USER'S MANUAL
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
Serial Number Decal
Model No. NTTL11511
Serial No.
Find the serial number in the location
shown below. Write the serial number
in the space above for reference.
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.–Fri., 6 a.m.–6 p.m. MST
Patent Pending

TABLE OF CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
OPERATION AND ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
TROUBLE-SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
CONDITIONING GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
PART LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Back Cover
Note: An EXPLODED DRAWING is attached in the center of this manual.
2
NordicTrack is a registered trademark of ICON Health & Fitness, Inc.

3
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Use the treadmill only as described in this
manual.
3. Place the treadmill on a level surface, with at
least eight feet of clearance behind it. Do not
place the treadmill on any surface that blocks
air openings. To protect the floor or carpet
from damage, place a mat under the treadmill.
4. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
5. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
6. Keep children under the age of 12 and pets
away from the treadmill at all times.
7. The treadmill should not be used by persons
weighing more than 250 pounds.
8. Never allow more than one person on the
treadmill at a time.
9. Wear appropriate exercise clothing when
using the treadmill. Do not wear loose cloth-
ing that could become caught in the treadmill.
Athletic support clothes are recommended for
both men and women. Always wear athletic
shoes. Never use the treadmill with bare feet,
wearing only stockings, or in sandals.
10. When connecting the power cord (see page 8),
plug the power cord into a surge suppressor
(not included) and plug the surge suppressor
into a grounded circuit capable of carrying 15
or more amps. No other appliance should be on
the same circuit. Do not use an extension cord.
11. Use only a single-outlet surge suppressor that
is UL 1449 listed as a transient voltage surge
suppressor (TVSS). The surge suppressor
must have a UL suppressed voltage rating of
400 volts or less and a minimum surge dissi-
pation of 450 joules. The surge suppressor
must be electrically rated for 120 volts AC and
15 amps. To purchase a surge suppressor, see
your local NordicTrack dealer or call 1-888-
825-2588 and order part number 146148.
12. Keep the power cord and the surge suppres-
sor away from heated surfaces.
13. Never move the walking belt while the power
is turned off. Do not operate the treadmill if
the power cord or plug is damaged, or if the
treadmill is not working properly. (See
BEFORE YOU BEGIN on page 5 if the tread-
mill is not working properly.)
14. Never start the treadmill while you are stand-
ing on the walking belt. Always hold the
handrails while using the treadmill.
15. The treadmill is capable of high speeds.
Adjust the speed in small increments to avoid
sudden jumps in speed.
16. The pulse sensor is not a medical device.
Various factors, including the user's move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
17. Never leave the treadmill unattended while it
is running. Always remove the key, unplug
the power cord and move the on/off switch to
the off position when the treadmill is not in
use. (See the drawing on page 5 for the loca-
tion of the on/off switch.)
18. Do not attempt to raise, lower, or move the
treadmill until it is properly assembled. (See
ASSEMBLY on page 6, and HOW TO FOLD
AND MOVE THE TREADMILL on page 22.) You
must be able to safely lift 45 pounds (20 kg) in
order to raise, lower, or move the treadmill.
19. Do not change the incline of the treadmill by
placing objects under the treadmill.
20. When folding or moving the treadmill, make
sure that the storage latch is fully closed.
WARNING:To reduce the risk of burns, fire, electric shock, or injury to persons, read the
following important precautions and information before operating the treadmill.
IMPORTANT PRECAUTIONS

21. When using iFIT.com CDs and videos, an
electronic “chirping” sound will alert you
when the speed and/or incline of the treadmill
is about to change. Always listen for the
“chirp” and be prepared for speed and/or in-
cline changes. In some instances, the speed
and/or incline may change before the per-
sonal trainer describes the change.
22. When using iFIT.com CDs and videos, you
can manually override the speed and incline
settings at any time by pressing the speed
and incline buttons. However, when the next
“chirp” is heard, the speed and/or incline will
change to the next settings of the CD or video
program.
23. Always remove iFIT.com CDs and videos from
your CD player or VCR when you are not
using them.
24. Inspect and tighten all parts of the treadmill
regularly.
25. Never insert or drop any object into any
opening.
26. DANGER:Always unplug the power
cord immediately after use, before cleaning
the treadmill, and before performing the main-
tenance and adjustment procedures de-
scribed in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized service
representative only.
27. This treadmill is intended for in-home use
only. Do not use this treadmill in any commer-
cial, rental, or institutional setting.
WARNING:Before beginning this or any exercise program, consult your physician. This
is especially important for persons over the age of 35 or persons with pre-existing health problems.
Read all instructions before using. ICON assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
SAVE THESE INSTRUCTIONS
The decal shown at the right has been placed on your treadmill. If the decal is
missing or illegible, please call our Customer Service Department, toll-free, to
order a free replacement decal (see ORDERING REPLACEMENT PARTS on
page 27). Apply the decal in the location shown.
Note: The decal shown at the
right is 49% of actual size.
4

