Nordson Vantage Reference guide

Vantager
Manual Spray Gun Control Unit
Customer Product Manual
Part 1066850-03
Issued 04/16
NORDSON CORPORATION •AMHERST, OHIO •USA
For parts and technical support, call the Industrial Coating
Systems Customer Support Center at [phone] or
contact your local Nordson representative.
This document is subject to change without notice.
Check http://emanuals.nordson.com for the latest version.

Part 1066850-03 E2016 Nordson Corporation
Table of Contents
Safety 1.......................................
Qualified Personnel 1.........................
Intended Use 1...............................
Regulations and Approvals 1...................
Personal Safety 1............................
Fire Safety 2.................................
Grounding 2.................................
Action in the Event of a Malfunction 2...........
Disposal 2...................................
Description 3..................................
Operating Modes 3...........................
Specifications 3..............................
Front Panel 4................................
Back Panel 5................................
Installation 6..................................
Circuit Board Configuration 6..................
Mounting Brackets 8.........................
Rail-Mounting Bracket 8....................
Wall-Mounting Bracket 9...................
Connections 10...............................
Typical Powder Spray System 10.............
Power Input Cord 11........................
Operation 12...................................
Gun Type Configuration 12.....................
Startup 12...................................
Shutdown 13..................................
Maintenance 13................................
Troubleshooting 14.............................
Electrical Schematic 16........................
Pneumatic Schematic 19.......................
Repair 20......................................
Regulator Assembly Replacement 20............
Circuit Board Replacement 21..................
Solenoid Valve Replacement 21.................
Parts 23.......................................
Using the Illustrated Parts List 23................
External Control Unit Parts 24..................
Internal Control Unit Parts 26...................
Optional Mounting Brackets 28.................
Rail-Mounting Bracket 28....................
Wall-Mounting Bracket 29...................
Air Tubing, Powder Tubing, and Fittings 30........
Contact Us
Nordson Corporation welcomes requests for information, comments, and
inquiries about its products. General information about Nordson can be
found on the Internet using the following address:
http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
555 Jackson Street
Amherst, OH 44001
Notice
This is a Nordson Corporation publication which is protected by copyright.
Original copyright date 2006. No part of this document may be
photocopied, reproduced, or translated to another language without the
prior written consent of Nordson Corporation. The information contained
in this publication is subject to change without notice.
Trademarks
Econo-Coat, Kinetix, Nordson, the Nordson logo, Sure Coat, Tribomatic,
Vantage, and Versa-Spray are registered trademarks of Nordson
Corporation.
All other trademarks are the property of their respective owners.

Change Record i
Part 1066850-03
E2016 Nordson Corporation
Change Record
Revision Date Change
03 04/16 Removed approval labels and DOC.

Change Record
ii
Part 1066850-03 E2016 Nordson Corporation

VantagerManual Spray Gun Control Unit 1
Part 1066850-03
E2016 Nordson Corporation
VantagerManual Spray Gun Control Unit
Safety
Read and follow these safety instructions. Task-
and equipment-specific warnings, cautions, and
instructions are included in equipment
documentation where appropriate.
Make sure all equipment documentation, including
these instructions, is accessible to all persons
operating or servicing equipment.
Qualified Personnel
Equipment owners are responsible for making sure
that Nordson equipment is installed, operated, and
serviced by qualified personnel. Qualified
personnel are those employees or contractors who
are trained to safely perform their assigned tasks.
They are familiar with all relevant safety rules and
regulations and are physically capable of
performing their assigned tasks.
Intended Use
Use of Nordson equipment in ways other than
those described in the documentation supplied with
the equipment may result in injury to persons or
damage to property.
Some examples of unintended use of equipment
include
Susing incompatible materials
Smaking unauthorized modifications
Sremoving or bypassing safety guards or
interlocks
Susing incompatible or damaged parts
Susing unapproved auxiliary equipment
Soperating equipment in excess of maximum
ratings
Regulations and Approvals
Make sure all equipment is rated and approved for
the environment in which it is used. Any approvals
obtained for Nordson equipment will be voided if
instructions for installation, operation, and service
are not followed.
All phases of equipment installation must comply
with all federal, state, and local codes.
Personal Safety
To prevent injury follow these instructions.
SDo not operate or service equipment unless you
are qualified.
SDo not operate equipment unless safety
guards, doors, or covers are intact and
automatic interlocks are operating properly. Do
not bypass or disarm any safety devices.
SKeep clear of moving equipment. Before
adjusting or servicing any moving equipment,
shut off the power supply and wait until the
equipment comes to a complete stop. Lock out
power and secure the equipment to prevent
unexpected movement.
SRelieve (bleed off) hydraulic and pneumatic
pressure before adjusting or servicing
pressurized systems or components.
Disconnect, lock out, and tag switches before
servicing electrical equipment.
SObtain and read Safety Data Sheets (SDS) for
all materials used. Follow the manufacturer’s
instructions for safe handling and use of
materials, and use recommended personal
protection devices.
STo prevent injury, be aware of less-obvious
dangers in the workplace that often cannot be
completely eliminated, such as hot surfaces,
sharp edges, energized electrical circuits, and
moving parts that cannot be enclosed or
otherwise guarded for practical reasons.

