Nova gear NG-52 User manual

NG-52
12V MULTI-FUNCTION TOOL
INSTRUCTION MANUAL
PRODUCT CODE: 40041
CAUTION: Read the operating
instructions to reduce the risk of inquiry
Battery and charger sold separately

2
ELECTRICAL SAFETY
This manual contains important
safety and operating instructions
for your battery charger (sold
separately).
› Before using the charger, read all
instructions and cautionary markings
on charger, battery pack and product
using the battery pack.
› This charger is not intended
for any uses other than charging
rechargeable batteries. Any other
use may result in risk of fire, electric
shock or electrocution.
› Do not place any object on top of the
charger or place the charger on a soft
surface that may result in excessive
internal heat. Place the charger in a
position away from any heat source.
› To reduce risk of damage to the
electric plug and cord, pull by the
plug rather than the cord when
disconnecting the charger.
› Make sure cord is located so that it
will not be stepped on, tripped over, or
otherwise subjected to damage or
stress.
› An extension cord should not be used
unless absolutely necessary. Use of an
improper extension cord could result
in the risk of fire, electric shock or
electrocution.
› Do not operate charger if it has
received a sharp blow, been dropped
or otherwise damaged in any way. Have
it checked by an electrician or power
tool repairer.
› Do not disassemble charger. Take it to
an electrician or power tool repairer
when service or repair is required.
Incorrect reassembling may result in
a risk of electric shock, electrocution
or fire.
› To reduce risk of electric shock,
unplug charger from the outlet before
attempting any cleaning. Removing the
battery pack will not reduce this risk.
› Never attempt to connect 2 chargers
together.
SAFETY
CAUTION: Read the operating
instructions to reduce the risk
of inquiry.
DOUBLE INSULATED
This tool is double insulated
in accordance with AS/NZS
60335-1; therefore no earth wire
is required.
DANGER! If the battery pack case is
cracked or damaged, do not insert
into charger. There is a danger of
electric shock or electrocution.
Warning: Do not allow any liquid to
get inside charger. Electric shock
may result. To facilitate cooling of
the battery pack after use, avoid
placing the charger or battery pack
in a warm environment such as in
a metal shed, or an uninsulated
trailer.
!
!

3
GENERAL SAFETY
› DO NOT store or use the tool and
battery pack in locations where the
temperature may reach or exceed
40ºC (such as outside sheds or metal
buildings in summer).
› The charger is designed to operate
on standard household electrical
power (240 volts). Do not attempt
to use it on any other voltage! The
battery pack is not fully charged out
of the carton. First read the safety
instructions and then follow the
charging notes and procedures.
› The longest life and best
performance can be obtained if the
battery pack is charged when the air
temperature is between 18 - 24ºC.
Do not charge the battery pack in
an air temperature below 10ºC or
above 40ºC. This is important and will
prevent damage to the battery pack.
› Do not incinerate the battery pack
even if it is seriously damaged or is
completely worn out. The battery can
explode in a fire.
› Never attempt to open the battery
pack for any reason. If the plastic
housing of the battery pack breaks or
cracks, immediately discontinue use
and do not recharge.
Save these instructions and other
documents supplied with this tool for
future reference.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in
explosive atmospheres, such as in
the presence of flammable liquids,
gases or dust. Power tools create
sparks which may ignite the dust or
fumes.
c) Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
b) Avoid body contact with earthed
or grounded surfaces, such as pipes,
radiators ,ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
c) Do not expose power tools to rain
or wet conditions. Water entering a
power tool will increase the risk of
Warning: Read all safety warnings
and all instructions. Failure to
follow the warnings and
instructions may result in electric
shock, fire and/or serious injury.
!