Congratulations for selecting the new NordicTrack®
2500 R treadmill. The 2500 R combines advanced
technology with innovative design to help you get the
most from your workouts in the convenience of your
home. And when you’re not exercising, the unique
2500 R can be folded up, requiring less than half the
floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have questions after read-
ing the manual, please call our Customer Service
Department toll-free at 1-888-825-2588, Monday
through Friday, 6 a.m. until 6 p.m. Mountain Time (ex-
cluding holidays). To help us assist you, please note
the product model number and serial number before
calling. The model number is NTTL11511. The serial
number can be found on a decal attached to the tread-
mill (see the front cover of this manual for the location).
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEGIN
Handrail
Console
Hand Weight Holder*
Lock Knob
Book Holder
Key/Clip
Circuit Breaker
On/Off Switch
Walking Belt
Flexible Walking Platform
Foot Pad
Power Cord
Rear Roller
Adjustment Bolts
Water Bottle Holder†
Pulse Sensor
RIGHT SIDE
LEFT SIDE
*For information about optional hand
weights, see page 21.
†No water bottle is included.
5

3. Refer to drawing 3a. While another person holds the
Handrails (89), thread Handrail Bolts (111) about 1” into
the two holes in each Handrail. Then, remove the
Handrail Bolts.
Refer to drawing 3b. Pinch the tabs on the Grounding
Bracket (115) so that the tabs will fit into the indicated
hole in the left Upright (110). Then, insert the Grounding
Bracket into the hole as far as possible.
Note: It may be helpful to set the Handrails (89) on the
Uprights (110) and loosely thread a Handrail Bolt (111)
into the left Upright and the left Handrail. Tip the
Handrails, if necessary, to thread in the Bolt. Have an-
other person support the Handrails as you complete the
remaining steps.
ASSEMBLY
Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench
and your own phillips screwdriver, adjustable wrench and wire cutters .
Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a
small amount of lubricant may be transferred to the top of the treadmill or the shipping carton. This is a normal
condition and does not affect treadmill performance. If there is lubricant on top of the walking belt or foot pads,
simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
1. With the help of a second person, carefully raise the
Uprights (110) to the position shown.
Refer to the inset drawing. Insert one of the Extension
Legs (88) into the treadmill as shown. Make sure that
the Extension Leg is turned so the Thick Base Pad (90)
is on the bottom. Note: It may be helpful to tip the
Uprights (110) forward as you insert the Extension Leg.
Insert the other Extension Leg (not shown) in the same
way.
1
110
2. With the help of a second person, carefully tip the
Uprights (110) down as shown. Make sure that the
Extension Legs (88) remain in the Uprights.
Attach each Extension Leg (88) with two Base Screws
(86) and a Base Pad (75) as shown.
With the help of a second person, carefully tip the
Uprights (110) back to the vertical position.
Note: One replacement Base Pad (75) and Spacer (not
shown) may be included. If a Base Pad becomes worn
and needs to be replaced, use the replacement Base
Pad. If a Thick Base Pad (90) needs to be replaced, use
the replacement Base Pad with the Spacer.
86
88
110 110 86
88
90 90
75
90 90
75
2
90
88
110
6
110
111
111
89
115
3a
3b

7. Make sure that all parts are tightened before you use the treadmill. Keep the included allen wrench in a
secure place. The allen wrench is used to adjust the walking belt (see page 24). To protect the floor or carpet
from damage, place a mat under the treadmill.
5. Insert two Handrail Bolts (111) with Handrail Washers
(112) and Handrail Bushings (113) into the right Upright
(110) and the right Handrail Spacer (114). Turn the
Handrail Bushings so they fit against the Upright with the
thick sides of the Bushings toward the center of the tread-
mill (refer to the inset drawing). Lift the right Handrail (89)
slightly and align the Bolts with the holes in the Handrail.
Loosely thread the Bolts into the Handrail. Do not
tighten the Bolts yet.
Refer to the inset drawing. Remove the Handrail Bolt
(111) used in step 3. Place the other Handrail Spacer
(114) on the left Upright (110), with the cutout toward the
treadmill. Reach inside the left Upright (110) and spread
the tabs on the Grounding Bracket (115) to allow a Bolt to
pass through the Grounding Bracket. Attach the left
Handrail (89) as described above. Make sure that the
Handrail Bushings (113) are turned properly and that the
Bolt goes through the Grounding Bracket. Tighten all
four Handrail Bolts. Press an Upright Endcap (116) into
each Upright.
5
111
111
112
113 Thick
Side
110
115
114
116
89
89
113
112
4. Pull the Upright Wire Harness (101) up through a
Handrail Spacer (114). Place the Handrail Spacer on the
right Upright (110) as shown, with the cutout turned to-
ward the treadmill (refer to inset drawing A). Place the
other Handrail Spacer on the left Upright.
Connect the Upright Wire Harness (101) to the wires ex-
tending from the Console Base (76). Insert the connec-
tors and the Upright Wire Harness into the hole in the
Console Base (refer to inset drawing B).
Set the Handrail (89) on the Handrail Spacers (114),
being careful not to pinch the Upright Wire Harness
(101).
4
101 110
89
76
114
110
114
76
101
A
B
Cutout
7
114
6. Press the Lock Knob Sleeve (106) into the left Upright
(110).
Make sure that the Lock Pin Collar (105) and the Spring
(104) are on the Lock Pin (102). Insert the Lock Pin into
the Lock Knob Sleeve (106) and the left Upright (110).
Next, press the Lock Knob Spacer (107) onto the left
Upright. Tighten the Lock Knob (108) onto the Lock Pin.
110
107
106
108 104 105102
6

