Notifier ID50 SERIES Instruction Manual

ID50/60 installation,
commissioning &
configuration
manual
997-263, Issue 4 September 2002

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
i 997-263, Issue 4
Se tember 2002
Contents
1 Introduction 1
1.1 Manual Purpose 1
1.2 System Design and Planning 1
1.3 General 2
1.3.1 Date-dependent Functions 2
1.4 CE Marking 3
1.5 EN54 unctions 3
1.6 Ancillary unctions 4
1.7 Related Documents 5
1.8 Warnings and Cautions 5
1.9 Tips 5
1.10 Glossary of Icons 6
2 Installation Guide 7
2.1 How to Use this Section 7
2.2 Pre-Installation Check List 7
2.1.1 Some Panel DOs and DONTs 7
2.3 Transient Protection 8
2.4 Product Inspection 9
2.4.1 Chec ing Your Panel for Damage 9
2.4.2 What to do if Panel is Damaged
or Suspect 10
2.5 Dismantling the Panel 11
2.5.1 Removing the Cover 11
2.5.2 Removing the Panel Electronics 12
2.5.3 Bac Box Fixing 13
2.5.4 Semi-Flush Mounting Bezel (Optional) 14
2.6 Assembling the Panel 15
2.7 RS485 Communications Link 16
2.7.1 Fitting the RS485 Interface Module PCB 17
2.8 RS232 Interface Connections 18
3 Cabling 19
3.1 Cabling Instructions 19
3.1.1 Cable Terminations 20
3.2 Cabling Installation Notes 21
3.2.1 Introduction 21
3.2.2 Quality of Cable and of Cable Installation 21
3.3 EMC Considerations 22

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
ii997-263, Issue 4
Se tember 2002
3.3.1 Screen Termination 22
3.3.2 Ferrite Sleeves (Optional) 22
3.4 MICC Cables 22
4 Commissioning 23
4.1 Introduction 23
4.2 Preliminary Checks 23
4.3 Internal Checks 24
4.3.1 Jumper Lin Options 24
4.4 External Wiring Checks 25
4.4.1 Loop Wiring 26
4.4.2 RS485 Communications Lin 27
4.4.3 DC Auxiliary Output 27
4.4.4 Sounder Circuit Outputs 28
4.4.5 CFG Outputs C and D 29
4.4.6 -VE Outputs 30
4.4.7 Digital / ÜE Inputs 30
4.4.8 Switch Connections 30
4.5 Powering the Panel 31
4.5.1 Start-up Language Selection 31
4.5.2 Batteries 32
4.6 Configuration and Handover 33
4.7 Commissioning Tests 34
4.7.1 Test LEDs 34
4.7.2 Test LCD 34
4.7.3 Test Zones 34
4.7.4 Test Auto High Test 34
4.7.5 Test Outputs 34
4.7.6 Test Buzzer 34
4.7.7 Test Keyboard 34
4.8 Sensors and Modules 35
4.8.1 EN54 Requirements 35
4.8.2 Loop Wiring Testing 35
5 Configuration 36
5.1 Introduction 36
5.2 Navigation and Number Entry 36
5.3 Level 2 Configuration Options 36
5.4 Level 3 Configuration Options 37
5.5 Setup Options 38
5.5.1 Language 38