4
electric shock.
d) Do not abuse the cord. Never
use the cord for carrying, pulling
or unplugging the power tool. Keep
cord away from heat, oil, sharp
edges or moving parts. Damaged or
entangled cords increase the risk of
electric shock.
e) When operating a power tool
outdoors, use an extension cord
suitable for outdoor use. Use of a
cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a
damp location is unavoidable, use
a residual current device (RCD)
protected supply. Use of an RCD
reduces the risk of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired
or under the influence of drugs,
alcohol or medication. A moment
of inattention while operating power
tools may result in serious personal
injury.
b) Use personal protective
equipment. Always wear eye
protection. Protective equipment
such as dust mask, non-skid safety
shoes, hard hat, or hearing protection
used for appropriate conditions will
reduce personal injuries.
Ensure the switch is in the off-
position before connecting to power
source and/or battery pack, picking
up or carrying the tool. Carrying
power tools with your finger on the
switch or energising power tools that
have the switch on invites accidents.
d) Remove any adjusting key or
wrench before turning the power
tool on. A wrench or a key left
attached to a rotating part of the
power tool may result in personal
injury.
e) Do not overreach. Keep proper
footing and balance at all times. This
enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear
loose clothing or jewellery. Keep
your hair, clothing and gloves away
from moving parts. Loose clothes,
jewellery or long hair can be caught in
moving parts.
g) If devices are provided for the
connection of dust extraction and
collection facilities, ensure these
are connected and properly used.
Use of dust collection can reduce
dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use
the correct power tool for your
application. The correct power tool
will do the job better and safer at the
rate for which it was designed.

5
b) Do not use the power tool if
the switch does not turn it on
and off. Any power tool that cannot
be controlled with the switch is
dangerous and must be repaired.
c) Disconnect the plug from the
power source and/or the battery
pack from the power tool before
making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures
reduce the risk of starting the power
tool accidentally.
d) Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power
tool or these instructions to operate
the power tool. Power tools are
dangerous in the hands of untrained
users.
e) Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any
other condition that may affect the
power tool’s operation. If damaged,
have the power tool repaired before
use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and
clean. Properly maintained cutting
tools with sharp cutting edges are
less likely to bind and are easier to
control.
g) Use the power tool, accessories
and tool bits etc. in accordance
with these instructions, taking into
account the working conditions and
the work to be performed. Use of the
power tool for operations different
from those intended could result in a
hazardous situation.
5) BATTERY TOOL USE AND CARE
a) Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
b) Use power tools only with
specifically designated battery. Use
of any other battery packs may create
a risk of injury and fire.
c) When the battery is not in use,
keep it away from other metal
objects, like paper clips, coins, keys,
nails, screws or other small metal
objects, that can make a connection
from one terminal to another.
Shorting the battery terminals
together may cause burns or a fire.
d) Under abusive conditions,
liquid may be ejected from the
battery; avoid contact. If contact
accidentally occurs, flush with
water. If liquid contacts eyes,
additionally seek medical help.
Liquid ejected from the battery may
cause irritation or burns.

6
ADDITIONAL SAFETY FOR
MULTI-FUNCTION TOOLS
a) Do not use the tool in wet or damp
conditions.
b) Wear ear protectors when this
tool is in use. Exposure to noise can
cause hearing loss.
This appliance is not intended for
use by persons (including children)
with reduced physical, sensory
or mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for
their safety.
Recommendations for the use of a
residual current device with a rated
residual current of 30mA or less:
› Wear a hard hat (safety helmet),
safety glasses and/or face shield. It
is also highly recommended that you
wear a dust mask, ear protection and
padded gloves.
› Hold the power tool with a firm grip.
› Secure the work piece. A work piece
clamped with clamping devices or
in a vice, is held more secure than
by hand.
› One-handed operation can be
hazardous. It is recommended you
hold the unit firmly with both hands
when operating the tool.
› After installing an accessory, pull
lightly on it to make sure that it does
not come loose. If the accessory is
not installed properly, it can come
loose during use, which can be
dangerous.
› Use an accessory that is appropriate
for the application.
› Check that any accessory to be used
is not cracked or broken. Broken or
cracked accessories are dangerous.
› If the ring securing the accessory is
damaged, the accessory may come
off during use causing personal
injury.
› The torque delivered by the multi-
function tool depends on how long it
is applied, the type of accessory and
other factors such as the state of the
battery charge.
› Never touch the accessory whilst it is
in motion. Do not let the accessory get
near your hands or any other part of
your body. You could be injured.
6) SERVICE
a) Have your power tool serviced by
a qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power
tool is maintained.
b) If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent or
similarly qualified persons in order to
avoid a hazard.

