Nokia C2-05 User manual

Nokia C2–05 User Guide
Issue 1.2

Contents
Safety 4
Get started 5
Keys and parts 5
Insert a SIM card and battery 6
Insert a memory card 7
Charge the battery 8
Switch the phone on or off 9
GSM antenna 10
Attach a strap 10
Basic use 10
Access codes 10
Lock the keys 11
Indicators 11
Copy contacts or pictures from your
old phone 12
Change the volume of a call, song, or
video 12
Use your device offline 12
Calls 13
Make a call 13
Call the last dialled number 13
View your missed calls 13
Contacts 13
Save a name and phone number 13
Use speed dial 14
Write text 14
Switch between text input modes 14
Write using traditional text input 15
Use predictive text input 15
Messaging 16
Send a message 16
Listen to voice messages 17
Send an audio message 17
Personalise your phone 17
About the home screen 17
Personalise your home screen 18
Add shortcuts to your home screen 18
Personalise your phone tones 18
Connectivity 19
Bluetooth 19
USB data cable 20
Clock 20
Change the time and date 20
Alarm clock 20
Music and audio 21
Media player 21
FM radio 23
Mail and Chat 24
About Mail 24
Send a mail 24
Read and reply to mail 25
About Chat 25
Chat with your friends 25
Browse the web 25
About the web browser 25
Browse the web 26
Add a bookmark 26
Fit a web page to your phone display 27
Save on data costs 27
Clear your browsing history 27
Nokia services 28
Nokia Services 28
Availability and costs of Nokia
Services 28
Access Nokia Services 28
Pictures and videos 28
Take a picture 28
Record a video 29
2Contents

Send a picture or video 29
Find help 29
Support 29
Subscribe to the Tips and Offers
service 30
Keep your phone up to date 30
Protect the environment 32
Save energy 32
Recycle 33
Product and safety information 33
Index 39
Contents 3

Safety
Read these simple guidelines. Not following them may be dangerous or illegal. For
further information, read the complete user guide.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, in hospitals or near
medical equipment, fuel, chemicals, or blasting areas. Obey all instructions
in restricted areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near
your ear when the loudspeaker is in use.
4Safety

Get started
Keys and parts
1Earpiece
2Display
3Selection keys
4Call key
5Keypad
6Navi™ key (scroll key)
7End/Power key
8Nokia AV connector (3.5 mm)
9Micro-USB connector
10 Charger connector
11 Wrist strap hole
12 Microphone
Get started 5

13 Camera lens
14 Loudspeaker
Insert a SIM card and battery
Note: Switch the device off and disconnect the charger and any other device
before removing any covers. Avoid touching electronic components while changing
any covers. Always store and use the device with any covers attached.
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a
micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may
damage the card or the device, and may corrupt data stored on the card.
Important: To prevent damage to the SIM card, always remove the battery before
you insert or remove the card.
This phone is intended for use with a BL-4C battery. Always use original Nokia
batteries.
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Place your finger in the recess at the top of the phone, and carefully lift and
remove the back cover (1).
2 If the battery is inserted, lift the battery out (2).
3 Insert or remove the SIM card (3 or 4). Make sure the contact area of the card is
facing down.
6 Get started

4 Line up the contacts of the battery and the battery compartment, and insert the
battery (5). To replace the back cover, direct the bottom locking catches toward
their slots (6), and press down until the cover locks into place (7).
Insert a memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on
the card.
Your phone supports memory cards with a capacity of up to 32 GB.
Get started 7

1 Remove the back cover.
2 Make sure the contact area of the memory card is facing down, and insert the
card. Push the card in, until it locks into place.
3 Replace the back cover.
Remove the memory card
Important: Do not remove the memory card when an application is using it. Doing
so may damage the memory card and the device and corrupt data stored on the card.
You can remove or replace the memory card without switching the phone off.
1 Remove the back cover.
2 Push the card in, until it is released, and pull the card out.
3 Replace the back cover.
Charge the battery
Your battery has been partially charged at the factory, but you may need to recharge
it before you can switch on your phone for the first time.
If the phone indicates a low charge, do the following:
1 Connect the charger to a wall outlet.
8 Get started

