Nokia X7 User manual

Nokia X7 User Guide
Issue FCC Review
DRAFT
RM-659 03 Aug 2010

Contents
Safety...........................................5
Getting started............................6
Keys and parts............................................6
Antenna locations......................................8
Headset.......................................................9
Change the volume of a call, song, or
video...........................................................9
Lock or unlock the keys and screen.........9
Insert or remove the SIM card..................9
Insert or remove the memory card.......11
Charging...................................................12
If your device stops responding............14
Switch the device on or off.....................14
Nokia account and Ovi services..............15
Copy contacts or pictures from your old
device.......................................................15
Device set-up...........................................16
Use the in-device user guide..................16
Install Nokia Ovi Suite on your
PC...............................................17
Touch screen actions.................18
Interactive home screen
elements...................................20
Call a phone number.................20
View your missed calls..............21
Save phone numbers and mail
addresses..................................21
Send a message.........................22
Personalisation.........................22
Profiles......................................................22
Change your theme.................................23
Home screen............................................24
Organise your applications.....................26
Explore Ovi services...................26
Visit Ovi by Nokia.....................................26
Nokia account and Ovi services..............27
About Ovi Contacts..................................27
About Ovi Files.........................................27
About Ovi Mail..........................................28
About Nokia's Ovi Maps...........................28
About Ovi Music.......................................28
About Ovi Store........................................28
Personalise your device............29
Profiles......................................................29
Change your theme.................................30
Set up the home screen..........................30
Organise your applications.....................32
Telephone.................................33
Use your T-coil hearing aid with your
device.......................................................33
Connect to a TTY device..........................33
Call a phone number...............................33
Search for a contact................................34
Call a contact............................................34
Make a conference call............................34
Use speed dial..........................................35
Use your voice to call a contact..............35
Make calls over the internet...................36
Call the last dialled number...................37
Record a phone conversation................37
Turn to silence.........................................38
View your missed calls............................38
Call your voice mailbox ..........................38
Divert calls to your voice mailbox or
another phone number..........................39
Prevent making or receiving calls.........39
Allow calls only to certain numbers......40
Video sharing...........................................40
Messaging.................................42
DRAFT
RM-659 03 Aug 2010

About Messaging.....................................42
Send a message.......................................43
Send an audio message..........................43
Receive messages....................................44
View a conversation................................44
Listen to a text message.........................45
Change language.....................................45
Chat...........................................................45
Mail............................................46
Mail...........................................................46
About Nokia Messaging..........................48
Open mail from the home screen..........48
Internet.....................................48
About Internet.........................................48
Browse the web.......................................49
Add a bookmark......................................49
Subscribe to a web feed.........................49
Camera......................................50
About Camera..........................................50
Take a picture..........................................50
Save location information to your
pictures and videos.................................51
Take a close-up picture...........................51
Take a picture in the dark......................52
Take a picture of a moving object.........52
Picture tips...............................................52
Record a video.........................................52
Send a picture..........................................53
Your pictures and videos...........53
About Photos...........................................53
View pictures and videos........................53
Edit the pictures you have taken...........54
Video editor.............................................54
Print a picture you have taken...............55
Videos and TV............................56
Videos.......................................................56
Watch Web TV..........................................57
Listen to music..........................57
Music player.............................................57
Protected content....................................59
Record sounds.........................................59
Play music through a radio....................60
FM radio....................................................61
Maps..........................................63
Maps overview.........................................63
My position...............................................63
Find places...............................................67
Favourites.................................................68
Drive and Walk.........................................70
Time management....................74
Clock..........................................................74
Calendar....................................................76
Office.........................................78
Quickoffice................................................78
Read PDF documents...............................79
Make a calculation...................................79
Write notes..............................................80
Translate words from one language to
another.....................................................80
Open or create zip files...........................81
Connecting your device.............81
Internet connections...............................81
Wireless LAN............................................82
Bluetooth.................................................83
USB data cable.........................................85
Close a network connection...................87
Mange your device....................87
Keep your device software and
applications up to date...........................87
Manage files.............................................89
Increase available memory for more
content.....................................................90
Manage applications...............................91
Synchronise content................................92
Copy contacts or pictures between
devices......................................................92
Protect your device.................................93
Find more help..........................94
Contents
DRAFT
RM-659 03 Aug 2010

