NPG DSR 4008 A User manual

English
Personal Grand Technology, S.A. Pol. Ind. De las Monjas C/ Ecuador, 14 28850 Torrejón de Ardoz-Madrid TEL. [phone] [email protected] www.npgtech.com
USER MANUAL
DSR 4008 A
DIGITAL SATELLITE RECEIVER

2
English
CONTENTS
GENERAL INFORMATION 3
Main Feature 3
For your Safety 3
General Operation 4
RCU 4-5
INSTALLATION 5
Rear Panel 6
Connecting to TV& VCR using SCART support 6
Connecting to TV using RCA support 6
Connecting to Digital Amplifier 6
MENU INFORMATION 7
Main Menu 7
1 . Channel List 7
1 . 1 TV Channel List 8
1 . 2 Radio Channel List 10
1 . 3 Delete All 10
2 . Installation 10
2 . 1 Antenna Connection 10
2 . 2 Satellite List 10
2 . 3 Antenna Setup 11
2 . 4 Single Satellite Search 12
2 . 5 Multi Satellite Search 13
2 . 6 TP List 13
3 . System Setup 14
3 . 1 Language 14
3 . 2 TV 14
3 . 3 Local Time setting 14
3 . 4 Timer Setting 14
3 . 5 Parental Control 15
3 . 6 OSD Setting 15
3 . 7 Favorite 15
3 . 8 Other 15
4 . Tools 16
4 . 1 Information 16
4 . 2 Factory Setting 16
4 . 3 SatcoDx Auto Programing 16
4 . 4 Upgrade y Rs 2 3 2 16
5 . Game 16
6 . Hot key 16
6 . 1 Info 16
6 . 2 EPG 16
6 . 3 Find 17
6 . 4 Numer 17
6 . 5 TV /Radio 17
6 . 6 Up /Down 17
6 . 7 Left /Right 17
6 . 8 Mute 17
6 . 9 Pause 17
6 . 1 0 OK 17
6 . 1 1 Audio 17
6 . 1 2 Recall 17
6 . 1 3 Fav 17
6 . 1 4 Teletext 18
6 . 1 5 Zoom 18
TROU LE SHOOTING 18

3
English
GENERAL INFORMATION
Main Features
A Digital Satellite&Terrestrial Receiver is a convenient product that allows you to
view a variety of programs provided through satellite or terrestrial antenna. This
user's guide covers the installation of the receiver and the necessary steps to im-
plement various features. This also explains special features available only in this
receiver in detail, which will allow you to make full of these feature.
Information confirmed in this document is subject to change. We reserves the
right, without notice, to make change in product design or performances as pro-
gress in engineering or technology.
•High quality Video & Audio & Digital Audio
•Fully MPEG - 2 , DV compliant
•Provide friendly and easy -to -use menu system
•Various channel editing function (Favorite , moving , locking , renaming , deleting
and sorting )
•User programmable various Satellite & Transponder information Automatically
search for newly added transponder
•Stores up to 4 0 0 0 channels
•Easy and speedy software upgrade through RS - 2 3 2 port Plug -and -play data
transfer system (DSR to DSR )
•Timer function , automatically turns On /Off by setting function (daily, monthly, ye-
arly ) Automatic reserved channel moving system
•Provide Electronic Program Guide (EPG )
•Teletext function support
•2 5 6 colors On -Screen -Display
•Last channel automatically saving
To avoid electric-shock hazards, do not open the cabinet,
refer servicing to qualified personnel only.
For Your Safety
Keep the receiver away from flower vases, tubs, sinks, etc.,
in order to avoid damaging the equipment.
Do not expose the receiver un-der the sunlight. And keep it
away from the heat source.
Do not block ventilation holes of the Receiver so that air can
circulate freely.
When the abnormal phenomenon occur, you should cut off
the power immediately.
Do not touch the receiver during thunder, since that might
create electric-shock hazards.
Switch the receiver off whenever it remains out of service
for an extended period.
e sure to turn the Receiver off and disconnect the AC
power cord before cleaning the Receiver surface. If the sur-
face is dirty, wipe clean with a cloth which has been dipped
in a weak soap-and-water solution and wrung out tho-
roughly, and then wipe again with a dry cloth.