2 Connect the charger to the phone.
3 When the phone indicates a full charge, disconnect the charger from the phone,
then from the wall outlet.
You do not need to charge the battery for a specific length of time, and you can use
the phone while it is charging. During charging, the phone may feel warm.
If the battery is completely discharged, it may take several minutes before the
charging indicator is displayed or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need to
connect the charger, then disconnect and reconnect it.
Charging the phone while listening to the radio may affect the quality of reception.
Switch the phone on or off
Press and hold the power key .
You may be prompted to get the configuration settings from your network service
provider. For more information on this network service, contact your network service
provider.
Get started 9

GSM antenna
The antenna area is highlighted.
Avoid touching the antenna area while the antenna is in use. Contact with antennas
affects the communication quality and may reduce battery life due to higher power
level during operation.
Attach a strap
Straps may be available separately.
Basic use
Access codes
The security code helps to protect your device against unauthorised use. You can
create and change the code, and set the device to request the code. Keep the code
secret and in a safe place separate from your device. If you forget the code and your
device is locked, your device will require service. Additional charges may apply, and
all the personal data in your device may be deleted. For more information, contact a
Nokia Care point or your device dealer.
10 Basic use

The PIN code supplied with the SIM card protects the card against unauthorised use.
The PIN2 code supplied with some SIM cards is required to access certain services. If
you enter the PIN or PIN2 code incorrectly three times in succession, you are asked
for the PUK or PUK2 code. If you do not have them, contact your service provider.
The module PIN is required to access the information in the security module of your
SIM card. The signing PIN may be required for the digital signature. The barring
password is required when using the call barring service.
To set how your device uses the access codes and security settings, select Menu >
Settings > Security.
Lock the keys
To avoid accidentally making a call when your phone is in your pocket or bag, lock the
keys.
Close the slide, and select Lock.
Unlock the keys
If the slide is closed, open the slide, or select Unlock > OK.
If the slide is open, select Unlock, and press *.
Set the keys to lock automatically
1 Select Menu > Settings and Device > Automatic keyguard > On.
2 Define the length of time after which the keys are locked automatically.
Indicators
You have unread messages.
You have unsent, cancelled, or failed messages.
The keypad is locked.
The device does not ring for incoming calls or text messages.
An alarm is set.
or The device is registered to the GPRS or EGPRS network.
or A GPRS or EGPRS connection is open.
or The GPRS or EGPRS connection is suspended (on hold).
Bluetooth is activated.
All incoming calls are diverted to another number.
Calls are limited to a closed user group.
The currently active profile is timed.
A headset is connected to the device.
The device is connected to another device, using a USB data cable.
Basic use 11

Copy contacts or pictures from your old phone
Want to copy your content from your previous compatible Nokia phone and start
using your new phone quickly? You can copy, for example, contacts, calendar entries,
and pictures to your new phone, free of charge.
1 Activate Bluetooth in both phones.
Select Menu > Settings > Connectivity > Bluetooth.
2SelectMenu > Settings > Sync & backup.
3SelectPhone switch > Copy to this.
4 Select the content to copy and Done.
5 Select your previous phone from the list.
6 If the other phone requires a passcode, enter the passcode. The passcode, which
you can define yourself, must be entered in both phones. The passcode in some
phones is fixed. For details, see the user guide of the other phone.
The passcode is valid only for the current connection.
7 If prompted, allow connection and copying requests.
Change the volume of a call, song, or video
Scroll up or down.
The built-in loudspeaker allows you to speak and listen from a short distance without
having to hold the device to your ear.
Activate the loudspeaker during a call
Select Loudsp..
Use your device offline
In places where you are not allowed to make or receive calls, you can activate the
flight profile and play games or listen to music.
Select Menu > Settings > Profiles and Flight > Activate.
12 Basic use

indicates that the flight profile is active.
Warning:
When the flight profile is activated, you cannot make or receive any calls, including
emergency calls, or use other features that require network coverage. To make a call,
activate another profile.
Calls
Make a call
1 Open the slide.
2 On the home screen, type in the phone number.
To delete a number, select Clear.
3 Press the call key.
4 To end the call, press the end key.
Call the last dialled number
Trying to call someone, but they are not answering? It is easy to call them again.
In the home screen, press the call key, select the number from the list, and press the
call key again.
View your missed calls
Want to see who made the call you missed?
On the home screen, select View. The caller's name is displayed, if stored in the
contacts list.
Missed and received calls are logged only if supported by the network, and the phone
is switched on and within the network service area.
Call back the contact or number
Go to the contact or number, and press the call key.
View the missed calls later
Select Menu > Contacts > Log and Missed calls.
Contacts
Save a name and phone number
Select Menu > Contacts.
Calls 13