Support.....................................................94
Accessibility solutions.............................95
Troubleshooting.......................95
If your device stops responding............95
Restore original settings........................95
What to do when the memory is
full?...........................................................95
Message indicator blinking....................96
A contact appears twice in the contacts
list.............................................................96
Unreadable characters while browsing
the web....................................................96
Prepare your device for recycling..........96
Green tips..................................97
Save energy..............................................97
Recycle......................................................97
Product and safety
information...............................98
Index.......................................109
Contents
DRAFT
RM-659 03 Aug 2010

Safety
Read these simple guidelines. Not following them may be dangerous or illegal.
Read the complete user guide for further information.
SWITCH OFF IN RESTRICTED AREAS
Switch the device off when mobile phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.
ROAD SAFETY COMES FIRST
Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.
INTERFERENCE
All wireless devices may be susceptible to interference, which could affect
performance.
QUALIFIED SERVICE
Only qualified personnel may install or repair this product.
CHARGERS AND OTHER ACCESSORIES
Use only chargers and other accessories approved by Nokia for use with this
device. Do not connect incompatible products.
KEEP YOUR DEVICE DRY
Your device is not water-resistant. Keep it dry.
GLASS PARTS
The front cover of the device is made of glass. This glass can break if the device
is dropped on a hard surface or receives a substantial impact. If the glass
breaks, do not touch the glass parts of the device or attempt to remove the
broken glass from the device. Stop using the device until the glass is replaced
by qualified service personnel.
PROTECT YOUR HEARING
Listen to a headset at a moderate level, and do not hold the device near your
ear when the loudspeaker is in use.
© 2010 Nokia. All rights reserved. 5
DRAFT
RM-659 03 Aug 2010

Getting started
Keys and parts
View keys and parts on top of device
1— Micro USB connector
2— Universal Jack connector (3.5 mm)
3— Power /Unlock/Lock key
Front
1— Earpiece
2— Menu key
© 2010 Nokia. All rights reserved.6
DRAFT
RM-659 03 Aug 2010

Back
1— Camera flash
2— Camera lens
3— Microphone
Sides
1— Memory card slot
2— SIM card slot
3— Volume/Zoom key
4— Camera key
5— Loudspeaker
Getting started
© 2010 Nokia. All rights reserved. 7
DRAFT
RM-659 03 Aug 2010

Bottom
1— Microphone
Touch screen
To control your device, lightly touch the screen with your fingertips. The screen
does not respond when you use your fingernails.
If your fingertips are cold, the screen may not respond to your touch.
To avoid scratching the touch screen, never use a pen, pencil, or other sharp object
to write on the touch screen.
Antenna locations
Avoid touching the antenna area unnecessarily while the antenna is transmitting
or receiving. Contact with antennas affects the communication quality and may
cause a higher power level during operation and may reduce the battery life.
Getting started
© 2010 Nokia. All rights reserved.8
DRAFT
RM-659 03 Aug 2010

Headset
You can connect a compatible headset or compatible headphones to your device.
Change the volume of a call, song, or video
Use the volume keys.
The built-in loudspeaker allows you to speak and listen from a short distance
without having to hold the device to your ear.
Activate or deactivate the loudspeaker during a call — Select Loudspeaker
or Activate handset.
Lock or unlock the keys and screen
To avoid accidentally making a call when your device is in your pocket or bag, lock
the keys and screen of your device.
To lock the keys and screen, quickly tap the power button.
To unlock the keys and screen, select the Menu key andUnlock.
Set the keys and screen to lock automatically
1. Select Menu > Settings and Phone > Display > Screen/
keylock time-out.
2. Define the length of time after which the keys and screen are
locked automatically.
Insert or remove the SIM card
Do not attach any stickers to your SIM card.
Getting started
© 2010 Nokia. All rights reserved. 9
DRAFT
RM-659 03 Aug 2010

1— Memory card slot cover
2— SIM card slot cover
Insert the SIM card
1. Use your finger to press open the cover of the SIM card slot.
2. Grab the tray to slide out the card slot.
3. Slide the SIM card into the tray.
4. Make sure the contact area of the SIM card is facing the back of the device and
lays snugly in the tray.
5. Slide the tray into the device.
Remove the SIM card
1. Use your finger to press open the cover of the SIM card slot.
2. Grab the tray to slide out the card slot and remove the card.
Getting started
© 2010 Nokia. All rights reserved.10
DRAFT
RM-659 03 Aug 2010

