NordicTrack T9ci NTL09908.0 User manual

www.nordJctrack.com
Model No. NTL09908.0
Serial No.
Write the serial number in the space
above for reference.
Serial
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
DO NOT CONTACT THE STORE;
please contact Customer Care.
iMPORTANT: You must note the
product model number and ser-
ial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.-Fri. 6 a.m.-6 p.m. MT
Sat. 8 a.m.-4 p.m. MT
ON THE WEB:
www.nordictrackservice.com
USER'S
@
AUAL

TABLE OF CONTENTS
WARNING DECAL PLACEMENT .............................................................. 2
IMPORTANT PRECAUTIONS ................................................................. 3
BEFORE YOU BEGIN ....................................................................... 5
ASSEMBLY ............................................................................... 6
OPERATION AND ADJUSTMENT ............................................................ 13
HOW TO FOLD AND MOVE THE TREADMILL .................................................. 27
TROUBLESHOOTING ...................................................................... 29
EXERCISE GUIDELINES ................................................................... 32
PART LIST ............................................................................... 34
EXPLODED DRAWING ..................................................................... 36
ORDERING REPLACEMENT PARTS .................................................. Back Cover
LIMITED WARRANTY ............................................................... Back Cover
WARNING DECAL PLACEMENT
This drawing shows the locations of the
warning decals, If a decal is missing or il-
legible, call the telephone number on the
front cover of this manual and request a
free replacement decal. Apply the decal
in the location shown. Note: The decals
may not be shown at actual size.
KEEPHANDSANDFEETAWAY
FROMTHISAREAWHILETHE
TREADMILLISINOPERATION.
Protect yourself and
others from risk of serious
injury. Read the user's
manual and :
•Stand only oil the
sde tails when
,Hold handrails to
prevent lalling, and
always wear the
safety clip whle
operating treadmill,
•Stop ifyou (eel rant,
di_y, or short of
breath,
•Fully engage storage
latch before tead-
m_ll _s moved or
stored
•Reduce incl _e to ts
lowest level before
folding treadmill Me
storage posit_on
: Nh__fe'eal°°n'_°raround tfeadm II,
•Remove key when
not inuse,
,Keep clothing,
beIt,_v_Y1 °m_q2ving
........... •Never t_y to adjust
or fix the belt while
it JsmovLng.
_ "Nways wear
aihletic shoes while
operating treadmill,
NordicTrack is a registered trademark of ICON IP, Inc.
2

iMPORTANT PRECAUTIONS
3

4

BEFORE YOU BEGIN
Thank you for selecting the revolutionary NordicTrack ®
T9CI treadmill. The T9CI treadmill offers a selection of
features designed to make your workouts at home
more enjoyable and effective. And when you're not ex-
ercising, the unique treadmill can be folded up, requir-
ing less than half the floor space of other treadmills.
For your benefit, read this manual carefully before
using the treadmill. If you have questions after read-
ing this manual, please see the front cover of this man-
ual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
Accessory Tray
Handrail
Console
Fan
Pulse Sensor
Key/Clip
Walking Belt
Reset/Off
Breaker
Foot Rail
-- Power Cord
Wheel
Platform Cushion
Idler Roller
Adjustment Bolts

ASSEMBLY
Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials, Do not
dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking
belt is coated with high-performance lubricant. During shipping, some lubricant may be transferred to the top of
the walking belt or the shipping carton. This is normal and does not affect treadmill performance, If there is lubri-
cant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
Assembly requires the included hex k _ys and your own Phillips screwdriver _ and
adjustable wrench _.
Use the drawings below to identify the assembly hardware. The number in parentheses below each drawing is
the key number of the part, from the PART LIST near the end of this manual. The number after the parentheses
is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it is preattached
to one of the parts to be assembled. To avoid damaging plastic parts, do not use power tools for assem-
bly. Extra hardware may be included.
#8 x 5/8" #8 x 1" Tek #8 x 1/2" Ground #10 x 1/2"
Screw (7)-8 Screw (8)-6 Screw (16)-1 Bolt (11)-2
©
#10 Star
Washer (3)-2
3/8" Nut (5)-5
#8 x 3/4"
Screw (1)-12
0
5/16" Star 3/8" Star
Washer (4)-4 Washer (18)-4
Base Foot
Spacer (87)-6
3/8" x 2" Bolt (2)-3
3/8" x 2 3/8" Bolt (10)-4
3/8" x 2 3/4" Bolt (6)-2
5/16" x 4" Bolt (12)-4

