Nortel 5500 series User manual

Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302
.

Document status: Standard
Document version: 01.04
Document date: 27 January 2010
Copyright © 2007–2010, Nortel Networks
All Rights Reserved.
Sourced in Canada and the United States of America
LEGAL NOTICE
While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed
to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY
KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject
to change without notice.

3
Contents
New in this release 5
Features 5
1000BASE-BX support 5
XFPs 5
Other changes 5
Cleaning procedures 5
1000BASE-LX specifications 5
New document 5
Introduction 7
Safety and equipment care information 9
Handling, safety, and environmental guidelines 9
Electrostatic discharge prevention 11
Care of fiber optic equipment 11
Fiber optic cable care 11
Fiber optic connector care 12
Cleaning single connectors 13
Cleaning duplex connectors 14
Cleaning receptacles 16
Product safety warnings and information 17
ESD and installation caution messages 17
Laser safety warnings 20
Electromagnetic interference compliance 22
Small form factor pluggable transceivers 25
Selecting an SFP 25
Procedure job aid: SFPs and common applications 26
Procedure job aid: SFPs and common applications 26
Procedure job aid: SFP models 27
Procedure job aid: SFP models with DDI support 28
Procedure job aid: SFP models with DDI support 29
Procedure job aid: SFP models with DDI support 29
Procedure job aid: SFP models with DDI support 30
Installing an SFP 32
Procedure job aid: locking and extractor mechanisms 33
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

4Contents
Removing an SFP 35
SFP specifications 37
SFP labels 38
General SFP specifications 38
100BASE-FX SFP specifications 39
T1 SFP specifications 39
T1 SFP—default settings 42
1000BASE-T SFP specifications 43
1000BASE-SX (LC) SFP specifications 43
1000BASE-SX (MT-RJ) SFP specifications 44
1000BASE-LX SFP specifications 45
1000BASE-XD CWDM SFP specifications 45
1000BASE-ZX CWDM SFP specifications 46
1000BASE-SX DDI SFP specifications 47
1000BASE-LX DDI SFP specifications 47
1000BASE-XD DDI 1310 nm SFP specifications 48
1000BASE-XD DDI 1550 nm SFP specifications 48
1000BASE-ZX DDI SFP specifications 49
1000BASE-XD DDI CWDM SFP specifications 50
1000BASE-ZX DDI CWDM SFP specifications 51
1000BASE-BX DDI SFP specifications 51
1000BASE-EX DDI SFP specifications 52
10 Gigabit small form factor pluggable transceivers 55
Selecting an XFP 55
Procedure job aid: XFP models 56
Installing an XFP 57
Removing an XFP 60
XFP specifications 61
XFP labels 61
General XFP specifications 62
10GBASE-SR XFP specifications 62
10GBASE-LR/LW XFP specifications 64
10GBASE-ER/EW XFP specifications 65
10GBASE-ER/EW XFP specifications 67
10GBASE-ZR/ZW XFP specifications 68
10GBASE-ZR/ZW XFP specifications 69
Index 72
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

5
New in this release
The following sections detail what’s new in Nortel Ethernet Routing Switch
5500 Series Installation — SFPs and XFPs for Release 5.1.
Features See the following sections for information about feature changes.
1000BASE-BX support
The Ethernet Routing Switch 5500 Series supports the 1000BASE-BX SFP.
See "1000BASE-BX DDI SFP specifications" (page 51).
XFPs The Ethernet Routing Switch 5530 supports the 10GBASE-LR,
10GBASE-ER, and 10GBASE-SR 10 Gigabit small form factor pluggable
transceivers. See "10 Gigabit small form factor pluggable transceivers"
(page 55).
Other changes
See the following sections for information about changes that are not
feature-related.
Cleaning procedures
The cleaning procedures for connectors and ports are updated. See "Fiber
optic connector care" (page 12).
1000BASE-LX specifications
The launch optical power specifications for the AA1419015-E5
1000BASE-LX SFP are -9.5 to -3.0 dBm. See "1000BASE-LX SFP
specifications" (page 45).
New document
This document is a new document based on Nortel Ethernet Routing Switch
8600 Installation — SFP and XFP Transceivers and GBICs (NN46205-305).
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

