NTT docomo L-02C User manual

       
                    
   
 
    

 
       
 
      
  


    
  
              
                 
 
        
  


    
  
              
  
                 
           
      
    
   
 
  
 
     
        
     
  
  
           
      
                   
                   
      
  
 
     




     
         
Contents/Precautions
Before Using this Terminal
Setting Up
L-02C Connection Software
Mobile Broadband
Configuring Network Manually
Overseas Use
Appendix/Troubleshooting
‘10.12
L-02C
Data Communication
Device

DOCOMOLTE・W-CDMA・GPRS
System
ThankYouforPurchasingthe"DataCommu-
nicationDeviceL-02C"
BeforeorwhileusingtheL-02C,besuretothoroughlyread
thismanualandtheindividualmanualforotheroperation
devicestoensureitscorrectuse.Forfurtherinformation,
contactthe"docomoInformationCenter"onthebackofthis
manual.TheL-02Cisdesignedtobeyourclosepartner.
Treatitcarefullyatalltimestoensurelong-term
performance.
BeforeUsingthisTerminal
•Becausethisterminalusesradiowaves,itmaynotfunctionin
locationswhereitisdifficultforradiowavestopenetrate,such
astunnels,undergroundpassages,Xiserviceareaandsome
buildingsinareaswhereradiowavesignalsareweakoroutof
theservicearea.Evenwhenyouareonahigherfloorofatall
buildingorcondominiumandnothingblocksyourviewoutside,
thisterminalmaynotbeabletoreceiveortransmitsignals.
Alsocommunicationmaybeinterruptedevenwhenthe
AntennaIndicationLamponthisterminallightsindicatinga
strongsignalreceptionwith3antennaindicationbar.
•Usethisterminalinwaysthatdonotdisturbothersinpublic
places,crowdedlocations,orquietlocations.
•Thisterminalcommunicatesviaradiowavesbyconverting
voicesintodigitalsignals.Ifyoumoveintoanareawheresignal
receptionispoor,thedigitalsignalsmaynotbeaccurately
decodedandwhatyouhearmaydifferslightlyfromwhatwas
actuallysaid.
•DOCOMOisnotresponsibleforanyeconomiclossesincurred
throughlostcommunicationopportunitiescausedbyexternal
factorssuchasmalfunctionorelectricaloutage.
•ThisterminalcanbeoperatedinXiarea,FOMAPlus-Areasand
FOMAHIGH-SPEEDAreas.
•ThisterminalcanbeusedonlyviaXinetwork,FOMAnetwork
providedbyDOCOMOandDOCOMO'sroamingarea.
•Thisterminaldoesnotsupporti-modefunctions(i-modemail,
connectiontoi-modesites(program)ori-αppli,etc.)
ForFirst-TimeUsersofthisTerminal
Ifthisisyourfirsttimetousethisterminal,readthe
manualinthefollowingordertolearnbasicoperations.
1. Learningtheprecautions....................... P7
2. Learningthenamesofpartsandfunctionsofthis
terminal..................................... P18
3. InsertingthisterminalintoaPC ............... P24
4. HavingthisterminalrecognizedbyyourPC......... P30
5. Settingthisterminalbeforecommunication ......... P56
Thelatestinformationofthismanualcanbedownloadedfrom
theDOCOMOwebsite.
■ TheURLofPDFforINSTRUCTIONMANUAL
http://www.nttdocomo.co.jp/english/support/trouble/
manual/download/index.html
※ TheURLandtheinformationcontainedinthemanualare
subjecttochangewithoutpriornotice.