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
iii 997-263, Issue 4
Se tember 2002
5.5.2 Date Format 39
5.5.3 Primary/Extend Delay Timers 39
5.5.4 Extinguishing System Delay 40
5.5.5 Extinguishing System Soa 40
5.5.6 Hold Switch Operation 41
5.5.7 Device Blin ing 41
5.5.8 Pulse On/Off Ratio 42
5.5.9 Service Phone Number 42
5.5.10 Site Name 43
5.5.11 Control Keys 43
5.5.12 RS232 Protocol 44
5.5.13 Print Control or Third Party 44
5.5.14 Repeater Protocol 45
5.5.15 Number of Repeaters 46
5.5.16 Transmission Device 46
5.5.17 FW4Input Disable 46
5.5.18 Digital Input 1 47
5.5.19 Day Mode Activity 48
5.5.20 Wee end Night Mode 49
5.5.21 Auto High Test 49
5.5.22 Diagnostic Mode 50
5.5.23 VdS Compatibility 50
5.6 Circuit Options 51
5.6.1 Signalling Line Circuit (SLC) - Devices 51
5.6.2 Signalling Line Circuit (SLC) - Learn 59
5.6.3 On-Board Circuits 60
5.7 Control-By-Event Output Rules 62
5.7.1 Output Type 65
5.7.2 Filter-by-type 66
5.7.3 Evacuation 67
5.7.4 Silence 67
5.7.5 Interrupt Delay 68
5.7.6 Class Change 68
5.7.7 Two Zone 69
5.7.8 Zones 70
5.7.9 Device Inputs 71
5.7.10 Soa Timer 72
5.8 Zone Texts 72
5.9 Access Options 74

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Contents
iv997-263, Issue
September 2002
5.10 System Options 75
5.10.1 Crystal Frequency 75
5.10.2 Wipe Memory 76
5.11 Normal 76
Appendix 1 - Specification A1-1 to A1-6
Appendix 2 - ID60 Sin le Loop Panel
Differences A2-1 to A2-5

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
1 997-263, Issue
October 2002
1 Introduction
1.1 Manual Purpose
This purpose of this manual is to provide the user with
all recommended procedures and full technical details
for the successful installation, commissioning and
programming of a NOTIFIER ID50 Series Panel.
The descriptions and procedures also apply to the
NOTIFIER ID60 panel. Differences between the ID50 and
ID60 panels are given in Appendix 2.
Procedures described in this manual include appropriate
warnings and cautions to guide the user towards adopting
safe and methodical work practices during the installation,
commissioning and programming phases.
Important Note
This manual must be read, and its content clearly
understood, before proceeding with any work relating to
the ID50 Series Panel. Damage to the control panel may
result from NOT following the recommended procedures
described in this manual.
This manual provides all necessary instructions for the
ID50 Series Panel and applies only to fire panels fitted
with compatible software.
CAUTION: In particular, care must be taken when
powering up down any repeaters.
If there are any areas of doubt, consult your supplier
before continuing with the system installation,
commissioning and programming.
1.2 System Design and Planning
It is assumed that the system, of which the ID50 Series
Panel equipment is a part, has been designed by a
competent fire alarm system designer in accordance with
the requirements of EN5 Part 1 and any other local
codes of practice that are applicable.
The design drawings should clearly show the positions
of all the ID50 Series Panel control equipment and field
devices.

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
2997-263, Issue 4
ctober 2002
1.3 General
The ID50 Series Panel is designed for use with
N TIFIERs range of addressable analogue sensors,
control and monitoring modules and addressable call
points. A unique signalling protocol is used, having digital
address and control signals and analogue pulse width
monitoring for the reply data from devices.
The serial communications interface operates under
RS485 protocol and enables communications between
the fire panel and repeaters.
While every effort is made to ensure the accuracy of the
content of this manual, the manufacturer reserves the
right to change the information without notice.
Installation
The ID50 Series Panel is easy to install providing the
recommended procedures described in this manual are
followed. To avoid inadvertent contamination of the PCB
Assembly, the manufacturer recommends it be installed
in the back box only after all other trades have completed
their tasks.
Commissioning
To commission the ID50 Series Panel, follow the
recommended procedures described in this manual. The
manufacturer recommends that during commissioning
and maintenance, ALL RS485 signal cables are
disconnected at the Panel end, BEF RE powering down
the system and are connected AFTER powering up the
system.
Configuration
To configure the panel and system, carefully read and
follow the procedures given in this manual. These
procedures describe the menus that are displayed on
the Liquid Crystal Display (LCD) Unit.
Refer to the ID50 Series perating manual (ref: 997-
264) for a description of compatible addressable
Signalling Loop Circuit (SLC) analogue devices.
1.3.1 Date-dependent Functions
The calendar end date for this product is 31/12/2063
(two thousand and sixty-three) and it will perform correctly
up to this date.
The calendar function has not been tested beyond
this date.
Only fit the electronics
module after all the other
trades have completed
their tasks!
Only suitably-qualified
engineers must install,
commission and
configure this product

