Nordson FP900 Reference guide

FP900 HP Ambient PUR Handgun
Customer Product Manual
Part 1094920A02
Issued 6/10
NORDSON CORPORATION DULUTH, GEORGIA USA
www.nordson.com
This document contains important safety information
Be sure to read and follow all safety information in this
document and any other related documentation.

Part 1094920A02 E2010 Nordson Corporation
All rights reserved
For CE Declaration, refer to melter manual.
Nordson Corporation welcomes requests for information, comments, and inquiries about its products. General information
about Nordson can be found on the Internet using the following address: http://www.nordson.com.
Address all correspondence to:
Nordson Corporation
Attn: Customer Service
11475 Lakefield Drive
Duluth, GA 30097
Notice
This is a Nordson Corporation publication which is protected by copyright. Original copyright date 2009.
No part of this document may be photocopied, reproduced, or translated to another language without the prior written
consent of Nordson Corporation. The information contained in this publication is subject to change without notice.
Trademarks
AccuJet, AeroCharge, Apogee, AquaGuard, Asymtek, Automove, Baitgun, Blue Box, Bowtie, CanWorks, Century, CF, CleanSleeve, CleanSpray, ColorMax,
Color-on-Demand, Control Coat, Coolwave, Cross-Cut, cScan+, Dispensejet, DispenseMate, DuraBlue, DuraDrum, Durafiber, DuraPail, Dura-Screen,
Durasystem, Easy Coat, Easymove Plus, Ecodry, Econo-Coat, e.DOT, EFD, Emerald, Encore, ESP, e stylized, ETI - stylized, Excel 2000, Fillmaster,
FlexiCoat, Flex-O-Coat, Flow Sentry, Fluidmove, FoamMelt, FoamMix, Fulfill, GreenUV, HDLV, Heli-flow, Horizon, Hot Shot, iControl, iDry, iFlow, Isocoil,
Isocore, Iso-Flo, iTRAX, Kinetix, LEAN CELL, Little Squirt, LogiComm, Magnastatic, March, Maverick, MEG, Meltex, Microcoat, Micromark, MicroSet,
Millennium, Mini Squirt, Mountaingate, Nordson, OptiMix, Package of Values, Pattern View, PermaFlo, Porous Coat, PicoDot, PowderGrid, Powderware,
Precisecoat, PRIMARC, Printplus, Prism, ProBlue, Prodigy, Pro-Flo, ProLink, Pro-Meter, Pro-Stream, RBX, Rhino, Saturn, Saturn with rings, Scoreguard,
Seal Sentry, Select Charge, Select Coat, Select Cure, Signature, Slautterback, Smart-Coat, Solder Plus, Spectrum, Speed-Coat, SureBead, Sure Clean,
Sure Coat, Sure-Max, Sure Wrap, Tracking Plus, TRAK, Trends, Tribomatic, TrueBlue, TrueCoat, Ultra, UpTime, u-TAH, Vantage, VersaBlue, Versa-Coat,
VersaDrum, VersaPail, Versa-Screen, Versa-Spray, Watermark, and When you expect more. are registered trademarks of Nordson Corporation.
Accubar, Advanced Plasma Systems, AeroDeck, AeroWash, AltaBlue, AltaSlot, Alta Spray, AquaCure, ATS, Auto-Flo, AutoScan, Axiom, Best Choice,
Blue Series, Bravura, CanPro+,Champion, Check Mate, ClassicBlue, Classic IX, Clean Coat, Cobalt, Controlled Fiberization, Control Weave, ContourCoat,
CPX, cSelect, Cyclo-Kinetic, DispensLink, Drop Cure, Dry Cure, DuraBraid, DuraCoat, DuraPUR, Easy Clean, EasyOn, EasyPW, Eclipse, e.dot+,
E-Nordson, Equalizer, EquiBead, FillEasy, Fill Sentry, FlowCoat, Fluxplus, Get Green With Blue, G-Net, G-Site, iON, Iso-Flex, iTrend, Lacquer Cure,
Maxima, Mesa, MicroFin, MicroMax, Mikros, MiniBlue, MiniEdge, Minimeter, MonoCure, Multifill, MultiScan, Myritex, Nano, OmniScan, OptiStroke,
Partnership+Plus, PatternJet, PatternPro, PCI, Pinnacle, Plasmod, Powder Pilot, Powder Port, Powercure, Process Sentry, Pulse Spray, Quad Cure,
Ready Coat, RediCoat, Royal Blue, Select Series, Sensomatic, Shaftshield, SheetAire, Smart, SolidBlue, Spectral, Spectronic, SpeedKing, Spray Works,
Summit, SureFoam, Sure Mix, SureSeal, Swirl Coat, TAH, ThruWave, TinyCure, Trade Plus, Trilogy, Ultra FoamMix, UltraMax, Ultrasaver, Ultrasmart,
Universal, ValueMate, Versa, Vista, Web Cure, and 2 Rings (Design) are trademarks of Nordson Corporation.
Designations and trademarks stated in this document may be brands that, when used by third parties for their own purposes,
could lead to violation of the owners’ rights.
Loctite is a registered trademark of Loctite Corporation.
Never Seez is a registered trademark of Bostik Inc.
Parker Lubricant is a registered trademark of Parker Seal.
Viton is a registered trademark of DuPont Dow Elastomers. L.L.C.