VantagerManual Spray Gun Control Unit
2
Part 1066850-03 E2016 Nordson Corporation
Fire Safety
To avoid a fire or explosion, follow these
instructions.
SDo not smoke, weld, grind, or use open flames
where flammable materials are being used or
stored.
SProvide adequate ventilation to prevent
dangerous concentrations of volatile materials
or vapors. Refer to local codes or your material
SDS for guidance.
SDo not disconnect live electrical circuits while
working with flammable materials. Shut off
power at a disconnect switch first to prevent
sparking.
SKnow where emergency stop buttons, shutoff
valves, and fire extinguishers are located. If a
fire starts in a spray booth, immediately shut off
the spray system and exhaust fans.
SClean, maintain, test, and repair equipment
according to the instructions in your equipment
documentation.
SUse only replacement parts that are designed
for use with original equipment. Contact your
Nordson representative for parts information
and advice.
Grounding
WARNING: Operating faulty electrostatic
equipment is hazardous and can cause
electrocution, fire, or explosion. Make
resistance checks part of your periodic
maintenance program. If you receive even
a slight electrical shock or notice static
sparking or arcing, shut down all electrical
or electrostatic equipment immediately. Do
not restart the equipment until the problem
has been identified and corrected.
All work conducted inside the spray booth or within
1 m (3 ft) of booth openings is considered within a
Class 2, Division 1 or 2 Hazardous location and
must comply with NFPA 33, NFPA 70 (NEC articles
500, 502, and 516), and NFPA 77, latest
conditions.
SAll electrically conductive objects in the spray
areas shall be electrically connected to ground
with a resistance of not more than 1 megohm
as measured with an instrument that applies at
least 500 volts to the circuit being evaluated.
SEquipment to be grounded includes, but is not
limited to, the floor of the spray area, operator
platforms, hoppers, photoeye supports, and
blow-off nozzles. Personnel working in the
spray area must be grounded.
SThere is a possible ignition potential from the
charged human body. Personnel standing on a
painted surface, such as an operator platform,
or wearing non-conductive shoes, are not
grounded. Personnel must wear shoes with
conductive soles or use a ground strap to
maintain a connection to ground when working
with or around electrostatic equipment.
SOperators must maintain skin-to-handle contact
between their hand and the gun handle to
prevent shocks while operating manual
electrostatic spray guns. If gloves must be
worn, cut away the palm or fingers, wear
electrically conductive gloves, or wear a
grounding strap connected to the gun handle or
other true earth ground.
SShut off electrostatic power supplies and
ground gun electrodes before making
adjustments or cleaning powder spray guns.
SConnect all disconnected equipment, ground
cables, and wires after servicing equipment.
Action in the Event of a
Malfunction
If a system or any equipment in a system
malfunctions, shut off the system immediately and
perform the following steps:
SDisconnect and lock out electrical power. Close
pneumatic shutoff valves and relieve pressures.
SIdentify the reason for the malfunction and
correct it before restarting the equipment.
Disposal
Dispose of equipment and materials used in
operation and servicing according to local codes.