4
English
General Operation
Throughout this manual you will notice that the everyday operation of the receiver
is based on a series of user friendly on screen display and menus. These menus
will help you get the most from your receiver, guiding you through installation, chan-
nel organizing, viewing and many other functions.
All functions can be carried out using the buttons on the RCU, and some of the
functions can also be carried out using the buttons on the front panel.
The receiver is easy to use, always at your command and adaptable for future ad-
vances.
Please be aware that new software may change the functionality of the receiver.
Should you experience any difficulties with the operation of your receiver, please
consult the relevant section of this manual, including the Problem Shooting, or al-
ternatively call your dealer or a customer service adviser.
RCU
*The picture is only for reference,please make the object as the standard.
Turns power ON /OFF of the DSR
When watching a channel , mute the sound
Enter number of the required menu item or
select a channel number to watch
Switches back to previous channel
This key one time to run menu onscreen
Moves
Return to the previous menu on the menu
screen or escape from the menu
Enter into the zoom in mode
Display the Audio window.
Enter into the nine -pictures mode displayed
on the screen .
Show information of the current channel
Press
Enter into the sleep in mode
Switch between TV and AV modes
Display the satellite list

5
English
RCU INSTALLATION
*The picture is only for reference,please make the object as the standard.
Switches between
TV and Radio
mode
Whenwatching a
channel change
channels or move to
the next higher or
lower item in the
menu
When watching a
channel , adjust the
volume or move to
the left or right item
in the menu
POWER ON/OFF
CONNECT TO 1 2 V TO AN EXTERNAL 0 / 1 2 V SWITCH
CONNECT TO A PC FOR S /W UPGRADE
LN IN : CONNECT TO SATELLITE ANTENNA
LN OUT:CONNECT TO THE OTHER RECEIVER
RF IN : CONNECT TO CA LE SINGAL
RF OUT: CONNECT TO TV ANT INPUT
CONNECT VIDEO TO TV USING RCA JACK
CONNECT TO AUDIO R /L TO TV OR AUDIO TUNER
CONNECT TO A DIGITAL AMPLIFIER
CONNECT TO TV AND VCR
USING A SCART CA LE
Executes the selec-
ted item in the menu
screen or enters the
desired value in any
input mode
When watching a
channel , adjust the
volume or move to
the left or right item
in the menu
Press once to pause
the screen picture ,
press once again to
go to the normal
mode
Call up the EPG
(Electronic Pro-
gram Guide )
Display the favo-
rite group list
Display the favo-
rite group list
Switch to teletext
or subtitle mode
Rear Panel

6
English
INSTALLATION
*The picture is only for reference,please make the object as the standard.
Connecting to TV using SCART support Connecting to TV using SCART support
Connecting to TV using RCA support
Satellite
Dish
DSR
TV
TV
TV
DSR
DSR
Satellite
Dish
Satellite
Dish
DIGITAL AUDIO
CONVERTOR OR
AMPLIFIER
SPEAKER

7
English
MENU INFORMATION
Main Menu
Make sure that you have properly installed and connected the cables of the recei-
ver well . If the receiver is the factory status or there is no program list , when
power on , the Main Menu window will be displayed on the screen .
During the normal TV /Radio mode , press MENU key on the RCU to enter into
the Main Menu window .
This menu consists of 5 major main menus as follow .
- Edit Channel
- Installation
- System Setup
- Tools
- Game
n If there is no program , you can not exit from the Main Menu window by pressing
MENU or EXIT key . System will inform "No channel" and the following items turn
grey.
1. Channel List
1. Press OK key or key to
pop up the "Input Password"
dialogue, you can not enter
into the menu unless the co-
rrect password is inputted.
The default password is
"0000".
2. Press PR+, PR- keys to
move the cursor up or down.
3. Press EXIT key or key to move the focus to the left menu.
n During the installation the OK key confirms a selection and LIST key shows Down
List ox if the column has 34mark . You can also use the numeric keys on the
RCU to enter numeric value .
Use the PR + , PR - key to move upwards and downwards from one line to another
line and use key to move from main menu to sub menu and move from left
side to right side or versa .
Meantime , you want to escape the menu system , please press MENUor EXITkey
on the RCU .
Sub-menu Turn grey when there is no program
Edit Channel TV Channel List
Radio Channel List
Delete all
Installation Antenna Connection Satellite List
Antenna Setup Single Satellite Search
Multi Satellite Search TP List
System Setup Language TV System Local Time Setting
Timer Setting Parental Lock OSD Setting
Favorite Other
Tools Information Factory Setting
SatecoDX Auto Programing
Rs232 Master
Game Tetris Othello