OPERATION AND ADJUSTMENT
THE PERFORMANT LUBETM WALKING BELT
Your treadmill features a walking belt coated with
PERFORMANT LUBETM, a high-performance lubricant.
IMPORTANT: Never apply silicone spray or other
substances to the walking belt or the walking plat-
form. Such substances will deteriorate the walking
belt and cause excessive wear.
HOW TO PLUG IN THE POWER CORD
Your treadmill, like any other type of sophisticated
electronic equipment, can be seriously damaged by
sudden voltage changes in your home’s power.
Voltage surges, spikes, and noise interference can
result from weather conditions or from other appliances
being turned on or off. To decrease the possibility of
your treadmill being damaged, always use a surge
suppressor with your treadmill (see drawing 1 at
the right).
To purchase a surge suppressor, see your local
NordicTrack dealer or call 1-888-825-2588 and order
part number 146148. Use only a single-outlet surge
suppressor that is UL 1449 listed as a transient voltage
surge suppressor (TVSS). The surge suppressor must
have a UL suppressed voltage rating of 400 volts or
less and a minimum surge dissipation of 450 joules.
The surge suppressor must be electrically rated for
120 volts AC and 15 amps.
This product must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. This product is equipped with a cord having
an equipment-grounding conductor and a grounding
plug. Plug the power cord into a surge suppressor,
and plug the surge suppressor into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
Important: The treadmill is not compatible with
GFCI-equipped outlets.
This product is for use on a nominal 120-volt circuit,
and has a grounding plug that looks like the plug illus-
trated in drawing 1 below. A temporary adapter that
looks like the adapter illustrated in drawing 2 may be
used to connect the surge suppressor to a 2-pole
receptacle as shown in drawing 2 if a properly
grounded outlet is not available.
The temporary adapter should be used only until a
properly grounded outlet (drawing 1) can be installed
by a qualified electrician.
The green-colored rigid ear, lug, or the like extending
from the adapter must be connected to a permanent
ground such as a properly grounded outlet box cover.
Whenever the adapter is used it must be held in place
by a metal screw. Some 2-pole receptacle outlet box
covers are not grounded. Contact a qualified elec-
trician to determine if the outlet box cover is
grounded before using an adapter.
DANGER:Improper connection
of the equipment-grounding conductor can
result in an increased risk of electric shock.
Check with a qualified electrician or service-
man if you are in doubt as to whether the
product is properly grounded. Do not modify
the plug provided with the product—if it will
not fit the outlet, have a proper outlet
installed by a qualified electrician.
1
2
Grounded Outlet Box
Grounded Outlet Box
Grounding Plug
Surge Suppressor
Surge Suppressor
Grounding Pin
Adapter
Lug
Metal Screw
Grounded Outlet
Grounding Pin
8

FEATURES OF THE CONSOLE
The advanced console offers an impressive array of
features to help you get the most from your exercise.
When the console is in the manual mode, the speed
and incline of the treadmill can be changed with a touch
of a button. As you exercise, the console will provide
continuous exercise feedback. You can even measure
your heart rate using the built-in pulse sensor.
Three preset workout programs are also offered. Each
program automatically controls the speed and incline
of the treadmill to give you an effective workout. You
can even create your own custom workout programs
and store them in memory for future use.
The console also features new iFIT.com interactive
technology. IFIT.com technology is like having a per-
sonal trainer right in your home. Using the included
audio cable, you can connect the treadmill to your
home stereo, portable stereo, or computer and play
special iFIT.com CD programs (iFIT.com CDs are avail-
able separately). IFIT.com CD programs automatically
control the speed and incline of the treadmill as a per-
sonal trainer guides you through every step of your
workout. High-energy music provides added motivation.
Each CD features two programs designed by certified
personal trainers.
In addition, you can connect the treadmill to your VCR
and TV and play iFIT.com video programs (videocas-
settes are available separately). Video programs offer
the same benefits as iFIT.com CD programs, but add
the excitement of working out with a class and an
instructor—the hottest new trend at health clubs.
With the treadmill connected to your computer, you
can also go to our Web site at www.iFIT.com and ac-
cess basic programs, audio programs, and video pro-
grams directly from the internet. Additional options are
soon to be available. See www.iFIT.com for details.
To purchase iFIT.com CDs or videocassettes, call toll-
free 1-800-735-0768. For information about an optional
chest pulse sensor, see page 21.
To use the manual mode of the console, follow the
steps beginning on page 11. To use a preset program,
see page 12. To create and use a custom program,
see pages 14 and 15. To use an iFIT.com CD or
video program, refer to page 18. To use an iFIT.com
program directly from our Web site, see page 20.
Program
Display
Pulse
Sensor Pulse
Sensor
Clip
Key
Note: If there is a thin sheet
of clear plastic on the face
of the console, remove it.
9

