NTI XTENDEX Series User manual

ST-C6USB4K18GB-HDBT
4K 18Gbps HDMI USB KVM Extender over
HDBase-T
Installation and Operation Manual
MAN356 Rev Date 2/26/2020
XTENDEX®Series

TRADEMARK
XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2019-2020 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored
in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the
right to make changes in the product design without reservation and without notification to its users.
Note: CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series products
should not be run underground, outdoors or between buildings.
WARNING: Outdoor or underground runs of CATx cable could be dangerous and will void the warranty.
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.

TABLE OF CONTENTS
Introduction......................................................................................................................................................................1
Materials..........................................................................................................................................................................1
Connectors and LEDs.....................................................................................................................................................2
Connectors and LEDs.....................................................................................................................................................3
Preparation for Installation ..............................................................................................................................................4
Installation .......................................................................................................................................................................5
Firmware Update.............................................................................................................................................................6
Technical Specifications..................................................................................................................................................6
Interconnection Cable Wiring Method.............................................................................................................................7
Warranty Information.......................................................................................................................................................7

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
1
INTRODUCTION
The XTENDEX®4K 18Gbps HDMI USB KVM Extender over HDBase-T with RS232 transmits uncompressed digital Ultra-HD
4Kx2K 60Hz 4:4:4 HDMI signal, USB, IR, RS232, and power up to 328 feet over a single solid or stranded CAT6/6a/7 cable (not
CAT5/5e) using HDBase-T technology. Each extender consists of a local unit that connects to a computer and provides local
keyboard, monitor and mouse connections; and a remote unit that connects to a keyboard, monitor and mouse.
Features
Transmits an uncompressed high speed HDMI signal over one CAT6/6a/7 cable.
Supports resolutions up to Ultra-HD 4Kx2K (3840x2160 and 4096x2160 @24/30/60Hz YUV 4:4:4).
oExtend a 4Kx2K signal up to 328 feet (100 meters) with solid or stranded CAT6/6a/7 cable.
oExtend a 1080p signal up to 492 feet (150 meters) with solid or stranded CAT6/6a/7 cable.
HDMI features supported:
oHDMI 2.0
oUp to 36-bit Deep Color
oRGB, YUV 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2
oDolby TrueHD, DTS-HD Master Audio, Dolby Digital, Dolby Digital+, Dolby Atmos, Dolby Digital 2/5.1CH, LPCM
2/5.1/7.1CH, LPCM 2CH, LPCM 5.1, DTS 5.1, DTS:X, and DTS 2/5.1CH.
oBandwidth up to 600 MHz (18 Gbps)
oSupport for CEC (consumer electronic control) compatible devices.
oHDR10
HDCP 2.2 and 1.4 compliant.
Local unit provides local KVM access.
Bi-directional Infrared Remote (IR) control of HDMI source or display. IR transport channel can be forward or backward per the
installation.
Supports full-duplex RS232 up to 115200 baud.
USB ports for keyboard, mouse and other USB devices.
oKeyboard and mouse are hot-pluggable.
Only one power supply is necessary to power both the local and remote units.
Use the DIP switch on the receiver to extract the digital HDMI audio signal and convert it to 2-channel analog stereo audio or
multi-channel SPDIF digital audio.
MATERIALS
Materials supplied with this kit:
Local and Remote Unit
100-240VAC, 50 or 60Hz-24VDC/1A AC Adapter w/ Adapters for US, EU, UK and AU
USB Type A Male to USB Type B Male cable
USB Type A male to USB Type Micro B male cable
2- Terminal Blocks
IR Transmitter
IR Receiver
Mounting Brackets w/ screws
URL Slip with path to this manual
Materials Not supplied but REQUIRED:
CAT6/6a solid/stranded UTP; CAT7 solid/stranded STP (referred to as "CATx" throughout this manual) twisted-pair
cables terminated with RJ45 connectors wired straight thru- pin 1 to pin 1, etc. (see page 7 for proper EIA/TIA 568 B wiring
method). CAT5/5e cable is NOT recommended for use with this product.
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.
HDMI male-male cable to connect a HDMI source or display (Order NTI # HD-xx-MM where xx=3, 6, 9,14,20,30, 50 and 100
foot cable).
DVI to HDMI male-male cable to connect a DVI source or display (Order DVI-HD-xM-MM where xx=1,2,3 or 5 meters)
(Note: Does not support 4Kx2K resolutions).
Always use the shortest possible cable for best performance.
Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324) in US & Canada
or 330-562-7070 (Worldwide) or at our website at http://www.networktechinc.com and we will be happy to be of assistance.

