Novatek Rotostrip ROTO100 Troubleshooting guide

2
© Copyright 2011 by NOVATEK Corporation
All rights reserved printed in the United States of America. No part of this manual may be used or reproduced in any form or
by any means, stored in data base or retrieval system, without prior written permission from NOVATEK Corporation.
Making copies of this manual for any purpose other than your own personal use is a violation of the United States copyright
laws.
January 1, 2011 issue 1.0
Specifications subject to changes without notice!
If you have any questions, please contact us:
NOVATEK CORORATION
216 Philips Road
Exton, PA 19341
USA
www.novatekco.com
Toll Free 866 563-7800
Telephone: [phone]
Fax [phone]
Email: [e-mail]

OPERATION AND MAINTENANCE MANUAL FOR
ROTOSTRIP –SURFACE PREPARATION TOOL
FOR PROFESSIONAL USE ONLY
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS PRODUCT.
IT IS YOUR RESPONSIBILITY TO MAKE THIS SAFETY INFORMATION
AVAILABLE TO OTHERS THAT WILL OPERATE THIS PRODUCT.
FAILURE TO OBSERVE THE FOLLOWING WARNING COULD RESULT IN INJURY.
PLACING TOOL IN SERVICE
Always install, operate, inspect and maintain
this product in accordance with all applicable
standards and regulations (local, state, country,
federal, etc.).
Compressed air models always use clean, dry
air at 90 psi (6.2bar/620kPa) maximum air
pressure at the inlet. Higher pressure may
result in hazardous situations including
excessive speed, rupture, or incorrect output
torque or force.
Electric models must always utilize proper
gauge, and rated electrical cords with correct
connections.
Be sure all hoses and fittings are the correctly
sized and secured.
Ensure an accessible emergency shut off has
been installed in the air or electrical supply line.
Make others aware of its location.
Do not use damaged, frayed, or deteriorated air
hoses and fittings.
Always use proper gauge electrical cords with
correct connections. (When applicable.)
Electric models must not use damaged, frayed, or
deteriorated electrical cords and connections.
Keep clear of whipping air hoses. Shut off the
compressed air before approaching a whipping
hose.
Always turn off and disconnect the tool from its
power supply before installing, removing or
adjusting any accessory, or before performing
any maintenance on the tool.
Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel. Use
only recommended lubricants.
Keep work area clean, uncluttered, ventilated and
illuminated.
Keep all electrical connections clear of water or
other liquids. (When applicable.)
Do not operate the machine while flammable or
volatile liquids such as gasoline, diesel or jet fuel
are present. Failure to do so can result in
explosion. (When applicable.)
Do not remove any labels. Replace any damaged
label.
USING THE TOOL
Always wear protection when operating or
performing maintenance on this tool.
Always wear hearing protection when operating
this tool.
Always use Personal Protective Equipment
appropriate to the tool used and material
worked. This may include dust mask or other
breathing apparatus, safety glasses, ear plugs,
gloves, apron, safety shoes, hard hat and other
equipment,
Prevent exposure and breathing of harmful dust
and particles created by power tool use:
- Some dust created by power sanding, sawing,
and grinding, drilling, and other construction
activities contains chemicals known to cause
cancer, birth defects or other reproductive
harm. Some examples of these chemicals are:
- Lead from lead based paints,
- Crystalline silica from bricks and cement and
other masonry products, and
- Arsenic and chromium from chemically treated
lumber
Your risk from these exposures varies, depending
on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well
ventilated area, and work with approved safety
equipment, such as those dust masks that are
specially designed to filter out microscopic
particles.
Keep others a safe distance from your work area,
or ensure they use appropriate Personal
Protective Equipment.
This tool is not designed for working in explosive
environments, including those caused by fumes
and dust, or near flammable materials.
NOTICE
WARNING