GETTING STARTED
Attach the clip to the waistband of your clothes.
Stand on the foot pads
of the treadmill. Find
the clip attached to the
key and slide the clip
onto the waistband of
your clothes. Next, in-
sert the key into the
console. Test the clip
by carefully taking a few steps backward until
the key is pulled from the console. If the key is
not pulled from the console, adjust the posi-
tion of the clip as needed. Then, remove the key
from the console.
Plug in the power cord.
See HOW TO PLUG IN THE POWER CORD on
page 8.
Move the on/off switch to the on position.
Locate the on/off switch
on the treadmill near the
power cord. Move the
on/off switch to the on
position.
Insert the key fully into the console.
Stand on the foot pads of the treadmill. Make sure
that the clip is securely attached to the waistband
of your clothes. Next, insert the key into the con-
sole. After a moment, various displays and indica-
tors on the console will light.
Enter your weight.
Although you can use
the console without
entering your weight, the
console will display your
calorie expenditure more
accurately if you enter
your weight. To enter your weight, press either of
the Enter Weight buttons. The current weight set-
ting will appear in the Speed/Pace display. Press
the Enter Weight buttons again to enter your
weight. A few seconds after the buttons are
pressed, the weight setting will disappear from the
display. Your weight will then be saved in memory.
Enter your age, if necessary.
Although you can use
the console without en-
tering your age, some
features on our Web site
may require you to enter
your age (see page 20).
To enter your age, press either of the Enter Age
buttons. The current age setting will
appear in the Time/Laps display. Press the Enter
Age buttons again to enter your age. A few sec-
onds after the buttons are pressed, the age setting
will disappear from the display. Your age will then
be saved in memory.
6
5
4
3
2
1
CAUTION:Before operating the
console, read the following precautions.
• Do not stand on the walking belt when turn-
ing on the power.
• Always wear the clip (see the drawing below)
while operating the treadmill.
• Adjust the speed in small increments to
avoid sudden jumps in speed.
• The pulse sensor is not a medical device.
Various factors, including the user’s move-
ment, may affect the accuracy of heart rate
readings. The pulse sensor is intended only
as an exercise aid in determining heart rate
trends in general.
• To reduce the possibility of electric shock,
keep the console dry. Avoid spilling liquids
on the console and place only a sealed water
bottle in the water bottle holder.
On
Position
Clip
10

HOW TO USE THE MANUAL MODE
Insert the key fully into the console.
See GETTING STARTED on page 10.
Select the manual mode.
When the key is in-
serted, the manual
mode will be selected
and the Manual indica-
tor will light. If a program
has been selected,
press the Select Pro-
gram button repeatedly to select the manual mode.
Press the Start button or the Speed + button to
start the walking belt.
A moment after the button is pressed, the walking
belt will begin to move at 1 mph. Hold the handrails
and begin walking. As you exercise, change the
speed of the walking
belt as desired by
pressing the Speed +
and – buttons. Each
time a button is
pressed, the speed set-
ting will change by 0.1
mph; if a button is held down, the speed setting
will change in increments of 0.5 mph. To change
the speed setting quickly, press the 1-step Speed
buttons. The speed range is 0.5 mph to 10 mph.
Note: After the buttons are pressed, it may take a
moment for the treadmill to reach the selected
speed setting.
During the first few minutes that you use the tread-
mill, inspect the alignment of the walking belt, and
align the walking belt if necessary (see page 24).
To stop the walking belt, press the Stop button.
The Time/Laps display will begin to flash. To
restart the walking belt, press the Start button or
the Speed + button.
Change the incline of the treadmill as desired.
To change the incline of
the treadmill, press the
Incline buttons. Each
time a button is
pressed, the incline will
change by 0.5%. The
incline range is 0% to 10%. Note: After the buttons
are pressed, it may take a moment for the treadmill
to reach the selected incline setting.
Follow your progress with the LED track and
the displays.
The LED track—When
the manual mode or the
iFIT.com mode is se-
lected, the program dis-
play will show an LED
track representing 1/4
mile. As you exercise, the indicators around the
track will light in sequence until you have walked or
run 1/4 mile. A new lap will then begin.
The Training Zone dis-
play—As you exercise,
the Training Zone dis-
play will show the ap-
proximate intensity level
of your exercise. For ex-
ample, if three or four indicators in the display are
lit, your intensity level is ideal for fat burning.
Time/Laps display—
When the manual mode
or the iFIT.com mode is
selected, this display will
show the elapsed time
and the number of 1/4-
mile laps you have completed. When a preset pro-
gram or a custom program is selected, the display
will show the time remaining in the program, the
time remaining in the current segment of the pro-
gram, and the number of 1/4-mile laps you have
completed. The display will change from one num-
ber to the next every few seconds, as shown by
the indicators around the display.
Distance/Incline dis-
play—This display
shows the distance that
you have walked and
the incline level of the
treadmill. The display will
change from one number to the other every few
seconds, as shown by the indicators around the
display.
Heart Rate/Calories
display—When you are
not using the handgrip
pulse sensor, this
display will show the
approximate number of
calories you have burned. When the are using the
handgrip pulse sensor or the optional chest pulse
sensor (see page 21), the display will also show
your heart rate (see step 6 on page 12).
5
4
3
2
1
Manual Indicator
11