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
3 997-263, Issue 4
ctober 2002
1.4 CE Marking
This panel is CE Marked to show that it conforms to the
requirements of the following European Community
Directives:
nElectromagnetic Compatibility Directive 89/336/EEC
(and the amending Directives 92/31/EEC, 93/68/EEC)
nLow Voltage Directive 73/23/EEC (and the amending
Directive 93/68/EEC).
1.5 EN54 Functions
This fire control panel is designed to comply with the
requirements of EN54 Part2/4:1997. In addition to the
basic requirements of EN54-2, the panel may be configured
to conform with the following optional functions - the
applicable clauses of EN54-2 are referenced as follows:
Options Clause
Indications:
Fault signals from points 8.3
Recording of the number of entries
into fire alarm condition 7.13
Controls:
Coincidence detection 7.12
Dela of the immediate actioning of outputs 7.11
Disablement of each address point 9.5
Test condition 10
Outputs:
Fire alarm device(s) (Sounders) 7.8
Fire alarm routing equipment 7.9
Fire protection equipment 7.10
Fault warning routing equipment 8.9
(requires monitoring b fault routing equipment)
The following features are provided by the Power Supply
Unit (PSU) of the ID50 Series Panel to comply with
EN54-4.
Features of the ID50 EN54-4
Power Supply Unit (PSU Clause
Derive power from the mains suppl 5.1
Derive power from a standb batter source 5.2
Charge and monitor the standb
batter /batteries 5.3
Detect and signal various PSU faults 5.4

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
4997-263, Issue 4
ctober 2002
1.6 Ancillary Functions
The following is a list of ancillary functions that are
provided by the ID50 Series panel in addition to the those
required by EN54-2/4. These functions are described in
the section of this manual as referenced (except those
marked thus * which are described in 997-264-XXX,
ID50 Series Panel-Operating Manual):
Ancillar Manual
Functions Section Refs.
Site Specific Setup Options 5.5
Access Options 5.9
Voltage Indications *4.11.7
Control-b -Event 5.7
Output modes 5.7.1
Input t pe pattern 5.7.9
Disable/enablement *4.9
Repeater interface 2.7
Self-learn configuration - manual 5.6.1
Self-learn configuration - auto 5.6.2
Module supervision options 5.6.1
Module silence options 5.7.4
Text editing 5.8
Sensor LED blinking on/off 5.5.7
Bell pulsing ratio 5.5.8
Displa of alarm count *4.11.6
Extend dela timer 5.5.3
Sounder Volt-free contact options 4.4.5
Rela drive output option 4.4.6
Extinguishing s stem features 5.5.4, 5.5.5, 5.5.6,
5.7.1