1
HowtoRead/RefertothisManual
Contents
L-02CManualiscomposedof"L-02CINSTRUCTIONMANUAL〜ConnectionGuide〜"and"L-02CINSTRUCTIONMANUAL
(recordedinCD-ROM)"(thismanual).
■ "L-02CINSTRUCTIONMANUAL〜ConnectionGuide〜"
Thefollowingcontentssuchasconnectiontocomputer,troubleshooting,specificationsofL-02Caredescribed.
•Contents/Precautions
•BeforeUsingthisTerminal
•SettingUp
•Appendix/Troubleshooting
■ "L-02CINSTRUCTIONMANUAL(recordedCD-ROM)"(thismanual)
Besidestheabovecontentsdescribedin"L-02CINSTRUCTIONMANUAL〜ConnectionGuide〜",thecontentsof
configuringcommunicationthroughspecialapplicationarealsowritten.
ThismanualissuppliedwithPDF.Toviewthismanual,AdobeReader(Version6.0orlaterisrecommended)isnecessary.
•L-02CConnectionSoftware
•MobileBroadband
•ConfiguringNetworkManually
•OverseasUse

2
HowtoRefertothisManual
Usethefollowingmethodstosearchfunctionsandservices.
･Pleaseunderstandthatin"L-02CManual","thisterminal"refersto"L-02C".
･Notethatin"L-02CINSTRUCTIONMANUAL","PC"referstoboth"WindowsPC"and"Mac".
･Operationproceduresandimagesmaydifferdependingonenvironment.
･Reprintingallorpartsofthismanualisprohibited.
･Informationcontainedinthismanualissubjecttochangewithoutpriornotice.
P124
Searchfunctionsorservicesbyfunctionnameorservicename.
Front
cover
Searchfunctionsorservicesfromindextabsprintedonfrontcover.
P5
Searchfromthecategorizedcontents.
P6
Searchthemainfeaturesfromhere.
FromIndex
FromTabsonFrontCover
FromContents
FromMainFeatures
Seenext
pagefor
detailed
descriptions

3
DescribeshowtosearchinthismanualthroughanexampleofinstallingL-02CconnectionsoftwareonMacintosh
(includingadriver).
I
Install
Communicationconfigurationfile
(Driveronly)              34 38
FlashPlayeronMacintosh     48
FlashPlayeronWindows        37
L 02CConnectionSoftwareon
Macintosh(includingadriver)  43
L 02CConnectionSoftwareon
Windows(includingadriver)   33
L
LTE                            53
L 02CConnectionSoftware
ConfiguringNetwork            92
ConfirmatingafterInstallation
                       39 46
Confirmingthepacket
communicationvolume       56
Fromthe
Index
XP124
Searchafunctionor
aservicenameas
theexample.
FromTabs
ontheFront
Cover
XFrontcover
Searchafunctionin
theorderof"Front
cover"→"Chaptertitle
page"→"Targetpage"
astheexample.
P43
Thispage
describes
installationof
L-02C
connection
softwareon
Macintosh
(includinga
driver)"
Tonextpage
FromTabs
ontheFront
Cover
XFrontcover
Searchafunctionin
theorderof"Front
cover"→"Chaptertitle
page"→"Targetpage"
astheexample.

4
43
SettingUp
MacintoshVersion
InstallationofL 02Cconnectionsoftwareisonlyrequired
toinsta lwhenconnectth sterminaltoyourPCforthe
firsttime
※Thefo lowingimagesaretheexamp esof MacOSX10 6 
Imagesmaydifferfor MacOSX10 5
PreparationbeforeUsingL-02C
SettingviathisTerminal
aTurnonthePCandactivateOS
bConnectthisterminalwiththePC
CD ROMiconisdisplayedonthedesktop
cDoubleclicktheCD ROMicon
dDoubleclick"L 02C接続ソフトインストーラー
.pkg(L 02Cconnectionsoftware
installer.pkg)"
Note
•Wheninstalling insertth sterminalintoUSBportafterOS
sactivated
•Donot nserttheCD ROMintoCDdrivewheninstal at on
viathisterminalstarts
•Donotremovethisterminalwh leinsta ling
•Endalltheappl cationsbeforeinstal ing Alsoend
programsonMacintoshinc udingviruschecksoftware
•Wheninstalling makesuretoinstallfromtheaccountwith
PCsupervisorprivi eges
Asectiontitle.
Explains
operation
procedures.
※：Theabovepageisanexample.
※：Screenimagesandillustrationscontainedinthismanualare
forreferenceonly.Theymaydifferfromtherealproduct.
Useful
Informationor
instructions
relatingto
operations. Keyscreensfor
operation
procedures.Refer
toscreensonyour
PC.Numbers,
settingsor
charactersentered
areforreference
only.
Index:
Searchinga
chapterisavailable.