Speed/Pace display—
This display shows the
speed of the walking
belt and your current
pace (pace is mea-
sured in minutes per
mile). The display will change from one number to
the other every few seconds, as shown by the indi-
cators around the display.
Note: The console can
display speed and dis-
tance in either miles or
kilometers. To find
which unit of measure-
ment is selected, hold
down the Stop button while inserting the key into
the console. An E, for English miles, or an M, for
metric kilometers, will appear in the Speed/Pace
display. Press the Speed + button to change the
unit of measurement. When the desired unit of
measurement is selected, remove the key and
then reinsert it. Note: For simplicity, all instructions
in this manual refer to miles.
To reset the displays, press the Stop button, re-
move the key, and then reinsert the key.
Measure your heart rate, if desired.
To measure your
heart rate, stand
on the foot pads
and place your
hands on the
metal contacts on
the handrail. Your
palms must be
resting on the
upper contacts,
and your fingers
must be touching
the lower con-
tacts—avoid
moving your hands. When your pulse is detected,
the Heart Rate indicator will flash, three dashes
(– – –) will appear in the Heart Rate/Calories dis-
play, and then your heart rate will be shown. For
the most accurate heart rate reading, continue
to hold the contacts for about 15 seconds.
When you are finished exercising, stop the
walking belt and remove the key.
Step onto the foot pads, press the Stop button,
and adjust the incline of the treadmill to the lowest
level. The incline must be at the lowest level
when the treadmill is raised to the storage po-
sition or the treadmill will be damaged. Next, re-
move the key from the console and put it in a se-
cure place. Note: If the displays and indicators
on the console remain lit after the key is re-
moved, the console is in the “demo” mode.
Refer to page 21 and turn off the demo mode.
When you are finished using the treadmill, move
the on/off switch near the power cord to the off
position and unplug the power cord.
HOW TO USE PRESET PROGRAMS
Insert the key fully into the console.
See GETTING STARTED on page 10.
Select one of the three preset programs.
When the key is inserted,
the manual mode will be
selected. To select one
of the preset programs,
press the Select Program
button repeatedly until the
Mountain Trail, Gorge
Trail, or Canyon Run indicator lights.
When you select a preset program, the program
display will show a simplified profile of the pro-
gram you have selected. For example, the profile
above shows that the intensity of the selected pro-
gram will increase during the first half of the pro-
gram, and then decrease during the last half of
the program. The Time/Laps display will show
how long the program will last.
Press the Start button or the Speed + button to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings for the program. Hold the handrails
and begin walking.
3
2
1
7
6Program Indicator
12

Each program is divided into several time seg-
ments of different lengths. The Time/Laps display
shows both the time remaining in the program and
the time remaining in the current segment. One
speed setting and one incline setting are pro-
grammed for each seg-
ment. The speed setting
for the first segment will
be shown in the flashing
Current Segment col-
umn of the program dis-
play. (The incline set-
tings are not shown in
the program display.) The speed settings for the
next five segments will be shown in the five
columns to the right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
tone will sound. In addition, if the speed and/or
incline of the treadmill is about to change, the
Speed/Pace display and/or the Distance/Incline
display will flash to alert you, and three tones will
sound. When the first segment is completed, all
speed settings will move one column to the left.
The speed setting for the second segment will
then be shown in the flashing Current Segment
column and the treadmill will automatically adjust
to the speed and incline settings for the second
segment.
The program will continue in this way until the
speed setting for the last segment is shown in the
Current Segment column and no time remains in
the Time/Laps display. The walking belt will then
slow to a stop.
Note: Each time a segment ends and the speed
settings move to the left, if all of the indicators in
the Current Segment column are lit, the speed set-
tings may move downward so that only the highest
indicators in the columns will appear in the pro-
gram display. When the speed settings move to
the left again and some indicators in the Current
Segment column are dark, the speed settings will
move back up.
If the speed or incline setting for the current
segment is too high or too low, you can manually
override the setting by pressing the Speed or
Incline buttons on the console. Every few times
one of the Speed buttons is pressed, an additional
indicator will light or darken in the Current Segment
column. If any of the columns to the right of the
Current Segment column have the same number
of lit indicators as the Current Segment column,
an additional indicator may light or darken in those
columns as well. Note: If you manually adjust the
speed setting so that all of the indicators in the
Current Segment column are lit, the speed settings
in the program display will not move downward as
described above. Note: If you manually override
the speed or incline setting for the current seg-
ment, when the segment ends the treadmill will
automatically adjust to the speed and incline
settings for the next segment.
To stop the program temporarily, press the Stop
button. The Time/Laps display will begin to flash.
To restart the program, press the Start button or
the Speed + button. To end the program, press
the Stop button, remove the key, and then reinsert
the key.
Follow your progress with the displays.
Refer to step 5 on page 11.
Measure your heart rate, if desired.
See step 6 on page 12.
When the program has ended, remove the key.
Step onto the foot pads and make sure that the in-
cline of the treadmill is at the lowest level. The in-
cline must be at the lowest level when the
treadmill is raised to the storage position. Next,
remove the key from the console and put it in a se-
cure place. Note: If the displays and indicators
on the console remain lit after the key is re-
moved, the console is in the “demo” mode.
Refer to page 21 and turn off the demo mode.
When you are finished using the treadmill, move
the on/off switch near the power cord to the off
position and unplug the power cord.
6
5
4
Current Segment
13

