NTI XTENDEX Series User manual

MAN349 Rev Date 9/30/2019
ST-2FODVIDD-LC
DVI-D Dual Link Extender via Fiber Optic
Cable
Installation and Operation Manual
XTENDEX®Series

TRADEMARK
XTENDEX is a registered trademark of Network Technologies Inc in the U.S. and other countries.
COPYRIGHT
Copyright © 2019 by Network Technologies Inc. All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written consent of Network Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network Technologies Inc reserves the
right to make changes in the product design without reservation and without notification to its users.

TABLE OF CONTENTS
Introduction......................................................................................................................................................................1
Materials..........................................................................................................................................................................1
Preparation for Installation ..............................................................................................................................................2
Installation .......................................................................................................................................................................2
Self-EDID Programming Procedure................................................................................................................................4
Troubleshooting...............................................................................................................................................................5
Technical Specifications..................................................................................................................................................5
Warranty Information.......................................................................................................................................................5
TABLE OF FIGURES
Figure 1- Location of LEDs................................................................................................................................................................2
Figure 2- Fiber Optic cable connection..............................................................................................................................................3
Figure 3- Connect to Source and Display..........................................................................................................................................3
Figure 4- Location of EDID Programming Button...............................................................................................................................4

NTI DVI EXTENDER VIA FIBER OPTIC CABLE
1
INTRODUCTION
The XTENDEX® DVI-D Dual Link Extender via Fiber Optic Cable extends a digital flat panel display up to 1,640 feet (500 meters)
away from a DVI-D dual link video source using a 2-strand fiber optic cable. Each DVI optical extender consists of a transmitter
that connects to a computer and a receiver that connects to a monitor.
The ST-2FODIVDD-LC optical DVI module transmits uncompressed WQXGA (2560x1600@60Hz) or WQUXGA
(3840x2400@33Hz) of Dual-link DVI up to 500 meters (1,640feet) over two (2) LC multi-mode fibers. The EDID (Extended Display
Identification Data) in a display can be read and stored by just connecting the transmitter to the display once. This Self-EDID
programming feature makes the installation of the ST-2FODVIDD-LC easy and flexible to any variable resolution display system.
For your convenience, 2560x1600@60Hz EDID has been pre-factory-programmed as a default.
Features:
Supports uncompressed 2560x1600 WQXGA and 3840x2400 WQUXGA resolutions for dual link devices.
Signal transmission via two-strand multimode LC fiber optic cable –no RF interference.
Small form factor –allowing for easy connection and placement.
Cables can be installed in conduit prior to extender installation.
Virtual DDC by self-EDID programming.
Low RFI/EMI for sensitive applications.
No software to install.
MATERIALS
Materials supplied with this kit:
NTI ST-2FODVIDD-LC Transmitter and Receiver
2 x 100-240VAC, 50 or 60Hz-5VDC/1A AC Adapter
URL Slip with path to this manual
Materials Not supplied but REQUIRED:
2-strand multi-mode LC fiber optic cable
Cables can be purchased from Network Technologies Inc by calling [phone] (800-RGB-TECH) in the US and Canada or
[phone] (worldwide).
Hardware Requirements
PC, SUN, or Mac computer with DVI graphic controller card and DVI-D Dual Link port

NTI DVI EXTENDER VIA FIBER OPTIC CABLE
2
PREPARATION FOR INSTALLATION
Locations should be chosen for the monitor and video source that also have space to connect the Receiver and Transmitter
modules within the distance provided by the fiber optic cables.
All cables should be installed in such a way that they do not cause stress on their connections to the equipment. Extended
lengths of cable hanging from a connection may interfere with the quality of that connection. Secure cables as needed to
minimize this.
Properly shut down and disconnect the power from the video source and monitor to be separated. If other equipment is
involved whose connections are being interrupted, be sure to refer to the instruction manuals for that equipment for proper
disconnection and re-connection procedures before proceeding.
INSTALLATION
1. Plug the 5V AC adapters into the Transmitter and Receiver. The Power LED will illuminate solid blue and the Status LED will
slowly blink blue.
Figure 1- Location of LEDs
2. Check to see if the display supports a resolution of 2560x1600 (WQXGA)@60Hz. This is the default resolution setting of the
ST-2FODVIDD-LC. If the display does not support this resolution, follow the Self-EDID programming Procedure.
3. Connect two (2) LC optical fibers between the Transmitter and Receiver. Be sure to connect port 1 on the Transmitter to port 1
on the Receiver, and port 2 on the Transmitter to port 2 on the Receiver. Make sure the fiber connectors are snapped in
securely.
Status LED Power LED