5
Contents/Precautions
Contents
HowtoRead/RefertothisManual ･･････････････････ 1
Contents ････････････････････････････････････････････ 5
FeaturesoftheL-02C･･･････････････････････････････ 6
SafetyPrecautions(ALWAYSFOLLOWTHESE
PRECAUTIONS) ･････････････････････････････････････ 7
HandlingandCare･････････････････････････････････ 13
BasicPackage ････････････････････････････････････ 16
BeforeUsing
thisTerminal
17
NamesofPartsandFunctions
UsingUIM
AvailableCommunications
ConnectingthisTerminaltoaPC
SettingUp
29
SettingUp
WindowsVersion
MacintoshVersion
L-02C
Connection
Software
51
L-02CConnectionSoftware
UsingPacketCommunication
EnvironmentConfiguration
CheckingTheNewestVersionof
Software
Mobile
Broadband
63
MobileBroadband
ConnectingthroughMobileBroad
-
band
DisconnectingMobileBroadband
ChangingAPNSettings
SettingUIM
Configuring
Network
Manually
69
WindowsVersion
Overseas
Use
89
InternationalRoamingService
(WORLDWING)
ServicesAvailableOverseas
BeforeUsingOverseas
SettingtheSearchingMethodfor
AvailableNetworks
ConfiguringNetwork
Appendix/
Trouble-
shooting
95
ATCommands
ATCommandList
Troubleshooting
ErrorMessages
WarrantyandAfter-SalesService
UpdatingSoftware
MainSpecifications
ExportAdministrationRegulations
IntellectualPropertyRights
Index

6Contents/Precautions
FeaturesoftheL-02C
"Xi"isaserviceofDOCOMOsupportedbyLTE(LongTermEvolution)whichistheinternationalcommunicationstandard.
FOMA(FreedomOfMobilemultimediaAccess)isthenameofaserviceprovidedbyDOCOMObasedontheW-CDMA
system,whichiscertifiedasoneoftheglobalstandardsof3rdgenerationmobilecommunicationsystems(IMT-2000).
■ SupportedXidatacommunication
Thisisasuperhighspeeddatacommunicationofupto
37.5Mbpsforreceivingdataandupto12.5Mbpsfor
sendingdata(PartoftheindoorfacilitieswithinXiarea
canreachthespeedofupto75Mbpsforreceiving
dataandupto25Mbpsforsendingdata).Youcan
enjoythebroadbandwiththespeedasfastasoptical
LANandthequickaccesswithinshorttime.
•Themaximumcommunicationspeediscalculatedbased
ontheoreticalstandard,nottherealspeed.Itisprovided
byBesteffortsystem.Therealcommunicationspeed
changesaccordingtothecommunicationenvironment
andnetworkcondition.
•TheFOMAareawhichisoutofXiareaisalsoavailable.
•RefertoDOCOMOwebsitefordetailedareassupportXi.
■ CorrespondencewiththeFOMAHIGH-SPEEDArea
Youcanenjoyhighspeedcommunication(Besteffort
system)atamaximumof7.2Mbpsforreceivingand
5.7Mbpsforsending.
•Communicationspeedistheoreticalvalueswhensending
andreceivingdatawhichdoesnotshowtheactualones.
Theactualcommunicationspeeddependson
communicationenvironmentandnetworkcongestion.
•Fordetailsofareassupportingamaximumof5.7Mbps
forsending,viewDOCOMOwebsite.
•Sendingandreceivingdatamaybecome384kbpseven
intheFOMAHIGH-SPEEDarea.
•Sendingandreceivingdatabecome384kbpsinFOMA
areaoutofFOMAHIGH-SPEEDarea.
■ InternationalRoamingService
DatacommunicationsfromaPCareavailablethrough
using3GnetworkorGPRSnetworkinforeign
countries.XP90
※ "WORLDWING"isusuallyappliedalongwiththe
contractofthisterminal.Pleasecontactadocomo
shoporadocomoInformationCentertoconfirmthe
details.