8
English
MENU INFORMATION
1 . 1 TV Channel List
1 . Press keys to select
satellite .
2 . Press PR + , PR - keys to
select the program that you
want to play, and then press
OKkey to view it in the small
window . If move the yellow
cursor to select up or down ,
you will see a gray line which indicates the playing program in the small window
3. Press FAV key to move the FAV button upward. Select the program and press
OK key to pop up the favourite group list. In the list, select the group that you want
to add into and press OKkey, and then you will find the favourite mark is displayed
at the right side of the selected program.
Press FAV key again to exit from the fav mode, and you will find the FAV button re-
turn to the origin position.
4. Press red colour key to
move the Lock button upward.
Select the program and press
OK key to mark this program
with the Lock mark. You can
cancel this mark by pressing
OK key once more.
Press red colour key again to
exit from the lock mode, and
you will find the Lock button return to the origin position.
5. Press green colour key to
move the Skip button upward.
Select the program and press
OK key to mark this program
with the skip mark. You can
cancel this mark by pressing
OK key once more.
Press green colour key again to exit from the skip mode, and you will find the Skip
button return to the origin position.
6. Press yellow colour key to
move the Move button up-
ward. Select the program and
press OKkey to mark this pro-
gram with the move mark.
Press PR+, PR- keys to move
the cursor to the position
where you want to locate and
press OK key to confirm.
Press yellow colour key again to exit from the yellow mode, and you will find the ye-
llow button return to the origin position.
7. Press blue colour key to enter into the Edit channel window.

9
English
MENU INFORMATION
I. Sort (red colour key)
Press red colour key to pop up the Sort drop-down list.
Name(A-Z): The ascending
order, omitting the $ charac-
ter, the number is ahead, then
the capital letter, at last the lo-
wercase.
Name (Z-A): The opposite
order of the above Name (A-Z).
Free/Scrabmle: All FTA pro-
grams are listed ahead, while
all scrambled programs are listed last.
Lock: all locked programs are listed at the last.
II. Edit (green colour key)
Press green colour key to
move the Edit button upward.
Select the program and press
OK key to pop up the Rename
window.
In Rename window, press red
colour key to switch between
capital letter and lower letter;
press green colour key to de-
lete the character on the cursor; press keys to move the cursor left or
right; press numeric keys (0-9) to input the character, please refer to the down
table. Press yellow colour key to save and exit, or press blue key to cancel and exit.
Numeric keys Press numeric key repeatedly , display in circle
1 . , * ? ! @ 1
2 A C 2
3 DEF 3
4 GHI 4
5 JKL 5
6 MNO 6
7 PQRS 7
8 TUV 8
9 WXYZ 9
0 [space ] _ - 0
If the name is empty, system will pop up a dialogue informing "Name" once yellow
colour key is pressed . Press OK key to close this dialogue .
III. Edit (blue colour key)
In Edit Channel window, press
blue colour key to move the
Delete button upward. Select
the program and press OKkey
to mark this program with the
deletion mark. You can cancel
this mark by pressing OK key
again.
Press EXIT key to pop up the dialogue "Are you sure to save?". Select Yes button
and press OKkey to save, or select NObutton and press OK key to exit without sa-
ving.

10
English
MENU INFORMATION
1.2 Radio Channel List
Sine the same operation as 1.1 TV Channel List, here we don't explain any more.
2.1 Antenna Connection
Press keys to select
between Motor Antenna and
Fixed Antenna.
2.2 Satellite List
1. Press PR+, PR- keys to select the satellite up or down. Press OK key to select
and mark, and you can press
OK key again to cancel the se-
lection and the mark.
2. If there is no satellite, the
red colour and blue colour
keys will be invalid.
3. Press red colour key to pop
up the Edit Satellite window.
Press PR+, PR- keys to move
cursor up or down.
Name: User numeric keys to change the name of the satellite, please refer to the
Edit Channel Name.
Longitude: You can press keys to switch between east longitude and west
longitude. After pressing OK key, you can use numeric keys to edit the longitude,
press EXIT key or the PR+, PR-keys to exit editing mode. The range of the longitude
is from 1 to 180 degree. If beyond this range, system will inform you "out of range"
when you press yellow colour key on the RCU.
2. Installation
1. Press OK key or key to pop up the "Input Password" dialogue, you can not
enter into the menu unless the
correct password is inputted.
The default password is
"0000".
2. Press PR+, PR- keys to
move the cursor up or down.
3. Press EXIT key or key
to move the focus to the left
menu.
1 . 3 Delete All
Move cursor to the Delete All item, and press OK Key to pop up the dialogue "War-
ning! Do you really want to de-
lete all channel?".
Press EXIT key to pop up the
dialogue "Are you sure to
save?". Select Yes button and
press OK key to save, or select
NO button and press OK key to
exit without saving.

