NTI ST-C5VRS-600 User manual

ST-C5VRS-600
VIDEO AND RS232
EXTENDER
Installation and Operation Manual
Manual 039 Rev. 3/13/03
XTENDEXTM Series
NTI NETWORK
TECHNOLOGIES
INCORPORATED
R

WARRANTY INFORMATION
The warranty period on this product (parts and labor) is one (1) year from the date of purchase. Please
contact Network Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070 or visit our
website at http://www.nti1.com for information regarding repairs and/or returns. A return authorization
number is required for all repairs/returns.
COPYRIGHT
Copyright © 2003 by Network Technologies Inc, all rights reserved. No part of this publication may be
reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior written consent of Network
Technologies Inc, 1275 Danner Drive, Aurora, Ohio 44202. For more information please contact Network
Technologies Inc at (800) 742-8324 (800-RGB-TECH) or (330) 562-7070.
CHANGES
The material in this guide is for information only and is subject to change without notice. Network
Technologies Inc reserves the right to make changes in the product design without reservation and without
notification to its users.

Table of Contents
Introduction..............................................................................................................................................................1
Materials..................................................................................................................................................................1
Features and Functions...........................................................................................................................................2
Limitations ...............................................................................................................................................................3
Preparation for Installation ......................................................................................................................................3
Installation ...............................................................................................................................................................4
The Local Unit......................................................................................................................................................4
The Remote Unit..................................................................................................................................................6
Plug-in and Boot Up................................................................................................................................................7
Video Quality...........................................................................................................................................................7
Technical Specifications..........................................................................................................................................8
Interconnection Cable Wiring Method.....................................................................................................................8
Troubleshooting.......................................................................................................................................................9
Table of Figures
Figure 1- Connect the Local Unit to the CPU.................................................................................................................... 4
Figure 2- Connect Local User's Monitor to Local Unit...................................................................................................... 5
Figure 3- Connect the Extended Components to the Remote Unit................................................................................ 6
Figure 4- Connect the AC adapters to the Remote and Local Units.............................................................................. 7
Figure 5- View looking into RJ45 female............................................................................................................................ 8

1
Introduction
The XTENDEX Series ST-C5VRS-600 Video and RS232 Extender is designed to enable one CPU to be viewed
or accessed by two touchscreen monitors, one local and one remote. The remote monitor can be located as
much as 600 feet away from a CPU via Category 5 unshielded twisted-pair cable. The local monitor will be
located near the CPU.
The XTENDEX Series ST-C5VRS-600 Video and RS232 Extender is extremely simple to install and has been
thoroughly tested to insure reliable performance. Through the use of Category 5 unshielded twisted-pair cable it
is possible to economically increase the flexibility of a computer system. Here are some of the features and
ways this can benefit any workplace:
•Allows the placement of a touchscreen monitor in a location where only this is needed without having
the CPU there too, taking up valuable space
•Allows a CPU to be accessed by both a local and remote user (up to 600 feet away)
•Compatible with XGA, VGA, and SVGA systems
•RS232 support enables the extension of a serial device (i.e. touch-screen monitor or mouse)
•Provides crisp and clear resolution up to 1280 x 1024 @ 600 feet
•Compatible with all NTI video switches and splitters, enabling the joining of products to create a
system that satisfies all networking needs
•Video quality is automatic providing optimum image quality
Materials
Materials Included with this kit:
9NTI ST-C5VRS-600 Video and RS232 Extender Local Unit
9NTI ST-C5VRS-600 Video and RS232 Extender Remote Unit
92- 120VAC or 240VAC at 50 or 60Hz-5VDC/2.0A AC Adapters
9This owner's manual
Additional materials may need to be ordered, depending upon the configuration:
¾VEXT-xx and DINT-xx if the Local Unit will be located further than 15" from the CPU or NTI switch
¾CAT5 unshielded twisted-pair cable(s) terminated with RJ45 connectors wired straight thru- pin 1 to pin 1,
etc. (see pg. 8 for proper EIA/TIA 568 B wiring method)
Contact your nearest NTI distributor or NTI directly for all of your KVM needs at 800-RGB-TECH (800-742-8324)
in US & Canada or 330-562-7070 (Worldwide) or at our website at http://www.nti1.com and we will be happy to
be of assistance.
Introduction
Materials