HOW TO CREATE CUSTOM PROGRAMS
Insert the key fully into the console.
See GETTING STARTED on page 10.
Select one of the custom programs.
When the key is in-
serted, the manual
mode will be selected.
To select one of the
custom programs, press
the Select Program but-
ton repeatedly until the
Learn 1 or Learn 2 indicator lights.
Note: If the custom program has not yet been
defined, three columns of indicators will be lit
in the program display. If more than three
columns of indicators are lit, refer to HOW TO
USE CUSTOM PROGRAMS on page 15.
Press the Start button or the Speed + button
and program the desired speed and incline
settings.
A moment after the button is pressed, the walking
belt will begin to move. Hold the handrails and
begin walking.
Refer to the program display. Each custom pro-
gram is divided into one-minute segments. One
speed setting and one incline setting can be pro-
grammed for each seg-
ment. The speed setting
for the first segment will
be shown in the flashing
Current Segment col-
umn of the program dis-
play. (The incline set-
tings are not shown in
the program display.) To program a speed setting
and an incline setting for the first segment, simply
adjust the speed and incline of the treadmill to the
desired levels by pressing the Speed and Incline
buttons. Every few times one of the Speed but-
tons is pressed, an additional indicator will light or
darken in the Current Segment column.
When the first segment of the program is com-
pleted, the current speed setting and the current
incline setting will be stored in memory. The three
columns of indicators will then move one column
to the left, and the speed setting for the second
segment will be shown in the flashing Current
Segment column. Program a speed setting and an
incline setting for the second segment as de-
scribed above. Note: After the third segment is
completed, the columns of indicators in the pro-
gram display will no longer move to the left.
Instead, each time a segment is completed, the
flashing Current Segment column will move one
column to the right. If the Current Segment col-
umn reaches the right side of the program display,
when the current segment is completed all
columns of indicators in the program display will
move three columns to the left.
Continue programming speed and incline settings
for as many segments as desired; custom pro-
grams can have up to forty segments. When you
are finished with your workout, press the Stop but-
ton twice. The speed and incline settings that you
programmed and the number of segments that you
programmed will then be saved in memory.
Follow your progress with the displays.
Refer to step 5 on page 11.
When the program has ended, remove the key.
Refer to step 6 on page 13.
5
4
3
2
1
Learn Indicator
Current Segment
14

HOW TO USE CUSTOM PROGRAMS
Insert the key fully into the console.
See GETTING STARTED on page 10.
Select one of the custom programs.
When the key is in-
serted, the manual
mode will be selected.
To select one of the
custom programs, press
the Select Program but-
ton repeatedly until the
Learn 1 or Learn 2 indicator lights.
When a custom program is selected, the program
display will show a simplified profile of the pro-
gram. The Time/Laps display will show how long
the program will last. Note: If only three
columns of indicators are lit in the program
display, refer to HOW TO CREATE A CUSTOM
PROGRAM on page 14.
Press the Start button or the Speed + button to
start the program.
A moment after the button is pressed, the tread-
mill will automatically adjust to the first speed and
incline settings for the program. Hold the handrails
and begin walking.
Each program is divided into several one-minute
segments. The Time/Laps display shows both the
time remaining in the program and the time re-
maining in the current segment. One speed set-
ting and one incline setting are programmed for
each segment. The
speed setting for the
first segment will be
shown in the flashing
Current Segment col-
umn of the program dis-
play. (The incline set-
tings are not shown in
the program display.) The speed settings for the
next five segments will be shown in the five
columns to the right.
When only three seconds remain in the first seg-
ment of the program, both the Current Segment
column and the column to the right will flash and a
tone will sound. In addition, if the speed and/or
incline of the treadmill is about to change, the
Speed/Pace display and/or the Distance/Incline
display will flash to alert you, and three tones will
sound. When the first segment is completed, all
speed settings will move one column to the left.
The speed setting for the second segment will
then be shown in the flashing Current Segment
column and the treadmill will automatically adjust
to the speed and incline settings for the second
segment.
The program will continue until the speed setting
for the last segment is shown in the Current
Segment column and no time remains in the
Time/Laps display. The walking belt will then slow
to a stop.
If desired, you can redefine to the program while
using the program. To change the speed or in-
cline setting during the current segment, sim-
ply press the Speed or Incline buttons. When the
current segment is completed, the new setting will be
saved in memory. To increase the length of the
program, first wait until the program is completed.
Then, press the Start button and program speed and
incline settings for as many additional segments as
desired. (Note: While you are adding segments to
the program, the speed settings in the program
display will not move to the left. Instead, each time
a segment is completed, the flashing Current
Segment column will move one column to the
right. If the Current Segment column reaches the
right side of the program display, when the current
segment is completed all columns of indicators in
the program display will move three columns to
the left.) When you have added as many seg-
ments as desired, press the Stop button twice. To
decrease the length of the program, press the
Stop button twice at any time before the program is
completed.
To stop the program temporarily, press the Stop
button. All displays will pause and the Time/Laps
display will begin to flash. To restart the program,
press the Start button or the Speed + button. To
end the program, press the Stop button, remove
the key, and then reinsert the key.
Follow your progress with the displays.
Refer to step 5 on page 11.
Measure your heart rate, if desired.
See step 6 on page 12.
When the program has ended, remove the key.
See step 6 on page 13.
6
5
4
3
2
1
Learn Indicator
Current Segment
15