VantagerManual Spray Gun Control Unit 3
Part 1066850-03
E2016 Nordson Corporation
Description
The VantagerManual Spray Gun Control Unit
provides pneumatic and electrostatic controls for
Nordson Econo-Coatr, N80, Vantage, and
Tribomaticrmanual spray guns. The control unit
provides the voltage output to the spray gun and
monitors the feedback current to control the
electrostatic charging of the coating material.
Three versions of the control unit are available
including a standard unit and 115V and 220V units
with vibratory motor control.
The vibratory motor control turns the vibrating
motor on whenever the spray gun is triggered and
remains running for approximately 30 seconds after
the spray gun is triggered off.
Operating Modes
The Vantage Manual Spray Gun Control Unit has
two operating modes:
kV: Operator may adjust the voltage output
AFC: Operator may adjust the maximum current
(μA) output
KV
AFC This key toggles between the two operating
modes. LEDs above the key indicate which mode
is currently active.
NOTE: When the controller is configured for use
with a Tribomatic spray gun, the display shows the
current feedback from the spray gun.
Specifications
NOTE: Because of continuous technological
improvements, specifications are subject to change
without notice.
Refer to Table 1.
NOTE: Supply air must be clean and dry. Use a
regenerative desiccant or refrigerated air dryer
capable of producing a 3.4 _C (38 _F) or lower
dewpoint at the maximum input air pressure. Use a
filter system with pre-filters and coalescent-type
filters capable of removing oil, water, and dirt in the
submicron range.
Table 1 Specifications
Air Pressures
Input 5−7 bar (80−100 psi)
Flow Rate 2 bar (30 psi)
Atomizing 0.7 bar (10 psi)
Fluidizing 0.1−0.3 bar (2−5 psi)
Electrical Requirements
Input Requirements 85−250 Vac, 1 phase,
50−60 Hz, 40 VA
Voltage Output
(To Spray Gun)
0−21 Vdc, 0.60 A
Installation Requirements
(per ANSI/ISA S82.01)
Pollution Degree 2
Installation Category II
Installation Zones for Control Unit
with Powder Applicators Zone 22 or Class II,
Division 2
kV Output to the Spray Gun
Gun Type kV Output
Econo-Coat
N80
Vantage
25−95
33−80
33−80

VantagerManual Spray Gun Control Unit
4
Part 1066850-03 E2016 Nordson Corporation
Front Panel
Refer to Table 1 and see Figure 1.
Table 1 Front Panel
Item Description Function
1Power Switch Turns on or off power to the control unit
2kV / μADisplay Indicators Indicate which unit of measure (kV or μA) is currently
being displayed on the digital display
3Digital Display Display depends on current operating state:
When Control Unit Is Powered On: Momentarily
displays the last, saved kV or μA set point
When Gun Is Not Triggered: Displays −−−
When Gun Is Triggered: Displays the spray gun’s
actual kV or μA output, or current feedback (Tribomatic
guns)
4Setpoint Adjust Keys Increase or decrease the spray gun’s kV or μA set point
5Flow Rate Air
Gauge/Regulator
Controls the flow rate air pressure
6Atomizing Air
Gauge/Regulator
Controls the atomizing air pressure
7kV / AFC Mode Indicators Indicate the currently selected operating mode
8kV / AFC Mode Key Changes the operating mode between kV and AFC
9View Key Switches the unit of measure (kV or μA) being displayed
on the digital display
135 6
9
24
KVKV uu AA
KVKV
AFCAFC
AFCAFC
KVKV
87
Figure 1 Front Panel