Table of Contents i
Part 1094920A02
E2010 Nordson Corporation
Table of Contents
Safety 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Alert Symbols 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Responsibilities of the Equipment Owner 2. . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Information 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instructions, Requirements, and Standards 2. . . . . . . . . . . . . . . . . . . . . .
User Qualifications 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Applicable Industry Safety Practices 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Intended Use of the Equipment 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instructions and Safety Messages 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation Practices 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating Practices 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance and Repair Practices 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Equipment Safety Information 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Equipment Shutdown 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Safety Warnings and Cautions 7. . . . . . . . . . . . . . . . . . . . . . . . . .
Other Safety Precautions 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Aid 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Labels and Tags 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Description 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Performance 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Design Flexibility 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nozzle Selection 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Installation 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Unpack the Handgun 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspect the Handgun 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Items Needed 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install the Suspension System 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install the Vertical Mast 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install the Pivoting Arm on the Mast 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Install the Tool Balancer 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the Handgun and Hose 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the Handgun to the Hose and Air Line 21. . . . . . . . . . . . . . . . . . .
Connect the Handgun and Hose to the Pivot Arm and Mast 22. . . . . . . .
Adjust the Tool Balancer 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Configure the Guide Handle, Module Position, and Balance Hanger 26. . .
Guide Handle Installation 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Module Position 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Balance Hanger Removal 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the Handgun to the Air Supply 27. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Connect the Hose to the Bulk Unloader 27. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table of Contents
ii
Part 1094920A02 E2010 Nordson Corporation
Operation 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daily Startup and Operation 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Swirl Handgun Pattern Adjustment 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Swirl Handgun to Extrusion Handgun Conversion 31. . . . . . . . . . . . . . . . . . .
Shutdown and Handgun Storage 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daily Maintenance 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Troubleshooting 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Repair 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replace the Needle Cartridge 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Disassemble the Module 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replace the Needle and Assemble the Module 42. . . . . . . . . . . . . . . . . . .
Parts 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Using the Illustrated Parts Lists 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FP900 Handgun Parts 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
FP900 Module Parts 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Nozzles 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Swirl Nozzle Adapter Kits 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Extrusion Nozzles 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shutdown/Storage Accessories 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Suspension Packages 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recommended Spare Parts and Supplies 49. . . . . . . . . . . . . . . . . . . . . . . . . .
Technical Data 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Handgun Specifications 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Specifications 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

FP900 HP Ambient PUR Handgun 1
Part 1094920A02
E2010 Nordson Corporation
FP900 HP Ambient PUR Handgun
Safety
Read this section before using the equipment. This section contains
recommendations and practices applicable to the safe installation,
operation, and maintenance (hereafter referred to as “use”) of the product
described in this document (hereafter referred to as “equipment”). Additional
safety information, in the form of task-specific safety alert messages,
appears as appropriate throughout this document.
WARNING! Failure to follow the safety messages, recommendations, and
hazard avoidance procedures provided in this document can result in
personal injury, including death, or damage to equipment or property.
Safety Alert Symbols
The following safety alert symbol and signal words are used throughout this
document to alert the reader to personal safety hazards or to identify
conditions that may result in damage to equipment or property. Comply with
all safety information that follows the signal word.
WARNING! Indicates a potentially hazardous situation that, if not avoided,
can result in serious personal injury, including death.
CAUTION! Indicates a potentially hazardous situation that, if not avoided,
can result in minor or moderate personal injury.
CAUTION! (Used without the safety alert symbol) Indicates a potentially
hazardous situation that, if not avoided, can result in damage to equipment
or property.

