Upgrading Memory in the Passport 2430
Multiservice Access Switch
The Passport™2430 Multiservice Access Switch supports a broad array of
primary and backup connectivity devices. This guide refers to the Passport 2430
Multiservice Access Switch as the Passport 2430.
If you want to upgrade your router by adding more DRAM, you can install a 16 or
32 MB single inline memory module (SIMM). This guide describes how to
replace or install a SIMM in the Passport 2430.
Before you begin, inspect the memory upgrade kit and verify the following:
• Your shipment is complete and undamaged.
• You have the proper equipment and tools.
Verifying Shipment Contents
Your shipping container should contain this guide and the SIMM. Inspect the
SIMM for shipping damage. If you detect any damage, do not continue with the
installation process. Contact one of the Nortel Networks™Technical Solutions
Centers listed in Table 1.
Table 1. Nortel Networks Technical Solutions Centers
Technical Solutions Center Telephone Number
Billerica, MA 800-2LANWAN (800-252-6926)
Santa Clara, CA 800-2LANWAN (800-252-6926)
Valbonne, France 33-4-92-96-69-68
Sydney, Australia 61-2-9927-8800
Tokyo, Japan 81-3-5740-1745

Upgrading Memory in the Passport 2430 Mutiservice Access Switch
2309894-A Rev 00
Tools
In addition to the shelf kit shipping contents you will need a Phillips screwdriver.
Installing the SIMM
You install a SIMM in the Passport 2430 with the following steps:
1. Turn off the Passport 2430.
2. Take the cover off the chassis.
3. Insert the SIMM into the SIMM slot.
4. Replace the cover of the chassis.
5. Power up the Passport 2430.
The following sections explain each step in greater detail.
Turn Off the Passport 2430
To turn off the Passport 2430:
1. Press the power switch to the off (0) position.
Figure 1. Power Switch
2. Pull the power supply plug out of the wall outlet.
COM 1 COM 2
Passport 2430
Link TX/RX
10/100 Console
Run
Boot
Fail
Power switch
VLK0035A
Flash 1
2l
O
PCMCIA
Modem

Upgrading Memory in the Passport 2430 Multiservice Access Switch
309894-A Rev 00 3
Remove the Cover from the Chassis
To take the cover off the Passport 2430 chassis:
1. Turn the Passport 2430 upside down and remove the four screws as
shown in Figure 2.
Figure 2. Removing the Screws from the Passport 2430
M/N
ATTACHWALL MOUNT BRACKET HERE
S/N
P/N
Passport 2430
VLK0052A

Upgrading Memory in the Passport 2430 Mutiservice Access Switch
4309894-A Rev 00
2. Carefully turn the Passport 2430 rightside up, grasp the cover near the
front and pull up and remove as shown in Figure 3.
Figure 3. Removing the Chassis Cover
3. Locate the SIMM slot (Figure 4).
Figure 4. Location of the SIMM Slot
If there is already a SIMM in the SIMM slot, go to “Removing a SIMM” on
page 5. Otherwise go to “Inserting a SIMM” on page 6.
VLK0053A
VLK0051A
SIMM

Upgrading Memory in the Passport 2430 Multiservice Access Switch
309894-A Rev 00 5
Removing a SIMM
To remove a SIMM currently in the Passport 2430:
1. Pull the tabs on either side of the SIMM as shown in Figure 5.
The SIMM pops up.
Figure 5. Pull the Tabs on Either Side of the SIMM
2. Grasp the SIMM and pull it out of the SIMM slot.
VLK0058A

Upgrading Memory in the Passport 2430 Mutiservice Access Switch
6309894-A Rev 00
Inserting a SIMM
To insert the SIMM:
1. Position the SIMM so that the notch on the SIMM lines up with the
socket key on the SIMM slot.
2. Gently push the SIMM into the slot as shown in Figure 6.
When in place, the SIMM pops-up.
Figure 6. Position and Insert the SIMM (1), then Push the
SIMM Down (2)
3. Push the SIMM down until you hear or feel a click (see Figure 6).
VLK0054A
Socket key
1
Notch
2