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
5 997-263, Issue
September 2002
1.7 Related Documents
This manual only describes the installation,
commissioning and configuration of the ID50 Series
Panel. All operating functions are covered by the:
nID50 Series Panel Operating Manual (ref:
997-26 -XXX)
Note: XXX is the country code for the manual. For the
UK this code is blank.
The Panel can support repeaters via the RS 85
communications link. This manual does not provide
details about the repeaters; these are described in:
nIDR-2A, -2P & -6A Repeaters User Manual
(ref:997- 11-XXX).
nIDR Mimic Installation and Commissioning Manual
(ref:997- 12-XXX).
Note: XXX is the country code for the manual. For the
UK this code is blank.
The ID50 Panel can also support the VIEWTM sensor.
This manual does not attempt to cover all the VIEWTM
sensor programming and calibration issues as these are
described in some detail in the following, which is
available from NOTIFIERs Technical Support
Department:
nVIEWTM Application Guide (ref:997-198).
1.8 Warnings and Cautions
Where appropriate, the manual includes advisory
warnings and cautions to remind you to consider safety
at all times, especially when following the procedures
described herein.
You are alerted to any areas where high voltage [i.e. non-
Safety Extra-Low Voltage (SELV)] is present, or where
there may be a risk of damage to static-sensitive devices
if the recommended procedures described in this manual
are not followed.
An example of a high voltage warning and an anti-static
caution is provided to the left of this paragraph.
The ID50 Series Panel incorporates some features
which, if used inappropriately, may contravene the
requirements of EN5 . Where there is a possibility of
such an occurrence, a suitable warning is given with brief
details of the EN5 requirement. A typical EN5 non-
compliance warning is illustrated at left.
1.9 Tips
Handy tips are included, where appropriate, to assist
you in following quick and safe procedures for fire
detection system installation and integration.
Look for the TIP! icon and supporting text, typically
illustrated at left.
Magnetise the tip of your
screwdriver to help when
offering small screws to
holes in confined spaces.
W RNING: High Voltage!
Take suitable precautions to
avoid electric shock
EN54-2:-8.8
One hardware-
configurable output
must be configured
as a fault relay

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Introduction
6997-263, Issue
September 2002
1.10 Glossary of Icons
Throughout this manual, and the other related ID50
Series Panel manuals, a number of icons are used either
as part of the illustrated process descriptions, or in the
main text to help clarify, or simplify, particular
configuration procedures.
The following icons are used to advise or indicate:
a. DO follow the recommended procedure or method.
b. DO NOT use this procedure or method.
c. Inspection of an item or sub-assembly is required at
this point.
d. Following a defined process meets does not meet
the required approval/inspection criteria or standards.
e. Additional items to be considered.
f. This icon placed next to a pushbutton requires you to
press it while configuring the panel. Where two or
more icons are used, a number may be placed on or
near each hand to indicate the order of selection: 1
coming before 2.
g. Activity process step - flow arrow for single action or
iterative actions.
h. Leader arrow - used with activity processes.
i. Internal buzzer operating/not-operating or silenced.
j. Sounder operating/not-operating or silenced.
k. Power connected and switched ON/disconnected and
switched OFF.
l. Manual Call Point (MCP)/Sensor.

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
7 997-263, Issue 4
Se tember 2002
2 Installation Guide
2.1 How to Use this Section
This Installation Guide rovides guidelines on how to
install an ID50 Series Panel quickly and safely.
For each stage in the anel installation and
commissioning rocedures a brief descri tion is given of
its ur ose, com lete with detail drawings, flow diagrams
and/or other gra hics to make the instructions easy to
follow. Where required, rocedures may be broken down
into one or more related diagrams, the number being
de endent u on the com lexity of the defined task.
2.2 Pre-installation Check List
Before installing the ID50 Series Panel or fitting sensors,
you must first ensure that the following criteria have been
met. Failure to do this may not only result in damage to
the equi ment, but may also cause roblems when
commissioning the equi ment or adversely affect its
erformance.
2.2.1 Some Panel DOs and DONTs
Before selecting a location for the ID50 Series Panel,
DO make sure that:
a. The o erating ambient tem erature is in the
recommended range:
+5oC to +35oC and
b. The relative humidity is between:
5% and 95%
c. The anel is wall mounted in a osition which allows
clear visibility of dis lays and easy access to o erating
controls. The height above floor level should be chosen
such that the LCD is just above normal eye level
(a roximately 1.5 metres).

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
8997-263, Issue 4
Se tember 2002
d. DO NOT locate the anel where it is ex osed to high
levels of moisture.
e. DO NOT locate the anel where there are high levels
of vibration or shock.
f. DO NOT site the anel where there would be restricted
access to the internal equi ment and cabling/wiring
connections.
2.3 Transient Protection
This equi ment contains transient- rotection devices.
Although no system is com letely immune from lightning
transients and interference, for these devices to function
correctly, and to reduce susce tibility, this equi ment
must be earthed correctly.
As with all solid state devices, this system may o erate
erratically or can be damaged if subjected to lightning-
induced transients.
The use of overhead or outside aerial wiring is not
recommended due to the increased susce tibility to
nearby lightning strikes.