FP900 HP Ambient PUR Handgun
2
Part 1094920A02 E2010 Nordson Corporation
Responsibilities of the Equipment Owner
Equipment owners are responsible for managing safety information,
ensuring that all instructions and regulatory requirements for use of the
equipment are met, and for qualifying all potential users.
Safety Information
SResearch and evaluate safety information from all applicable sources,
including the owner-specific safety policy, best industry practices,
governing regulations, material manufacturer’s product information, and
this document.
SMake safety information available to equipment users in accordance
with governing regulations. Contact the authority having jurisdiction for
information.
SMaintain safety information, including the safety labels affixed to the
equipment, in readable condition.
Instructions, Requirements, and Standards
SEnsure that the equipment is used in accordance with the information
provided in this document, governing codes and regulations, and best
industry practices.
SIf applicable, receive approval from your facility’s engineering or safety
department, or other similar function within your organization, before
installing or operating the equipment for the first time.
SProvide appropriate emergency and first aid equipment.
SConduct safety inspections to ensure required practices are being
followed.
SRe-evaluate safety practices and procedures whenever changes are
made to the process or equipment.

FP900 HP Ambient PUR Handgun 3
Part 1094920A02
E2010 Nordson Corporation
User Qualifications
Equipment owners are responsible for ensuring that users:
Sreceive safety training appropriate to their job function as directed by
governing regulations and best industry practices
Sare familiar with the equipment owner’s safety and accident
prevention policies and procedures
Sreceive, equipment- and task-specific training from another qualified
individual
NOTE: Nordson can provide equipment-specific installation,
operation, and maintenance training. Contact your Nordson
representative for information
Spossess industry- and trade-specific skills and a level of experience
appropriate to their job function
Sare physically capable of performing their job function and are not
under the influence of any substance that degrades their mental
capacity or physical capabilities
Applicable Industry Safety Practices
The following safety practices apply to the use of the equipment in the
manner described in this document. The information provided here is not
meant to include all possible safety practices, but represents the best safety
practices for equipment of similar hazard potential used in similar industries.
Intended Use of the Equipment
SUse the equipment only for the purposes described and within the limits
specified in this document.
SDo not modify the equipment.
SDo not use incompatible materials or unapproved auxiliary devices.
Contact your Nordson representative if you have any questions on
material compatibility or the use of non-standard auxiliary devices.

FP900 HP Ambient PUR Handgun
4
Part 1094920A02 E2010 Nordson Corporation
Instructions and Safety Messages
SRead and follow the instructions provided in this document and other
referenced documents.
SFamiliarize yourself with the location and meaning of the safety warning
labels and tags affixed to the equipment. Refer to Safety Labels and
Tags at the end of this section.
SIf you are unsure of how to use the equipment, contact your Nordson
representative for assistance.
Installation Practices
SInstall the equipment in accordance with the instructions provided in this
document and in the documentation provided with auxiliary devices.
SEnsure that the equipment is rated for the environment in which it will be
used and that the processing characteristics of the material will not
create a hazardous environment. Refer to the Material Safety Data
Sheet (MSDS) for the material.
SIf the required installation configuration does not match the installation
instructions, contact your Nordson representative for assistance.
SPosition the equipment for safe operation. Observe the requirements for
clearance between the equipment and other objects.
SInstall lockable power disconnects to isolate the equipment and all
independently powered auxiliary devices from their power sources.
SProperly ground all equipment. Contact your local building code
enforcement agency for specific requirements.
SEnsure that fuses of the correct type and rating are installed in fused
equipment.
SContact the authority having jurisdiction to determine the requirement for
installation permits or inspections.
Operating Practices
SFamiliarize yourself with the location and operation of all safety devices
and indicators.
SConfirm that the equipment, including all safety devices (guards,
interlocks, etc.), is in good working order and that the required
environmental conditions exist.
SUse the personal protective equipment (PPE) specified for each task.
Refer to Equipment Safety Information or the material manufacturer’s
instructions and MSDS for PPE requirements.
SDo not use equipment that is malfunctioning or shows signs of a
potential malfunction.

