Notifier IFS-2600 Instruction Manual

IFS-2600
Fire Indicator Panel
OPERATION, INSTALLATION &
PROGRAMMING MANUAL
DOC-01-009 ECN11-0012
19
/
04
/201
1
Rev:
1
.0
2

Documentation Feedback
Your feedback helps us keep our documentation up to date and accurate. If you have any comments or
suggestions about our printed manuals you can email us.
Please include the following information:
Product name and version number (if applicable)
Manual part number and revision (found on the front cover)
Page number
Brief description of the content you think should be improved or corrected
Your suggestion for how to correct/improve documentation
Send email messages to:
[email protected]
Please note this email address is for documentation feedback only. If you have any technical issues,
please contact your nearest branch for technical support.

Installation Precautions
Adherence to the following will aid in problem-free installation with long-term reliability:
WARNING - Several different sources of power
can be connected to the fire alarm control
panel. Disconnect all sources of power before
servicing. Control unit and associated equipment
may be damaged by removing and/or inserting
cards, modules, or interconnecting cables while
the unit is energized. Do not attempt to install,
service, or operate this unit until manuals are read
and understood.
Verify that wire sizes are adequate for all
initiating and indicating device loops. Most devices
cannot tolerate more than a 10% I.R. drop from
the specified device voltage.
Like all solid state electronic devices, this
system may operate erratically or can be damaged
when subjected to lightning induced transients.
Although no system is completely immune from
lightning transients and interference, proper
grounding will reduce susceptibility. Overhead or
outside aerial wiring is not recommended, due to
an increased susceptibility to nearby lightning
strikes. Consult with the Technical Services
Department if any problems are anticipated or
encountered.
Disconnect AC power and batteries prior to
removing or inserting circuit boards. Failure to do
so can damage circuits.
Remove all electronic assemblies prior to any
drilling, filing, reaming, or punching of the
enclosure. When possible, make all cable entries
from the sides or rear. Before making
modifications, verify that they will not interfere with
battery, transformer, or printed circuit board
location.
Do not over tighten screw terminals. Over
tightening may damage threads, resulting in
reduced terminal contact pressure and difficulty
with screw terminal removal.
This system contains static-sensitive
components. Always ground yourself with a
proper wrist strap before handling any circuits so
that
Static charges are removed from the body. Use
static suppressive packaging to protect electronic
assemblies removed from the unit.
Follow the instructions in the installation,
operating, and programming manuals. These
instructions must be followed to avoid damage to
the control panel and associated equipment.
FACP operation and reliability depend upon proper
installation.
This equipment must be correctly programmed
and installed to suit the specific application.
Please ensure correct operational parameters are
set prior to commissioning. If further details on
programming options are required, please consult
the programming manual or contact our helpful
technical support personnel.
EMC WARNING:
This equipment may radiate radio frequency energy. It may also be affected by radio frequency energy and, if
not installed and operated in accordance with the manufacturer’s instructions, may cause interference to radio
communications. It has been tested and found to comply with the Class A radiated and conducted EMI
requirements of AS/NZS CISPR 22:2009 (including Amendments 1 & 2) as well as the EMI susceptibility
requirements of Clause C3.5 in AS4428.0:1997.
Radio communication devices should not be used in the vicinity of fire panels or associated ancillary devices
and systems.
This is a Class A product. In a domestic environment this product may cause radio interference in which case
the user may be required to take adequate measures.