7
Contents/Precautions
SafetyPrecautions(ALWAYS
FOLLOWTHESEPRECAUTIONS)
■ Beforeusingthisterminal,readthese"Safety
Precautions"carefullysothatyoucanuseitproperly.
Afterreadingthesafetyprecautions,keepthismanualin
asafeplaceforlaterreference.
■ Theseprecautionsareintendedtoprotectyouand
othersaroundyou.Readandfollowthemcarefullyto
avoidinjury,damagetotheproductordamageto
property.
■ Thesignsbelowindicatethelevelsofdangerordamage
thatmayoccuriftheparticularprecautionsarenot
observed.
■ Thefollowingsymbolsindicatespecialwarnings
regardingproductusage.
■ "SafetyPrecautions"areexplainedinthefollowing
4sections.
GeneralPrecautionsforthisTerminalandUIM ………… 8
PrecautionsforthisTerminal ………………………………… 9
PrecautionsfortheUIM …………………………………… 11
NotesonUsingnearElectronicMedicalEquipment …… 11
Thissignindicatesthat
incorrecthandlinghasa
highpossibilityof
causingdeathorserious
injury.
Thissignindicatesthat
incorrecthandlingposes
ariskofcausingdeathor
seriousinjury.
Thissignindicatesthat
incorrecthandlingposes
ariskofcausingslight
injuryordamagetothe
productorproperty.
DANGER
WARNING
CAUTION
Denotesthingsnottodo(prohibition).
Denotesnottodisassemble.
Denotesnottousewhereitcouldget
wet.
Denotesmandatoryinstructions
(mattersthatmustbecompliedwith).
Not d sassembl
y
Not liquids

8Contents/Precautions
GeneralPrecautionsforthisTerminal
andUIM
DANGER
DonotuseorleavethisterminalandUIM
inplaceswithahightemperaturesuchas
incarsundertheblazingsun.
Fire,burns,orinjurymayresult.
DonotputthisterminalorUIMinheating
appliancessuchasmicrowavesorhigh
pressurecontainers.
Fire,burns,injury,orelectricshockmay
result.
Donotdisassembleorremodelthis
terminalanditsaccessories.
Fire,burns,injury,orelectricshockmay
result.
Donotgetthisterminalandits
accessorieswetwithwater,drinking
water,peturine,etc.
Fire,burns,injury,orelectricshockmay
result.
WARNING
Donotsubjectthisterminalandits
accessoriestosevereshocks,orthrow
them.
Fire,burns,injury,orelectricshockmay
result.
Keepconductiveforeignobjects(metal,
pencillead,etc.)awayfromtheUSB
connector.Donotinsertsuchobjects
insidethisterminal.
Fire,burns,injury,orelectricshockmay
result.
Donotcoverorwrapthisterminalorits
accessorieswithbedding,etc.whileusing.
Fireorburnsmayresult.
Makesuretoturnoffthecomputerwhich
isconnectedwiththisterminalbeforeyou
gonearaflammablegassuchasgasoline
fumes.
Catchingfiremayresult.
Not disassembly
Not liquids