2
Features and Functions
1. Green LED- traffic indicator- illuminates when RS232 data is passing through the CAT5 cable
2. Yellow LED- power indicator- illuminates when power has been supplied to the unit
3. Cat 5- RJ45 female- for connecting the CAT 5 cable
4. Video Connector- 15HD female- for connecting the local user's monitor
5. 5VDC- 2.0A- connection jack for the AC adapter
6. RS232 Connector- 9D male- for connecting the local user's touchscreen monitor RS232 cable
7. RS232 Connector- light gray 9D female- for connecting to the RS232 port on the CPU or NTI switch
8. Video Connector- blue 15HD male- for connecting to the video port on the CPU or NTI switch
9. RS232 Connector- 9D male- for connecting the remote touchscreen monitor RS232 cable
10. Video Connector- 15HD female- for connecting the remote user's monitor
Features and Functions
8 7
1
3
S T - C 5 V R S - 6 0 0 L o c a l U n i t
2
4
6
F E A T U R E S A N D F U N C T I N S
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
-
+
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
-
+
5
( F r o n t V i e w ) ( R e a r V i e w )
1 0
S T - C 5 V R S - 6 0 0 R e m o t e U n i t
9
1
3
2
5
-
+
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
-
+
( F r o n t V i e w ) ( R e a r V i e w )

3
Limitations
•RS232 devices connected to the Local and Remote Units must be identical.
•The RS232 ports on the Local and Remote Units will support serial devices other than touchscreen monitors
as follows:
•2 simple devices (i.e. mice) connected to each unit, or
•1 complex device (i.e. serial modem, RS232 command port on an NTI switch) connected to
either the Remote or Local Unit.
•Even though two users will have full access to the single CPU, if both users attempt to access the CPU at
the same time, there will be a conflict. For example, if both the local and remote users are attempting to
move the mouse pointer, it may jump around the screen and move in unintended directions.
•The maximum baud rate supported by the RS232 port is 56K bits per second and the attached CPU must
be configured accordingly.
Preparation for Installation
•Locations should be chosen for the touchscreen monitors that also have space to connect the Remote and
Local Units within the distance provided by the cables. If extension cables are needed, contact NTI for the
cables required.
•The CAT5 cables must be run to the locations where the Remote and Local Units will be connected. Be
careful to route the cables away from any sources of magnetic fields or electrical interference that might
reduce the quality of the video signal (i.e. AC motors, welding equipment, etc.). NOTE: If CAT5 cable is
already installed in the wall and there are RJ45 wall outlets, it will be necessary to obtain male-to-male
straight through connection cables long enough to reach from the wall outlets to the connection locations of
the Remote and Local Units.
•A properly grounded, polarized, and preferably surge-protected 120V or 240V electrical outlet (depending
on the AC adapter being used) must be installed close enough to the connection location of the Remote and
Local Units and monitors to plug them into.
•All cables should be installed in such a way that they do not cause stress on their connections to the
equipment. Extended lengths of cable hanging from a connection may interfere with the quality of that
connection. Secure cables as needed to minimize this.
•Properly shut down and disconnect the power from the CPU, monitor, and RS232 device to be separated.
If other equipment is involved whose connections are being interrupted, be sure to refer to the instruction
manuals for that equipment for proper disconnection and re-connection procedures before proceeding.
Preparation for Installation
Limitations