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
9 997-263, Issue 4
Se tember 2002
2.4 Product Inspection
The ID50 Series Fire Control Panels are relatively sim le
to install roviding the recommended rocedures
described in this Installation Guide are followed.
Follow all installation instructions described in this
manual. These instructions must be understood and
the manufacturers recommendations followed to
avoid damage to the control panel and associated
equipment.
2.4.1 Checking Your Panel for Damage
It is important to check all supplied equipment for
damage before proceeding with the installation!
Before attem ting to install your ID50 Series Panel, you
should do the following:
1After removing the anel, from its acking, and before
you roceed with installing it in its chosen location,
check for any damage that may have been caused
during transit.
Note In the unlikely event that the anel su lied has
been damaged, you MUST NOT install it but return
it to your su lier. The rocedure for returning faulty
items is described in Section2.4.2, What to do if
Your Panel is Damaged or Suspect.
2If you are satisfied that the anel has NOT been
damaged you can now roceed with the installation
rocedure. This manual addresses the recommended
installation methods of the anel. Refer to the relevant
sections that a ly to your configuration requirements.
To revent unnecessary damage to the electronic
com onents, the back box should be installed without
the electronics fitted. Refer to Sections2.5.1 to 2.5.3
for details.
To avoid damage to the
control panel ensure that
you follow these
instructions
1
2

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
10997-263, Issue 4
Se tember 2002
2.4.2 hat to do if Panel is Damaged or Suspect
If you have roblems regarding the quality of any su lied
order items including the control anel, its ancillaries or
this manual or items are missing, follow the rocedure
below:
1DO NOT continue with the installation but contact your
su lier for advice on what to do next.
Similarly, if the roduct is found to be faulty during
installation or while in use contact your su lier
immediately.
2To aid your su lier and the manufacturer, you are
requested to:
a. Quote the manufacturers unique batch reference
number which can be found on the ackaging or
inside the back box.
b. With reference to PCBs, quote the art number
and revision level which can be found along one
edge of the PCB - refer to the a licable section
of this manual for s ecific details.
c. Note all the details relevant to your com laint, date
of recei t, ackaging condition, etc. and forward
this to your su lier.
3Where the roduct needs to be returned to your
su lier, you are requested to use the original
ackaging, or suitable anti-static equivalent,
wherever ossible.
1
2
3

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
11 997-263, Issue 4
Se tember 2002
2.5 Dismantling the Panel
For installation ur oses, it is recommended that the
cover is removed from the back box and stored in a safe
lace until ready for commissioning.
If any other trades, e.g. lasterers or decorators, will be
working in the vicinity after fitting the ID50 Series Panel,
it is strongly recommended that before re-fitting the cover
you remove the anel electronics and store in a safe lace
until ready for commissioning. The main com onents
within the ID50 Series Panel are shown below.
ID50 Series Panel Assembly
A. Back box
B. PCB Assembly
C. LCD Unit
D. Fascia & Control Key ad
E. Cover
2.5.1 emoving the Cover
To remove the ID50 Series Panel cover, it is
recommended that the following rocedure is carried out
on a work bench BEFORE siting the anel on the wall:
1Remove the four M3 x 6mm screws and washers (A)
using a No.1 Posidriv screwdriver, or the four hex
button-headed screws and clear washers (B) using a
2mm hex key, from the cover, and store safely.
2Carefully withdraw the cover away from the back box,
until the earth blade terminal (C) within the cover is
accessible.
3Carefully detach the shrouded earth lead s ade
terminal (D) from the earth blade terminal (C) located
in the left-hand inner side wall of the cover.
Note All blade connections to earth incor orate a locking
barb. To make a connection ush the shrouded
rece tacle on to the earth blade (1). To remove
this connection, ull the shroud (2), NOT the earth
wire.
4Remove and store the cover in a safe lace.
Before installing the back box, remove the anel
electronics (see Section2.5.2, Panel Electronics).
AB
CD
E