VantagerManual Spray Gun Control Unit 5
Part 1066850-03
E2016 Nordson Corporation
Back Panel
Refer to Table 2 and see Figure 2.
Table 2 Back Panel
Item Description Function
1Fluidizing Air Valve (10 mm) Regulates the fluidizing air pressure when used with a
powder feed hopper (not used with a vibratory box feeder
system).
2IN Air Connection (10 mm) Connects the system to an air supply.
32 Amp, 250 Vac Fuses Protect the control unit from electrical surges.
4POWER INPUT Cable Connects the system to a power supply.
5VIBRATORY MOTOR CTL Connects the system to a vibratory motor control unit.
6GUN OUTPUT Receptacle Connects the spray gun to the control unit.
7Gun Air Connection (4 mm) Supplies air to the gun to keep powder from
accumulating on the powder spray gun electrode.
NOTE: This connection is optional. If it is not used, it will
be plugged.
8Flow Rate Air Connection
(8 mm)
Supplies flow rate air to pump.
9Atomizing Air Connection
(8 mm)
Supplies atomizing air to pump, or if using a Tribomatic
gun, to diffuser.
10 Ground Stud Connects the control unit to a true earth ground.
0−100 PSI
0−7 BAR
F2 2A
250VAC
F1 2A
250VAC
IN
GUN POWER
12
10 9 86
3
Separate only in a
Non−Hazardous area
7
VANTAGE
XXXXXXX
VIBRATORY
MOTOR CTL. INPUTOUTPUT
45
Figure 2 Back Panel
Note: The vibratory motor control (5) and gun air (7) connections are optional. If they are not used, they will be plugged.

VantagerManual Spray Gun Control Unit
6
Part 1066850-03 E2016 Nordson Corporation
Installation
WARNING: Allow only qualified personnel to perform the following tasks. Follow the safety
instructions in this document and all other related documentation.
WARNING: When installing motor to the Vantage Controller to use the vibrator box feed option, the
cord on the motor must be extra hard usage. The strain relief provided is rated for 4.3−11.4 mm dia.
wire. All local electrical code requirements must be met when installing this.
Circuit Board Configuration
CAUTION: Electrostatic sensitive device.
To avoid damaging the circuit board wear
an ESD wriststrap and use proper
grounding techniques.
NOTE: Follow these guidelines when you first put
the control unit into service or when you replace the
circuit board.
Before you install the control unit, make sure that it
is configured to suit your application.
See Figure 3 to locate the jumpers and identify
their settings. If the default settings do not suit your
application, remove the control unit cover and
change the jumper settings as appropriate.

VantagerManual Spray Gun Control Unit 7
Part 1066850-03
E2016 Nordson Corporation
OPTIONAL
(Econo-Coat Control Unit Retrofit)
DEFAULT
(VANTAGE Control Unit)
JP1
CONTROL UNIT TYPE
1
1
OPTIONAL
(TRIBOMATIC SPRAY GUN)
DEFAULT
(IPS SPRAY GUNS)
JP2
GUN TYPE
IPS TRIBO IPS TRIBO
Figure 3 Circuit Board Configuration

VantagerManual Spray Gun Control Unit
8
Part 1066850-03 E2016 Nordson Corporation
Mounting Brackets
Use the following procedures to mount the control
unit using one of the optional mounting brackets
listed on pages 28−29. If your control unit is part of
a mobile spray system, disregard these procedures
and refer to the installation instructions provided
with the system.
Rail-Mounting Bracket
1. See Figure 4. Remove the three M5 pan-head
screws (6) and washers (7) from the bottom,
front edge of the control unit (1).
2. Line up the holes on the bracket (2) with the
holes on the control unit.
3. Use the washers and the three longer M5
pan-head screws (6) included with the bracket
to secure the bracket to the control unit.
NOTE: Two pairs of M8 machine screws are
included to secure the bracket to the rail. Use
the appropriate length screws and discard the
other two.
4. Thread the jam nuts (4) onto two of the M8
machine screws (5). Thread the screws
through the back of the bracket.
5. Place the controller and bracket on the booth’s
operator platform railing (3).
6. Tighten the machine screws until the bracket is
secured to the rail. Tighten the jam nuts
against the bracket to lock the machine screws
in place.
1
2
3456
7
Figure 4 Rail-Mounting Bracket
1. Control unit
2. Rail-mounting bracket
3. Railing
4. Jam nut
5. M8 Machine screw
6. M5 Pan-head screw
7. Lock and flat washers