4
Installation
The Local Unit
1. Plug the cables of the Local Unit into the back of the CPU. (See Fig. 1.)
a. Connect the blue 15HD cable end to the VGA port on the back of the CPU.
b. Connect the light gray 9D cable end to the RS232 port on the back of the CPU.
Figure 1- Connect the Local Unit to the CPU
2. Make connections for a Local User
a. Connect the video cable from the local user's VGA monitor to the female 15HD port on the
Local Unit.
b. Connect the local user's RS232 cable from a touchscreen monitor (see Fig. 2) to the 9D male
port on the Local Unit.
Installation
S T - C 5 V R S - 6 0 0 L o c a l U n i t
( F r o n t V i e w )
1 5 H D F e m a l e
V i d e o C o n n e c t o r
( B L U E - V I D E )
C P U
V I D E
C N N E C T R
1 5 H D M a l e
V i d e o C o n n e c t o r
( L I G H T G R A Y - R S 2 3 2 )
9 D F e m a l e C o n n e c t o r
9 D M a le
R S 2 3 2 C o n n e c t o r
S E R I A L
C N N E C T R
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
-
+

5
Figure 2- Connect Local User's Monitor to Local Unit
3. Connect the CAT5 cable to the “Cat 5” port on the Local Unit. (See Fig. 2.) When properly inserted
the cable end should snap into place.
Note: If an RJ45 wall outlet is being used, connect the other end of the extension cable to the
RJ45 wall outlet.
WARNING: Never connect the ST-C5VRS-600 Extender to an ethernet card, ethernet router,
hub or switch or other ethernet RJ45 connector of an ethernet device. Damage to devices connected
to the ethernet may result.
!
V G A
M u l t i - S c a n
T o u c h - s c r e e n
M o n i t o r
1 5 H D F e m a l e
V i d e o C o n n e c t o r
F r o n t V i e w o f
L o c a l U n i t
S T - C 5 V R S - 6 0 0 L o c a l U n i t ( F r o n t a n d R e a r V i e w )
9 D M a le
R S 2 3 2 C o n n e c t o r
C A T 5 C a b l e t o
R e m o t e U n i t
R e a r V i e w o f L o c a l U n i t
L o c a l U s e r ' s M o n i t o r
G r e e n T r a f f i c L E D
Y e l l o w P o w e r L E D
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
-
+

6
The Remote Unit
1. Position the Remote Unit such that the CAT5 cable, the monitor cable, RS232 cable, and the AC adapter
power connector can each reach the Remote Unit comfortably.
2. Connect the monitor cable to the female 15HD video connector on the Remote Unit.
3. Connect the RS232 cable from a touchscreen monitor (see Fig. 3) to the male 9D connector
on the Remote Unit.
Figure 3- Connect the Extended Components to the Remote Unit
4. Make sure the CAT5 cable has been installed in accordance with the “Preparation for Installation”
instructions on page 3. Connect the CAT5 cable to the “Cat 5” port on the Remote Unit. (See Fig. 3.)
When properly inserted the CAT5 cable end should snap into place.
Note: If an RJ45 wall outlet is being used, connect the other end of the extension cable to the RJ45
wall outlet.
WARNING: Never connect the ST-C5VRS-600 Extender to an ethernet card, ethernet router,
hub or switch or other ethernet RJ45 connector of an ethernet device. Damage to devices connected
to the ethernet may result.
!
F r o n t V i e w o f
R e m o t e U n i t
S T - C 5 V R S - 6 0 0 R e m o t e U n i t ( F r o n t a n d R e a r V i e w )
R e a r V i e w o f R e m o t e U n i t
V G A
M u l t i - S c a n
T o u c h - s c r e e n
M o n i t o r
1 5 H D F e m a l e
V i d e o C o n n e c t o r
9 D M a le
R S 2 3 2 C o n n e c t o r
C A T 5 C a b l e t o
L o c a l U n i t
R e m o t e U s e r ' s M o n i t o r
N T I
R
N e t w o r k T e c h n o l o g i e s I n c
X T E N D E X
-
+