Select Add new, and enter the number and name.
Add or edit the details of a contact
1SelectNames and a contact.
2SelectOptions > Add detail.
Tip: To add a ringtone or picture for a contact, select the contact and Options > Add
detail > Multimedia.
Use speed dial
You can quickly call your friends and family when you assign your most-used phone
numbers to the number keys of your phone.
Select Menu > Contacts > More > Speed dials.
Assign a phone number to a number key
1 Go to a number key, and select Assign. 1 is reserved for the voice mailbox.
2 Enter a number or search for a contact.
Remove or change a phone number assigned to a number key
Go to a number key, and select Options > Delete or Change.
Make a call
On the home screen, press and hold a number key.
Deactivate speed dialling
Select Menu > Settings and Call > Speed dialling.
Write text
Switch between text input modes
When writing text, you can use traditional or predictive text input.
, , and indicate the character cases. indicates that number mode is
activated.
Activate or deactivate predictive text input mode
Select Options > Prediction > Prediction on or Prediction off. Not all languages are
supported by predictive text input.
Switch between character cases
Press #.
14 Write text

Activate number mode
Press and hold #, and select Number mode. To return to letter mode, press and hold
#.
Tip: To quickly enter an individual number, press and hold the number key.
Set the writing language
Select Options > Writing language.
Tip: To activate number mode, activate or deactivate predictive text input mode, or
set the writing language, you can also press and hold #, and select the appropriate
option.
Write using traditional text input
1 Press a number key (2-9) repeatedly, until the desired character is displayed.
2 Insert the next character. If it is located on the same key, wait until the cursor is
displayed, or move the cursor.
The available characters depend on the selected writing language.
Move the cursor
Scroll left or right.
Insert a common punctuation mark
Press 1repeatedly.
Insert a special character
Press *, and select the desired character.
Insert a space
Press 0.
Use predictive text input
Write using predictive text input
The built-in dictionary suggests words as you press the number keys.
1 Press each number key (2–9) once for each character.
2Press*repeatedly, and select the desired word from the list.
3 To confirm the word, move the cursor forward.
Write text 15

Add a missing word to the dictionary
If ?is displayed when you enter a word using predictive text input, the word is not in
the dictionary. You can add it to the built-in dictionary.
1SelectSpell.
2 Write the word using traditional text input.
3SelectSave.
Write a compound word
1 Write the first part of the word. To confirm the word, move the cursor forward.
2 Write the next part of the word, and confirm again.
Messaging
Send a message
Keep in touch with your family and friends with text and multimedia messages. You
can attach your pictures, videos, and business cards to your message.
Select Menu > Messaging.
1SelectCreate message.
2 Write your message.
3 To add an attachment , select Options > Insert object.
4SelectSend to.
5 To enter a phone number or mail address manually, select Number or mail. Enter
a phone number, or select Mail, and enter a mail address. To select a recipient or
a contact group, select Contacts or Contact groups.
6SelectSend.
Tip: To insert a special character or smiley, select Options > Insert symbol.
Sending a message with an attachment may be more expensive than sending a normal
text message. For more information, contact your service provider.
You can send text messages that are longer than the character limit for a single
message. Longer messages are sent as two or more messages. Your service provider
may charge accordingly.
Characters with accents, other marks, or some language options, take more space,
limiting the number of characters that can be sent in a single message.
If the item you insert in a multimedia message is too large for the network, the device
may automatically reduce the size.
16 Messaging

Only compatible devices can receive and display multimedia messages. Messages
may look different in different devices.
Listen to voice messages
When you can't answer, you can divert calls to your voice mailbox and listen to your
messages later.
You may need a voice mailbox subscription. For more information on this network
service, contact your service provider.
1 Select Menu > Messaging > More > Voice messages and Voice mailbox no..
2 Enter your voice mailbox number, and select OK.
3 To call your voice mailbox, on the home screen, press and hold 1.
Send an audio message
Don't have time to write a text message? Record and send an audio message instead!
Select Menu > Messaging.
1 Select More > Other messages > Audio message.
2 To record your message, select .
3 To stop recording, select .
4 Select Send to and a contact.
The size of a message must be less than 300 kilobytes.
Check the size of a message
After writing a multimedia or audio message, select Options > Preview > Options >
Show contents. Details of the individual parts of the message are displayed.
Personalise your phone
About the home screen
In the home screen, you can:
•See notifications of missed calls and received messages
•Open your favourite applications
•Add shortcuts for different features, such as writing a message
Personalise your phone 17