HOW TO CONNECT THE TREADMILL TO YOUR
CD PLAYER, VCR, OR COMPUTER
To use iFIT.com CDs, the treadmill must be con-
nected to your portable CD player, portable stereo,
home stereo, or computer with CD player. See pages
16 and 17 for connecting instructions. To use iFIT.com
videocassettes, the treadmill must be connected to
your VCR. See page 18 for connecting instructions. To
use iFIT.com programs directly from our Web site,
the treadmill must be connected to your home com-
puter. See page 17 for connecting instructions.
HOW TO CONNECT YOUR PORTABLE CD PLAYER
Note: If your CD player has separate LINE OUT and
PHONES jacks, see instruction A below. If your CD
player has only one jack, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your CD player. Plug your headphones into the
PHONES jack.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your CD player. Plug your
headphones into the other side of the Y-adapter.
HOW TO CONNECT YOUR PORTABLE STEREO
Note: If your stereo has an RCA-type AUDIO OUT
jack, see instruction A below. If your stereo has a
3.5mm LINE OUT jack, see instruction B. If your
stereo has only a PHONES jack, see instruction C.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter. Plug
the adapter into an AUDIO OUT jack on your stereo.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your stereo.
C. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your stereo. Plug your
headphones into the other side of the Y-adapter.
LINE OUT
PHONES LINE OUT
PHONES
Audio
Cable Head-
phones
A
AUDIO OUT
RIGHT
LEFT
Audio
Cable Adapter
A
LINE OUT
Audio
Cable
B
PHONES
Audio
Cable
C
PHONES
PHONES
Audio
Cable
3.5mm
Y-adapter
Headphones
B
3.5mm
Y-adapter
Headphones
16

HOW TO CONNECT YOUR HOME STEREO
Note: If your stereo has an unused LINE OUT jack,
see instruction A below. If the LINE OUT jack is
being used, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the LINE OUT jack on your
stereo.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the LINE OUT jack on your
stereo and plug the wire into the unused side of the
RCA Y-adapter. Plug the RCA Y-adapter into the
LINE OUT jack on your stereo.
HOW TO CONNECT YOUR COMPUTER
Note: If your computer has a 3.5mm LINE OUT jack,
see instruction A. If your computer has only a
PHONES jack, see instruction B.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the LINE OUT jack on
your computer.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into a 3.5mm Y-adapter
(available at electronics stores). Plug the Y-adapter
into the PHONES jack on your computer. Plug your
headphones or speakers into the other side of the
Y-adapter.
LINE OUT
CD
VCR
Amp
LINE OUT
Audio
Cable Adapter
A
LINE OUT
Audio
Cable
A
CD
VCR
Amp
LINE OUT
Audio
Cable
RCA
Y-adapter
Wire removed from
LINE OUT jack
B
Adapter
PHONES
Audio
Cable
B
3.5mm
Y-adapter
Headphones/Speakers
17

HOW TO CONNECT YOUR VCR
Note: If your VCR has an unused AUDIO OUT jack,
see instruction A below. If the AUDIO OUT jack is
being used, see instruction B. If you have a TV
with a built-in VCR, see instruction B. If your VCR
is connected to your home stereo, see HOW TO
CONNECT YOUR HOME STEREO on page 17.
A. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into the AUDIO OUT jack on your
VCR.
B. Plug one end of the audio cable into the jack on the
front of the treadmill near the power cord. Plug the
other end of the cable into the included adapter.
Plug the adapter into an RCA Y-adapter (available
at electronics stores). Next, remove the wire that is
currently plugged into the AUDIO OUT jack on your
VCR and plug the wire into the unused side of the
RCA Y-adapter. Plug the RCA Y-adapter into the
AUDIO OUT jack on your VCR.
HOW TO USE IFIT.COM CD AND VIDEO
PROGRAMS
To use iFIT.com CDs or videocassettes, the treadmill
must be connected to your portable CD player, portable
stereo, home stereo, computer with CD player, or
VCR. See HOW TO CONNECT THE TREADMILL TO
YOUR CD PLAYER, VCR, OR COMPUTER on page
16 and 17. Note: To purchase iFIT.com CDs or
videocassettes, call toll-free 1-800-735-0768.
Follow the steps below to use an iFIT.com CD or video
program.
Insert the key fully into the console.
See GETTING STARTED on page 10.
Select the iFIT.com mode.
When the key is in-
serted, the manual
mode will be selected.
To use an iFIT.com CD
or video program, press
the iFIT.com button or
press the Select Program button repeatedly until
the indicator on the iFIT.com button lights.
Insert the iFIT.com CD or videocassette.
If you are using an iFIT.com CD, insert the CD
into your CD player. If you are using an iFIT.com
videocassette, insert the videocassette into your
VCR.
Press the PLAY button on your CD player or
VCR.
A moment after the button is pressed, your per-
sonal trainer will begin guiding you through your
workout. Simply follow your personal trainer’s
instructions. Note: If the Time/Laps display is
flashing, press the Start button or the Speed +
button on the console. The treadmill will not re-
spond to a CD or video program when the
Time/Laps display is flashing.
During the CD or video program, an electronic
“chirping” sound will alert you when the speed
and/or incline of the treadmill is about to change.
CAUTION: Always listen for the “chirp” and be
prepared for speed and/or incline changes. In
some instances, the speed and/or incline may
change before the personal trainer describes
the change.
4
3
2
1
AUDIO OUT
RIGHT
LEFT
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio
Cable Adapter
A
VIDEO AUDIO
ANT.IN
RF OUT
IN
OUT
CH
34
Audio
Cable Adapter
B
Wire removed from
AUDIO OUT jack
RCA Y-adapter
18