Insert or remove the memory card
Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored
on the card.
Memory cards are sold separately.
Do not attach any stickers to your memory card.
Insert the memory card
1. Use your finger to press open the cover of the memory card slot.
2. Grab the tray to slide out the card slot.
3. Slide the memory card sideways into the tray.
Make sure the contact area of the memory card is facing the back of the device.
4. Push the card in, until you hear a click.
5. Slide the tray into the device.
Getting started
© 2010 Nokia. All rights reserved. 11
DRAFT
RM-659 03 Aug 2010

Remove the memory card
1. Use your finger to press open the cover of the memory card slot.
2. Grab the tray to slide out the card slot and remove the card.
Charging
About the battery
Your device has an internal, nonremovable, CTIA 1725-certified rechargeable
battery. Use only Nokia approved chargers designated for this device. You can also
use a compatible USB data cable to charge your device.
Do not attempt to remove the battery from the device. Take the device to the
nearest authorised service facility for replacement of the battery.
You can use USB charging when a wall outlet is not available. Data can be
transferred while charging the device. The efficiency of USB charging power varies
significantly, and it may take a long time for charging to start and the device to
start functioning.
Getting started
© 2010 Nokia. All rights reserved.12
DRAFT
RM-659 03 Aug 2010

Only connect your device to products that have a USB-IF logo or have completed
the USB-IF compliance program.
Authorised retail points may also offer a battery replacement service.
When your device is low on power, it goes into power save mode. To deactivate
power save mode, press , and select Deactivate power saving. When power
save mode is activated, you may not be able to modify the settings of certain
applications.
Charge the battery
Your battery has been partially charged at the factory, but you may need to
recharge it before you can switch on your device for the first time.
If the device indicates a low charge, do the following:
1. Connect the charger to the device.
2. Connect the charger to the power supply.
You do not need to charge the battery for a specific length of time, and you can
use the device while it is charging.
If the battery is completely discharged, it may take several minutes before the
charging indicator appears on the display or before any calls can be made.
If the battery has not been used for a long time, to begin charging, you may need
to connect the charger, then disconnect and reconnect it.
Tip: You can also use a compatible USB charger to charge your battery.
Getting started
© 2010 Nokia. All rights reserved. 13
DRAFT
RM-659 03 Aug 2010

Charge the battery over USB
Battery low, but you don't have a charger with you? You can use a compatible USB
cable to connect to a compatible device, such as a computer.
To avoid breaking the charger connector, be careful when connecting or
disconnecting the charger cable.
If connected to a computer, you can synchronise your
device while charging.
Charging over USB can take longer to start, and may
not work if you connect through a non-powered USB
hub. Your device charges more quickly when
connected to a wall outlet.
When the battery is charging, the charging indicator
light next to the USB connector is lit. When the battery
charge is low, the charging indicator light flashes. It
may take a while for charging to start.
If your device stops responding
Restart your device. Press and hold for about 8 seconds. The device vibrates
three times and switches off. To switch your device on again, press .
No content is deleted when you restart your device.
Switch the device on or off
Press and hold .
Getting started
© 2010 Nokia. All rights reserved.14
DRAFT
RM-659 03 Aug 2010

Nokia account and Ovi services
When you switch on your device for the first time, you are prompted to create or
sign on to a Nokia account, so you can access Ovi services.
With Ovi services, you can:
●See status updates from social networking services
●Download mobile games, applications, videos, pictures, themes, and ringing
tones from Ovi Store
●Synchronise your favourite locations from your device to the Ovi Maps internet
service
To learn more about Ovi services, go to www.ovi.com.
To create a Nokia account later, use your device to access an Ovi service, and you
are prompted to create an account.
Copy contacts or pictures from your old device
Want to copy important information from your previous compatible Nokia device
and start using your new device quickly? Use the Phone switch application to copy,
for example, contacts, calendar entries, and pictures to your new device, free of
charge.
Select Menu > Applications > Tools > Phone setup and Data transfer.
Getting started
© 2010 Nokia. All rights reserved. 15
DRAFT
RM-659 03 Aug 2010

