STANDARD INSTALLATION MANUAL
NORDIC HVLS FAN SERIES
ENGLISH
Vers. 1.0

2
The Nordic Fan Company ApS
Contents
General Safety Information, Pre- installation checks ...................................................................... 3
What’s in the box?........................................................................................................................... 4
Required Tools & accessories, Standard Mounting ........................................................................ 5
Standard Installation Process .......................................................................................................... 6
Mounting & securing safety wire .................................................................................................... 7
Mounting the Air Blades ................................................................................................................. 8
Connecting Power & Controller...................................................................................................... 9
Configuring the Controller............................................................................................................ 10
Controlling your NORDICTM fan .................................................................................................... 11
Download other Guides................................................................................................................ 11
The NORDICTM HVLS Fan Series is a
230V/50Hz ‘Plug & Play’ solution. It is
the ideal choice for providing year-round
comfort in air circulation and de-strat-
ification applications. Featuring an
aerodynamic air blade design and a high
efficiency direct drive motor, the
NORDIC HVLS Fan Series delivers
maximum airflow at a fraction of the
operating cost of other HVLS fans. With
its universally designed ceiling mount it is
optimised for simple plug-and-play instal-
lations, making it the easiest HVLS fan to
install on the market.
NORDIC HVLS Series
INSTALLATION INFO:
Installation can be performed by a single person and is
estimated to take between 2 to 4 hours per system

3
The Nordic Fan Company ApS
1. Verify that the fan is to be installed in a location where the airblades will be a minimum of 3,0 meters above the finished floor with
a minimum of 1,2 meter of clearance to any obstructions.
2. If the building has a mezzanine or other elevated spaces that may be occupied by people, verify that no component of the fan can
be reached from the highest level or deck. The fan must be positioned so that the tips of the airblades are a minimum of 1,2 meter
away from the furthest point that a person could extend an appendage outward.
3. Check that the fan will not be mounted in a location near overhead doors or other building openings where gusts of wind may
occur. Fans should not be installed or operated in locations where wind is present.
4. If the building is equipped with a fire sprinkler system, verify that the placement of the fan will not interfere with correct sprinkler
operation and that the fan installation complies with all building codes.
5. Check to see if the intended placement of the fan is directly below any building lights or skylights. If possible, avoid installing fans
directly below a light source to prevent a strobing effect that can be caused by fan rotation.
6. For best performance, the fan must be installed with a two-fan diameter minimum clearance to radiant heaters and HVAC system
discharges or intakes.
7. BEFORE INSTALLATION, IT IS IMPORTANT TO VERIFY THE MOUNTING SURFACE WILL BEAR THE OPERATING WEIGHT
AND MAXIMUM TORQUE (TWISTING FORCE) OF THE TO-BE-INSTALLED NORDIC™ SYSTEM. IT IS THE SOLE RESPON-
SIBILITY OF THE INSTALLER TO ENSURE THAT THE MOUNTING STRUCTURE AND FAN INSTALLATION METHOD ARE
ADEQUATE FOR SAFE OPERATION OF THE NORDIC™ FAN.
MAX TORQUE PER NORDIC™ FAN SIZE
Fan size (meter) 1,8 2,4 3,1 3,7 4,3
Max. torque (Nm) 8,4 13,0 28,2 43,1 54,8
8. THE FIXING MEANS FOR THE ATTACHMENT TO THE CEILING SHALL BE FIXED WITH A SUFFICIENT STRENGTH TO WITH-
STAND FOUR (4) TIMES THE WEIGHT OF THE SPECIFIC NORDIC™ CEILING FAN (SEE ALSO TABLE BELOW).
NORDIC™ SYSTEM F13-1,8M F13-2,4M F13-3,1M F13-3,7M F13-4,3M
HANGING WEIGHT 31kg 34kg 37kg 39kg 41kg
9. INSTALLATION AND MAINTENANCE ARE TO BE PERFORMED BY QUALIFIED PERSONNEL ONLY, FAMILIAR WITH
LOCAL REGULATIONS AND EXPERIENCED WITH THIS TYPE OF EQUIPMENT.
Pre-installation checks
To reduce the risk of fire, electric shock, or injury to persons, observe the following:
1. Use this unit only in the manner intended by the manufacturer. If you have questions, contact the Nordic Fan Company or its
representative.
2. Before servicing or cleaning the unit, switch power off at service panel and lock the service disconnecting means to prevent
power from being switched on accidentally.
3. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and stan-
dards.
4. DO NOT ALLOW WATER OR SOLVENTS TO ENTER THE MOTOR OR THE DRIVE. UNDER NO CIRCUMSTANCES SHOULD
MOTORS OR DRIVES BE SPRAYED WITH STEAM, WATER OR SOLVENTS.
5. It is highly recommended that an emergency disconnect switch is installed between each NORDIC™ fan and the electrical mains.
Ensure that such a switch is NOT located directly above air blades, so that it can be accessed at all times - even when fan is operating.
General Safety Information
WARNING
IMPORTANT: Consult all applicable rule and codes to ensure that all necessary requirements are met. It is the sole responsibil-
ity of the installer to ensure compliance with applicable codes.