FP900 HP Ambient PUR Handgun 5
Part 1094920A02
E2010 Nordson Corporation
Maintenance and Repair Practices
SPerform scheduled maintenance activities at the intervals described in
this document.
SRelieve system hydraulic and pneumatic pressure before servicing the
equipment.
SDe-energize the equipment and all auxiliary devices before servicing the
equipment.
SUse only new Nordson-authorized refurbished or replacement parts.
SRead and comply with the manufacturer’s instructions and the MSDS
supplied with equipment cleaning compounds.
NOTE: MSDSs for cleaning compounds that are sold by Nordson are
available at www.nordson.com or by calling your Nordson
representative.
SConfirm the correct operation of all safety devices before placing the
equipment back into operation.
SDispose of waste cleaning compounds and residual process materials
according to governing regulations. Refer to the applicable MSDS or
contact the authority having jurisdiction for information.
SKeep equipment safety warning labels clean. Replace worn or damaged
labels.
Equipment Safety Information
This equipment safety information is applicable to the following types of
Nordson equipment:
Shot melt and cold adhesive application equipment and all related
accessories
Spattern controllers, timers, detection and verification systems, and all
other optional process control devices

FP900 HP Ambient PUR Handgun
6
Part 1094920A02 E2010 Nordson Corporation
Equipment Shutdown
To safely complete many of the procedures described in this document, the
equipment must first be shut down. The level of shut down required varies
by the type of equipment in use and the procedure being completed.
If required, shut down instructions are specified at the start of the
procedure. The levels of shut down are:
Relieving System Hydraulic Pressure
Completely relieve system hydraulic pressure before breaking any hydraulic
connection or seal. Refer to the melter-specific product manual for
instructions on relieving system hydraulic pressure.
De-energizing the System
Isolate the system (melter, hoses, guns, and optional devices) from all
power sources before accessing any unprotected high-voltage wiring or
connection point.
1. Turn off the equipment and all auxiliary devices connected to the
equipment (system).
2. To prevent the equipment from being accidentally energized, lock and
tag the disconnect switch(es) or circuit breaker(s) that provide input
electrical power to the equipment and optional devices.
NOTE: Government regulations and industry standards dictate specific
requirements for the isolation of hazardous energy sources. Refer to the
appropriate regulation or standard.
Disabling the Guns
NOTE: Adhesive dispensing guns are referred to as “applicators” in some
industries.
All electrical or mechanical devices that provide an activation signal to the
guns, gun solenoid valve(s), or the melter pump must be disabled before
work can be performed on or around a gun that is connected to a
pressurized system.
1. Turn off or disconnect the gun triggering device (pattern controller, timer,
PLC, etc.).
2. Disconnect the input signal wiring to the gun solenoid valve(s).
3. Reduce the air pressure to the gun solenoid valve(s) to zero; then
relieve the residual air pressure between the regulator and the gun.

FP900 HP Ambient PUR Handgun 7
Part 1094920A02
E2010 Nordson Corporation
General Safety Warnings and Cautions
Table 1 contains the general safety warnings and cautions that apply to
Nordson hot melt and cold adhesive equipment. Review the table and
carefully read all of the warnings or cautions that apply to the type of
equipment described in this manual.
Equipment types are designated in Table 1 as follows:
HM = Hot melt (melters, hoses, guns, etc.)
PC = Process control
CA = Cold adhesive (dispensing pumps, pressurized container, and
guns)
Table 1 General Safety Warnings and Cautions
Equipment
Type Warning or Caution
HM
WARNING! Hazardous vapors! Before processing any polyurethane
reactive (PUR) hot melt or solvent-based material through a
compatible Nordson melter, read and comply with the material’s
MSDS. Ensure that the material’s processing temperature and
flashpoints will not be exceeded and that all requirements for safe
handling, ventilation, first aid, and personal protective equipment are
met. Failure to comply with MSDS requirements can cause personal
injury, including death.
HM
WARNING! Reactive material! Never clean any aluminum component
or flush Nordson equipment with halogenated hydrocarbon fluids.
Nordson melters and guns contain aluminum components that may
react violently with halogenated hydrocarbons. The use of
halogenated hydrocarbon compounds in Nordson equipment can
cause personal injury, including death.
HM, CA WARNING! System pressurized! Relieve system hydraulic pressure
before breaking any hydraulic connection or seal. Failure to relieve
the system hydraulic pressure can result in the uncontrolled release of
hot melt or cold adhesive, causing personal injury.
Continued...

