH-
51U (US plug)/ CH-51A (Australia plug)/ CH-51N (India plug) chargers.
HMD Global may make additional battery or charger models available
for this device. Charging time can vary depending on device
capability. Some of the accessories mentioned in this user guide,
such as charger, headset, or data cable, may be sold separately.
The surface of the device is nickel-free.
Parts of the device are magnetic. Metallic materials may be attracted
to the device. Do not place credit cards or other magnetic stripe
cards near the device for extended periods of time, since the cards
may be damaged.
Note: Pre-installed system software and apps use a significant
part of memory space.
Keep a safe distance when using the flash. Do not use the flash on
people or animals at close range. Do not cover the flash while taking
a photo.
Certification information (SAR)
This mobile device meets guidelines forexposure to radio waves as
set forth by the Council of Europe (CE). Refer to the following.
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed thelimits for exposure to radio waves recommended
by international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety
margins designed to assure the protection ofallpersons, regardless
of age and health. The guidelines use a unit of measurement known
as the Specific Absorption Rate, or SAR.
The SARlimit for mobile devices is 2.0 W/kg and the highest SAR
value for this device when tested at theearis0.446 W/kg*. As
mobile devices offer a range of functions, they can be used in other
positions, such asonthebody. Inthis case, the highest tested SAR
value is 1.608 W/kg* at theseparation distance of0.5 cm from the
body.
For electronic safety, maintain the separation distance with
accessories containing no metal, that position handset a minimum of
the above distance. Use of other accessories may not ensure
compliance with RF exposure guidelines.
*The tests are carried out in accordance with international guidelines
for testing.
This mobile device meets guidelines for exposure to radio waves as
set forth by the Federal Communications Commission (FCC). Refer to
the following.
FCC RFExposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. The guidelines are based on
standards that were developed by independent scientific
organization through periodic and thorough evaluation ofscientific
studies. The standards include a substantial safety margin designed
to assure the safety ofall persons, regardless of age and health. The
exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit setby the FCC is 1.6 W/kg. The tests are performed in
positions and locations (e.g. at the ear and worn on the body) as
required by the FCC foreach model. The highest SAR value for this
handset model as reported to the FCC whentested for use at the ear
is 0.43 W/kg,and when worn on the body in a holderor carry case, is
1.37 W/kg.
Body-worn Operation; This device was tested for typical body-worn
operations with the handset kept 1.0 cm from the body. To
maintain compliance with FCC RF exposure requirements, use
accessories that maintain a 1.0 cm separation distance between the
user’s body and the handset. The use ofbelt clips, holsters and
similar accessories should not contain metallic components in its
assembly. The useofaccessories that do not satisfy these
requirements may not comply with FCC RF exposure requirements,
and should be avoided. The FCChas granted an Equipment
Authorization for this handset model with all reported SAR levels
evaluated as in compliance with the FCC RF emission guidelines. SAR
information on this handset model is on file with the FCC and can be
found under the FCC ID Search section of www.fcc.gov/oet/ea/
after searching onFCC ID 2AJOTTA-1188 or 2AJOTTA-1191.
Additional information on Specific Absorption Rates (SAR) can be
found on the FCC website at www.fcc.gov/general/radio-frequency-
safety-0.
To send data ormessages, a good connection to the network is
needed. Sending may be delayed until such a connection is available.
Follow the separation distance instructions until the sending is
finished.
During general use, the SAR values are usually well below the values
stated above. This is because, for purposes of system efficiency and
to minimise interference on the network, the operating power of your
mobile is automatically decreased when full power is not needed for
the call. The lower the power output, the lower the SAR value.
Device models may have different versions and more than one value.
Component and design changes may occur over timeand some
changes could affect SARvalues.
For more info, go to www.sar-tick.com.Note that mobile devices
may be transmitting even if you are notmaking a voice call.
Your mobile device is also designed to meet theUnited States
Federal Communications Commission (FCC) guidelines. FCC ratings
for your device and more information on SAR can be found at http:/
/transition.fcc.gov/oet/rfsafety/sar.html.
The World Health Organization (WHO) has stated that current
scientific information does notindicate the need for any special
precautions when using mobile devices. If you are interested in
reducing your exposure, they recommend you limityour usage or use
ahands-free kit to keep the device away from your head and body.
For more information and explanations and discussions on RF
exposure, go to the WHO website at www.who.int/peh-emf/en.
Copyrights and other notices
EU Declaration of Conformity
Hereby, HMD Global Oy declares that this product is in
compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU. A copy of the
EU Declaration of Conformity can be found at https://
www.nokia.com/en_int/phones/declaration-of-conformity.
FCC notice:
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. For more info, go to www.fcc.gov/engineering-
technology/electromagnetic-compatibility-division/radio-
frequency-safety/faq/rf-safety. Any changes or modifications not
expressly approved by HMD Global could void the user’s authority to
operate this equipment. Note: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device has an electronic label for certification information. To
access it, select Settings > System > Certification.
© 2019 HMD Global. HMD Global Oy is the exclusive licensee of the
Nokia brand for phones & tablets. Nokia is a registered trademark of
Nokia Corporation.
The Bluetooth word mark and logos are owned by the Bluetooth
SIG, Inc. and any use of such marks by HMD Global isunder license.
Google, Google Assistant and other related marks aretrademarks of
Google LLC.
GSM 850, 900 35 dBm
GSM 1800, 1900 32 dBm
WCDMA 1, 5, 8 25 dBm
LTE 1, 3, 5, 7, 8, 20,
28, 38, 40, 41 (2535-
2655 MHz)
25 dBm
Bluetooth® 9.07 dBm
WLAN 2.4G 16.43 dBm