7
LITHIUM-ION BATTERY &
CHARGER SAFETY
OVER CHARGING PROTECTION
This feature ensures that the battery is
never overcharged. When the battery
has reached its full charge capacity
the charger will shut off protecting the
internal components of the battery
from being damaged.
OVER DISCHARGE PROTECTION
An internal component of the
battery pack is an over discharge
protector. This feature will stop the
battery from discharging beyond the
recommended lowest safety voltage.
OVER HEAT PROTECTION
The battery has an internal Thermister
cut off sensor which will cease the
charging cycle if the battery becomes
hot during the charging process. This
Thermister sensor will also stop the
battery from operating should the
battery become too hot during the
operation of the tool. This can happen
when the tool is overloaded or being
used for extended periods of time.
Up to 30min in cooling time may
be required depending on ambient
temperature and operation being
performed.
OVER CURRENT PROTECTION
Should the battery be overloaded
and the maximum current draw be
exceeded the battery will temporarily
stop working to protect the internal
components. The battery will resume
to normal operation once the
excessive current draw has returned
to normal safe level. This may take a
few seconds.
SHORT CIRCUIT PROTECTION
If the battery pack was to short circuit
the short circuit protector would
immediately stop the battery pack
from operating. This will ensure that
no further internal components of the
battery or the tools are damaged.
› Do not touch the accessory after
it has been in use for an extended
period. It could be hot and burn you.

8
INTENDED USE
The cordless multi-function tool is
suitable for sanding / grinding small
areas and cutting or scraping with the
appropriate accessory attached.
The equipment is designed for
the sanding / grinding of wood,
iron, plastic and similar materials
using the appropriate sanding /
grinding accessory. Furthermore, the
equipment is intended for sawing
wood, plastic and similar materials,
as well as scraping off glued carpets,
filling compound residues, old paint
and similar applications.
The equipment may only be used for
the tasks it is designed to handle. Any
other use is deemed to be a case of
misuse. The user / operator and not
the manufacturer will be liable for any
damage or injuries of any kind caused
as a result of this.
TECHNICAL SPECIFICATIONS
SPECIFICATIONS NG-52 Multi-function Tool
Product code 40041
Warranty 3 years
Voltage 12V
Oscillation angle 3°
Variable speed 5000 - 16000 RPM
Battery type Li-ion 2000mAh
Battery charge time 30 mins

9
PRODUCT OVERVIEW
IDENTIFICATION
BATTERY AND CHARGER
This tool is compatible with the
NG-6020 battery and NG-61 charger.
4
1
2
5
3
1. On / off switch
2. Variable speed switch
3. Accessory drive spindle
4. Metal gear box
5. Battery release button
(battery not included)
ACCESSORIES INCLUDED
› 1x cutting blade
› 1x hex spanner

10
INSTALLING AND REMOVING
THE BATTERY
Always switch off the multi-function
tool before insertion or removal of the
battery.
INSTALLING THE BATTERY
› Hold the multi-function tool upright and
pick up the battery in your opposite hand.
Place two fingers over the battery release
buttons and insert the battery until it
clicks into place (Fig. 1).
› Do not use excessive force when
inserting the battery. If the battery does
not slide in easily, it is not being inserted
correctly. It is also possible that there
could be damage to the battery, battery
terminals or the multi-function tool.
REMOVING THE BATTERY
Press both the battery release buttons on
either side and gently pull the battery out
of the multi-function tool.
BATTERY LIFE
The length of service from each charging
cycle will depend on the type of work you
are doing. To obtain the longest possible
battery life, we suggest the following:
› Store and charge your battery in a cool
area. Temperatures above or below normal
room temperature will shorten battery life.
› Store and charge your battery in a cool
area. Temperatures above or below
Fig.1