NTI DVI EXTENDER VIA FIBER OPTIC CABLE
3
Figure 2- Fiber Optic cable connection
4. Plug the transmitter to the DVI port of the DVI source (such as a PC) and the receiver to the DVI port of the display.
Note 1: The maximum extension length by multi-mode fiber is 500 meters.
Note 2: We recommend NOT to use any intermediate cable or adapter between the fiber and the Receiver orTtransmitter
to avoid undesirable performance degradation.
5. Power ON the PC and the display and ensure that the Status LED in the Transmitter and receiver illuminate.
Figure 3- Connect to Source and Display

NTI DVI EXTENDER VIA FIBER OPTIC CABLE
4
SELF-EDID PROGRAMMING PROCEDURE
The video source generally requires supported EDID information (resolution and timing) from the connected display.
ST-2FODVIDD-LC supports Self-EDID programming. The Transmitter can read the EDID from the display and store it. It may be
necessary to perform the Self-EDID Programming Procedure if the display does not support the pre-programmed resolution of
2560x1600@60Hz. Follow the steps below to perform the procedure.
Note 1: If you know that EDID is not required by the video source, Self-EDID programming will not be necessary.
1. Power ONthe display.
2. Plug the 5V power adapter into the power jack of the Transmitter. Ensure the
Power LED illuminates.
3. Push the EDID Programming button of the Transmitter with a narrow pin. The status LED will illuminate.
Figure 4- Location of EDID Programming Button
4. Connect the transmitter to the display, not to the PC. The status LED will begin to blink rapidly. This indicates reading the EDID
from the display and storing it. After 7 to 8 seconds, the status LED will illuminate solid ON indicating
completion of programming.
5. Disconnect the Transmitter from the display. Install the Transmitter and Receiver as previously described.
E
D
I
D
-Pro
g
rammin
g
button
Power Jack

NTI DVI EXTENDER VIA FIBER OPTIC CABLE
5
TROUBLESHOOTING
The display shows only a black screen. Ensure that all power supply connections are firmly seated. Ensure that the Power
and Status LEDs are illuminated.
Ensure that the Transmitter and Receiver are firmly plugged in to the video source
and display.
Check if the PC and display are powered ON and properly booted.
Reset the system by unplugging and re-plugging the Transmitter to the video
source or Receiver to the display, or by unplugging and re-plugging the
power connections to the Transmitter and Receiver modules.
Re-boot up the video source.
Screen is distorted or displays electrical
noise (static) Check if the display resolution is properly set. Go to the display settings in
Windows and adjust as needed. Ensure that the resolution is set at 3840x2400 at
33Hz or less.
Re-boot the video source and display.
Disconnect and reconnect the fiber optic cables and/or 5VDC adapters.
TECHNICAL SPECIFICATIONS
Connectors (Transmitter
and Receiver) One male DVI-D dual link connector and two LC fiber connectors
Resolutions supported HDTV resolutions up to 1080p and computer resolutions up to 3840x2400@30Hz /
2560x1600@60Hz.
Dimensions (WxDxH) 1.54x2.83x0.59 in (39x72x15 mm)
Power 100 to 240 VAC at 50 or 60 Hz-5VDC/1A AC adapter (US AC adapters included)
Operating temperature 32 to 122°F (0 to 50°C)
Storage temperature 22 to 158°F (-30 to 70°C)
Operating/storage relative
humidity 0 to 85% non-condensing RH
Maximum distance 1,640 feet (500 meters) over 50μm or 62.5μm multimode LC fiber optic cable
Cable type Use one duplex LC 50-micron or 62.5-micron multimode fiber optic cable to extend the Receiver
from the Transmitter up to 1,640 feet (500 meters).
Regulatory Approvals CE, FCC, RoHS
WARRANTY INFORMATION
The warranty period on this product (parts and labor) is two (2) years from the date of purchase. Please contact Network
Technologies Inc at [phone] (800-RGB-TECH) or [phone] or visit our website at http://www.networktechinc.com for
information regarding repairs and/or returns. A return authorization number is required for all repairs/returns.
MAN349 Rev. 9/30/19