IFS-2600 Fire Indicator Panel Section 1
About this Manual
DOC-01-009
Table of Contents
Section 1 - About this Manual................................................................1
1.1. Notes, Cautions and Warnings..................................................................... 1
Section 2 - System Overview...................................................................2
2.1. Overview..................................................................................................... 2
2.2. Features...................................................................................................... 2
2.3. System Description...................................................................................... 3
2.4. Internal Buzzer............................................................................................. 3
2.5. LCD Display................................................................................................. 4
2.6. Keypad........................................................................................................ 5
Section 3 - Operation...............................................................................7
3.1. Suggested Alarm Procedure........................................................................ 7
3.2. Fire Fighter Functions.................................................................................. 7
3.3. Global Operator Functions........................................................................... 8
3.4. Zone Operator Function..............................................................................11
3.5. Standard Outputs........................................................................................14
3.6. Relay Expansion Boards.............................................................................15
3.7. Printer Output.............................................................................................15
Section 4 - Installation...........................................................................16
4.1. Compatible Detectors .................................................................................16
4.2. Specification...............................................................................................17
4.3. Overview of IFS-2600 System Equipment...................................................20
4.4. Power Supply .............................................................................................21
4.4.1 Power Supply Ratings & Settings for NI-2017-01 & NI-2025-01 Boards......21
4.4.2. Power Supply Ratings & Settings for IFS-2005 & IFS-2006 Boards............ 23
4.4.3. Battery Type and Capacities......................................................................25
4.5. Technical Description..................................................................................26
4.6. Placing Into Operation.................................................................................33
Section 5 - Programming........................................................................36
5.1. Program Mode............................................................................................36
5.2. Zone Options & Programming.....................................................................39
5.2.1. Zone Options............................................................................................. 39
5.2.2. Zone Programming.................................................................................... 40
5.3. Relay Options & Programming....................................................................42
5.3.1. Relay Options............................................................................................42
5.3.2. Relay Programming...................................................................................44

IFS-2600 Fire Indicator Panel Section 1
About this Manual
DOC-01-009
5.4. Global Options & Programming...................................................................46
5.5. Print Programming Data..............................................................................48
Section 6 Appendix.................................................................................49
6.1. Appendix A.................................................................................................49
6.2. Appendix B.................................................................................................50
6.3. Appendix C.................................................................................................52
6.4. Technical Drawings.....................................................................................59
6.4.1. System Sensor Conventional Detector Connection Diagram ......................59
6.4.2. Hochiki Conventional Detector Connection Diagram...................................60
6.4.3. Ancillary Connection Diagram....................................................................61
6.4.4. ASE Connection Diagram.........................................................................62
6.4.5. MIMIC Connection Diagram.......................................................................63
6.4.6. Dual Fan Connection Diagram...................................................................64
6.4.7. Exhaust Fan Connection Diagram..............................................................65
6.4.8. Supply Fan Connection Diagram................................................................66
6.4.9. Smoke Spill Fan Connection Diagram........................................................67
6.4.10. 10W EVAC Connection Diagram................................................................68

IFS-2600 Fire Indicator Panel Section 1
About this Manual
DOC-01-009 1
Section 1 - About this Manual
1.1. Notes, Cautions and Warnings
This manual contains notes, cautions and warnings to alert the reader as follows:
NOTE: Supplement information for a topic such as tips and references.
CAUTION: Information about procedures that could cause programming errors, runtime
errors, or equipment damage.
WARNING: Indicates information about procedures that could cause irreversible
equipment damage, irreversible loss of programming data or personal injury.

IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 2
Section 2 - System Overview
2.1. Overview
The overall intent of a fire protection system is to provide warning should smoke or a fire be detected.
The systems can be configured to alert occupants of the building, advise fire brigades and take necessary
action to either extinguish the fire and/or stop the fire from spreading. The fire indicator panel is an
essential part of a building fire protection systems, it must therefore be properly and carefully installed,
configured and maintained.
2.2. Features
The IFS-2600 Fire Indicator Panel (FIP) has many custom designed components along with
microprocessor and circuitry, ensuring greater reliability and suppression from external sources.
The FIP uses both a liquid crystal display and conventional LED displays for fast and accurate display of
system status and changing events.
A custom designed membrane keypad is used together with the liquid crystal display and LED indicators
to provide fast, efficient and simple modes of operation. The keypad also provides the required flexibility
for the programming of many user configurable options of this FIP. The FIP can be configured on-site
without the need of expensive programmers or components. These configured options are retained by
the FIP even if the power is totally disconnected.
A serial printer can also be connected if required. The printer can be used to output programming
information for ease of modification, for safekeeping and to assist in the commissioning of the installation.
The IFS-2600 uses serial chain mimic outputs which significantly saves time and costs of cabling to mimic
panels.
A door holder power supply is incorporated into the system for the release of smoke and fire doors on
alarm (Optional transformer may be used).
IFS-2600 is available in a standard 8-zone configuration and can be upwards expandable to its fully
expanded state as required. IFS-2600 in its fully expanded state can;
• Monitor 64 detection zones
• Control 64 optional "mapped" relay outputs
• Output to a serial printer
• Output serially to a mimic panel (Max seven panels)
• Control up to 30 door holders
• Interface as required to any Australian Fire Brigade
IFS-2600 has been designed to be functional, flexible and reliable whilst maintaining a user-friendly
environment.

IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 3
2.3. System Description
The basic IFS-2600 Fire Indicator Panel (FIP) consists of
Quantity
Description
1Wall Mounting Cabinet with Manual Call Point
1Main Control Board (Located on inside of inner door) –CPU – NI-2004-01
1Main Termination Board (Located in rear of panel enclosure) – NI-2025-01
1NPS Brick Power Supply(2.6A/5.6A/11.7A)
1Power Supply Interface Board (PSI) – NI-2017-01
For Older IFS-2600 Panels,
1Mains Transformer
1Main Control Board (Located on inside of inner door) –CPU – IFS-2004
1Power Supply PCB fitted to Main Termination Board – IFS-2005
1Power Supply Interface Board (PSI) – IFS-2006
Optional equipment that may be found fitted to the IFS-2600 FIP
Maximum
Quantity Description
2Batteries 12V
7Zone Expansion Board (8 Zone)
4Display Expansion Board (16 Zone)
8Relay Expansion Board
For Older IFS-2600 Panels,
1Door Holder Power Supply Transformer
Table 2-1, IFS-2600 Panel Components
IFS-2600 requires the basic equipment as listed above to function. The microprocessor and other
sensitive electronic components are located on the Main Processor Board, located on the inner panel that
can be easily removed during installation to allow improved terminal access.
Power supplies and I/O's are located on the main Termination Board. Terminated to this board, at a
minimum, should be the NPS brick power supply, batteries, bell and at least one AZF circuit.
With the cabinet outer door closed, the viewing window allows a clear view of the keypad, LCD and
LED's.
2.4. Internal Buzzer
A buzzer is located on the main termination board to provide an audible alert to persons in the near
vicinity of the FIP of a fault or a zone has gone into alarm. This buzzer sound can be activated or heard
by hitting any key on the keypad.
The buzzer is also used for "audio-feedback" during keypad operation; one short beep as any key is
depressed verifies the key operation.
One long beep (approx 2 seconds) indicates that an incorrect entry has been made.
Two consecutive short beeps verify entry into a different mode, i.e. "ALARM TEST MODE", "ISOLATE
MODE" etc.

IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 4
2.5. LCD Display
In addition to the LED's a 16-character x 2-line liquid crystal display is provided to indicate system status,
changing events and programming information. Any keystroke or event will actuate the backlighting on
the display for better readability in dark areas. The backlighting will automatically turn off in 30 seconds if
no further keys are pressed.
The primary task of the LCD is for programming and subsequent configuration of the fire indicator panel.
The LCD is also used to indicate the current mode of operation, e.g. "ISOLATE MODE", "ALARM TEST
MODE" etc. The LCD is also used as a prompt for user entries e.g. "ENTER ZONE #".
When the panel is in the normal mode of operation, the LCD displays and constantly updates the current
zone status including the total number of;
Zones In Alarm – A=00
Zones In Fault – F=00
Zones Isolated – I=00
Current Date
Current Time (As per the settings)

IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 5
2.6. Keypad
The custom-designed 30 key membrane keypad is the users interface to accessing all zone and global
functions of the IFS-2600.These 30 keys consist of;
Figure 2-1, IFS-2600 Keypad
1. Five Specialised single-stroke Fire Fighters Keys
2. Four Zone function keys
3. Twelve Keys for Numeric Entry
4. Five Global function keys
5. Four Programming Keys
Operations and functions of these keys are explained in Section 3
Fire Fighter’s
Keys
Zone Function
Keys
Numeric
Keys
Global Function
Keys
Programming
Keys
EXT BELL ISOLATE ALARM TEST 0 – 9 Keys
ENT Key
ALL Key
AUTO TEST PREVIOUS
WARN SYS
ISOLATE FAULT TEST ACF ISOLATE NEXT
ACK ISOLATE ACF RESET SELECT
RESET RESET WALK TEST EXIT
ISOLATE BATT TEST
FIRE FIGHTER
’
S FACILITY
BELLS
WARNING SYSTEM
ACF
1
2
3
4
5
6
7
8

IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 6
Qty Descriptor Colour Function Buzzer
1 MAINS ON Green Illuminates when there is AC supply to the panel.
1BATTERY
FAULT Yellow Illuminates if the battery fails a battery test.
Illuminates if batteries are disconnected >30 seconds.
Illuminates if batteries are short circuit >30 seconds. Yes
1 PSU FAULT Yellow Illuminates if the power supply is outside the manufacturers
range. (Also if power supply is disconnected) Yes
1CHARGER
FAULT Yellow Illuminates if the battery charger is outside the recommended float charge voltage. Yes
1COMMON
FAULT Yellow
Illuminates if there is Any fault;
Any un-isolated zone is in open circuit fault.
ACF output is open or short circuit
Bell output is open or short circuit
Warning System output is open or short circuit
Power Supply Fault including Battery or Charger
MAF Isolate Input is Open Circuit
Configuration Fault
Yes
1 ACF ACT Red Illuminates if the ACF output has been activated.
1 ACF FLT Yellow Illuminates if the ancillary circuit is open or short circuit. Yes
1 ACF ISO Yellow Illuminates if the ancillary output has been manually
isolated.
1 Bell ACT Red Illuminates when the bell output has been energised.
1 Bell FLT Yellow Illuminates if the bell circuit is open or short circuit. Yes
1 Bell ISO Yellow Illuminates if the bell output has been manually isolated.
1Warning
System ACT Red Illuminates if the Warning System output has been energised.
1Warning
System FLT Yellow Illuminates if the Warning System circuit is open or short circuit. Yes
1Warning
System ISO Yellow Illuminates if the Warning System has been manually isolated.
8ALARM
LEDS Red
This LED will flash if its corresponding zone goes into
alarm. It will remain flashing until it is Acknowledged at
which time it will go steady and remain on until the alarm is
reset. If the zone is programmed as a time delay type, a
steady LED indicates the “pre-alarm” condition. If the zone
is isolated and in alarm it will also be steady.
Yes
8 FAULT LEDS Yellow This LED illuminates if it's corresponding zone goes into
fault. It will remain on until the fault is removed. Yes
8ISOLATE
LEDS Yellow This LED illuminates if its corresponding zone is isolated. It
will remain on until the zone is de-isolated.
Table 2-2, Key Pad Description