FP900 HP Ambient PUR Handgun
8
Part 1094920A02 E2010 Nordson Corporation
General Safety Warnings and Cautions (contd)
Table 1 General Safety Warnings and Cautions (contd)
Equipment
Type Warning or Caution
HM
WARNING! Molten material! Wear eye or face protection, clothing that
protects exposed skin, and heat-protective gloves when servicing
equipment that contains molten hot melt. Even when solidified, hot
melt can still cause burns. Failure to wear appropriate personal
protective equipment can result in personal injury.
HM, PC
WARNING! Equipment starts automatically! Remote triggering
devices are used to control automatic hot melt guns. Before working
on or near an operating gun, disable the gun’s triggering device and
remove the air supply to the gun’s solenoid valve(s). Failure to disable
the gun’s triggering device and remove the supply of air to the
solenoid valve(s) can result in personal injury.
HM, CA, PC
WARNING! Risk of electrocution! Even when switched off and
electrically isolated at the disconnect switch or circuit breaker, the
equipment may still be connected to energized auxiliary devices.
De-energize and electrically isolate all auxiliary devices before
servicing the equipment. Failure to properly isolate electrical power to
auxiliary equipment before servicing the equipment can result in
personal injury, including death.
HM, CA, PC
WARNING! Risk of fire or explosion! Nordson adhesive equipment is
not rated for use in explosive environments and should not be used
with solvent-based adhesives that can create an explosive
atmosphere when processed. Refer to the MSDS for the adhesive to
determine its processing characteristics and limitations. The use of
incompatible solvent-based adhesives or the improper processing of
solvent-based adhesives can result in personal injury, including death.
Continued...

FP900 HP Ambient PUR Handgun 9
Part 1094920A02
E2010 Nordson Corporation
Table 1 General Safety Warnings and Cautions (contd)
Equipment
Type Warning or Caution
HM, CA, PC
WARNING! Allow only personnel with appropriate training and
experience to operate or service the equipment. The use of untrained
or inexperienced personnel to operate or service the equipment can
result in injury, including death, to themselves and others and can
damage to the equipment.
HM
CAUTION! Hot surfaces! Avoid contact with the hot metal surfaces of
guns, hoses, and certain components of the melter. If contact can not
be avoided, wear heat-protective gloves and clothing when working
around heated equipment. Failure to avoid contact with hot metal
surfaces can result in personal injury.
HM
CAUTION! Some Nordson melters are specifically designed to
process polyurethane reactive (PUR) hot melt. Attempting to process
PUR in equipment not specifically designed for this purpose can
damage the equipment and cause premature reaction of the hot melt.
If you are unsure of the equipment’s ability to process PUR, contact
your Nordson representative for assistance.
HM, CA
CAUTION! Before using any cleaning or flushing compound on or in
the equipment, read and comply with the manufacturer’s instructions
and the MSDS supplied with the compound. Some cleaning
compounds can react unpredictably with hot melt or cold adhesive,
resulting in damage to the equipment.
HM
CAUTION! Nordson hot melt equipment is factory tested with
Nordson Type R fluid that contains polyester adipate plasticizer.
Certain hot melt materials can react with Type R fluid and form a solid
gum that can clog the equipment. Before using the equipment,
confirm that the hot melt is compatible with Type R fluid.

FP900 HP Ambient PUR Handgun
10
Part 1094920A02 E2010 Nordson Corporation
Other Safety Precautions
SDo not use an open flame to heat hot melt system components.
SCheck high pressure hoses daily for signs of excessive wear, damage,
or leaks.
SNever point a dispensing handgun at yourself or others.
SSuspend dispensing handguns by their proper suspension point.
First Aid
If molten hot melt comes in contact with your skin:
1. Do NOT attempt to remove the molten hot melt from your skin.
2. Immediately soak the affected area in clean, cold water until the hot melt
has cooled.
3. Do NOT attempt to remove the solidified hot melt from your skin.
4. In case of severe burns, treat for shock.
5. Seek expert medical attention immediately. Give the MSDS for the hot
melt to the medical personnel providing treatment.