7
Plug-in and Boot Up
1. Plug the power cord from each monitor into a power outlet.
2. Connect the power connector from each AC adapter to the 5VDC port on the Remote and Local Units.
Make sure each power connector goes into the port all the way. Plug each AC adapter into a power outlet.
The yellow LED on the RJ45 connector on the Remote and Local Units should illuminate, indicating that a
proper power connection has been made to both. (See Fig. 4.)
Figure 4- Connect the AC adapters to the Remote and Local Units
3. Turn ON the CPU and Monitors. They should each react as if they were directly connected to each other.
NOTE: The green LED on each RJ45 connector will illuminate anytime data traffic is passing between
the Local and Remote Units, indicating proper CAT5 cable connection and communication. (See Fig. 4)
Video Quality
Video quality adjustment is done automatically to assure the image is as clear as possible for varying lengths
of CAT5 cable.
Note: When the cable is longer than 300 feet some colored lines can be seen at the black-to-white
transitions. This is a normal behavior and is caused by the different twisting rates of each pair of wires
in the CAT5 cable.
V
ideo Qualit
y
Plu
g
-in and Boot Up
G r e e n T r a f f i c L E D
5 V D C
A d a p t e r
A D A P T E R
B a r r e l
( I n s i d e
b a r r e l )
( u t s i d e
b a r r e l )
P o w e r C o n n e c t o r
2 . 1 m m x 5 . 5 m m F e m a l e
5 V D C @ 2 . 0 A U T P U T
Y e l l o w P o w e r L E D
R e a r V i e w o f R e m o t e / L o c a l U n i t

8
Technical Specifications
Maximum Resolution
(refresh frequency 60Hz) 1280 x 1024 - up to 600 feet
Video Compatibility SVGA, XGA, VGA
Video Quality Adjustment Automatic, for up to 600 feet of CAT5 cable
Video Coupling DC
Video Connectors HD15 male to PC
HD15 female to monitor
RS232 Connectors 9D male to device
9D female to CPU
RS232 Baud Rate 56K bps maximum (no baud rate adjustment is necessary)
RS232 Compatibility RXD, TXD, RTS, DTR, CTS, DSR
Sync Types Supported Separate and composite TTL Level and sync on green
Interconnect Cable CAT 5/5e Solid UTP EIA/TIA 568 B wiring w/ male RJ45
connectors
Remote and Local Unit Power 120V or 240V at 50 or 60Hz-5VDC/2.0A via AC Adapters
Dimensions 3.1" W x 3.4" D x 1" H
Interconnection Cable Wiring Method
The connection cable between the remote and local is terminated with RJ45 connectors and must be wired
according to the EIA/TIA 568 B industry standard. Wiring is as per the table and drawing below.
Pin Wire Color Pair Function
1 White/Orange 2 T
2 Orange 2 R
3 White/Green 3 T
4Blue 1 R
5 White/Blue 1 T
6Green 3 R
7 White/Brown 4 T
8Brown 4 R
Figure 5- View looking into RJ45 female
T
1
+
R
2
-
T
3
+
R
4
-
T
5
+
R
6
-
T
7
+
R
8
-
Pair 2 Pair 1 Pair 4
Pair 3
Technical Specifications
Interconnection Cable Wirin
g
Method