Electrically powered tools are not insulated
against electric shock.
Be aware of buried, hidden or other hazards in
your work environment. Do not contact or
damage cords, conduits, pipes, or hoses that
may contain electrical wires, explosive gases or
harmful liquids.
Keep hands, loose clothing, long hair and
jewelry away from working end of tool.
Power tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions
may be harmful to your hands and arms. Stop
using any tool if discomfort, tingling feeling or
pain occurs. Seek medical advices before
resuming use.
Keep body stance balanced and firm. Do not
overreach when operating this tool. Anticipate
and be alert for sudden changes in motion,
reaction torques, or forces during startup and
operation.
Tool and/or accessories may briefly continue
their motion after throttle is released,
To avoid accidental starting –ensure tool in
“off” position before applying air pressure or
connecting to electricity. Avoid throttle when
carrying, and release throttle with loss of air or
electricity.
Ensure work pieces are secure. Use clamps or
vises to hold work piece whenever possible.
Do not carry or drag the tool by the hose or
power cord.
Do not use power tools when tired, or under the
influence of medication, drugs, or alcohol.
Never us a damaged or malfunctioning tool or
accessory,
Do not modify the tool, safety devices, or
accessories.
Do not use this tool for purposed other than
those recommended.
Use accessories recommended by Novatek
Corp.
Never operate a tool with an accessory unless it
is properly installed and the tool is held firmly
against the work,
Always use a retainer, when furnished, in
addition to proper barriers to protect persons in
surrounding or lower areas from possible
ejected accessories.
When wearing gloves and operating models
with inside trigger, always be sure that the
gloves will not prevent the trigger from being
released.
Wear safety shoes, hard hat, safety goggles,
gloves, dust mask and any other appropriate
protective clothing while operating the tool.
Do no indulge in horseplay. Distraction can
cause accidents.
Keep hands and fingers away from the throttle
lever until it is time to operate the tool.
Never rest the tool on your foot.
Never point the tool at anyone.
Compressed air is dangerous. Never point an air
hose at yourself or others.
Never blow clothes free of dust with compressed
air.
Be sure all hose connections are tight. A loose
hose not only leaks but can come completely off
the tool and while whipping under pressure, can
injure the operator and other in the area. Attach
safety cables to all hosed to prevent injury in case
a hose is accidentally broken.
Never disconnect a pressurized air hose. Always
turn off the air supply and bleed the tool before
disconnecting a hose.
When applicable, the operator must keep limbs
and body clear of the chisel. If a chisel breaks,
the tool with the broken chisel projecting from the
tool will suddenly surge forward.
Do not ride the tool with one leg over the handle.
Injury can result if the chisel breaks while riding
the tool.
Know what is underneath the material being
worked. Be alert for hidden water, gas, sewer,
telephone or electric lines.
Use only proper cleaning solvents to clean parts.
Use only cleaning solvents which meet current
safety and health standards. Use cleaning
solvents in a well ventilated area.
Do not flush the tool or clean any parts with diesel
fuel. Diesel fuel residue will ignite in the tool
when the tool is operated, causing damage to
internal parts. When using models with outside
triggers or throttle levers, take care when setting
the tool down to prevent accidental operation.
Do not operate the tool with broken or damaged
parts.
Never start the tool when it is lying on the ground.
This tool is not designed for working in explosive
atmospheres.

5
TABLE OF CONTENTS
SECTION I
INTRODUCTION ................................................................................................................................................6
SECTION II
GENERAL DESCRIPTION.................................................................................................................................6
SECTION III
WORKING AREA................................................................................................................................................6
PERSONAL SAFETY .........................................................................................................................................6
SECTION IV
TOOL CARE AND USAGE.................................................................................................................................6
SPECIAL SAFETY INSTRUCTIONS..................................................................................................................7
SECTION V
PLACING IN OPERATION .................................................................................................................................8
ABRASIVE BRUSH ASSEMBLY........................................................................................................................8
ERASER WHEEL ASSEMBLY...........................................................................................................................9
SECTION VI
SERVICE INSTRUCTIONS................................................................................................................................9
TROUBLESHOOTING........................................................................................................................................9
SECTION VII
PARTS BREAKDOWN .................................................................................................................................... 10
DIAGRAM OF UNIT......................................................................................................................................... 10
NOVATEK CORPORATION LIMITED WARRANTY....................................................................................... 11

