Nokia 130 2017 User manual

Nokia 130 (2017)
User Guide
Issue 2023-06-23 en-IL

Nokia 130 (2017) User Guide
Table of Contents
1 About this user guide 5
2 Get started 6
Keysandparts.......................................... 6
Setupandswitchonyourphone................................ 7
Chargeyourphone ....................................... 10
Lockorunlockthekeys..................................... 10
3 Basics 11
Get the most out of the two SIM cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Exploreyourphone ....................................... 11
Changethevolume ....................................... 15
Change your ring or message tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Changethewallpaper...................................... 16
Writetext............................................. 16
4 Calls, contacts, and messages 17
Calls................................................ 17
Contacts ............................................. 17
Sendandreceivemessages .................................. 18
5 Personalize your phone 19
Change your ring or message tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Change the look of your home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Profiles .............................................. 20
SettingsforGoto ........................................ 20
6 Camera 22
Photos .............................................. 22
Videos............................................... 22
© 2023 HMD Global Oy. All rights reserved. 2

Nokia 130 (2017) User Guide
7 Music and videos 23
Musicplayer ........................................... 23
Videoplayer ........................................... 23
8 Radio 24
Findandsaveradiostations .................................. 24
Listentoradio .......................................... 24
9 Clock, calendar, and calculator 25
Setthetimeanddatemanually ................................ 25
Alarmclock............................................ 25
Calendar ............................................. 25
Calculator............................................. 26
10 Bluetooth 27
ActivateBluetooth........................................ 27
UseSlam ............................................. 27
11 Copy and remove content 28
Copycontent........................................... 28
Remove private content from your phone . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Restorefactorysettings .................................... 29
12 Settings 30
Callsettings ........................................... 30
Phonesettings.......................................... 30
Enhancements.......................................... 30
Securitysettings......................................... 30
Messagesettings ........................................ 31
© 2023 HMD Global Oy. All rights reserved. 3

Nokia 130 (2017) User Guide
13 Product and safety information 32
Foryoursafety.......................................... 32
Networkservicesandcosts................................... 34
Emergencycalls ......................................... 34
Takecareofyourdevice .................................... 35
Recycle .............................................. 36
Crossed-out wheelie bin symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Battery and charger information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Smallchildren .......................................... 37
Medicaldevices ......................................... 37
Implantedmedicaldevices ................................... 38
Hearing .............................................. 38
Protect your device from harmful content . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Vehicles.............................................. 39
Potentially explosive environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Certification information (SAR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Copyrightsandothernotices ................................. 40
About Digital Rights Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
© 2023 HMD Global Oy. All rights reserved. 4

Nokia 130 (2017) User Guide
1 About this user guide
Important: For important information on the safe use of your device and battery, read
“Product and safety information” before you take the device into use. To find out how to
get started with your new device, read the user guide.
© 2023 HMD Global Oy. All rights reserved. 5

Nokia 130 (2017) User Guide
2 Get started
KEYS AND PARTS
Explore the keys and parts of your new phone.
Your phone
The keys and parts of your phone are:
1. Charger connector
2. Earpiece
3. Selection key
4. Function key, call key
5. Microphone
6. Function key, end call/power key
7. Headphone connector
8. Flash light
9. Camera
10. Loudspeaker
11. Antenna area
12. Back cover opening slot
To lock the keys, select Go to > Lock keypad .
To unlock the keys, quickly press , and select Unlock .
To quickly switch the flash light on, in the idle screen, press the scroll key up twice. To switch
the light off, press the scroll key up once more. Do not shine the light in anyone’s eyes.
Avoid touching the antenna area while the antenna is in use. Contact with antennas affects the
communication quality and may reduce battery life due to higher power level during operation.
Do not connect to products that create an output signal, as this may damage the device. Do
not connect any voltage source to the audio connector. If you connect an external device
or headset, other than those approved for use with this device, to the audio connector, pay
special attention to volume levels.
© 2023 HMD Global Oy. All rights reserved. 6

Nokia 130 (2017) User Guide
Parts of the device are magnetic. Metallic materials may be attracted to the device. Do not
place credit cards or other magnetic storage media near the device, because info stored on
them may be erased.
Some of the accessories mentioned in this user guide, such as charger, headset, or data cable,
may be sold separately.
Note: You can set the phone to ask for a security code. The pre-set code is 12345. Change
it to protect your privacy and personal data. Note, however, that when you change the code,
you need to remember the new code, as HMD Global is not able to open or bypass it.
SET UP AND SWITCH ON YOUR PHONE
Learn how to insert the SIM card, memory card, and battery, and how to switch on your phone.
Mini SIM
Important: This device is designed to be used with a mini SIM card only. Use of incompatible
SIM cards may damage the card or the device, and may corrupt data stored on the card.
Note: Switch the device off and disconnect the charger and any other device before removing
any covers. Avoid touching electronic components while changing any covers. Always store
and use the device with any covers attached.
© 2023 HMD Global Oy. All rights reserved. 7