If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, when the next “chirp” is
heard, the speed and/or incline will change to
the next settings of the CD or video program.
To stop the walking belt at any time, press the
Stop button on the console. The Time/Laps dis-
play will begin to flash. To restart the program,
press the Start button or the Speed + button. After
a moment, the walking belt will begin to move at
1.0 mph. When the next “chirp” is heard, the
speed and incline will change to the next set-
tings of the CD or video program.
When the CD or video program is completed, the
walking belt will stop and the Time/Laps display will
begin to flash. Note: To use another CD or video
program, press the Stop button or remove the key
and go to step 1 on page 18.
Note: If the speed or incline of the treadmill
does not change when a “chirp” is heard:
• Make sure that the iFIT.com indicator is lit and
that the Time/Laps display is not flashing. If
the Time/Laps display is flashing, press the
Start button or the Speed + button on the
console.
• Adjust the volume of your CD player or VCR.
If the volume is too high or too low, the con-
sole may not detect the program signals.
• Make sure that the audio cable is properly
connected, that it is fully plugged in, and that
it is not wrapped around a power cord.
• If you are using your portable CD player and
the CD skips, set the CD player on the floor or
another flat surface instead of on the console.
• See the bottom of page 24.
Follow your progress with the LED track and
the displays.
See step 5 on page 11.
Measure your heart rate, if desired.
Refer to step 6 on page 12.
When the program is completed, remove the
key.
See step 6 on page 13.
CAUTION: Always remove iFIT.com CDs and
videocassettes from your CD player or VCR
when you are finished using them.
7
6
5
19

HOW TO USE PROGRAMS DIRECTLY FROM
OUR WEB SITE
Our Web site at www.iFIT.com allows you to access
basic programs, audio programs, and video programs
directly from the internet. Additional options are soon
to be available. See www.iFIT.com for details.
To use programs from our Web site, the treadmill must
be connected to your home computer. See HOW TO
CONNECT YOUR COMPUTER on page 17. In
addition, you must have an internet connection and
an internet service provider. A list of specific system
requirements will be found on our Web site.
Follow the steps below to use a program from our
Web site.
Insert the key fully into the console.
See GETTING STARTED on page 10.
Select the iFIT.com mode.
When the key is in-
serted, the manual
mode will be selected.
To use a program from
our Web site, press the
iFIT.com button or
press the Select Program button repeatedly until
the indicator on the iFIT.com button lights.
Go to your computer and start an internet
connection.
Start your web browser, if necessary, and go to
our Web site at www.iFIT.com.
Follow the desired links on our Web site to se-
lect a program.
Read and follow the on-line instructions for using a
program.
Follow the on-line instructions to start the
program.
When you start the program, an on-screen count-
down will begin.
Return to the treadmill and stand on the foot
pads. Find the clip attached to the key and
slide the clip onto the waistband of your cloth-
ing.
When the on-screen countdown ends, the program
will begin and the walking belt will begin to move.
Hold the handrails, step onto the walking belt, and
begin walking. During the program, an electronic
“chirping” sound will alert you when the speed
and/or incline of the treadmill is about to change.
CAUTION: Always listen for the “chirp” and be
prepared for speed and/or incline changes.
If the speed or incline settings are too high or too
low, you can manually override the settings at any
time by pressing the Speed or Incline buttons on
the console. However, when the next “chirp” is
heard, the speed and/or incline will change to
the next settings of the program.
To stop the walking belt at any time, press the
Stop button on the console. The Time/Laps display
will begin to flash. To restart the program, press
the Start button or the Speed + button. After a mo-
ment, the walking belt will begin to move at 1.0
mph. When the next “chirp” is heard, the speed
and incline will change to the next settings of
the program.
When the program is completed, the walking belt
will stop and the Time/Laps display will begin to
flash. Note: To use another program, press the
Stop button and go to step 5.
Note: If the speed or incline of the treadmill
does not change when a “chirp” is heard, make
sure that the iFIT.com indicator is lit and that
the Time/Laps display is not flashing. In addi-
tion, make sure that the audio cable is properly
connected, that it is fully plugged in, and that it
is not wrapped around a power cord.
Follow your progress with the LED track and
the displays.
See step 5 on page 11.
When the program has ended, remove the key.
See step 6 on page 13.
9
8
7
6
5
4
3
2
1
20