6
SECTION I
INTRODUCTION
This operation and maintenance manual is furnished with each RotoStrip unit. It outlines general equipment use and the
operation and maintenance requirements for efficient and safe operation.
READ ALL INSTRUCTIONS AND DATA IN THIS OPERATION AND MAINTENANCE MANUAL PRIOR TO OPERATION
OF THIS EQUIPMENT.
These instructions are for your protection and convenience. Please read them carefully since failure to follow the
precautions could result in injury. Whenever using powered equipment, basic safety precautions should be followed.
If after reading this manual anything seems unclear, contact a NOVATEK authorized distributor or NOVATEK directly by
dialing 1-866-563-7800.
SECTION II
GENERAL DESCRIPTION
The RotoStrip is an east to handle, light weight surface preparation tool with a lot of power. This versatile piece of
equipment utilizes a variety of abrasives from wire brushes, coating removal discs to erasers for removal of adhesive
products.
SECTION III
WORKING AREA
Inspect the unit for any loose or damaged parts every time prior to use.
CAUTION: Make sure power supply is off prior to inspection!
1. Keep your working area clean from dirt and debris. A cluttered working area is dangerous!
2. NEVER allow unauthorized individuals or individuals operate the tool without proper safety attire or even enter the work
area.
3. ALWAYS operate the RotoStrip in a well ventilated are.
PERSONAL SAFETY
1. Always wear suitable protective clothing. NEVER wear loose fitting clothing, jewelry or other items that could become
trapped in moving parts. Wear gloves and shoes with non-skid shoes.
2. Always wear safety glasses, face mask and hearing protection.
3. Make sure you have a firm grip on the tool before you begin operation.
SECTION IV
TOOL CARE AND USAGE
1. After fitting the RotoStrip hub with your appropriate accessory remove the hex socket wrench and re-attach any
removed parts before operation.
CAUTION: Make sure the hex socket wrench is removed before start up!
2. NEVER carry the tool connected to power source anywhere other than your designated work area. Make certain that
your hand is nowhere near the starter.
3. Work at a safe distance to ensure that individuals cannot be injured by debris.

7
4. Follow the instructions on lubrication and proper replacement of tool accessories.
5. When not in use, prior to servicing and on changing accessories, switch off the tool and disconnect from the power
source.
6. Prior to replacing accessories, the tool MUST BE removed from power source. DO NOT perform any servicing work on
the tool when it is connected to the power source.
7. Regularly check pneumatic lines, electrical cords and replace them if they are damaged. Keep vertical handle and tool
body dry, clean and free of oil and grease.
CAUTION: An unmaintained tool can cause accidents!
SPECIAL SAFETY INSTRUCTIONS
1. Prior to operating the tool, always check for faulty and or defective parts. Never use the tool if it is damaged in any way.
Any damaged safety features, starter lever or other faulty parts are to be repaired or replaced IMMEDIATELY before
usage.
2. Always use both hands when operating the RotoStrip.
CAUTION: NOVATEK’s accessories are designed for use on RotoStrip tools and therefore should not be utilized on
or in conjunction with any other machines.
3. After replacing any accessory check the adapter system for correct assembly before operating the machine.
4. For pneumatic model insure that sufficient length of air hose, supplied with a minimum of 5 SCFM compressed air at 90
psi, is available. A supply of clean, dry air and suitable lubrication is recommended for trouble free use. Tighten all hose
connector fittings and blow out hose to insure that all debris is purged from the supply line before use.
5. For electric model wipe down the outside surface of the drive motor enclosure to remove accumulated dirt, dust and
other residue from preceding cleaning operation. Test run the motor to insure no arcing is indicated between the
brushes. If arcing takes place and additional air jet cleaning does not correct the arcing, contact a NOVATEK
authorized distributor or NOVATEK directly by dialing 1-866-563-7800.
6. Check the compressed air at regular intervals to ensure the compressed air is clean and oiled. If it is necessary
integrate a service until into the compressed air line.
7. If the tool is not in use, disconnect it from the air supply and store it in a suitable clean/dry location to prevent any
unauthorized use.
8. ALWAYS hold both the tool body and the vertical handle while in use.
9. Keep in mind that brushes can create sparks while running on hard surfaces. Take precautions while in use.
CAUTION: ALWAYS wear eye protection to prevent injuries.
10. Never carry the tool by the air hose or power cord. Protect lines against heat, sharp edges and the possibility of running
over while in use.
11. If the tool suddenly feels different, production level suddenly drops or produces a different noise, the tool should be shut
down immediately and checked for any possible damage.
SECTION V
PLACING IN OPERATION