11
English
MENU INFORMATION
After setting, press yellow colour key
to save and exit, while press blue co-
lour key to exit vwithout saving.
4. Press green colour key to pop up
the Add Satellite window. Since the
same operation as the above Edit Sa-
tellite window, here we don't explain
any more.
5. Press blue colour key to pop up the dialogue "Are you sure to delete?". Select
Yes button and press OK key to delete the selected satellite. You can cancel this
operation by pressing OK key at the NO button.
2.3 Antenna Setup
Part A: Fixed
Suppose that you have selected Fixed Antenna in the Antenna Connection win-
dow .
1 . Satellite : All selected satellites in the satellite list are displayed in this item .
Press keys to select the satellite in circle . Or press OK key to pop up the
drop-down list , then select the desired satellite in the list and press OK key to
confirm .
2 . LN Freq , Transponder ,
DiSEqC 1 . 0 , DiSEqC 1 . 1 :
The same operation as the
above .
3 . 2 2 K , 0 / 1 2 V, Toneburst
, LN Power : You can press
keys to select in circle.
Part : Moter
Suppose that you have selected Moter Antenna in the Antenna Connection win-
dow.
1. LN Type: Select the proper LN type.
2. Motor Type: Select between DiSEqC1.2 and USALS. If you select DiSEqC1.2, the
following Local Longitude and Local Latitude items will turn grey.
3. Delete All: Press OK key to
pop up the dialogue "Are you
sure to clear set satellite posi-
tion of this tuner?". Press OK
key at the Yes button to clear
all the memories about the po-
sition of the satellites that has

12
English
MENU INFORMATION
4 . Motor Setting : Press OK
key to the Motor Setting win-
dow .
Satellite : Press keys
to select the satellite in circle .
Or press OK key to pop up the
drop down list , then select
the desired satellite in the list
and press OK key to confirm
Transponder: The same operation as the above.
Position No., & Save: The range is from 0 to 63. "0" delegates the original position.
You can select the proper value when you has rotated the antenna.
Go to X: Press OK key to pop up the drop-down list, select the proper position (re-
ference or from 1to 63) to realize the selected position.
West <Save> East: Press key to turn west, while press key to turn east.
Press OK key to pop up the dialogue "Are you sure to change this satellite's posi-
tion?". Press OK key at the Yes button to save the current position, or press OK
key at the No button to cancel the operation.
Recalculation: Press OK key to pop up the dialogue "Are you sure to change this
satellite's position?". Press OK key at the Yes button to recalculation.
5. Limit Setup: Press OK key to
pop up the Limit Setup window.
Limit Setup: Press
keys to switch among Disable
Limit, East Limit and West
Limit.
Limit Setup: Move cursor to
the Limit Setup button. You
can press key to turn west , or press key to turn east.
Go to Reference: Press OK key to go to reference. If you select Disable Limit in the
above Limit Setup item, this button will turn grey.
6. If select USALS, Delete All item will turn grey.
Local Longitude, Local Latitude: Press keys to switch between West and
East, or press keys to switch between North and South. Press OK key to
enter into the editing mode.
Use numeric keys (0-9) to
input the longitude or latitude,
press MENUkey or EXITkey to
exit. The range of the longitude
is from 0 to 180,while the
range of the latitude is from 0
to 90. If the inputted value is
not in this range, system will
pop up a dialogue "Our of Range" when exit from this window. You can press OK
key to close this dialogue.
7. Motor Setting: Press OK key to enter into the Motor setting window.
Satellite, Transponder: Press keys to select satellite or transponder, or
press OK key to pop up the drop-down list and select in the list.
2.4 Single Satellite Search
1. Satellite : Press keys to select the satellite in circle. Or press OK key to
pop up the drop-down list, then select the desired satellite in the list and press OK
key to confirm.
2. FTA Only: Press keys
to select between Yes and No.
3. Scan Channel: Press
keys to select among
TV+Radio, TV Channel

