Novis BL5148 BetterLiving User manual

Standard Wheelchair
Grip rings
Detachable, swing away footrests
Padded backrest
Nylon heel loops
Detachable,
height adjustable
padded armrests
Quick release
24” (610 mm)
rear drive wheels
Profiled grip attendant handles
Park brakes
Prior to use please read all instructions.
We recommend you keep this User Guide in a safe place for future reference.
user guide

2
Product Overview
An economical self propelled wheelchair that
is easy to manoeuvre, fold, transport and
carry. Lightweight non-corroding aluminium
frame equipped with comfortable profiled grip
handles, detachable height adjustable padded
armrests, sturdy park brakes and anti-tip
wheels for added safety.
The detachable, height adjustable footrests
are equipped with heel loops, offering greater
security and user comfort. Both footrests
fold away to increase accessibility and ease
of transfer. The chair is simple to fold for easy
travel and storage.
Novis Standard Wheelchair
Box Contents and Inspection
Carefully remove all components from the box and
check items against the list below. Any damaged
or missing components should be reported to your
authorised dealer or Novis Healthcare.
Prior to use, remove all packaging and plastic
wrapping and check the wheelchair for any
damage that may have occurred in transit,
paying particular attention to:
›Any cracks or damage to the wheels,
tyres or chassis.
›Damage to the seat and backrest.
›Any missing or loose screws, wheelnuts
or fasteners.
Intended Use
›This wheelchair is designed for indoor and outdoor
use, and is intended for either self propulsion or
propulsion by an attendant.
›The maximum user weight is 110 kilograms,
as stated on the manufacturer’s label.
›The wheelchair should only be used and
maintained in accordance with the instructions in
this User Guide.
User Guide (this document)
Wheelchair
Left hand footrest
Right hand footrest
Tool kit

3
Unfold the wheelchair
To unfold the wheelchair, place on a
stable surface and stand behind the
wheelchair.
Use both hands to press down on
the outer edges of the seat frame to
unfold. It may help to gently tilt the
wheelchair back to lift the front wheels
off the floor.
Once open, press firmly to make sure
cross brace is locked.
Set Up
Attach the footrests
With the footrest at a 90 angle to the chassis
(ie swung outwards to ensure the semi circle
recess on the footrest bracket fits around the
leg post), attach the footrest by aligning and
dropping the hinge at the top of each footrest
into the hole in the top of the chassis leg
section.
Now swivel the footrest inward to lock into
position and fold down the footplates.

4
Adjusting the armrest height
To adjust the height of the armrests, press and
rotate the rectangular lever (located directly
below the armrest) to unlock.
Adjust each armrest individually by moving the
armrest T-bar up or down the armrest shaft.
Once preferred height is set, rotate the
rectangular lever back to lock the armrest into
position.
Adjustments
Adjusting the brakes
When fully released, the maximum distance
between the brake latch and the tyre should be
no more than 15 mm.
To adjust the brakes, loosen the two bolts at
the top of the brake (refer to picture) and slide
the metal bar left or right to set the correct
distance. Please note, it is easier to access the
bolts when the armrests are removed.
Once position is set, securely tighten both bolts
and check the adjustment has not affected
proper brake function (when the brakes are
engaged the rear wheels should not move).
15
mm

5
Adjusting the footrest height
Correct leg position is achieved when the occupant’s feet can
be placed flat on the footplates when his/her thighs are resting
horizontally on the seat.
To adjust the height of the footrests, use the Allen Key (provided
in the toolkit) to remove the bolt and washer from the footrest.
Adjust each footrest by sliding up or down until the desired
position and height are reached, ensuring both footplates are at
the same height.
Reinsert the bolt and washer into the frame and tighten the bolt
firmly to lock into place.
Adjustments
Adjusting the anti-tip wheels
This wheelchair includes adjustable anti-tip wheels for
enhanced stability and safety. They can be rotated up and out of
the way or adjusted in length to suit the individual occupant.
To adjust the length of the anti-tip wheels, push the locking
pin in until the tube is free to move. Slide the tube up or down
to adjust the height of the wheels to the desired length and
then release the locking pin in line with one of the holes to lock,
making sure it is fully extended into the hole.