Nokia 130 (2017) User Guide
Set up your phone (single SIM)
1. Place your fingernail in the small slot at the
bottom of the phone, lift and remove the
cover.
2. If the battery is in the phone, lift it out.
3. Slide the SIM into the SIM slot with the
contact area face down.
4. If you have a memory card, slide the
memory card into the memory card slot.
5. Line up the battery contacts, and put the
battery in.
6. Replace the back cover.
© 2023 HMD Global Oy. All rights reserved. 8

Nokia 130 (2017) User Guide
Set up your phone (dual SIM)
1. Place your fingernail in the small slot at the
bottom of the phone, lift and remove the
cover.
2. If the battery is in the phone, lift it out.
3. Slide the first SIM into SIM slot 1 with the
contact area face down. Slide the second
SIM into SIM slot 2. Both SIM cards are
available at the same time when the device
is not being used, but while one SIM card
is active, for example, making a call, the
other may be unavailable.
4. If you have a memory card, slide the
memory card into the memory card slot.
5. Line up the battery contacts, and put the
battery in.
6. Replace the back cover.
Switch on your phone
Press and hold .
Remove the SIM card
Open the back cover, remove the battery, and slide the SIM out.
© 2023 HMD Global Oy. All rights reserved. 9

Nokia 130 (2017) User Guide
Remove the memory card
Open the back cover, remove the battery, and pull the memory card out.
CHARGE YOUR PHONE
Your battery has been partially charged at the factory, but you may need to recharge it before
you can use your phone.
Charge the battery
1. Plug the charger into a wall outlet.
2. Connect the charger to the phone. When done, unplug the charger from the phone, then
from the wall outlet.
If the battery is completely discharged, it may take several minutes before the charging
indicator is displayed.
Tip: You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly, and it
may take a long time for charging to start and the device to start functioning. Make sure your
computer is switched on.
LOCK OR UNLOCK THE KEYS
Lock the keypad
To avoid accidentally pressing the keys, use keypad lock. Select Go to > Lock keypad .
Unlock the keypad
Press , and select Unlock .
© 2023 HMD Global Oy. All rights reserved. 10

Nokia 130 (2017) User Guide
3 Basics
GET THE MOST OUT OF THE TWO SIM CARDS
Your phone can use two SIM cards, and you can use them for different purposes.
Select which SIM card to use
1. Select Menu > > Dual SIM settings .
2. To choose which SIM to use for calls, select Default SIM for calls , and select
Ask every time , or SIM1 , or SIM2 .
3. To choose which SIM to use for messages, select Default SIM for msgs , and select
Ask every time , or SIM1 , or SIM2 .
You can set which SIM you want to use in standby mode, too, and assign a name to both SIMs.
EXPLORE YOUR PHONE
See the apps and features of your phone
Select Menu .
© 2023 HMD Global Oy. All rights reserved. 11

Nokia 130 (2017) User Guide
Go to an app or feature
Press the scroll key up, down, left, or right.
Open an app or select a feature
Select Choose .
© 2023 HMD Global Oy. All rights reserved. 12

Nokia 130 (2017) User Guide
Go back to the previous view
Select Back .
Go back to the home screen
Press the end key.
© 2023 HMD Global Oy. All rights reserved. 13

Nokia 130 (2017) User Guide
Switch on the flashlight
On the idle screen, quickly scroll up twice to switch on the flashligt.
To switch off the flashlight, scroll up once.
Do not shine the light in anyone’s eyes.
© 2023 HMD Global Oy. All rights reserved. 14

Nokia 130 (2017) User Guide
CHANGE THE VOLUME
Turn the volume up or down
Trouble hearing your phone ringing in noisy environments, or calls too loud? You can change
the volume to your liking.
Scroll up or down to change the volume during a call or when listening to the radio.
CHANGE YOUR RING OR MESSAGE TONE
You can choose a new ringtone or message tone.
Change your ringtone
1. Select Menu > > Tone settings .
2. Choose Ringing tone .
3. Scroll to a ringtone.
4. Press OK .
Tip: Is your ringtone too loud or too silent? Select Ringing volume and scroll left or right.
© 2023 HMD Global Oy. All rights reserved. 15