13
English
MENU INFORMATION
4. Network Search: Select between
No and Yes. This item turns grey
when Auto Scan is selected in the fo-
llowing Scan mode item.
5. Scan Mode: Press keys
to select between Auto Scan and
Preset Scan. Auto Scan is lind
scan, while Preset Scan is to search
the preset frequencies.
6. Search: Press OK key to start searching.
2.5 Multi Satellite Search
From the Multi Satellite Se-
arch window, you can search
several satellites at the one
time.
1. Satellite: All selected satelli-
tes in the satellite list window
are displayed on the down
part. You can press keys to switch among them.
2. FTA Only: Press keys to select between Yes and No.
3. Scan Channel: Press keys to select among TV + Radio, TV Channel,
Radio.
4. Network Search: Select between No and Yes. This item turns grey when Auto
Scan is selected in the following Scan mode item.
5. Scan Mode: Press keys to select between Auto Scan and Preset Scan.
Auto Scan is lind scan, while Preset Scan is to search the preset frequencies.
6. Search: Press OK key to start searching.
2.6 TP List
1. Press PR+,PR- keys to select the proper satellite.
2. Press red colour key to pop up the Edit TP window.
Frequency, Symbol rate: Press
keys to add or reduce
by step one. Or press numeric
keys (0-9)to input the desired
value. The range of the fre-
quency is 3000-13450, while
the range of the symbol rate is
1000~45000. The inputted
value is beyond this range, the
value will return to the origin
value.
Polarity: Press keys to switch between Vertical and Horizontal.
3. Press green colour key to pop up the Add TP window. Since the same operation
as the above Edit TP window, here we don't explain any more.
4. Press yellow colour key to pop up dialogue " Are you sure to delete?". Press OK
key at the Yes button to delete the selected TP, or press EXITkey to cancel the ope-
ration.
5. Press bluecolour key to pop
up the TP Search window.
FTA only, Scan Channel, Net-
work Search:
Press keys to select
the proper option.
Press OK key at the OK button
to start searching.

14
English
MENU INFORMATION
3. System Setup
1. Press OK key or key to move the cursor to the right menu.
2. Press PR+, PR- keys to move the cursor up or down.
3. Press EXIT key or key to move the focus to the left menu.
3.1 Language
1. Press OK key to enter into
the Language window. Press
keys to select the lan-
guage in circle, while press
PR+, PR-keys to move the cur-
sor up or down in circle.
2. Press MENUkey or EXITkey
to save and exit.
3. The types of the language, pleaser refer to the configuration of the customer.
3.2 TV System
Press PR+, PR- key to move the cursor up or down, while press keys to
change the setting and the setting will take effect immediately.
1. Display Mode: Select among Auto,PAL, PAL-M, PAL-N, NTSC.
2. Aspect Mode: Select among 4:3 Letter ox, 4:3PanScan, 16:9.
3. Video Output: Select between RG and CV S.If you select the mode of RG ,the
VCR Loopthrough will turn grey below.
4. RF System,RF Channel: PAL:21~29,NTSC:14~83
3.3 Local Time Setting
1. Summer Time: Select bet-
ween ON and OFF. "OFF" dele-
gates the normal time. If
select ON, time will add one
hour.
2. GMT Offset: When select
"ON" in GMT Usage item,
system will get the date and
time information from the
screen automatically. Date and Time two items will turn grey. Select the proper
option in the GMT Offset item. The default setting is GMT ON.
3.Date, Time: When select "OFF" in GMT Usage, Date and Time two items take ef-
fect, while GMT Usage turns grey. Use numeric keys to input the desired value.5.
After setting, press MENU key or EXIT key to exit and save. If the value is invalid,
system will inform "Invalid input! Continue to edit?". Press OK key at the Yes button
to continue the modification, or press OK key at the No button to exit without sa-
ving.
3.4 Timer Setting
If there is no program, you can
not enter into this window.
There are 8 timers that can
be set. Select Timer up or
down, and press OK key to
enter into the setting window.
1. Timer mode: The default
mode is off. You can set the
timer once, daily, weekly,
monthly and yearly.