9
Contents/Precautions
CAUTION
DonotplacethisterminalorUIMon
unstablelocationssuchaswobblytables
orslantedlocations.
ThisterminalorUIMmayfall,resultingin
injury.
DonotstorethisterminalorUIMinhumid
ordustyplaces,orinhotareas.
Fire,burns,orelectricshockmayresult.
IfchildrenusethisterminalorUIM,a
guardianshouldexplaintheprecautions
andcorrectoperations.Theguardian
shouldalsomakesurethatthe
instructionsarefollowedduringuse.
Injurymayresult.
Keepoutofreachofbabiesandinfants.
Accidentalswallowingorinjurymayresult.
PrecautionsforthisTerminal
WARNING
Donotgetliquidssuchaswaterorforeign
objectssuchasmetalpiecesor
flammablematerialsintotheUIMslotof
thisterminal.
Fire,burns,injury,orelectricshockmay
result.
Turnoffthisterminalinplaceswhereuse
isprohibitedsuchasairplanesorhospi-
tals.
Electronicdevicesorelectronicmedical
devicesmaybeadverselyaffected.Follow
theinstructionswhenusinginsidemedical
facilities.
Ifyouwearanyimplantedelectronic
medicaldevices,contactthe
manufacturerordealeroftheelectronic
medicaldevicetoaskabouttheeffect
fromradiowaves.
Electronicmedicaldevicesmaybe
adverselyaffected.

10 Contents/Precautions
RemovethisterminalfromUSBportin
placesnearhigh-precisionelectronic
devicesordevicesusingweakelectronic
signals.
Electronicdevicesmaybeadversely
affectedbyreasonssuchasmalfunction.
※ Electronicdevicesthatmaybeaffected
Hearingaids,implantedcardiacpacemakers,
implanteddefibrillators,othermedical
electronicdevices,firealarms,automatic
doorsandotherautomaticallycontrolled
devices.
Ifyouareusinganimplantedcardiacpace
maker,implanteddefibrillatororanyother
electronicmedicaldevice,consultthe
manufacturerorretailerofthedevicefor
adviceregardingpossibleeffectsfromradio
waves.
CAUTION
Donotusethebrokenterminal.
Fire,burns,injury,orelectricshockmay
result.
Ifyouusethisterminalinacar,contact
thecarmanufacturerordealertoask
abouttheeffectfromradiowaves.
Dependingonthetypeofacar,in-car
electronicdevicescouldbeadversely
affected.Inthiscase,stopusingthis
terminalimmediately.
Itching,rashoreczemamaybecaused
dependingonyourphysicalconditionsor
predisposition.
Ifanabnormalityoccurs,stopusingthis
terminalimmediately,andthenseek
medicalattention.
Forthematerialofeachpart→P12
"MaterialList"
Becarefulnottogetyourfingercaughtin
thepartswhenyoucloseoropenthis
terminal.
Injuryorotheraccidentsmayresult.

11
Contents/Precautions
PrecautionsfortheUIM
CAUTION
BecarefulnottotouchtheedgeofUIM
whenremovingit.
Injurymayresult.
NotesonUsingnearElectronicMedical
Equipment
■Thedescriptionbelowmeets"Guidelineonthe
UseofRadio-communicationEquipmentsuchas
CellularTelephones-SafeguardsforElectronic
MedicalEquipment"bytheElectromagnetic
CompatibilityConference.
WARNING
Besuretoadheretothefollowing
regulationsinsidemedicalfacilities.
●Keepthisterminaloutofoperating
rooms,intensivecareunits(ICUs)or
coronarycareunits(CCUs).
●TurnoffthePCinhospitalwards.
●TurnoffthePCinhospitallobbiesand
corridorsifelectricalmedicaldevices
couldbenearby.
●Ifthemedicalfacilityhasspecificzones
whereuseorpossessionofmobile
terminalsisprohibited,followthose
regulations.
TurnoffthePCincrowdedtrainsorother
publicplaceswhereimplantedcardiac
pacemakerordefibrillatorwearerscould
benearby.
Operationofanimplantedcardiac
pacemakerorimplanteddefibrillatormay
beadverselyaffectedbyradiowaves.