11
normal room temperature will shorten
battery life.
› Never store batteries in a
uncharged condition. Recharge them
immediately after they are uncharged.
› All batteries gradually lose their
charge. The higher the temperature
the quicker they lose their charge. If
you store your multi-function tool for
long periods of time without using it,
recharge the batteries every month or
two. This practice will prolong battery
life.
ASSEMBLY
ATTACHING ACCESSORIES
1. To attach an accessory to the Multi-
function Tool, turn the tool upside down
and ensure the surface is clean and free
of debris (Fig. 2). Ensure that the large
hole located within the series of smaller
perforated holes on the accessory is
correctly placed over the raised locating
ring on the accessory drive spindle.
Choose the desired angle required for
your application and position the series
of smaller accessory perforated holes
over the raised accessory locating pins
on the drive spindle of the Multi-function
Tool (Fig. 3).
Be sure that all of the holes of the
accessory are now correctly located
onto the accessory drive spindle and the
accessory is sitting flat against the face of
the accessory drive spindle.
Fig.2
Fig.3

12
2. Place the accessory fixing washer
in alignment with the inner hole of the
accessory drive spindle (Fig. 4). Ensure the
flat side of the accessory fixing washer is
facing towards the accessory.
3. Insert the locking bolt through the
accessory fixing washer and into the
accessory drive spindle of the Multi-
function Tool.
4. Tighten the locking bolt using an allen
key in an anti-clockwise direction. (Fig. 5)
Do not overtighten.
REMOVING ACCESSORIES
1. Loosen the locking bolt using the allen
key in a clockwise direction.
2. Remove the locking bolt and the
accessory fixing washer from the Multi-
function Tool. Remove the accessory.
3. To re-attach an accessory, follow the
instructions on “Attaching accessories”.
REPLACING SAND PAPER
1. Align the sanding paper to the hook &
loop sanding pad and press firmly to hold
in place. As this product does not include a
dust extraction system, it is not critical that
the holes in the sanding paper line up with
the holes on the hook & loop sanding pad.
2. To remove or change the sanding paper
carefully peel off the sanding paper from
one of the triangle ends.
Fig.4
Fig.5

13
OPERATION
ON / OFF SWITCH
1. Slide the on / off switch forward to the
“on” position (Fig.6).
2. Slide the on / off switch towards the
back of the Multi-function Tool to the “off”
position.
VARIABLE SPEED
NOTE: In various applications you will
need to select the correct speed.
1. When the Multi-function Tool power
is turned on, select the “variable speed
switch” by scrolling the variable speed
dial to your desired speed (Fig. 7). The
higher the number on the variable speed
dial the faster the oscillation frequency of
the Multi-function Tool.
2. Recommended oscillation frequency
for applications:
High oscillation
frequency
Sanding, sawing,
rasping, and
polishing stone and
metal.
Low oscillation
frequency Polishing varnishes
Variable speed
selector
Fig.7
On / off switch
Fig.6

14
SANDING
CHOOSING THE CORRECT SANDING PAPER:
Sanding paper is rated according to the
number marked on the rear of the
sanding paper. The higher the number, the
smaller and less coarse the particles
are on the sanding paper. The lower the
number, the larger and more coarse the
particles are on the sanding paper, this
will provide a more aggressive sanding
action for quick material removal.
› Coarse grit (eg.40) is used for removing
paint and sanding down rough surfaces.
› Medium grit (eg.80) is used for sanding
down plain timber.
› Fine grit (eg.120) is used to give a smooth
finish to bare wood.
› Extra fine grit (eg.400-1200) is used for
polishing or sanding between coats of
paint.
NOTE: When using the Multi-function Tool
in sanding application, try not to apply
excessive pressure when using course grit
paper as this can lead to swirl marks on
the work piece.
NOTE: Ensure you have the correct
sanding paper for your application. Always
test on a scrap work piece before using on
your final work piece.
1. In sanding mode, the Multi-function Tool
can be used on materials such as wood,
plastic, metal and painted surfaces.
2. Slide the on/off switch forward to the
“on” position. Ensure the Multi-function
Tool is not placed on the work piece.
3. Select the desired oscillation frequency
speed on the variable speed dial and
wait until the motor reaches its maximum
speed.
4. Place the Multi-function Tool on your
work piece, ensuring the whole area of
the sanding base is in contact with the
work surface.
5. Allow the Multi-function Tool to do the
work and do not apply heavy pressure on
the Multi-function Tool. Heavy pressure
does not increase the removal of material
but will wear your sanding paper faster.
6. If sanding corners in hard to reach
areas use the tip or triangle edge of the
hook & loop sanding pad.
NOTE: For best results, the sanding pad
must be kept flat on the work piece. Do
not tilt the sanding base and use the
edge of the sanding paper or the sanding
pad may become damaged, causing the
sanding paper not to adhere to the base
correctly.
SQUARE BLADE SAWING
NOTE: Ensure your blades are not blunt or
damaged in any way before commencing
your application.
Caution: Clamp your work piece
securely if possible before
commencing your work.
!