15
English
MENU INFORMATION
2. Timer Service: Select between Channel and Message. If Channel is selected, the
Wakeup Channel is displayed in the following item. If Message is selected, the Wa-
keup Message is displayed in
the following item. In wakeup
message, you can select
among irthday, Anniversary,
General. At the same time the
duration item turns grey.
3. Wakeup Date, On Time: Use
numeric keys to input the valid
date.
Duration: Set the gap time. After waking up, system will power off automatically
after the duration time.
Press MENU or EXIT key to save and exit.
3.5 Parental Lock
efore entering into the Pa-
rental Lock window, you need
input the correct password.
The default password is
0000
.
1. Menu Lock: Press
keys to select between Off and
On. If select "On" , you can not
enter into the most window
before entering the password.
2. Channel Lock: Press
keys to select between Off and On. The default value is Off.
If select "On", you can not view the locked channel set in Chanel List Edit window
until you have inputted the correct password.
3. New Password: User numeric key (0-9) to input the new password.
4. Confirm Password:Input the new password once again. Confirm password must
be the same as the New password. System will inform you "
Change password suc-
cessfully!
" while they are the same, or inform you to input the password of Confirm
password once again when they are not the same.
3.6 OSD Setting
1. Subtitle Display: Press keys to select between On and Off.
2. OSD Timeout: Press keys toselect from 1 to 10 by step1. The default
values Is 5.
3. OSD Transparency: Press keys to select among Off, 10%, 20%, 30%,
40%. The default option is Off.
3.7 Favorite
There are 32 favorites group
listed in this window. Press
PR+, PR- keys to select one
and press OK key to the Re-
name window. Since the same
operation as the above the
Add Satellite window, here we
don't explain any more.
3.8 Other
1. LN Power: Select between Off and On.
2. Channel Play Type: Select among All, Free, Scramble.
3. Channel Change: Select between Freeze and lack screen.
4. eeper: Select between Off and On.

16
English
MENU INFORMATION
4. Tools
1. Press OK key or key to
pop up the "Input Password"
dialogue, you can not enter
into the menu unless the co-
rrect password is inputted.
The default password is
0000
.
2. Press PR+, PR- keys to
move the cursor up or down.
3. Press EXIT key or key to move the focus to the left menu.
4.1 Information
Press OK key to the Information window.
4.2 Factory Setting
Press OK key to enter into the Factory Setting window.
Select Yes button and press OK key to return to the factory setting. All searched
channels and set information will be erased.
Select No button and press OK key to cancel this operation, or press MENU or
EXIT key to cancel and exit.
4.3 SatcoDX Auto Programing
Press OK key at the Start button to start receiving date from RS232 for 10 se-
conds.
4.4 Upgrade Rs232
1. Press keys to select among allcode, maincode, card,Radioback,keydate
defaultdb, userdb. The default option is allcode.
2. Press OK key at the Start button to start checking serial port.
5. Game
1. Press OK key or key to enter into the game.
2. Press PR+, PR- keys to move the cursor up or down.
3. Press EXIT key or key to move the focus to the left menu.
4. Select the game that you want to play and press OK key to enter into the win-
dow.
6. Hot Key
6.1 Info
Press INFO key to pop up the Info bar.
Press INFO key again to pop up the program guide of the current program. You
can press keys to know the program guide of the future 16 days.
6.2 EPG
Press EPG key to enter into the EPG window.
1. Press PR+, PR-, keys to select up or down, left or right.
2. Press red colour key to pop up the Time ar window. Press PR+, PR- keys to se-
lect up or down, while press keys to select left or right in the time bar.
:Press OK key at this button to return to the EPG window.
w : Press OK key at this but-
ton to move the cursor to the
current time line.
a d : Press OK key to push the
time forward or backward by
half an hour.
5 6: Press OK key to push
the time forward or backward
by half an hour.
aaa ddd: Press OK key to push
the time forward or backward
by a day. From the current day, you can switch among the future 14 days in circle.
A