1. Make sure that the power cord is unplugged.
With the help of a second person, carefully tip
the treadmill onto its side as shown. Partially
fold the Frame (54) so the treadmill is more sta-
ble. Do not fully fold the Frame until the
treadmill is completely assembled.
Attach six Base Feet (88) and six Base Foot
Spacers (87) to the Base (85) and the Extension
Legs (90) in the locations shown with six #8 x 1"
Tek Screws (8). Do not overtighten the Tek
Screws. 54
90
88
8
85
,Attach a Wheel (92) to an Extension Leg (90)
with a 3/8" x 2 3/4" Bolt (6) and a 3/8" Nut (5).
Do not overtighten the Nut; the Wheel must
turn freely.
7

.Identify the Right Upright (112), which is marked
with a sticker. Have a second person hold the
Right Upright near the Base (85) as shown.
Slide the Right Base Cover (119) onto the end
of the Right Upright.
See the inset drawing. Tie the wire tie in the
Right Upright (112) securely around the end of
the Wire Harness (79). Then, pull the other end
of the wire tie until the Wire Harness is routed
completely through the Right Upright.
3Wire
Tie
112
119
85
.Hold the Right Upright (112) against the Base
(85), with the bend in the Right Upright posi-
tioned as shown. Be careful not to pinch the
Wire Harness (79).
Attach the Right Upright (112) to the Base (85)
with two 3/8" x 2 3/8" Bolts (10) and two 3/8"
Star Washers (18); do not fully tighten the
Bolts yet.
Bend
112 79
85
.Slide the Right Base Cover (119) over the Base
(85). Attach the Right Base Cover with three #8
x 3/4" Screws (1). Do not overtighten the
Screws.
119
85
8

.With the help of a second person, carefully tip
the treadmill onto its side as shown, Partially
fold the Frame (54) so the treadmill is more sta-
ble, Do not fully fold the Frame until the
treadmill is completely assembled.
Hold the Left Upright (111) against the Base
(85), with the bend in the Left Upright positioned
as shown, Slide the Left Base Cover (118) onto
the end of the Left Upright.
Attach the Left Upright (111) to the Base (85)
with two 3/8" x 2 3/8" Bolts (10) and two 3/8"
Star Washers (18); do not fully tighten the
Bolts yet.
Attach a Wheel (92) to an Extension Leg (90)
with a 3/8" x 2 3/4" Bolt (6) and a 3/8" Nut (5).
Do not overtighten the Nut; the Wheel must
turn freely.
85
118 Bend
111
54
.Slide the Left Base Cover (118) over the Base
(85). Attach the Left Base Cover with three #8 x
3/4" Screws (1). Do not overtighten the
Screws.
With the help of a second person, tip the tread-
mill so that the Base (85) is flat on the floor. 1
118
.Set the console assembly face down on a soft
surface to avoid scratching the console assem-
bly.
Identify the Left Accessory Tray (93) and the
Right Accessory Tray (94), which are marked
with an "L" and an "R" on the bottom.
Attach the Left and Right Accessory Trays (93,
94) to the console assembly with eight #8 x 5/8"
Screws (7). Do not overtighten the Screws.
93
94
Console
Assembly
9

.Hold the Right Handrail (107), which is labeled
with a sticker, near the console assembly. Insert
the console wire into the hole in the side of the
Right Handrail.
Attach the Console Ground Wire (102) to the
bracket on the Right Handrail (107) with the #8 x
1/2" Ground Screw (16).
Set the Handrails (106, 107) on the console as-
sembly. Start four #8 x 3/4" Screws (1) into the
Handrail; do not fully tighten the Screws yet.
Be careful not to pinch the console wire.
107 1
Console
Assembly
Console
Wire
10. Partially tighten two #8 x 3/4" Screws (1)into
the Left and Right Handrails (106, 107); do not
fully tighten the Screws yet.
Tighten two #10 x 1/2" Bolts (11) with two #10
Star Washers (3) into the Left and Right
Handrails (106, 107).
See assembly steps 9 and 10. Tighten the six
#8 x 3/4" Screws (1). Do not overtighten the
Screws.
10
Console
Assembly
\
106
11-__.
3-----$ 107
10