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
12997-263, Issue
October 2002
2.5.2 Removing the Panel Electronics
The ID50 Series Panel electronics comprises the PCB
assembly with mounted LCD unit and the mounted fascia.
These are supplied as one spared item in kit
PN:020-635-XXX. This assembly is located within the
back box, but should ONLY be removed when installing
the back box or if the PCB requires replacement.
CAUTION: The electronic circuits of the ID50 Series
Panel use CMOS devices which can e damaged y
static discharge. Suita le precautions MUST e taken
when handling circuit oards.
Procedure
When installing the back box or, if it becomes necessary
to remove the PCB assembly for another reason, follow
this recommended procedure:
1Remove the cover and store in a safe place, see
Section2.5.1, Removing the Cover. Then make a
back-up of the current system configuration,
remembering to disconnect the link at jumper J19.
Note: The blade connection to the cover fitted in back
boxes incorporates a locking barb. To remove this
connection, pull the shroud (B), NOT the earth wire,
from the earth blade terminal (A).
2Isolate the mains power supply and disconnect the
battery interlink wire if fitted.
3At the two-part connector TB1 (on the PCB assembly),
using a constant pulling action carefully disconnect
the mains and battery power supply wiring.
4Taking suita le anti-static precautions remove the
RS 85 Interface PCB, if fitted (refer to Section2.7.1,
Installing the RS485 Interface Module PCB).
5At the PCB assembly, note the polarity and
connections of all cables and any jumper configuration
settings. Using a screwdriver, loosen all the connector
securing screws. Carefully secure all external cable
tails away from the electronics and from the back box.
6Using a No.1 Posidriv screwdriver, remove the eight
(8) M3 x 8mm clinch screws from the PCB assembly.
Gently lift the PCB assembly clear of the supporting
pillars, place it in an anti-static bag and store safely.
Note: If the PCB is to be returned to the manufacturer
note its Serial Number and Revision Level (located
along one edge).

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
13 997-263, Issue
September 2002
2.5.3 Back Box Fixing
The ID50 Series Panels (PN:002- 55-XXX) are 110mm
deep (external dimensions including fixing dimples). The
back box holds two 12V batteries, up to a maximum rating
of 12Ah each.
The back box must be fixed to the wall with screws at
three fixing locations (see drawing) using the procedure
given below.
The back box must only be installed when the panel
electronics have been removed (see Section2.5.2,
Removing the Panel Electronics).
Wall Flatness
To prevent distortion, the back box MUST be installed on
the wall as flat as possible, i.e. with a maximum flatness
deviation between any two points of 3mm. Where the
wall is out of tolerance, use appropriate packing pieces
when installing the back box to meet the above
requirements.
Failure to comply with this requirement will result in
the misalignment o the covers securing screws,
which may cause di iculties in itting the cover.
Procedure
When a suitable location has been found for installing
the panel and the panel electronics have been removed,
fix the back box to the wall as follows:
1Using a suitable-sized drilling bit - for holes to take up
to 6mm (No.12-sized) wood screws - drill a hole at
position A in the wall. Fit a suitable-sized Rawl-plug,
or equivalent.
2Hold the back box in position at hole A (ensure the
panel is level) and mark the position of the remaining
fixing holes (B). Remove the back box and store safely.
3Drill two holes at positions B in the wall, and fit suitable-
sized Rawl-plugs, or equivalent.
4Prepare apertures (20mm knockouts) required for
cable access.
Note: Make sure paint is scraped from the area
surrounding the knockouts, to ensure good
earthing for glands.
5Secure the back box to the wall using all three fixing
holes and appropriate-sized screws (up to 6mm
[No.12-sized] round or pan-head screws - do not use
countersunk screws).
DO NOT use the back
box as a guide when
drilling
All dimensions are in millimetres. Fixing
hole diameters are 6mm.
37.50 301.00
376.00
45.00
365.00
275.00
188.00
45.00
2
1, 3
5
A
BB