6New in this release
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

7
Introduction
This document provides installation instructions and technical specifications
for Small Form Factor Pluggable (SFP) transceivers and 10 Gigabit SFPs
(XFP).
For a list of supported SFPs and XFPs, see your latest product-specific
release notes. Information contained in the Release Notes takes
precedence over any information contained in this document.
Navigation
•"Safety and equipment care information" (page 9)
•"Small form factor pluggable transceivers" (page 25)
•"SFP specifications" (page 37)
•"10 Gigabit small form factor pluggable transceivers" (page 55)
•"XFP specifications" (page 61)
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

8Introduction
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

9
Safety and equipment care information
This section contains important safety and regulatory information. Read this
section before you install Small Form Factor Pluggable (SFP) transceivers,
10 Gigabit SFP (XFP) transceivers, or GigaBit Interface Converters (GBIC).
This section contains important safety and regulatory information. Read this
section before you install Small Form Factor Pluggable (SFP) transceivers.
This section contains important safety and regulatory information. Read this
section before you install Small Form Factor Pluggable (SFP) transceivers
or 10 Gigabit SFP (XFP) transceivers.
This section contains important safety and regulatory information. Read this
section before you install Small Form Factor Pluggable (SFP) transceivers
or GigaBit Interface Converters (GBIC).
This section contains important safety and regulatory information. Read this
section before you install GigaBit Interface Converters (GBIC).
Navigation
•"Handling, safety, and environmental guidelines" (page 9)
•"Care of fiber optic equipment" (page 11)
•"Product safety warnings and information" (page 17)
•"Electromagnetic interference compliance" (page 22)
Handling, safety, and environmental guidelines
Before you install a GBIC, SFP, or XFP, read the following handling, safety,
and environmental guidelines:
•GBICs, SFPs, and XFPs are static sensitive. To learn how to prevent
damage from electrostatic discharge (ESD), see "Electrostatic discharge
prevention" (page 11).
•GBICs, SFPs, and XFPs use optical connectors whose performance
can be reduced by dust contamination. When you store a GBIC, SFP, or
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

10 Safety and equipment care information
XFP, or when you disconnect it from a fiber optic cable, always keep a
dust cover over the GBIC, SFP, or XFP optical bore.
•Dispose of this product according to all national laws and regulations.
Before you install an SFP, read the following handling, safety, and
environmental guidelines:
•SFPs are static sensitive. To prevent damage from electrostatic
discharge (ESD), see "Electrostatic discharge prevention" (page 11).
•SFPs use optical connectors whose performance can be reduced by
dust contamination. When you store an SFP, or when you disconnect it
from a fiber optic cable, always keep a dust cover over the optical bore.
•Dispose of this product according to all national laws and regulations.
Before you install an SFP or XFP, read the following handling, safety, and
environmental guidelines:
•SFPs and XFPs are static sensitive. To prevent damage from
electrostatic discharge (ESD), see "Electrostatic discharge prevention"
(page 11).
•SFPs and XFPs use optical connectors whose performance can be
reduced by dust contamination. When you store an SFP or XFP, or
when you disconnect it from a fiber optic cable, always keep a dust
cover over the optical bore.
•Dispose of this product according to all national laws and regulations.
Before you install a GBIC or SFP, read the following handling, safety, and
environmental guidelines:
•GBICs and SFPs are static sensitive. To prevent damage from
electrostatic discharge (ESD), see "Electrostatic discharge prevention"
(page 11).
•GBICs and SFPs use optical connectors whose performance can be
reduced by dust contamination. When you store a GBIC or SFP, or
when you disconnect it from a fiber optic cable, always keep a dust
cover over the optical bore.
•Dispose of this product according to all national laws and regulations.
Before you install a GBIC, read the following handling, safety, and
environmental guidelines:
•GBICs are static sensitive. To prevent damage from electrostatic
discharge (ESD), see "Electrostatic discharge prevention" (page 11).
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