VantagerManual Spray Gun Control Unit 9
Part 1066850-03
E2016 Nordson Corporation
Wall-Mounting Bracket
1. See Figure 5. Using the wall-mounting
bracket (2) as a template, drill four 9-mm
(0.354-in.) holes in the booth wall.
NOTE: The screw heads must be on the inside of
the booth wall.
2. Secure the wall-mounting bracket to the booth
wall using the M8 pan-head screws (9),
washers (7, 8), and nuts (6) included with the
bracket.
3. Remove the five M5 pan-head screws (3) and
washers (4, 5) from the bottom, rear of the
control unit (1). Discard the screws, but save
the washers.
4. Line up the holes on the bracket with the holes
on the control unit.
5. Secure the control unit to the bracket using the
washers you removed in step 3 and the five M5
pan-head screws included with the bracket.
1
2
89
6
78
3
4
5
Figure 5 Wall-Mounting Bracket
1. Control unit
2. Wall-mounting bracket
3. M5 Pan-head screws
4. Lock washers
5. Flat washers
6. Hex nuts
7. Lock washers
8. Flat washers
9. M8 Pan-head screws

VantagerManual Spray Gun Control Unit
10
Part 1066850-03 E2016 Nordson Corporation
Connections
If your control unit is part of a mobile spray system,
refer to the installation instructions provided with
the system. The installation instructions included in
this manual are for installing a standalone control
unit.
Typical Powder Spray System
See Figure 6 and refer to Table 3 for a description
of the control unit connections.
NOTE: Refer to the spray gun, pump, and hopper
manuals for more detailed installation instructions.
Table 3 Typical Powder Spray System Connections
Item Description Size Control Unit Back
Panel Connection
Other Equipment
Connection
1Ground Wire
with Clamp —True Earth Ground
2Fluidizing Air Tubing
(Blue) 10-mm OD Powder Feed Hopper Fluidizing Air Fitting
3Atomizing Air Tubing
(Blue) 8-mm OD
Powder Pump
Connector A
or Diffuser (Tribomatic)
4Flow Rate Air Tubing
(Black) 8-mm OD Powder Pump Connector F
5Gun Air—Optional
(Clear) 4-mm OD Spray Gun
6VIBRATORY
MOTOR CTL —VIBRATORY MOTOR CTL Vibratory Motor
7Feed Hose 12.7-mm
(1/2-in.) ID
(not connected to
control unit)
Powder Pump Outlet;
Spray Gun Inlet
8Spray Gun Cable —GUN OUTPUT
(See Note)
Spray Gun Handle
(pre-wired)
9POWER INPUT Cable —POWER INPUT
(pre-wired)
Refer to Power Input
Cord on page 11.
10 Air Supply Tubing
(Blue) 10-mm OD
IN
0−100 PSI
0−7 BAR
Main Air Supply
NOTE: Tighten the gun cable retaining nut to 6 NSm (4.4 ft-lb). An optional 4-meter extension cable is
available. Do not add more than two extension cables to the gun cable.

VantagerManual Spray Gun Control Unit 11
Part 1066850-03
E2016 Nordson Corporation
A
10
1
2
C
7
8
9
D
B
Tighten to
6 NSm (4.4 ft−lb)
4
3
GUN
OUTPUT
POWER
INPUT
VIBRATORY
MOTOR CTL.
56
Figure 6 Connections −Corona Gun
A. Control unit
B. Powder pump
C. Hopper
D. Powder spray gun
1. Ground wire with clamp
2. Blue, 10-mm air tubing (fluidizing)
3. Blue, 8-mm air tubing (atomizing)
4. Black, 8-mm air tubing (flow rate)
5. Clear, 4-mm gun air fitting
(optional)
6. VIBRATORY MOTOR CTL
7. Powder feed hose
8. POWER INPUT cable
9. GUN OUTPUT cable
10. Blue, 10-mm air tubing (IN)
Note: Typical powder pump and hopper shown. Connections for a vibratory box feeder system are slightly different than
those shown.
Power Input Cord
Connect the power input cord to a plug or electrical
panel using these guidelines:
Wire Color Function
Blue N (neutral)
Brown L (hot)
Green/Yellow GND (ground)