4
The Nordic Fan Company ApS
what’s in the box?
1
2
3
4
5
6
7
8
9
10
10
11
11
12
13
12
9
8
7
6
4
3
2
Swivel Mount
Drop Tube
Drive and Onboard Electronics
Motor
Controller
Starfish Blade Hub
1,5m CAT 5E Cable with RJ45 Plug
1,5m 3 x 1,5mm 230V Powercord
Mount Cover
Anodized Aluminum Air Blades
Safety Wire
Safetywire Lock (Gripple)
Required screws and bolts
5
SCREWS FOR CONCRETE
MOUNTING
4 pcs. HUS3-H 6x80 mm.
SCREWS FOR WOOD
MOUNTING
4 pcs. 6x100 mm.
BOLTS FOR STEEL
MOUNTING
4 pcs. 6x25 mm.
4 washers, 4 locknuts
BOLTS FOR MOUNTING
AIR BLADES
8 pcs. 6x20 mm. 8 tooth
washers, 4 locknuts, 4 capnuts
BOLTS FOR MOUNTING
SWIVEL TO DROP TUBE
2 pcs. 10x70 mm.
4 washers, 2 locknuts
13
DRILL BIT 5MM HSS NO DRILL BIT NEEDED DRILL BIT 6MM HSS NO DRILL BIT NEEDED NO DRILL BIT NEEDED
1

5
The Nordic Fan Company ApS
required Tools & accessories
10,13 & 17 MM
WRENCH
LEVEL DRILL PHILLIPS
SCREWDRIVER
SLOTTED
SCREWDRIVER
SOCKET
WRENCH
3 X 1,5MM 230V
POWERCORD
CAT 5E CABLE
LIFT OR
SCAFFOLDING
STANDARD MOunting
4 & 14 MM
ALLEN KEY
Using the swivel mount, the NORDICTM FAN SYSTEM can be
mounted directly on to standard I and H steel beams, wood
beams and concrete beams. This is done using relevant bolts
and screws as shown on page 4 and explained on page 6.
For installations using the optional mounting brackets or guy
wires, please refer to the manual: ‘INSTALLATION MANUAL
- EXTRA MOUNTING OPTIONS’ which can also be accessed
from www.nordicfancompany.com/manuals
Before performing a standard installation, please check that
the mounting beam has sufficient width to accomodate the
Swivel Mount.
If this is not the case, the extra mounting options can be
used, as explained in the manual: ‘INSTALLATION MANUAL -
EXTRA MOUNTING OPTIONS’.
10,13 & 17 MM
WRENCH SOCKET
SWIVEL MOUNT DIMENSIONS
 
 






14,6 cm
10,0 cm
8,0 cm
12,0 cm

6
The Nordic Fan Company ApS
Standard Installation process
Attach the fan assembly to the swivel
mount via the drop tube using bolts
specied on page 4 and fasten securely.
Fasten the swivel mount to the moun-
ting surface using screws (concrete and
wood) or bolts (steel).
Tighten thoroughly.
Pull safety wire, power cord and CAT
5E cable through designated hole.
Using the swivel mount as a template,
drill required holes in the mounting
beam (wood beams do not require
pre-drilling of holes) using the drill bit
specied on page 4.
Please note the difference between
drill bits and designated screws for
concrete, wood or steel mounting.
Secure safety wire around mounting
beam.
IMPORTANT: follow steps on page 7.
Push the mount cover up and twist to
lock in place by the two small screws as
shown above.
4 5
1 2 3
NOTE: IF YOU CANNOT INSTALL DIRECTLY ON THE MOUNTING SURFACE, YOU CAN USE THE ADDITIONAL MOUNTING
OPTIONS as expained in the manual ‘INSTALLATION MANUAL - EXTRA MOUNTING OPTIONS’.