Care of fiber optic equipment 11
•GBICs use optical connectors whose performance can be reduced by
dust contamination. When you store a GBIC, or when you disconnect it
from a fiber optic cable, always keep a dust cover over the optical bore.
•Dispose of this product according to all national laws and regulations.
Electrostatic discharge prevention
To prevent equipment damage, observe the following electrostatic discharge
(ESD) precautions when handling or installing the components.
•Ground yourself and the equipment to an earth or building ground. Use
a grounded workbench mat (or foam that dissipates static charge) and
a grounding wrist strap. The wrist strap should touch the skin and be
grounded through a one megaohm resistor.
•Do not touch anyone who is not grounded.
•Leave all components in their ESD-safe packaging until installation, and
use only a static-shielding bag for all storage, transport, and handling.
•Clear the area of synthetic materials such as polyester, plastic, vinyl, or
styrofoam because these materials carry static electricity that damages
the equipment.
Care of fiber optic equipment
Fiber optic equipment must be kept clean and damage-free. Use the
information in this section to properly maintain and care for fiber optic
equipment.
Care of fiber optic equipment navigation
•"Fiber optic cable care" (page 11)
•"Fiber optic connector care" (page 12)
•"Cleaning single connectors" (page 13)
•"Cleaning duplex connectors" (page 14)
•"Cleaning receptacles" (page 16)
Fiber optic cable care
Although the glass fiber of fiber optic cable is protected with reinforcing
material and plastic insulation, it is subject to damage. Use the following
precautions to avoid damaging the glass fiber.
•Do not kink, knot, or vigorously flex the cable.
•Do not bend the cable to less than a 40 mm radius.
•Do not stand on fiber optic cable; keep the cable off the floor.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

12 Safety and equipment care information
•Do not pull fiber optic cable any harder than you would a cable containing
copper wire of comparable size.
•Do not allow a static load of more than a few pounds on any section
of the cable.
•Place protective caps on fiber optic connectors that are not in use.
•Store unused fiber optic patch cables in a cabinet, on a cable rack, or
flat on a shelf.
Frequent overstressing of fiber optic cable causes progressive degeneration
that leads to failure.
If you suspect damage to a fiber optic cable, either due to mishandling or
an abnormally high error rate observed in one direction, reverse the cable
pairs. If the high error rate appears in the other direction, replace the cable.
CAUTION
Risk of equipment damage
Do not crush fiber optic cable. If fiber optic cable is in the same
tray or duct with large, heavy electrical cables, it can be damaged
by the weight of the electrical cable.
Fiber optic connector care
Before connecting them to transmission equipment, test equipment, patch
panels, or other connectors, ensure fiber optic connectors are clean. The
performance of an optical fiber connector depends on how clean the
connector and coupling are at the time of connection.
A damaged or dirty connector can damage a connector with which it is
mated. A connector must be absolutely clean before it is inserted into a
transmitter or receiver.
Never clean an optical connector that is carrying light. Optical power can
cause ignition of the cleaning material when it contacts the end of the
optical connector, destroying the connector. Typical cleaning materials, for
example, tissues saturated with alcohol, combust almost instantaneously
when exposed to optical power levels of +15 dBm or higher.
Visually inspect the connector to determine cleanliness and to determine if
it needs replacing. Any connector that has a scratch across the core, or a
scratch that appears to end in the core, must be replaced.
The proper connector cleaning method depends on the connector
contaminants:
•Cleanliness is best judged by visual inspection with a fiber microscope.
First inspect the connector, then clean as required.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

Care of fiber optic equipment 13
WARNING
Risk of eye injury
When inspecting a connector, ensure that light sources are
off. The light source used in fiber optic cables can damage
your eyes.
•If you suspect only the possibility of dust particles (for example, which
can occur when a connector is left uncapped in a clean environment),
use high-quality canned air or a reel cleaner (for example, a Cletop) to
clean the connector. A reel cleaner is a good choice for making sure that
no dust contaminates the connector.
•If the connector is visibly dirty or suspected to be contaminated by
chemicals (for example, matching gel), use high-quality alcohol and
canned air to clean the connector (see the following procedure). This
is the most thorough cleaning method. In some cases, a reel cleaner
may suffice.
Always keep in mind that the more surface manipulation applied to the
connector, the more likely the connector to become damaged.
When you insert a connector ferrule into a connector or adapter, ensure that
the ferrule tip does not touch the outside of the mating connector or adapter.
This can produce scratches and dirt deposits on the connector.
To help prevent them from collecting dust, ensure connectors are covered
when not in use. To avoid the transfer of oil or other contaminants from
your fingers to the end face of the ferrule, handle connectors with care. Do
not touch the connector end face.
Cleaning single connectors
Clean connectors so that the optical signal is minimally attenuated by the
connector.
This procedure is appropriate when more than dust contamination is
suspected.
Prerequisites
•lens-grade, lint-free tissue (for example, Kimwipes)
•optical-grade isopropyl alcohol (IPA) (98% or more pure)
•high-quality canned compressed air with extension tube Compressed air
must be free of dust, water and oil, or filmy deposits or scratches on the
surface of the connector can result.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