8
This tool is used for the removal of rust, corrosion, mill scale, protective coatings, body filler, adhesive labels, etc.
1. Always use suitable sealing material to fasten the connection of the pneumatic hose to the RotoStrip.
2. There are two sizes of abrasive brushes to choose from; 11mm or 23mm straight or bent bristle brushes along with
23mm erasers and coating removal wheels.
Straight Brush
Bent Brush
Eraser Wheel
Coating Removal Wheel
3. NEVER place an 11mm abrasive into a 23mm hub or vice versa. This can cause damage to the machine and operator.
4. Start the tool by moving the safety stop forward and depressing the throttle level. The throttle level will return to its initial
position when it is released.
5. NEVER operate the tool while not in contact with the work surface or if there is the possibility of bodily contact with the
rotating hub.
6. Hold the tool by the body and the vertical handle at the same time. This is to ensure proper substrate removal and
secure handling of the tool during operation.
7. Work only with minimum surface pressure and even movements across surface. Excess pressure can reduce the
desired results and wear abrasives prematurely.
ABRASIVE BRUSH ASSEMBLY

9
ERASER WHEEL ASSEMBLY
SECTION VI
SERVICE INSTRUCTIONS
The tool is to be serviced only by a Novatek Technician. Improper use of service of the RotoStrip can also result in injury or
damage to the machine. Unauthorized parts or services of the RotoStrip will void the warranty.
TROUBLESHOOTING
Here are some trouble shooting and maintenance tips:
A. If the abrasive hub is not turning or turning slowly.
a. Check the power source.
b. Check air hose or power cord for cracks or any imperfections.
c. Clean tool thoroughly with compressed air and a clean cloth.
d. Increase compressor pressure and verify compressor can produce enough SCFM.
e. Check Panel Box circuit breaker.
f. Add a few drops of oil to the compressed air connection and air inlet of pneumatic tool.
B. If the machine is making an unusual sound.
a. Check the same connections as listed above.
b. Make sure hub assembly is together properly.
c. Check to ensure hub is attached properly to drive motor.
d. Make sure there are no obstructions near moving parts.
e. Check and replace any worn abrasives or parts.
C. Heavy vibration of the Rotating Abrasive.
a. Check hub assembly for proper fit and wear.
b. Replace with new hub assembly.
D. Hub Assembly comes undone during operation.
a. Check to ensure hub screw is tight.
b. Use a separate lock washer and tighten screw to secure connections.
IF AFTER FOLLOWING THESE PROCEDURES REGULAR OPERATION IS NOT RESTORED
CONTACT A NOVATEK FACTORY TECHNICIAN.