17
English
MENU INFORMATION
3. Detail Information: In the EPG win-
dow, press PR+, PR- keys to
select the channel and program, and
press OK key to know the detail infor-
mation of the current program.
4. Press green colour key to enter into
the Timer window. You can add the cu-
rrent program to the Timer. If 8 timers
is already, system will inform "Timer is
full!'.
6.3 Find
Press FIND key on to pop up the Find window. User numeric keys to enter into the
character and use the colour keys to realized the corresponding operation.
6.4 Number
Use the numeric keys (0-9) to input the number of the desired channel. If the in-
putted number is beyond the valid channel number, system will "No such a channel"
and press OK key to close this message.
6.5 TV/RADIO
In normal mode, press TV/RADIOkey to switch between TV mode and Radio mode.
6.6 Up/Down (Channel Change)
Press PR+, PR-keys to change the channel up or down. If in the all satellites group,
you can select channel in all searched channels. If in the specific satellite, only can
select channel in the satellite group.
6.7 Left/Righ (Volume+/-)
Press keys to change the volume. Press keys to decrease the volume
by step 1, while press keys to add the volume by step1.
6.8 Mute
Press key to close the volume. You can press key once again to restore
the volume, or press keys to open the volume.
6.9 Pause
During the viewing, you can press PAUSE key to stop the picture while the volume
continues. You can play the picture by pressing PAUSE key once again.
6.10 OK
1. During the viewing or listening, press OK key to pop up
the TV program list or the Radio program list.
2. Press PR+, PR-keys to select the channel up or down,
and then press OK key to play this channel in full-screen.
3. Press keys to select the satellite.
4. Press MENU or EXIT key to close this window.
6.11 Audio
1. Press keys to enter into the Audio window.
2. Press keys to select among Left, Right, Stereo,
and Mono.
3. Changing the audio mode is only connected with the
current channel, not all the channels.
4. Press MENU or EXIT key to close this window.
6.12 Recall
Press PR key to switch the current channel to the previous channel.
6.13 FAV
1. Press FAV key to pop up the favourite group window.

18
English
MENU INFORMATION TROU LE SHOOTING
TROU LE SHOOTING
2. Press keys to select the favorite group. Press PR+, PR- keys to select
the channel up or down.. Press OK key at the selected channel to view it in full-
screen. Press MENU or EXIT key to exit.
3. If there is no favorite channel, system will inform " No FAV Channel!" when you
press FAV key.
6.14 Teletext
Press TXT keys to open the teletext on the screen. If there is no teletext, system
will inform "No Teletext Data". Press EXIT key to exit.
6.15 Zoom
1. Press ZOOM key to switch among Zoom*1, Zoom*2, Zoom*4, Zoom*6,
Zoom*8, Zoom*12, Zoom*16.
2. In zoom mode, press PR+, PR- keys to move the cursor up, left, right,
down.
3. Press MENU or EXIT key to exit
Problem Possible causes What to do
ad picture / blocking
error.
The satellite dish is
not pointing at the
satellite. Adjust the dish.
Signal is too strong. Connect a signal attenuator to the
LN input.
Satellite dish is too
small. Change to a larger dish.
LN noise factor
too high. Change to an LN with lower noise
factor.
The LN is faulty. Change the LN .
The picture is not sho-
wed on the screen,
when switching on.
The system is con-
nected by RF
leads.
Check the UHF channel fixed in
your system and tune the UHF
channel properly.
There is interference
on your digital satellite
channels, an existing te-
rrestrial channel or
video signal.
The system is con-
nected by RF leads
and the output
channel of the re-
ceiver interferes
with an existing te-
rrestrial channels
or Video signal.
Change the receiver output chan-
nel to a more suitable channel, or
connect the system by SCART
leads.
The RCU is not working. attery exhausted. Change the batteries.
RCU is incorrectly
aimed. Aim RCU at the receiver, or check
that nothing blocks the front panel.
Problem Possible causes What to do
The display on the front
panel does not light up. Main cable is not
connected.
Check that the main cable is plug-
ged into
the power socket.
No sound or picture,
but the front panel
shows red light.
The receiver is in
standby mode. Press the standby button.
No sound or picture.
The satellite dish is
not pointing at the
satellite.
Adjust the dish. Check the signal
level in the Antenna Setup menu.
No signal or weak
signal.
Check the cable connections, LN
and other equipment connected
between the LN and the receiver,
or adjust the dish.
Note : If you have tried all of the actions suggested above, without solving the pro-
blem, please contact your dealer or service provider.

19
English
Personal Grand Technology, S.A. Pol. Ind. De las Monjas C/ Ecuador, 14 28850 Torrejón de Ardoz-Madrid TEL. [phone] [email protected] www.npgtech.com
This symbol on the product or in the instructions means that
your electrical and electronic equipment should be disposed at
the end of life separately from your household waste.There are
separate collection systems for recycling in the EU.For more in-
formation,please contact the local authority or your retailer
where you purchased the product ..
Personal Grand Technology S.A.reserves the right to change
specifications and / or functions of its products without notice in
order to improve technically.
i

English