14 Safety and equipment care information
•fiber optic microscope for inspecting connectors
WARNING
Risk of eye injury
When inspecting a connector, ensure that light sources are off.
The light source used in fiber optic cables can damage your eyes.
To avoid getting debris in your eyes, wear safety glasses when
working with the canned air duster.
To avoid eye irritation on contact, wear safety glasses when
working with isopropyl alcohol.
Procedure steps
Step Action
1Remove dust or debris by applying canned air to the cylindrical and
end-face surfaces of the connector.
2Gently wipe the cylindrical and end-face surfaces with a tissue
dampened with optical-grade isopropyl alcohol.
3Gently wipe the cylindrical and end-face surfaces with a dry tissue.
ATTENTION
Do not let the IPA evaporate; wipe it dry immediately. Alcohols can leave
a residue that is difficult to remove.
4Dry the connector surfaces by applying canned air.
5Inspect the connector to ensure it is clean and undamaged.
To prevent contamination, do not touch the connector surfaces after
cleaning; and cover connectors with dust caps if you are not going
to use them right away.
—End—
Cleaning duplex connectors
Clean connectors so that the optical signal is minimally attenuated by the
connector.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

Care of fiber optic equipment 15
This procedure is appropriate when more than dust contamination is
suspected.
Prerequisites
•lens-grade, lint-free tissue (for example, Kimwipes)
•optical-grade isopropyl alcohol (IPA) (98% or more pure)
•high-quality canned compressed air with extension tube Compressed air
must be free of dust, water and oil, or filmy deposits or scratches on the
surface of the connector can result.
•fiber optic microscope for inspecting connectors
WARNING
Risk of eye injury
When inspecting a connector, ensure that light sources are off.
The light source used in fiber optic cables can damage your eyes.
To avoid getting debris in your eyes, wear safety glasses when
working with the canned air duster.
To avoid eye irritation on contact, wear safety glasses when
working with isopropyl alcohol.
Procedure steps
Step Action
1To remove or retract the shroud, do one of the following.
•On removable shroud connectors, hold the shroud on the top and
bottom at the letter designation, apply medium pressure, and pull
it free from the connector body. Do not discard the shroud.
•On retractable shroud connectors, hold the shroud in its retracted
position.
2Remove dust or debris by applying canned air to the cylindrical and
end-face surfaces of the connector.
3Gently wipe the cylindrical and end-face surfaces of both ferrules
using a tissue saturated with optical-grade isopropyl alcohol.
4Gently wipe the cylindrical and end-face surfaces with a dry tissue.
5Blow dry the connector surfaces with canned air.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

16 Safety and equipment care information
ATTENTION
Do not let the IPA evaporate; wipe it dry immediately. Alcohols can leave
a residue that is difficult to remove.
6Blow dry the connector surfaces with canned air.
7Inspect the connector to ensure it is clean and undamaged.
8Using care to not touch the clean ferrules, gently push the shroud
back onto the connector until it seats and locks in place.
—End—
Cleaning receptacles
Clean connector receptacles or ports so that the optical signal is minimally
attenuated by the connection.
Prerequisites
•optical-grade isopropyl alcohol (IPA) (98% or more pure)
•cleaning swabs (also called cleaning sticks or wands)
•high-quality canned compressed air with extension tube Compressed air
must be free of dust, water and oil, or filmy deposits or scratches on the
surface of the connector can result.
CAUTION
Risk of equipment damage
To avoid contamination, optical ports should only be cleaned when
there is evidence of contamination or reduced performance, or
during their initial installation.
To prevent oil contamination, use only high-quality canned
compressed air.
Do not allow the air extension tube to touch the bottom of the
optical port.
Procedure steps
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