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
CONNECTORS AND LEDS
# LABEL CONNECTOR DESCRIPTION
FRONT
1 IR In 3.5mm Stereo Jack For connecting IR Extender (Receiver)
Place IR Receiver where IR Remote Control will have line-of-sight
2 IR Out 3.5mm Stereo Jack For connecting the IR Emitter
Place the IR blaster in direct line-of-sight of the equipment to be
controlled.
3 USB USB Type A
female x 2 For connecting supported USB devices (keyboard, mouse, CAC Card
Reader, Whiteboard, Touchscreen Monitor)
4 USB USB Type B female For connecting USB device cable from CPU
5 Long Reach DIP Switch Switch to“ 0 ” to transmit video up to 4K@60Hz up to 100m
Switch to “1” to transmit video up to 1080P@60Hz up to 150m.
(Before powering ON, TX and RX must be selected to 0 or 1 at the same
time. Do not switch while powered ON.)
6 Loop EDID DIP Switch Switch to “0” to copy EDID from display connected to Remote Unit
Switch to “1” to copy EDID from display connected to Local Unit
Do not switch while powered ON.
7 HDMI LED HDMI Signal indicator
6 Power LED Power indicator
REAR
1 DC24V Power Jack Connection jack for the AC adapter (only the Local or the Remote Unit
needs to be powered, not both)
2 FW USB Type Micro B For connecting USB cable for Firmware Update
3 RS232 Terminal Block For connecting RS232 cable from PC
4 HDBT Out RJ45 female For connecting the CAT6/6a/7 cable between the Local and Remote units
5 HDMI Output HDMI female video For connecting the local display device
6 HDMI Input HDMI female video For connecting HDMI cable from video/audio source
WARNING: If the CATx IN or CATx OUT ports of a powered Remote or Local extender are connected to the RS232 port of
another Remote or Local unit, the CATx port will be damaged and render the XTENDEX unusable and void the warranty.
2
Front
Rear

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
CONNECTORS AND LEDS
# LABEL CONNECTOR DESCRIPTION
FRONT
1 IR Out 3.5mm Stereo Jack For connecting the IR Emitter
Place the IR blaster in direct line-of-sight of the equipment to be
controlled, up to 1.5 meters from the equipement.
2 IR In 3.5mm Stereo Jack For connecting IR Extender (Receiver)
Place IR Receiver where IR Remote Control will have line-of-sight up to 7
meters away.
3 USB USB Type A
female x 2 For connecting support USB devices (keyboard, mouse, CAC Card
Reader, Whiteboard, Touchscreen Monitor,USB Hub)
4 Long Reach DIP Switch Switch to“ 0 ” to receive video up to 4K@60Hz up to 100m
Switch to “1” to receive video up to 1080P@60Hz up to 150m.
(Before powering ON, TX and RX must be selected to 0 or 1 at the same
time. Do not switch while powered ON.)
5 Audio Off DIP Switch Switch to “0” enable SPDIF/Audio Out port
Switch to "1" disable analog audio and SPDIF
Do not switch while powered ON
6 HDMI LED HDMI Signal indicator
7 Power LED Power indicator
REAR
1 DC24V Power Jack Connection jack for the AC adapter (only the Local or the Remote Unit
needs to be powered, not both)
2 FW USB Type Micro B For connecting USB cable for Firmware Update
3 RS232 Terminal Block For connecting serial cable from controlled device
4 HDBT In RJ45 female For connecting the CAT6/6a/7 cable between the Local and Remote units
5 HDMI HDMI female video
connector For connecting the remote display
6 SPDIF Out RCA Jack For connecting SPDIF audio cable
7 Audio Out 3.5mm Stereo Jack For connecting stereo audio self-powered speakers
WARNING: If the CATx IN or CATx OUT ports of a powered Remote or Local extender are connected to the RS232 port of
another Remote or Local unit, the CATx port will be damaged and render the XTENDEX unusable and void the warranty.
3
Front
Rear