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 7
Section 3 - Operation
3.1. Suggested Alarm Procedure
The following is a suggested alarm procedure for use by building fire officers or duty wardens. The fire
indicator panel is designed for use by qualified fire fighters and it is strongly recommended that the fire
panel not be operated in an emergency situation by anyone other than suitably qualified fire fighters.
Do not open fire indicator panel door or press any buttons until fire officers arrive
Determine location of the fire by inspecting the label beside any lit red zone alarm LEDs on the
Panel (Location -> number).
Visually inspect area at a safe distance for actual fire or false alarm.
Notify fire-monitoring station of either result.
Perform evacuation and extinguishing operations as required.
IF a FIRE, direct fire fighters to the fire indicator panel and cause of alarm as they arrive.
IF a FALSE ALARM, advise maintenance technicians to determine and rectify cause.
Record all events in logbook.
3.2. Fire Fighter Functions
Fire Fighter Functions are those specifically used by the Fire Brigade on attendance. Following is an
explanation of their operation and the keystrokes required to perform the function required. These keys
are located at the top of the keypad marked “FIREFIGHTER’S FACILITY” and bordered in red.
The purpose of the internal buzzer is to alert people of a new event on the panel, and a new potential fire
danger. Once the fire's location has been determined, the fire-fighter may wish to silence the internal
buzzer without having to totally reset the alarm.
When the buzzer is operating, pressing the "ACK" key once will silence it, however the External Alarm
Bell will continue to sound. If a subsequent alarm arises, the buzzer will be reactivated and a second
ACK operation will be required to silence it.
When an alarm is acknowledged, the Alarm LED will stop flashing and light continuously.
RESET RESET
The reset function momentarily disconnects power and resets all alarm parameters for the zone(s) that
have been acknowledged. This returns the zone back to its "normal" state. The reset key only operates
on zones with acknowledged alarms.
NOTE: A suitably qualified fire officer should perform the above procedure. These are
suggested procedures only, and if specific fire procedures are available or issued, they
must prevail.
ACKNOWLEDGE ACK