Product safety warnings and information 17
Step Action
1Remove dust or debris by blowing canned air into the optical port of
the device using the canned air extension tube.
2Clean the optical port by inserting a wand moistened with alcohol
into the receptacle and rotating it.
Each cleaning wand should only be used to clean one optical port.
3Dry the optical port by inserting a dry wand into the receptacle and
rotating it.
ATTENTION
Do not let the IPA evaporate; wipe it dry immediately. Alcohols can leave
a residue that is difficult to remove.
4Remove any lint by blowing compressed air into the optical port.
5Reconnect the optical connector and check for proper function.
If you are not reinstalling the connector, be sure to use a protective
cap.
If problems persist, ensure that the connector or receptacle are not
damaged.
—End—
Product safety warnings and information
The products described in this guide meet requirements of:
IEC 60950 3rd edition
CSA 22.2 No. 60950 3rd edition
UL 60950 3rd edition
EN60950 3rd edition
EN60825-1, +A11, +A2
ESD and installation caution messages
This section provides electrostatic discharge (ESD) and installation caution
messages.
This section provides electrostatic discharge (ESD) and installation caution
messages and translations.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

18 Safety and equipment care information
CAUTION
Risk of equipment damage
Only qualified technicians should install this equipment. Place all
printed circuit boards on an antistatic mat until you are ready to
install them. If you do not have an antistatic mat, wear a discharge
leash to free yourself of static before touching any of the printed
circuit boards, or free yourself of static by touching a grounded
metal object before you handle a printed circuit board.
CAUTION
Risk of equipment damage
To prevent damage from electrostatic discharge, always wear an
antistatic wrist strap connected to an ESD jack.
CAUTION
ATTENTION
Risque d’endommagement de l’équipement
Pour prévenir tout dommage dû à une décharge électrostatique,
vous devez toujours porter un un bracelet antistatique connecté
à une prise ESD.
CAUTION
ACHTUNG
Risiko eines Geräteschadens
Risiko eines Geräteschadens Um Schäden durch elektrostatische
Entladung zu verhindern, tragen Sie bei der Instandhaltung dieses
Produkts immer ein antistatisches Band am Handgelenk, welches
mit einer ESD-Buchse verbunden ist.
CAUTION
PRECAUCIÓN
Riesgo de daño del equipo
Para prevenir el daño producido por una descarga electrostática,
use siempre una pulsera antiestática conectada a un enchufe
ESD.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

Product safety warnings and information 19
CAUTION
CUIDADO
Risco de danos ao equipamento
Para evitar danos com descarga eletrostática, sempre use uma
pulseira antiestática que esteja conectada a uma tomada ESD.
CAUTION
ATTENZIONE
Rischio di danni all’apparecchiatura
Per evitare danni derivanti da scariche elettrostatiche, indossare
sempre un polsino antistatico collegato a una presa ESD.
CAUTION
Risk of equipment damage
Only trained personnel can install this product.
CAUTION
ATTENTION
Risque d’endommagement de l’équipement
L’installation doit être effectuée exclusivement par un personnel
qualifié.
CAUTION
ACHTUNG
Risiko eines Geräteschadens
Nur geschultes Personal kann dieses Produkt installieren.
CAUTION
PRECAUCIÓN
Riesgo de daño del equipo
Sólo el personal capacitado puede instalar este producto.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.

20 Safety and equipment care information
CAUTION
CUIDADO
Risco de danos ao equipamento
Somente pessoal treinado pode instalar este produto.
CAUTION
ATTENZIONE
Rischio di danni all’apparecchiatura
Questo prodotto può essere installato solo da personale esperto.
Laser safety warnings
This section provides laser safety warnings and translations.
WARNING
Risk of eye injury by laser
Fiber optic equipment can emit laser or infrared light that can
injure your eyes. Never look into an optical fiber or connector port.
Always assume that fiber optic cables are connected to a light
source.
WARNING
AVERTISSEMENT
Risques de blessure oculaire par lumière laser L’équipement de
fibres optiques peut émettre une lumière laser ou infrarouge
nuisible à vos yeux. Ne regardez jamais en direction de fibres
optiques ou d’un port connecteur. Supposez toujours que les
câbles de fibres optiques sont connectés à une source de lumière.
Nortel Ethernet Routing Switch 5500 Series
Installation — SFPs and XFPs
NN47200-302 01.04 Standard
5.1 27 January 2010
Copyright © 2007–2010, Nortel Networks
.