10
SECTION VII
PARTS BREAKDOWN
Ref. Part No. Description
1 SCREW
2 O-RING (P12)
3 O-RING (P8)
4 AIR REGULATOR
5 SPRING
6 VALVE STEM BUSHING
7 VALBE STEM
8 O-RINGS (3.5*1.4)
9 AIR INLET
11 O-RING (26.7*1.78)
12 CONE MUFFLER
13 PROTECTING RUBBER
14 HOUSING
15 SPRING PIN
16 LEVER
17 BEARING
18 REAR PLATE
19 ROTOR BLADE
20 ROTOR
21 PIN
22 CYLINDER
23 FRONT PLATE
24 BEARING
25 WASHER
26 BEARING
27 THREAD RING GEAR
28 IDLE GEAR
29 NEEDLE BEARING
30 IDLE GEAR PIN
Ref. Part No. Description
31 GEAR PLATE
32 SLIDING KEY
33 BEARING
34 CLAMP NUT
35 BEVEL GEAR
36 WASHER
37 SCREW (M4*6)
38 PLASTIC HOUSING
40 TOOTHED PULLEY
41 KEY (3*13)
42 BELT DRIVE SHAFT
43 TOOTHED BELT
44 LEFT BEVEL GEAR
45 BELT DRIVE SHAFT
46 SCREW (3*18L)
47 NUT
48 HANDLE RING
49 HANDLE
50 VACUUM ADAPTER
51 NUT (M4)
52 SCREW (M4*27L)
53 SCREW
54 COVER
56 SCREW (1/4”*28UNF*1”)
58 HEX (3/16”)
59 WASHER
60 WASHER
61 SCREW
64 PIN (3*5)
DIAGRAM OF UNIT

11
NOVATEK CORPORATION LIMITED WARRANTY
The TOOLS manufactured by NOVATEK CORPORATION are warranted to be free
from defects in material and workmanship for a period of 180 DAYS from the date of
purchase from NOVATEK CORPORATION. This warranty does not apply to
accessories. All electrical components of the tool are also warranted to be free from
defects in material and workmanship for a period of 180 DAYS.
This warranty applies only to TOOLS purchased new from NOVATEK CORPORATION.
This warranty does not apply to any TOOL which has been abused, misused, modified
or repaired by someone other than NOVATEK CORPORATION or its authorized repair
center.
If a TOOL proves defective in material or workmanship within one year of purchase from
NOVATEK CORPORATION, it should be returned to NOVATEK CORPORATION,
transportation pre-paid. The return must be authorized by a RETURN MERCHANDISE
AUTHORIZATION NUMBER (R.M.A. #) obtained from NOVATEK CORPORATION
prior to returning the UNIT. All packages must show clearly on the outside the return
merchandise authorization number. All packages received without any R.M.A. # on the
outside will be refused by NOVATEK CORPORATION receiving department.
Warranty claims will only be considered upon adequate proof of date of purchase.
NOVATEK CORPORATION will, at its option, REPAIR or REPLACE DEFECTIVE
PARTS. Repairs or replacements are warranted as above for the remainder of the
original warranty period. The sole liability of NOVATEK CORPORATION and the user’s
exclusive remedy under this warranty is limited to the repair or replacement of the
defective product.
THERE ARE NO OTHER WARRANTIES EXPRESSED OR IMPLIED AND NOVATEK
CORPORATION SHALL NOT BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL OR
SPECIAL DAMAGES OR ANY OTHER EXPENSES OR REPAIR OR REPLACEMENT
AS DESCRIBED ABOVE.
All warranty claims should be forwarded to:
NOVATEK CORPORATION
216 Philips Road
Exton, PA 19341
ATTENTION: CLAIM AND SERVICE DEPARTMENT
R.M.A. # ____________
CALL Toll Free at 1-866-563-7800 for your RMA number prior to shipping.
Also include a brief description of the problem as well as a phone number, contact name
and return address in case NOVATEK CORPORATION service personnel has to get in
contact with you.