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 8
ISOLATE ISOLATE
The isolate function prevents the transmission of alarms or faults from the zones to the master alarm
facility. The isolate key only operates on zones with acknowledged alarms.
BELL ISOLATE EXT BELL
ISOL
Pressing the "EXT BELL ISOLATE" key will isolate the bells. The "Ext Bells Isolate" LED will illuminate
and the bells will not sound until the bells are de-isolated. Pressing "EXT BELL ISOLATE" a second time
will de-isolate the bell.
WARN SYS ISOLATE WARN SYS
ISOL
Pressing the "WARN SYS ISOLATE" key will isolate the warning system. The "Warn Sys Isolate" LED
will illuminate and the warning system will not operate in the event of an alarm.
Pressing "WARN SYS ISOLATE" a second time will de-isolate the warning system.
3.3. Global Operator Functions
Global functions are those relating to the overall system and are not specific to particular zones.
Following is an explanation of their operation and the keystrokes required to perform the function.
BATTERY TEST BATT
TEST
For NI-2025-01 & NI-2017-01 Boards:
Press BTST/RST button located on the PSI board to start the Battery test. Once this key is pressed a
Yellow light illuminates next to the B.TST location on PSI board. This yellow light automatically turns off
after one hour, indicating the end of Battery test.
To manually turn off the Battery test, press the same button once again. Yellow light turns off, indicating
the end of battery test.
NOTE: Battery test button on keypad will not function.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 9
For IFS-2005 & IFS-2006 Boards:
This function tests the performance of the batteries fitted to the system. Pressing this button will initiate a
battery test as specified in AS4428. The test will temporarily disconnect the batteries from the panel and
apply load on the batteries for 15 seconds.
The result of the test will be displayed on the LED's. If the "Battery Fault" LED is on, only a successful
battery test will turn the LED off. The pressing of any key during the test period will abort the battery test
and return the system back to normal mode.
This function will perform a fixed automatic test procedure to the panel. This mode cannot be selected if
any zone(s) is in alarm. Auto test will perform the following test functions;
1. Displays firmware revision REV-6
2. Turn on ALL LEDs for 0.5 seconds
3. Test LCD Backlighting
4. Test Panel memory(E2ROM & RAM)
5. Test LCD
6. Isolate all alarm zones
7. Fault test all alarm zones
8. Alarm test all alarm zones
9. Test buzzer (Beeps twice)
WALK TEST MODE WALK
TEST
This function will place the panel into "walk test" mode. Walk test mode is used for the on-site testing of
detector zones. This mode cannot be selected if any zone(s) are in alarm.
When WALK TEST button is pressed, panel will be automatically placed in walk test mode, which is
acknowledged by two buzzer beeps and LCD displays “WALK TEST MODE, PRESS ANY KEY TO
EXIT”.
Selecting any key from the keypad triggers the buzzer to beep twice and activates the BELL relay leading
BELL ACT LED to blink thrice.
NOTE: Battery test function is disabled when the panel is in alarm condition.
AUTO TEST MODE AUTO
TEST
NOTE: Pressing of any key during "AUTO TEST" will abort the tests and return the system back
to normal mode once the current test is complete.
During "AUTO TEST", all zones are treated as zone type #1 (standard latching type with
2 Second delay). Once AUTO TEST has finished, all zones will be reset and returned
back to their previously configured types.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 10
For the duration of walk test mode, all zones are changed to output configuration #2 (indicate and ring
bells only) and all zones are set to type #1 (standard latching, 2 second).
If the bells are not required to ring during walk test, simply press the "EXT BELL ISOLATE" key once. The
EXT BELL ISOLATE LED will illuminate to verify that the bells have been isolated.
Any alarm signal from detectors will be received by the panel on its appropriate zone. The panel will
beep to acknowledge receipt of the alarm and indicate the alarm by illuminating the appropriate alarm
LED for 4 seconds (the bells will also ring for a 3 second period unless previously isolated).
The zone and detector will then be automatically reset for 15 seconds.
If the optional printer is connected, the alarm will be printed out as it is received. This can eliminate the
need for a second serviceman to record zone numbers during walk test and the printout can be retained
for verification at a later date.
Pressing any key will terminate the walk test mode and return the panel back to normal operation,
restoring all zone types and output configurations also ensuring that bell and ancillary outputs are de-
isolated. The bells will give three pulses of 1 second each to warn any testers still in the building that walk
test mode has been terminated.
Failure to receive any alarms or keystrokes within a 15 minutes period will result in the panel
automatically exiting walk test mode and returning back to normal as follows:
1. Bell outputs to be de-isolated.
2. Ancillary outputs to be de-isolated.
3. Bell will sound 3 times, each of 1-second duration.
4. Exit from walk test mode.
5. Zone types and output configurations restored
ACF ISOLATE ACF
ISOL
Pressing the "ACF ISOLATE" key will isolate the ACF (Ancillary output) and the Door Holder Output. The
ACF isolated LED will illuminate and the output will not operate until de-isolated. Pressing "ACF
ISOLATE" for a second time will de-isolate the output.
If the ancillary output has already been tripped and is programmed as latching, isolating the ACF will not
affect the existing ancillary output. If the ACF is isolated prior to the alarm, it will prevent the ancillary
output from tripping. This does not apply to the Door Holder output.
ACF RESET ACF
RESET
Resetting of the ancillary output (ACF) is only required if the ancillary output was programmed as
latching.
The ancillary alarm will remain latched until manually reset. Pressing the "ACF RESET" button will
extinguish the 'ACF Activated' LED and de-energise the ancillary output. Pressing "ACF RESET" when
the ACF is not tripped will have no effect.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 11
3.4. Zone Operator Function