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
4
PREPARATION FOR INSTALLATION
Locations should be chosen for the monitor that also has space to connect the Remote unit within the distance provided by
the cables. If extension cables are needed, contact NTI for the cables required.
The CATx cables must be run to the locations where the Remote and Local units will be connected. Be careful to route the
cables away from any sources of magnetic fields or electrical interference that might reduce the quality of the video signal
(i.e. AC motors, welding equipment, fluorescent lighting, etc.).
All cables should be installed in such a way that they do not cause stress on their connections to the equipment. Extended
lengths of cable hanging from a connection may interfere with the quality of that connection. Secure cables as needed to
minimize this.
Properly shut down and disconnect the power from the video source and monitor to be separated. If other equipment is
involved whose connections are being interrupted, be sure to refer to the instruction manuals for that equipment for proper
disconnection and reconnection procedures before proceeding.
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
INSTALLATION
Make your cable connections as illustrated below.
5
CAT6/6a/7 Cable
RS232 Device
i.e. Free Rotating
Camera
The IR Blaster and/or IR Extender can be
either connected to the Local Unit, or the
Remote Unit (depending upon where it is
needed).
The power supply can be either
connected to the Local Unit, or the
Remote Unit (depending upon where
power is most conveniently located).
A USB Hub can be used (i.e. USB2-
HUB-SQUID-4 and USB2-HUB-IND-7)
can be used to extend multiple USB
devices for increased USB support

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
6
FIRMWARE UPDATE
Note: No firmware updates are available as of this publication.
TECHNICAL SPECIFICATIONS
Items Specifications
Operating Temperature 23 to 104 °F
-5 to 40°C
Operating Humidity 5 to 90% RH (no condensation)
Input Video Signal 0.5-1.0 Volt p-p
Video Format Supported DTV/HDTV;
4K/1080p/1080i/720p(50Hz),576p,480p,576i,480i
Output Video HDMI 2.0 + HDCP 1.4/2.2
Output Audio Support PCM, DTS-HD, Dolby-HD
Maximum Transmission Distance 492 feet for 1080p, 328 feet for 4K
Power Supply 100-240VAC 5/60Hz; 24VDC1A
POC Power from TX to RX over CATx Cable
Power Consumption 14 Watts
Dimensions (WxDxH) 6.79 x 4.46 x 0.94 in
172.4 x 113.2 x 24 mm
Weight (Local and Remote) 1.147kg (2.52lb)
Maximum Extension Distance
(using solid or stranded
CAT6/6a/7 cable)
4K x 2K up to 328 feet (100 meters)
1080p up to 492 feet (150 meters)
Video Cable Lengths Up to 20 Feet for 4Kx2K; 50 Feet for 1080p
Longer distances possible using cables with built-in video
equalizer ("Active HDMI cables")

NTI 4K HDMI USB KVM EXTENDER VIA CAT CABLE
7
INTERCONNECTION CABLE WIRING METHOD
The CATx connection cables (CAT6/6a/7 only) between the Remote and Local are terminated with RJ45 connectors and must be
wired according to the EIA/TIA 568 B industry standard. Wiring is per the table and drawing below.
Note: CAT5/5e cable is not recommended for use with this product.
Pin Wire Color Pair Function
1 White/Orange 2 T
2 Orange 2 R
3 White/Green 3 T
4 Blue 1 R
5 White/Blue 1 T
6 Green 3 R
7 White/Brown 4 T
8 Brown 4 R
WARNING: The CATx connection cable used between NTI XTENDEX Series Local and Remote or any XTENDEX Series
products must be wired straight through (pin 1 to pin 1, pin 2 to pin 2, etc.) The use of a CROSSOVER CABLE will
damage the extender and void your warranty.
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network
Technologies Inc at [phone] (800-RGB-TECH) or [phone] or visit our website at http://www.networktechinc.com for
information regarding repairs and/or returns. A return authorization number is required for all repairs/returns.
MAN356 Rev. 2/26/20
T
1
+
R
2
-
T
3
+
R
4
-
T
5
+
R
6
-
T
7
+
R
8
-
Pair 2 Pair 1 Pair 4
Pair 3