If your old Nokia device does not have the Phone
switch application, your new device sends it in a
message. Open the message in the old device, and
follow the instructions.
1. Select the device you want to connect to, and pair
the devices. Bluetooth needs to be activated.
2. If the other device requires a passcode, enter the
passcode. The passcode, which you can define
yourself, must be entered in both devices. The
passcode in some devices is fixed. For details, see
the user guide of the device.
The passcode is valid only for the current
connection.
3. Select the content and OK.
Device set-up
To define some basic settings for your device, select the Phone set-up widget
which is on one of your home screens. To switch between home screens, swipe
left or right. With the Phone set-up widget, you can do the following:
●Copy contacts, pictures, and other content from your previous Nokia device
●Personalise your device, by changing the ringing tone and visual theme
●Set up mail
●Update your device software
To define the settings later, you can also select Menu > Applications > Tools >
Phone setup.
Use the in-device user guide
Select Menu > Applications > User guide.
Open the user guide from an application — Select Options > User guide. This
is not available for every application.
Search the user guide — When the user guide is open, select Options >
Search, and enter a letter or a word in the search field.
Getting started
© 2010 Nokia. All rights reserved.16
DRAFT
RM-659 03 Aug 2010

Switch between the user guide and an application — Press and hold the menu
key, swipe left or right, and select the desired application.
Links to related topics may be at the end of instructions. indicates a link to a
related topic, and indicates a link to a web page.
Install Nokia Ovi Suite on your PC
With the Nokia Ovi Suite PC application, you can manage content on your device,
and keep it in sync with your computer. You can also update your device with the
latest software, and download maps.
Download the latest version of Nokia Ovi Suite from www.ovi.com/suite.
If you cannot connect to the internet, to install Ovi Suite and Nokia Ovi Player from
your device:
1. Use a compatible USB data cable to connect your device to your computer.
If you are using Windows XP or Windows Vista on your computer, set the USB
mode of your device to Mass storage. On your device, select the notification
area in the top right corner, and select > USB > Mass storage.
Your memory card appears as a removable disk on your PC.
2. On your computer, select Install Nokia Ovi Suite.
If the installation window does not open automatically,
open the installation file manually. Select Open folder
to view files, and double-click
Install_Nokia_Ovi_Suite.exe.
Install Nokia Ovi Suite on your PC
© 2010 Nokia. All rights reserved. 17
DRAFT
RM-659 03 Aug 2010

3. Follow the instructions.
4. When the installation is complete, if you are using
Windows XP or Windows Vista on your computer,
set the USB mode of your device to Media
transfer. On your device, select the notification
area in the top right corner, and select > USB > Media transfer.
To learn more about Ovi Suite, go to www.ovi.com.
Touch screen actions
To interact with the user interface, tap or tap and hold the touch screen.
Open an application or other screen element — Tap the application or element.
Access functions quickly — Tap and hold the item. A pop-up menu with available
options opens. For example, to send an image or delete an alarm, tap and hold the
image or alarm, and from the pop-up menu, select the appropriate option. If you
Touch screen actions
© 2010 Nokia. All rights reserved.18
DRAFT
RM-659 03 Aug 2010

tap and hold the home screen, editing mode is activated.
Drag an item — Tap and hold the item, and slide your
finger across the screen. The item follows your finger. You
can drag items in the home screen or the main menu,
when you have activated editing mode.
Swipe — Place a finger on the screen, and steadily slide
your finger in the desired direction. For example, when
you are viewing a picture, to view the next picture, swipe
left.
Scroll in a list or menu — If the list has a scroll bar,
drag the scroll bar slider. Or place your finger on the
screen, slide it quickly up or down the screen, then
lift your finger. The content of the screen scrolls with
the speed and direction it had at the moment of
release. To select an item from a scrolling list and to
stop the movement, tap the item.
Zoom in — Place two fingers on an item, such as a
picture or web page, and slide your fingers apart.
Zoom out — Place two fingers on the item, and slide
your fingers together.
Touch screen actions
© 2010 Nokia. All rights reserved. 19
DRAFT
RM-659 03 Aug 2010

Interactive home screen
elements
The home screen elements are interactive. For example, you can change the date
and time, set alarms, write calendar entries, or edit the profiles directly in the home
screen.
Set an alarm — Select the clock (1).
Activate or edit profiles — Select the profile (2).
View or edit your schedule — Select the date (3).
View available WLANs or missed events — Select the notification area (4).
Modify the connectivity settings — Select the notification area (4) and .
In most other views, you can select the notification area (4), and do the following:
●Modify the connectivity settings.
●Open the Clock application, and set an alarm.
●View the battery status, and activate power saving mode.
●View notifications of missed calls or received messages.
●Open the WLAN wizard, and connect to a WLAN.
Call a phone number
1. In the home screen, select Call to open the dialler, and enter the phone number.
Interactive home screen elements
© 2010 Nokia. All rights reserved.20
DRAFT
RM-659 03 Aug 2010