Zone functions are those relating specifically to the detection zones. Following is an explanation of their
operation and the keystrokes required to perform the function required.
ALARM TEST ALARM TEST # ENT
The alarm test function momentarily disconnects the detector lines of the zone(s) under test and
simulates a detector going into alarm, therefore testing the zone(s) alarm detection capability.
A resistive load equal to worst case alarm condition is placed on the zone for a period of 120 seconds
and then removed. If the zone being tested is not a latching type, the alarm will reset automatically once
the load is removed. Acknowledging and resetting the alarm will terminate an alarm test.
Once the zone has alarmed, all outputs are initiated (as programmed) similar to a real alarm. The zone
may be isolated prior to an alarm test if desired; this will prevent any outputs from operating.
‘#’ in the above key sequence is the zone number, which can be selected using Numeric keys on the
keypad.
If only one zone is to be tested, use the appropriate number. Alternatively the "ALL" button can be used to
simultaneously test all zones.
To perform an alarm test:
1. Press the "ALARM TEST" button once; the buzzer will give 2 short beeps to indicate that alarm
test mode has been entered
2. The LCD display will read "ALARM TEST MODE, ENTER ZONE No"
3. Now enter the zone number Individual zone ("#") 1 - 64 or select “ALL” key
4. Press "ENT"
If a correct entry is made, alarm testing on the zone commences immediately. However remember there
is a 2 second transient delay on all zones. It will therefore take approximately 2 seconds before the zone
registers an alarm (this could be longer, depending on zone type).
LED’s on the respective selected zone(s) will start blinking with a continuous buzzer sound and a red LED
light is illuminated next to BT INH location on PSI board.
Pressing ACK acknowledge key stops the buzzer sound and blinking LED automatically turns into
continuous lighting.
Pressing RESET key automatically brings panel to its normal condition.
A long beep will signify an incorrect entry and will revert back to normal operating mode. The "ALARM
TEST" button will need to be pressed again to re-enter alarm test mode.
NOTE: This LED is for new IFS-2600 termination boards(NI-2025-01) only.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 12
FAULT TEST FAULT TEST # ENTER
The fault test function momentarily disconnects the detection zone(s) under test and simulates the worst-
case condition for fault.
A resistor load equal to worst case fault is placed on the zone continuously for 5 seconds then the zone is
returned back to its normal condition.
If several zones are being tested consecutively and are being entered at a rate faster than the 5-second
fault timer, the fault timeout will occur 5 seconds after the last entry was completed.
Once the zone has registered a fault, all outputs relating to that zone are initiated similar to a real fault.
The zone may be isolated prior to a fault test if desired. This will prevent any outputs from operating.
‘#’ in the above key sequence is the zone number.
If only one zone is to be tested, use the appropriate zone number. Alternatively the "ALL" button can be
used to simultaneously test all zones.
To perform a fault test on a particular zone or on all zones:
1. Press the "FAULT TEST" button once. The buzzer will give 2 short beeps to indicate
that fault test mode has been entered.
2. The LCD display will read "FAULT TEST MODE, ENTER ZONE No.".
3. Enter the zone number ("#") 1-64 or “all”.
4. Press "ENTER".
If a correct entry is made, fault testing on the selected zone(s) commences with a long beep of about 10-
15 seconds and an illuminated fault LED next to the selected zone(s).
A long beep will signify an incorrect entry and the panel will revert back to normal operating mode. The
"FAULT TEST" button will need to be pressed again to re-enter fault test mode.
ISOLATE ISOLATE # ENTER
The isolate function prevents the transmission of alarms or faults from the zones, to the master alarm
facility.
‘#’ in the above key sequence is the zone number.
If only one zone is to be isolated, use the appropriate zone number. Alternatively the "ALL" button can be
used to simultaneously isolate all zones.
To isolate a particular zone or all zones:
1. Press the "ISOLATE" button. The buzzer will give 2 short beeps to indicate that isolate
mode has been entered.
2. The LCD display will read "ALARM ISOL. MODE, ENTER ZONE No.".
3. Enter the zone number ("#") 1-64 or “all”.
4. Press "ENTER".
A long beep will signify an incorrect entry and will revert back to normal operating mode. The "ISOLATE"
button will need to be pressed again to re-enter isolate mode.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 13
If a correct entry is made, the zone is immediately isolated. If the zone is already in alarm, all of its alarm
outputs are isolated and indicators remain visible.
If the "ALL" function is performed, all zones will be isolated, regardless of their previous state. Performing
the "ALL" function for a second time will de-isolate all zones.
RESET RESET # ENTER
The reset function momentarily disconnects power, and resets all alarm parameters for the zone(s) being
reset. This returns the zone back to its "normal" state.
‘#’ in the above key sequence is the zone number.
If only one zone is to be reset, type in the zone number. Alternatively the "ALL" button can be used to
simultaneously reset all zones.
To perform a reset on a particular zone or on all zones:
1. Press the "RESET" button. The buzzer will give 2 short beeps to indicate that reset mode has
been entered.
2. The LCD display will read "ALARM RESET MODE, ENTER ZONE NO".
3. Enter the zone number ("#") 1-64 or “all”.
4. Press "ENTER".
A long beep will signify an incorrect entry and will revert back to normal operating mode. The "RESET"
button will need to be pressed again to re-enter reset mode.
If a correct entry is made, resetting of the zone begins immediately. Any alarm indication will be removed
immediately; also resetting the zone(s) programmed outputs.
NOTE: If the Zone is still active after the RESET function, it will automatically revert back to
alarm mode.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 14
3.5. Standard Outputs
Output Type Description
Standby