12 Contents/Precautions
Ifyouuseanimplantedcardiac
pacemakerorimplanteddefibrillator,use
themobileterminal22cmormoreaway
fromtheimplantedcardiacpacemakeror
implanteddefibrillator.
Operationofanimplantedcardiac
pacemakerorimplanteddefibrillatormay
beadverselyaffectedbyradiowaves.
Patientsusingelectronicmedical
equipmentotherthanimplantedcardiac
pacemakersorimplanteddefibrillators
(usingoutsidemedicalfacilitiesfor
treatmentathome,etc.)shouldcheckthe
influenceofradiowavesuponthe
equipmentbyconsultingthe
manufacturer.
Operationsofelectronicmedical
equipmentmaybeadverselyaffectedby
radiowaves.
MaterialList
Part Material/Surfacetreatment
Exteriorcase
(Frontpart)
PCLUPOYSC1004A(KPA1)/
SFCLEAR(Aphotic100%)
Exteriorcase
(Backpart:side,back)
PCLUPOYSC1004A(KPA1)/
SFCLEAR(Aphotic100%)
BackCover PCLUPOYSC1004A(KPA1)/
SFCLEAR(Aphotic100%)
FrontCover PCLUPOYSC1004A(EM59P)/
SSCP160NCB
(Euphotic8:Aphotic2)
Exteriorcase
(Backpart:Surface)
PCLUPOYSC1004A(EM59P)/
SSCP160NCB
(Euphotic8:Aphotic2)
Stopper URETHANE
PWRLamp ILD-7550/DiffusionPC(Milky)
Communication
StatusLamp ILD-7550/DiffusionPC(Milky)
USBconnector
bracket
LGChemistry,SC2302(KA02),
PC+GF30%/SFCLEAR
(Aphotic100%)

13
Contents/Precautions
HandlingandCare
GeneralUsageGuidelines
■Keepthisterminalawayfromwater.
ThisterminalandUIMarenotwaterproof.Donot
usetheterminalinplaceswithhighhumiditysuch
asabathorwhererainmaygetitwet.Ifyoucarry
thecardclosetoyourbody,moisturefromsweat
maycorrodetheinternalpartscausinga
malfunction.Notethatmalfunctionsdeemedto
becausedbywaterarenotcoveredbythe
warranty,andmaybeimpossibletorepair.Since
thesemalfunctionsarenotunderwarranty,even
whenrepairispossible,itwillbedoneatthe
user'sexpense.
■Cleanthisterminalwithadry,softcloth(Lens
cleaningcloth).
Ifthisterminaliswipedwithalcohol,paintthinner,
benzineordetergent,theprintingmaydisappear
orcolormayfade.
■Keeptheconnectorcontactscleanwithadry
cottonswab.
Cleantheconnectorcontactswithadrycottonswab
topreventcontactsfromgettingdirtywhichcan
resultinintermittentconnections.Becarefulwhen
cleaningtheconnectorcontacts.
■Donotplacetheequipmentnearairconditioner
outlets.
Condensationmayformduetorapidchangesin
temperature,andthismaycorrodeinternalparts
andcausemalfunction.
■Donotplacethisterminalwhereexcessiveforce
willbeappliedtoit.
Ifthisterminalisinsertedtoafullbag,orplaced
inapocketandsaton,itsinternalPCBsmaybe
damagedormalfunction.Suchdamageisnot
coveredbywarranty.
■Readtheindividualmanualattachedtothis
terminal.
ThisTerminal
■Avoidusinginextremelyhighorlowtemperatures.
Thisterminalshouldbeusedwithinatemperature
rangefrom5°Cto35°Candahumidityrange
from45%to85%.
■Thisterminalmayadverselyaffectfixedphones,
televisionsorradiosinusenearby.Useasfaras
possiblefromsuchappliances.
■Keepaseparaterecordofanyinformationstored
onthisterminalandstorethecopiesinasafe
location.
DOCOMOassumesnoresponsibilityfortheloss
ofanyofyourdata.
■Donotdropthisterminalorsubjectittoshocks.
Damageormalfunctionmayresult.