Nokia 130 (2017) User Guide
Change your message tones
1. Select Menu > > Tone settings .
2. Scroll to a Message alert tone .
3. Select the tone you want to use and select OK .
CHANGE THE WALLPAPER
Choose a new wallpaper
You can change the background of your home screen with Wallpaper setting.
1. Select Menu > > Display settings > Wallpaper .
2. Select the wallpaper, and then the option to position the wallpaper on the screen.
WRITE TEXT
Write using the keypad
Writing with the keypad is easy and fun.
Press a key repeatedly until the letter is shown.
To type in a space press 0 .
To type in a special character or punctuation mark, press * .
To switch between character cases, press # repeatedly.
To type in a number, press and hold a number key.
© 2023 HMD Global Oy. All rights reserved. 16

Nokia 130 (2017) User Guide
4 Calls, contacts, and messages
CALLS
Make a call
Learn how to make a call with your new phone.
1. Type in the phone number. To type in the + character, used for international calls, press *
twice.
2. Press the call key. If asked, select which SIM to use.
3. To end the call, press the end key.
Answer a call
Press .
Tip: If you are in a situation where you cannot answer the phone and you need to silence it
quickly, select Silence .
CONTACTS
Add a contact
Save and organize your friends’ phone numbers.
1. Select Menu > > Add contact .
2. Select where you want to save it, on Phone or SIM card
3. Write the name, and type in the number.
4. Select OK .
Tip: To save a phone number in the dialer, type in the number, and select Opt. > Save .
© 2023 HMD Global Oy. All rights reserved. 17

Nokia 130 (2017) User Guide
Save a contact from call log
You can save contacts from call log.
1. Select Menu > > Received or Missed , depending on from where you want to save the
contact.
2. Highlight the number you want to save, and select Options > Save .
3. Add the contact’s name and Save .
Call a contact
You can call a contact directly from the contacts list.
1. Select Menu > > Names and scroll to a contact you want to call.
2. Select the contact and press the call key.
SEND AND RECEIVE MESSAGES
Write and send messages
1. Select Menu > > Create message .
2. Write a message on the message field.
3. Select Opt. > Send , to add a recipient. You can enter a phone number or add a recipient
by selecting Search to open Contacts .
4. Select Send .
Writing options
You can find different options for writing a message, in Options when you are in the message
field. You can, for example, insert symbols, and save or discard messages.
You can also turn on the predictive text (dictionary) from Options .
Message options
When you have received messages in your phone, open a message and select Options . Scroll
to Use number , and select Opt. > Call to call the sender. You can delete conversations, and
add the sender to a screened list.
© 2023 HMD Global Oy. All rights reserved. 18

Nokia 130 (2017) User Guide
5 Personalize your phone
CHANGE YOUR RING OR MESSAGE TONE
You can choose a new ringtone or message tone.
Change your ringtone
1. Select Menu > > Tone settings .
2. Choose Ringing tone .
3. Scroll to a ringtone.
4. Press OK .
Tip: Is your ringtone too loud or too silent? Select Ringing volume and scroll left or right.
Change your message tones
1. Select Menu > > Tone settings .
2. Scroll to a Message alert tone .
3. Select the tone you want to use and select OK .
CHANGE THE LOOK OF YOUR HOME SCREEN
Change the look of your home screen with display settings.
Choose a new wallpaper
You can change the background of your home screen with Wallpaper setting.
1. Select Menu > > Display settings > Wallpaper .
2. Select the wallpaper, and then the option to position the wallpaper on the screen.
© 2023 HMD Global Oy. All rights reserved. 19

Nokia 130 (2017) User Guide
Show date and time
You can choose if you want to see date and time on the home screen of your phone.
1. Select Menu > > Time settings > Display of time and date .
2. Select Show clock to have them visible on the home screen.
If you want your phone to have time updated automatically, set Auto-update of date and time
to On .
PROFILES
Your phone has different profiles for different situations. You can edit the profiles to your
liking.
Personalize profiles
There are several profiles that you can use in different situations. There is, for example, a
silent profile for when you cannot have sounds on, and an outdoor profile with loud tones.
You can personalize profiles further.
1. Select Menu > > Profiles .
2. Select a profile and Personalise .
For each profile you can set a specific ringtone, ringtone volume, message sounds and so on.
Tip: You can add different profiles to Go to menu for quick access.
SETTINGS FOR GO TO
You can add quick links to different applications and settings to Go to .
© 2023 HMD Global Oy. All rights reserved. 20