VantagerManual Spray Gun Control Unit
12
Part 1066850-03 E2016 Nordson Corporation
Operation
WARNING: Allow only qualified personnel
to perform the following tasks. Follow the
safety instructions in this document and all
other related documentation.
WARNING: This equipment can be
dangerous unless it is used in accordance
with the rules laid down in this manual.
WARNING: This apparatus shall be used
only in spraying areas according to
EN 50050 or under equivalent conditions.
WARNING: All conductive equipment in
the spray area must be connected to a true
earth ground. Failure to observe this
warning may result in a severe shock.
Gun Type Configuration
Use this procedure to configure which type of spray
gun will be controlled by the control unit. This will
only need to be done when the control unit is first
installed, the circuit board is replaced, or a new
type of spray gun is connected.
1. See Figure 7. Make sure that the power
switch (1) is in the off position.
2. While holding down the kV/AFC key (6), turn
the power switch to the on position. A code will
appear, identifying he currently selected gun
type.
3. Use the +/−keys (3) to select the appropriate
gun type code.
Spray Gun Code
Econo-Coat C-1
Not Used C-2
Not Used C-3
Tribomatic C-4
Not Used C-5
N80 C-6
Vantage
Econo-Coat
(output Voltage limited to 80 kV) C-7
4. Press the kV/AFC key to save the gun type and
begin operation.
Startup
Make sure that the following conditions have been
met before operating the control unit:
SAll of the Connections on page 10 have been
completed.
SThe air supply system’s filters and dryer are
working properly.
SThe booth exhaust fans are operating.
1. See Figure 7. Make sure the fluidizing air
valve (8) is turned fully clockwise.
2. Set the supply air pressure to 5−7 bar
(80−100 psi).
3. Install the appropriate coating material source.
4. Fluidize the powder supply.
Powder
Feed
Hopper
Turn the fluidizing air valve (8)
counterclockwise 1/2turn. Allow
the powder in the hopper to
fluidize for at least 5 minutes.
Vibratory
Box Feeder
The vibratory motor will turn on
as the spray gun is triggered.
The motor will remain on until
approximately 30 seconds after
the trigger is released.
5. Turn the control unit power switch (1) to the on
position.
NOTE: The following air pressure settings are
average starting points. Experimentation will be
necessary to achieve the desired results.

VantagerManual Spray Gun Control Unit 13
Part 1066850-03
E2016 Nordson Corporation
NOTE: The flow rate and atomizing air pressures
can only be adjusted while the gun is spraying.
6. Point the spray gun into the booth and hold
down the trigger. As a starting point, set the
flow rate (4) and atomizing (5) air pressures to
the following specifications:
Flow Rate Air: 2 bar (30 psi)
Atomizing Air: 0.7 bar (10 psi)
NOTE: Refer to your pump and spray gun
manuals for recommended pressures.
7. Corona Guns: Select the operating mode and
adjust the kV or μA setpoints as desired using
the +/−keys (3).
NOTE: The recommended starting point in
AFC mode is 30 μA.
Key Function
Selects which unit of measure
(kV or μA) is currently displayed
KV
AFC
Selects which operating mode
(kV or AFC) is currently active
NOTE: The kV increments in multiples of 1.
The μA increments in multiples of 5.
NOTE: To reset the kV setpoint to 0, press and
hold the +/−keys at the same time until 0
appears on the display.
8. Corona Guns: Pull the spray gun trigger to test
the spray pattern. Adjust the kV or μA setpoint
and the flow rate and atomizing air pressures to
obtain the desired spray pattern.
Tribomatic Guns: Pull the spray gun trigger to
test the spray pattern. The display will show
the current feedback from the gun. Adjust the
flow rate and atomizing air pressures to obtain
the desired charging rate and spray pattern.
NOTE: The kV and μA setpoints are saved in the
control unit’s memory if the control unit remains on
for longer than 10 minutes.
145
7
3
3
8
2
6
KVKV uuAA
KVKV
AFCAFC
AFC
KV
Figure 7 Control Unit Operation
1. Power switch
2. Digital display
3. +/- Keys
4. Flow rate air regulator
5. Atomizing air regulator
6. KV/AFC Mode Key
7. View key
8. Fluidizing air valve
Shutdown
See Figure 7.
1. Turn off the main air supply and relieve system
air pressure.
2. Close the fluidizing air valve (8).
3. Turn the power switch (1) to the off position.
Maintenance
Perform these tasks daily:
SCheck all ground connections, including part
grounds. Ungrounded or poorly grounded parts
will affect transfer efficiency, electrostatic wrap,
and the quality of the finish. Ungrounded
equipment and parts may accumulate a charge
that could arc and cause a fire or explosion.
SCheck power and gun cable connections.
SMake sure that the air being supplied to the
control unit is clean and dry.
SWipe off the control unit with a clean, dry cloth.