7
The Nordic Fan Company ApS
Mounting & securing safety wire
Insert wire in
A
-follow arrow direction
Tighten wire. Cut or organize excess wire to ensure it does not interfere with fan performance.
Pull wire through
B
Pull wire around mounting beam,
and insert wire in
C
- follow arrow direction
A
B
C
NOTE: THE SAFETY WIRE MUST BE INSTALLED. THIS WILL PREVENT
THE FAN FROM FALLING IN THE UNLIKELY EVENT THAT THE MOUN-
TING SYSTEM SHOULD FAIL. THE FAN SHOULD NEVER BE OPERATED
WITHOUT A PROPERLY INSTALLED SAFETY WIRE, AS THIS COULD
RESULT IN DEATH, SERIOUS INJURY OR ASSET DAMAGE. FAILURE TO
INSTALL SAFETY WIRE WILL RESULT IN VOIDING OF THE FAN WAR-
RANTY.

8
The Nordic Fan Company ApS
Mounting the air blades
Slide air blade onto the starsh hub.
Air blade view from above.
Ensure air blade holes are directly over
the starsh holes.
Air blade view from below
Secure air blade using screws, bolts
and tools as specied on page 4.
1 2 3
CORRECT POSITIONING OF THE SCREWS
NOTE: Before mounting the air blades, ensure the fan is vertically and horizontally level.
IMPORTANT: Do not operate the fan without the air blades mounted, as this may damage the
motor and the motor drive.
NOTE: BE SURE TO NOTE THE DIFFERENCE BETWEEN
THE INNER AND OUTER SETS OF SCREWS FOR MOUN-
TING OF THE AIR BLADES.
CHECK: ROTATE THE FAN BY HAND TO ENSURE THAT
IT ROTATES FREELY AND DOES NOT COME INTO CON-
TACT WITH ANY OBSTRUCTIONS.
IMPORTANT: IF AIR BLADES MUST BE REMOVED AND
RE-INSTALLED FOR ANY REASON, DO NOT RE-USE THE
SAME LOCKNUTS AS RE-USE INCREASES THE RISK OF
LOCKNUTS LOOSENING.

9
The Nordic Fan Company ApS
Connecting power & controller
1
3
2
MOUNT CONTROLLER ON
THE WALL
CONNECT THE POWER PLUG TO THE POWER
CORD. THEN CONNECT TO 230V SINGLE PHASE
POWER SUPPLY, USING EXTRA POWER CORD AS
NEEDED.
CONNECT THE CONTROLLER WITH
THE FAN USING A CAT 5E CABLE
IMPORTANT:
DO NOT CONNECT THE CAT
5E CABLE TO ANYTHING
OTHER THAN THE NORDIC
CONTROLLER BOX.
DOING SO WILL SEVERELY
DAMAGE THE FAN MOTOR
AND DRIVE AND MAY
POTENTIALLY CAUSE A
MOTOR FAULT

10
The Nordic Fan Company ApS
Configuring the controller
The home screen
will automatically
appear. To go to fan
settings, press this
button and hold for
4 seconds.
You are now in Bla-
de Length settings.
As a standard, the
blade length is set
to 1,8 meters, as in-
dicated by the star.
Press the shift but-
ton to change blade
length setting. Con-
tinue until you reach
the correct fan size.
A star will appear
when the blade
length size is cor-
rectly chosen and
saved.
Press once to return
to home screen.
When connecting
the controller using
the CAT 5E cable,
this screen will
appear after a few
moments.
This screen indi-
cates that a fan is
found and is only
shown briey.
When this screen
appears, you are in
Fan Settings mode.
Press once on the
‘arrow down’ button.
When you reach
the correct fan size
press the on/off
button to save.
1
3
4 5
4
2
THE FAN IS NOW CONFIGURED AND
READY FOR USE
Before use, please perform an initial security check of the fan
on a secure distance by slowly increasing speed by pressing the
arrow “up” one speed level at a time. If any shaking, vibrations,
or similar appears, decrease speed immediately and make the
fan come to a complete stop. Go back and make sure all instal-
lation steps were performed correctly and make any necessary
adjustments. Perform a second check, and if any anormalities
persist, please turn off fan and contact your local support ofce.
ENJOY!

11
The Nordic Fan Company ApS
controlling your nordictm fan
Other manuals, such as Advanced User Guides for setting up fan
networking mode and integrating fans to a building management
system etc. can be downloaded from our website:
www.nordicfancompany.com/manuals
Address
The Nordic Fan Company ApS
Snaremosevej 192A
7000 Fredericia
Denmark
contact
[phone]
[e-mail]
www.nordicfancompany.com
Download
DIRECTION
--> Forward
<-- Reverse
USER DISPLAY
INCREASE
SPEED
DECREASE
SPEED
ON/OFF