9
Troubleshooting
Each and every piece of every product produced by Network Technologies Inc is 100% tested to exacting
specifications. We make every effort to insure trouble-free installation and operation of our products. If
problems are experienced while installing this product, please look over the troubleshooting chart below to see if
perhaps we can answer any questions that arise. If the answer is not found in the chart, please check the
FAQs (Frequently Asked Questions) at our website at http://www.nti1.com or contact us directly for help at 1-
800-742-8324 (800-RGB-TECH) in US & Canada or 1-330-562-7070 worldwide. We will be happy to assist in
any way we can.
Problem Cause Solution
Local or Remote Unit
yellow power LED does
not illuminate
•Power supply is not connected
or plugged-in. •Make sure outlet is live and AC adapter is plugged-
in.
•Make sure 5VDC jack is fully connected.
No Video on monitor •One or more video cables is
loose or disconnected.
•No power to Remote or Local
Units.
•Video Cable was not attached
when CPU was booted.
•CAT5 cable is not connected.
•Check all video cable connections
•Make sure yellow LEDs are illuminated for local
and remote. If not, see Solution for “Local or
Remote Unit yellow power LED does not
illuminate” above.
•With all the cables properly connected, reboot the
CPU.
•Check cable connections. Make sure they are
snapped-in properly and completely and reboot.
Video Picture is not
sharp or is smeared •All Video Cables are not firmly
seated.
•CAT5 cable is too long.
•The CAT5 cable is not
properly connected.
•Check all connections. Make sure all cables are
fully seated.
•Verify length is within specified limits-600'.
•Check cable connections. Make sure they are
snapped-in properly and completely.
The picture on the
monitor is black and
white, rather than color
The video cable was not attached
to the CPU when it was booted. With the cables all properly connected, reboot the
CPU.
A constant vertical
wobble appears down
the screen
CAT5 cable is too close to a strong
power source. Reroute CAT5 cable if possible.
Monitor sometimes
loses sync, causing it
to go blank for a
second or two
•Electrical power system is very
noisy, particularly the ground.
•The CAT5 cable is not
properly connected.
•Make sure the interconnection cable is not near
any power lines.
•Check cable connections. Make sure they are
snapped-in properly and completely.
No RS232
Communication •One or more RS232 cables is
loose or disconnected •Check all RS232 cable connections
Troubleshootin
g

10
If the answer to a question is not in our troubleshooting chart or on our website and a call to us is required,
please have the following information available at the time of the call:
1. NTI Model Number and Serial Number (from the bottom) of the Local Unit and the Remote Unit.
Local M/N __________ S/N ______________
Remote M/N __________ S/N ______________
2. The total length of the CAT5 extension cable in use.______
3. Make and Model Number of the touchscreen monitor. ___________________________________
4. Computer Information:
•Manufacturer ___________________ •BIOS Revision______________________________
•Model _________________________ •Operating System___________________________
•RAM __________________________ •Graphics Card Name and Model _______________
•BIOS Mfr._______________________ •Operating Video Resolution ___________________
5. Make and Model Number of any other equipment connected between the touchscreen monitor and the
CPU.
__________________________________________________________________________
ST-C5VRS-600 ST-C5VRS-600
REMOTE UNIT LOCAL UNIT
Manual 039 Rev. 3/13/03
SERIAL NO:
DATE:
INSPECTED BY:
SERIAL NO:___________
DATE:________________
INSPECTED BY:____________
Table of contents
Other NTI Extender manuals

NTI
NTI XTENDEX Series User manual

NTI
NTI USB2-C5-LC User manual

NTI
NTI ST-C51394-250 User manual

NTI
NTI ST-IPUSB4K-L-VW User manual

NTI
NTI XTENDEX ST-C6USBHE-HDBT User manual

NTI
NTI XTENDEX Series ST-C5RS-LCRS232 User manual

NTI
NTI XTENDEX Series User manual

NTI
NTI XTENDEX Series User manual

NTI
NTI ENVIROMUX Series User manual

NTI
NTI USB2-C5-LCND User manual

NTI
NTI USB-C5-200 User manual

NTI
NTI Xtendex ST-C5USB2V2ARST User manual

NTI
NTI XTENDEX Series User manual

NTI
NTI ST-WL4K-98 User manual

NTI
NTI XTENDEX ST-C6HD-HDBT-LC User manual

NTI
NTI XTENDEX Series User manual

NTI
NTI USB2-C5-LCND492 User manual

NTI
NTI ST-FO4K10GB-LC User manual

NTI
NTI XTENDEX ST-C5USBV User manual

NTI
NTI USB2-C5-4LC User manual