Change
over relay
contact
Normally energised relay: Will de- energise if system volts fall below 21V. This
usually means AC has failed and batteries are getting low. I.e. panel is about
to shut down.
Brigade
Alarm #1
Change
over relay
contact
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non- isolated zone(s) in alarm. (Programmable)
Brigade
Alarm #2
Change
over relay
contact
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non- isolated zone(s) in alarm. (Programmable)
FaultChange over relay
contact Normally energised relay: Will de-energise if a common fault is registered.
Mains Fail
(NV)
Change
over relay
contact Normally energised relay: Will de-energise if the AC fails
Isolate Change over relay
contact Normally de-energised relay: Will energise if any zones are isolated.
General
Alarm 1
Change
over relay
contacts
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non-isolated zone(s) in alarm. (Non-Programmable)
General
Alarm 2
Change
over relay
contacts
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non-isolated zone(s) in alarm. (Non-Programmable)
Bell
Monitored
24 VDC
Output 1A
Fused
Normally de-energised: Output will energise if requested by the zone output
configuration of the non-isolated zone(s) in alarm. Will remain energised until
alarm is reset or warning system is isolated.
Warning
System
Monitored
24 VDC
Output 1A
Fused
Normally De-energised: Output, will energise if requested by the zone output
configuration of the non- isolated zone(s) in alarm.
Ancillary
(ACF)24 VDC Output 1A
Fused
If ancillary is set as non-latch: Ancillary will remain energised until alarm(s) is
reset.
If ancillary is set as latching: Ancillary will remain energised until ancillary is
manually reset from the keypad. Even if the zone has been reset.
Door
Holder 24 VDC Output up
to 3A
Normally energised 24VDC output: Will de-energise on general alarm.
NOTE: This output is isolated through the ACF Isolate Function.
Auxiliary
Power 24 VDC Continuous Power output for use with ancillaries (500mA maximum).
Mimic
Outputs Serial four wire mimic
outputs
This output mimics the status of all alarm zones fitted on the panel to a remote
mimic panel in the building.
Table 3-1, Standard Outputs
NOTE: Normally energised (fail safe) relay
Monitored circuit, EOL resistor or load is required.

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 15
3.6. Relay Expansion Boards
The maximum number of boards that can be fitted is eight (i.e.: 64 relays). Each board contains 8
change-over relay outputs. Relays can be programmed to simulate:
Brigade Alarm Relay #1
Brigade Alarm Relay #2
Fault Relay
Mains Fail Relay
Isolate Relay
General Alarm Relays
Bell Output
Ancillary Output
Door Holder Output
Door Switch
Reset
or can be used to
3.7. Printer Output
Located on the main termination board, a portable serial printer may be connected to the DB9 serial port
provided.
Most standard IBM compatible serial printers are suitable for this operation, which uses hardware
handshaking and will be enabled automatically.

AND MAP”
“OR MAP”
“MAP FAULT”
“MAP ISOLATE”
“MAP ISO/FLT”
Up to 5 zones in Alarm
Up to 5 zones in Alarm
Up to 5 zones in Fault
Up to 5 zones in Isolate
Up to 5 zones in Fault or Isolate