Personalise your home screen
Want to see your favourite landscape or pictures of your family in the background of
your home screen? You can change this wallpaper, and rearrange items on your home
screen, to personalise it to your liking.
Change the wallpaper
1SelectMenu > Settings and Display > Wallpaper.
2 Select a folder and a picture.
You can also take a picture with your phone camera, and use that picture.
Tip: Download more wallpapers from Nokia Store. For more information, go to
www.nokia.com/support.
To rearrange items on your home screen, replace the shortcuts with new ones.
Add shortcuts to your home screen
Want to open your favourite apps directly from your home screen? You can add
shortcuts to your most used features.
1 On the home screen, select Options > Personalise view.
2 Select a bar, then select an item, such as a widget, and Done.
Tip: To remove an app or shortcut from the home screen, select Options > Set as
empty.
Change a shortcut on the shortcut widget
1 On the home screen, scroll to the shortcut you want to change, then select
Options > Change shortcut.
2 Select the desired item from the list.
Tip: To change all shortcuts at the same time, select Select shortcuts.
Personalise your phone tones
You can personalise the ringtones and key and warning tones for each profile.
Select Menu > Settings and Tones.
Change the ringtone
Select Ringtone > Options > Change, and select the ringtone.
Tip: Download more ringtones from Nokia Store. To learn more about Nokia Store,
go to www.nokia.com/support.
18 Personalise your phone

Change the volume of the keypad tones
Select Keypad tones, and scroll left or right.
Connectivity
Bluetooth
About Bluetooth connectivity
Select Menu > Settings > Connectivity > Bluetooth.
Use Bluetooth to connect wirelessly to compatible devices, such as other mobile
devices, computers, headsets, and car kits.
You can also send items from your device, copy files from your compatible PC, and
print using a compatible printer.
Bluetooth uses radio waves to connect, and devices must be within 10 metres (33
feet) of each other. Obstructions, such as walls or other electronic devices, can cause
interference.
Send a picture or other content to another device using Bluetooth
Use Bluetooth to send pictures, videos, business cards, and other content created
by you to your computer or a friend's compatible phone or device.
1 Select the item to send.
2 Select Options > Send > Via Bluetooth.
3 Select the device to connect to. If the desired device is not displayed, to search
for it, select New search. Bluetooth devices within range are displayed.
4 If the other device requires a passcode, enter the passcode. The passcode, which
you can define yourself, must be entered in both devices. The passcode in some
devices is fixed. For details, see the user guide of the device.
The passcode is valid only for the current connection.
Connectivity 19

The available options may vary.
USB data cable
Copy content between your phone and a computer
You can use a USB data cable to copy your pictures and other content between your
phone and a compatible computer.
1 Use a USB data cable to connect your phone to a computer.
2 Select from the following modes:
Nokia Suite — Nokia Suite is installed on your computer.
Media transfer — Nokia Suite is not installed on your computer. If you want to
connect your phone to a home entertainment system or printer, use this mode.
Mass storage — Nokia Suite is not installed on your computer. The phone is
displayed as a portable device on your computer. Make sure a memory card is
inserted. If you want to connect your phone to other devices, such as a home or
car stereo, use this mode.
3 To copy the content, use the file manager of the computer.
To copy your contacts, music files, videos, or pictures, use Nokia Suite.
Clock
Change the time and date
Select Menu > Settings and Date and time.
Change the time zone when travelling
1SelectDate & time settings > Time zone.
2 To select the time zone of your location, scroll left or right.
3SelectSave.
The time and date are set according to the time zone. This makes sure that your
phone displays the correct sending time of received text or multimedia messages.
For example, GMT -5 denotes the time zone for New York (USA), 5 hours west of
Greenwich, London (UK).
Alarm clock
You can set an alarm to sound at a desired time.
Set the alarm
1SelectMenu > Apps > Alarm clock.
2 To activate the alarm, scroll left or right.
20 Clock