15
1. In sawing mode, the Multi-function Tool
can be used on wood, plastics and
sheet metal.
2. Slide the on/off switch forward to the
“on” position. Ensure it is not placed
on the work piece.
3. Select the desired oscillation frequency
speed on the variable speed switch and
wait until the motor reaches its maximum
speed
4. If plunging, use a slight pendulum
motion to allow sufficient chip or debris
removal.
NOTE: If using the Multi-function Tool for
plunge cuts: only use this application on
soft materials such as wood or gypsum
plaster boards. Check there are no nails
or screws in the work piece before
cutting.
SCRAPING
NOTE: The scraping blade is designed for
scraping surfaces and the removal
of soft materials. Ensure you have the
correct angle and only apply light
pressure to avoid cutting the surface.
Warning: If installing power points,
please ensure all electricity is
switched off at the fuse box prior to
work commencing. It is important
to seek the advice of a licensed
electrician when conducting any
work around the home which
involves electricity.
!
1. In scraping mode the Multi-function
Tool can be used to remove materials
such as fabrics, adhesives and vinyls on
materials such as wood, plastic, metal
and painted surfaces.
2. Slide the on/off switch forward to the
“on” position. Ensure it is not placed on
the work piece.
3. Select the desired oscillation frequency
speed on the variable speed dial and wait
until the motor reaches its maximum
speed.
4. Place the Multi-function Tool on the
work piece. Ensure you have angled the
scraper blade correctly.
5. Allow the scraper to do the work and
do not apply heavy pressure on the Multi-
function Tool. Heavy pressure can cut into
the surface or overload the Multi-function
Tool.
MAINTENANCE
› When not in use, the Multi-function
Tool should be stored in a dry, frost free
location, out of reach of children.
› Keep ventilation slots of the Multi-
function Tool clean at all times and
prevent any foreign matter from
entering.
› If the housing of the Multi-function Tool
requires cleaning, do not use solvents
but a moist soft cloth only.
› Blow out the ventilation slots with
compressed air periodically.

16
WASTE DISPOSAL
& RECYCLING
SERVICING
Do not dispose of this product
in household waste!
Please recycle this product
responsibly in accordance with
local and national law.
For information on servicing
and repairs please contact
Spot-on on 1300 658 338 or
visit www.spoton.com.au.
NOTE: Nova Gear will not be
responsible for any damage or
injuries caused by repair of the
Multi-function Tool by an unauthorised
person or by mishandling of the Multi-
function Tool

17
WARRANTY
The NG-52 Multi-function Tool comes
with a 3 year manufacturers warranty.
Our goods come with guarantees that
cannot be excluded under the Australian
Consumer Law. You are entitled to a
replacement or refund for a major
failure and for compensation for any
other reasonably foreseeable loss or
damage. You are also entitled to have
the goods repaired or replaced if the
goods fail to be of acceptable quality
and the failure does not amount to a
major failure.
Separate to the above Australia
Consumer Law, Spot-on offers a global
warranty.
The warranty period commences on
the date of purchase, which can be
verified on your receipt or invoice. We
cannot offer a warranty for damages
and defects on appliances or their
parts caused by improper use or
treatment. Damage caused by failure
to comply with the operating manual
will be excluded from the warranty.
In the event that an unauthorised
persons has modified the appliance,
the warranty will be rendered void.
Damages that are caused by improper
handling are excluded from the
guarantee.
If you have any concerns or wish to
make a warranty claim please contact
your retailer or Spot-on Laser and Tool
Company on 1300 658 338.
Spot-on Laser and Tool Company PTY LTD
10-12 Dowsett Street,
South Geelong, VIC 3220
Australia

18
NOTES

19

Spot-on Laser and Tool Company | 1300 658 338 | www.spoton.com.au