14 Contents/Precautions
■DonotinsertanUSBconnectortoPCcrookedly
ordonotpullitwhenitisinserted.
Damageormalfunctionmayresult.
■RemovethisterminalfromthePCwhen
transporting.
Malfunctionordamagemayresult.
■Itisnormalforthisterminaltobecomewarm
duringuse.Youcancontinuetouseitevenwhen
itiswarm.
■Takecarenottodropthisterminalwhenremoving
thisterminalfromthecarryingcase(Sample).
■Whenitisnotinuse,keepthisterminalinits
carryingcase(Sample)tokeeptheconnector
contactsclean.
Dirtycontactsmayresultinintermittent
connections.
■Whenputtingthisterminalincarryingcase(Sam-
ple),keepitawayfromwetorhightemperature
place.Payattentionnottoputexcessiveforce
onthisterminal.
Transformationandtarnishmayresult.
UIM
■DonotputexcessiveforceontheUIMwhen
insertingorremovingitintothisterminal.
■AlwayskeeptheICportionoftheUIMclean.
■CleantheUIMwithasoft,drycloth(Lens
cleaningcloth).
■Besuretokeepaseparatenoteofthe
informationregisteredtothisterminal.
DOCOMOassumesnoresponsibilityfortheloss
ofanyofyourdata.
■VisitdocomoShoptoreturntheUIMforthe
environmentalpurpose.
■Donotscratch,touchcarelesslyorshortcircuit
theICportion.
Datalossormalfunctionmayresult.
■DonotdroporgiveshocktotheUIM.
Malfunctionmayresult.
■DonotbendorputheavythingsontheUIM.
Malfunctionmayresult.
■DonotinsertUIMintothisterminalwithlabelsor
stickersattachedon.
Malfunctionmayresult.

15
Contents/Precautions
CAUTION
■Donotusethemodifiedthisterminal.Using
modifiedthisterminalresultinviolatingthelawof
ElectromagneticCompatibility.
Thisterminalhasbeencompliedwithtechnical
standardofwirelessequipmentstipulatedbylaw
ofElectromagneticCompatibility.Asaproof,
"Technicalstandardcompliancemark "is
indicatedintheinscriptionseal.Ifthisterminalis
modifiedbyturningthescrewtotheleftto
disassemble,technicalstandardcompliance
becomesinvalid.
Pleasedonotusethisterminalduringthetime
whentechnicalstandardcomplianceisbeing
invalid,sinceyouareinviolationofthelawof
ElectromagneticCompatibility.
■Keepthisterminal5mmormoreawayfromyour
bodywhilecommunicating.

16 Contents/Precautions
BasicPackage
■ L-02CTerminal(With Front Cover L01, Back Cover
L20andWarranty)
■ L-02CINSTRUCTIONMANUAL〜ConnectionGuide〜
■ L-02CCD-ROM
•L-02CConnectionSoftware(ForWindows/
Macintosh)
•L-02CAPNSettingTool(ForWindows)
•L-02CINSTRUCTIONMANUAL(PDF)
※Softwarespecificationsaresubjecttochange
withoutpriornotice.
■ CarryingCase(Sample)
Putthisterminalintothecarryingcasewhennotin
useorcarryingit.

■ USBExtensionCable(Sample)

■ MountingHolder(Sample)


17
BeforeUsingthisTerminal
NamesofPartsandFunctions･･･････････････････ 18
UsingUIM････････････････････････････････････････ 19
AvailableCommunications ･･･････････････････････ 23
ConnectingthisTerminaltoaPC････････････････ 24

18 BeforeUsingthisTerminal
NamesofPartsandFunctions
aCommunicationStatusLamp→P19
Indicatesstatusofthisterminal
bFrontCoverL01
ThepartforinsertingfrontcoverL01iscalledfrontpart.
cPWRLamp→P19
Indicatesthepowersupplyconditions
dUSBConnector
AconnectionterminalusedtoconnectwithPC
eAntennaPart
Theantennaisinsidethisterminal.
fBackCoverL20
ThepartforinsertingbackcoverL20iscalledbackpart.
a
c
d
e
e
f
b