VantagerManual Spray Gun Control Unit
14
Part 1066850-03 E2016 Nordson Corporation
Troubleshooting
WARNING: Allow only qualified personnel
to perform the following tasks. Follow the
safety instructions in this document and all
other related documentation.
This section contains troubleshooting procedures.
These procedures cover only the most common
problems that you may encounter. If you cannot
solve the problem with the information given here,
contact your local Nordson representative for help.
Problem Possible Cause Corrective Action
1. Uneven spray pattern;
unsteady or
inadequate powder
flow
Blockage in spray gun, feed hose,
or pump
Disconnect the feed hose from the
pump and blow out the feed hose.
Disassemble and clean the pump
and spray gun.
Replace the feed hose if it is clogged
with fused powder.
Disassemble and clean the pump.
Poor fluidization of powder in
hopper
Increase the fluidizing air pressure.
Hopper Systems: Remove the
powder from the hopper. Clean or
replace the fluidizing plate if it is
contaminated.
Box Feeder Systems: Replace the
fluidizing disk insert at the end of the
pickup tube. Refer to your mobile
powder spray system instructions.
Moisture in powder Check the powder supply, air filters,
and dryer.
Replace the powder supply if it is
contaminated.
Worn nozzle Remove, clean, and inspect the
nozzle. Replace the nozzle if
necessary.
If excessive wear or impact fusion is
present, reduce the flow rate and
atomizing air pressures.
Low atomizing or flow rate air
pressure
Increase the atomizing and/or flow
rate air pressures.
2. Loss of wrap; poor
transfer efficiency
Low electrostatic voltage Increase the electrostatic voltage.
Poor electrode connection Check the resistance of the gun
electrode assembly. Refer to your
spray gun manual for instructions.
Poorly grounded parts Check the part hangers for powder
buildup. The resistance between the
parts and the ground must be
1 megohm or less. For best results,
the resistance should be 500 ohms or
less.
Continued...

VantagerManual Spray Gun Control Unit 15
Part 1066850-03
E2016 Nordson Corporation
Problem Possible Cause Corrective Action
3. No kV output from the
spray gun
Damaged spray gun cable Test the continuity of the spray gun
cable. If an open or short circuit is
found, replace the cable. Refer to
your spray gun manual for
instructions.
Malfunctioning trigger switch Test the continuity of the spray gun
cable and trigger switch. If there is
no continuity, replace the cable.
Refer to your spray gun manual for
instructions.
Malfunctioning voltage multiplier Check the resistance of the spray
gun’s voltage multiplier. Refer to
your spray gun manual for
instructions.
Poor electrode connection Check the resistance of the spray
gun’s electrode assembly as
described in your spray gun manual.
Circuit board not configured
correctly
Refer to Circuit Board Configuration
on page 6. Make sure that JP1 is
set to the appropriate setting.
Malfunctioning power supply Unplug the gun end of the cable from
the voltage multiplier. With the
trigger switch actuated, check for 21
Vdc between pins 2 and 3 of the gun
end of the gun cable. If the reading
is not 21 Vdc, contact your Nordson
representative.
4. No kV output and no
powder output
Malfunctioning solenoid valve Replace the solenoid valve.
Malfunctioning trigger switch or
cable
Check the resistance of the spray
gun’s cable. If no short or open
circuit is found in the trigger switch,
replace the cable. Refer to your
spray gun manual for instructions.
5. Gun will not trigger;
−−−flashing on
display
Gun trigger shorted Replace the gun cable. Refer to your
spray gun manual for more
information.
6. Keypad will not work Circuit board not configured
correctly
Refer to Circuit Board Configuration
on page 6. Make sure that JP1 is
set to the default setting.

VantagerManual Spray Gun Control Unit
16
Part 1066850-03 E2016 Nordson Corporation
Electrical Schematics
See Figure 8.
Figure 8 Electrical Schematic for Vantage Controller without Vibratory Motor Control