FP900 HP Ambient PUR Handgun 11
Part 1094920A02
E2010 Nordson Corporation
Safety Labels and Tags
Figure 1 illustrates the location of the product safety labels and tags affixed
to the equipment. Table 2 provides an illustration of the hazard identification
symbols that appear on each safety label and tag, the meaning of the
symbol, or the exact wording of any safety message.
1
Figure 1 Safety labels and tags
Table 2 Safety Labels and Tags
Item Part Description
1. 1087000
Tag, warning

FP900 HP Ambient PUR Handgun
12
Part 1094920A02 E2010 Nordson Corporation
Description
The Nordson FP900 handgun, when combined with balance-assist devices,
allows the operator to maintain a neutral wrist position while manually
applying PUR material to vertical and horizontal substrates.
4203213
1
2
3
4
5
6
7
8
Figure 2 FP900 handgun components (swirl nozzle shown)
1. Multi-plane swivel fitting (hydraulic hose
connection)
2. Balancer hanger
3. Trigger safety
4. Trigger
5. Trigger handle
6. Air line
7. Module
8. Handgun handle
A suspension package, which includes a mast and retracting tool balancer,
bears the weight of the handgun and hose and allows a wide range of
operator movement. The handgun assembly easily swings both left/right
and in/out on the pivoting arm, relative to the operator’s position. This
weight-support design and ergonomic configuration help reduce worker
fatigue and physical stress in bench-top gluing applications, such as those
involving automotive panels, appliance panels, and furniture.

FP900 HP Ambient PUR Handgun 13
Part 1094920A02
E2010 Nordson Corporation
1
2
3
4
5
6
Figure 3 Suspension system components
1. Hose clamps
2. Retracting tool balancer
3. Sliding bracket
4. Pivoting arm
5. Stationary hose mount
6. Vertical mast

FP900 HP Ambient PUR Handgun
14
Part 1094920A02 E2010 Nordson Corporation
Performance
A light-touch trigger activates an air valve in the handgun handle, providing
instant material flow. The ball and seat design assures clean cutoff at the
nozzle.
Design Flexibility
FP900 adhesive dispensing modules permit exceptional control of swirl
density without overspray. FP900 handguns can easily be converted from
swirl to extrusion application. Refer to Parts for swirl nozzle adapter kits and
for extrusion nozzle kits.
FP900 handguns have an auxiliary guide handle that permits two-handed
use for further control. The auxiliary guide handle can be positioned for
either left- or right-handed use. The module can be positioned to apply
material either vertically or horizontally.
An air supply line connects to FP900 handguns through an air pressure
regulator, eliminating the need for an air control kit.

FP900 HP Ambient PUR Handgun 15
Part 1094920A02
E2010 Nordson Corporation
Nozzle Selection
Swirl nozzles are single-piece assemblies consisting of a retainer nut and a
wide pattern swirl disk. The swirl nozzle’s recessed tip protects the nozzle
from damage that can be caused by tools or by dropping the nozzle. The
swirl nozzle is easier to clean but can be damaged if it is installed
incorrectly.
Extrusion nozzles provide for the direct application of material without
atomization of the material.
Factors that determine nozzle size include:
SMaterial viscosity
SApplication deposition
SPattern width
Wide pattern swirl and extrusion nozzles are available in 0.035 in., 0.040 in.,
0.049 in., and 0.055 in. orifice sizes.

FP900 HP Ambient PUR Handgun
16
Part 1094920A02 E2010 Nordson Corporation
Installation
WARNING! Allow only personnel with appropriate training and experience
to operate or service the equipment. The use of untrained or inexperienced
personnel to operate or service the equipment can result in injury, including
death, to themselves and others, and damage to the equipment.
This section provides unpacking, safety, and installation information
necessary for the FP900 handgun.
Unpack the Handgun
Exercise normal care to prevent equipment damage during unpacking.
The handgun and module are configured according to each customer’s
particular sales order. If there is a discrepancy between the sales order and
the equipment received in the shipment, contact your Nordson
representative.
Inspect the Handgun
After unpacking the handgun, make the following inspections:
SCheck for handgun surface dents, scratches, corrosion, or other
physical damage. Contact your Nordson representative if there is any
physical damage.
SRemove any foreign material in the service block air and fluid ports.
STighten any loose fasteners.