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
1997-263, Issue
September 2002
2.5.4 Semi-Flush Mounting Bezel (Optional)
If semi-flush mounting of the ID50 Series Panel is
required, a recess 80mm deep and just large enough to
accommodate the back box must be cut in the wall (see
dimensions below).
All dimensions in millimetres
To fit the bezel:
1Before continuing, remove panel electronics and
batteries (if fitted) - see Section2.5, Dismantling the
Panel.
2Offer the bezel (A), flat sideways towards you, to the
front of the back box (B) and position it so the bezel
front face (C) is lined up with the rear of the rounded
sides of the back box (D).
3With the bezel held in position, use the slotted holes
(E) on the bezel as guides and drill four appropriate
sized holes to fit M3 screws centrally in the slots.
Remove any swarf created.
4Secure the bezel using suitable M3 fixings. Ensure
the fixings are accessible from the outside of the back
box.
Note: The ID50 Series Panel back box must be fixed to
a solid vertical surface, or sub-frame inside the
recess, using its rear fixing holes. Do NOT rely on
the bezel as a means of fixing.
5Fit back box with attached bezel to the wall recess
and assemble the panel, see Section2.6.
Before drilling the back
box, make sure that no
equipment is fitted
367
437
383
453
329
375
D
B
C
25
2
WALL
RECESS
WALL
RECESS
E (x4)
E(x4)
3
3
A

ID50 Series Panel - Installation, Commissioning & Configuration Manual
Installation Guide
15 997-263, Issue
October 2002
2.6 Assembling the Panel
With the back box secured to the wall and all external
cabling ready for termination, assemble the panel as
follows:
1Ensure that all power to the panel is isolated and
observe ALL safety and anti-static precautions when
installing the PCB assembly.
2Install all kits that require the removal of the PCB
assembly.
3Align the PCB assembly to the supporting pillars and,
using a No.1 Posidriv screwdriver, screw the eight
(8) M3 x 8mm SEM screws into position.
4Fit the labels. They may require the application of a
low tack adhesive:
i Apply low tack adhesive to hatched area indicated.
ii Slide each label into position.
iii Apply slight pressure to the area along the bottom
edge of the fascia to ensure the labels are secure.
5Apply the mains power supply and then connect the
batteries. Check the PCB assembly operates correctly
and then isolate all power to the panel.
6At the PCB assembly:
i Noting the cable polarity, connect all cables and
secure at the correct termination blocks, see
Cables & Wiring.
ii Set all required hardware jumper configurations,
refer to the Section4 Commissioning.
7Fit the RS 85 Interface Module PCB, if applicable,
refer to Section2.7.1 itting the RS485 Interface
Module PCB.
8Re-apply the mains power supply and then connect
the batteries.
9Disconnect the links at the earth fault monitoring
jumper E_FLT (J19) and configuration lock MEM (J9).
Then connect the RS232 9-way D type Data Transfer
Lead (PN082-173) to the panel at the RS232
connector, PL5. Using the Support Tool, transmit the
latest system configuration to the panel.
10 Remove the lead and fit the links at J9 and J19, then
fit the cover.
Note: Connect the earth wire to the inner side wall of the
cover at the tag marked with the earth symbol.
Cables & Wiring
i Power Supply from transformer (TB1),
ii CFG Outputs D and C (TB3),
iii 4 V Auxiliary Power Supply (TB4),
iv Sounder Outputs B and A (TB4),
v Loop Cable Output (TB5),
vi RS485 Communications Cable (TB6),
vii FBF Communications Cable (VdS Only) (TB9),
viii FBF Power Supply (VdS Only) (TB8),
ix Digital / ÜE Cable (TB8), and
x -VE Outputs (TB ),
xi Keyswitch.
