Nu-Way MPSR Series Installation and operating instructions

Installation - Maintenance
MULTIPLEX
SELF RECUPERATIVE gas burner
The Nu-way Multiplex Recuperative System offers the alternative of a self-recuperative burner or a separate
recuperator and burner. the recuperative system is designed to extract expensive waste heat from the flue
products of medium to high temperature industrial processes and to pre-heat the cold combustion air, returning
heat to the process and so considerably reducing the fuel usage. The system is designed for the modernisation
of existing furnaces or for use in new, energy-efficient furnace designs. Applications include forge furnaces,
reheating furnaces, intermittent kilns, soaking pits, heat treatment furnaces, crucible furnaces and indirect
heating processes.
The system nay be used with flue gas entry temperatures up to 1400°C. combustion air makes three passes
through the recuperator to give a high level of heat recovery from the hot gases. Depending on the flue gas
temperature and burner rating, fuel savings of up to 50% or even more may be achieved. The recuperator
design ensures that the combustion air is preheated only by the flue gases and not by the burner or furnace.
Low pressure drops through the system giving reduced horsepower on the combustion air/eductor air fan.
All internal parts of the unit are manufactured from high grade heat resisting materials and the design ensures
that these components are not subject to thermal stress. The design allows for easy dis-assembly to facilitate
inspection, cleaning and replacement of internal sections should the need arise.
The burner section of this package has all the industry proven features and advantages of the Nu-way Multiplex
nozzle-mix burner range. Multiplex nozzles have proven themselves in a total of over 100,000 hours use at
pre-heated air temperatures of 500°C to 650°C. Operation can be on-ratio, excess air or excess fuel. In each
case a wide turndown range can be achieved. A high tunnel exit velocity assures good heat penetration into
the furnace load and prevents “short circuiting” back through the flue.
CONTROLS
As a packaged unit the system design simplifies the control system required. All controls are on the cold side of
the recuperator eliminating the need for costly high temperature air controls. The burner can be manually or
automatically controlled. For on-ratio control it is recommended that the Nu-way double diaphragm
proportionator is used. This will ensure close control over a wide turndown and will automatically compensate
for varying back pressures through the recuperator as the air becomes preheated. Existing burner shut-off
systems and combustion air fans can often be re-used and Nu-way will be pleased to advise.
IGNITION AND FLAME FAILURE
Burner may be ignited manually, or by direct spark ignition using the well-proven Multiplex arrangement, and
where required, flame monitoring is provided using an ultra-violet scanner.
MOUNTING
The complete unit is mounted in the furnace wall, installation involves little more than that of fitting a
conventional burner.
SERIES
MPSR

1. INSTALLATION, START-UP AND MAINTENANCE INSTRUCTIONS
All burners are provided with a mounting flange which is pre-drilled to dimensions given on the data sheet.
Combustion chamber hire hole should be to required dimensions (See dimensions on data sheet).
Screwed studs or alternative fixings should be provided on burner flange holes centres.
When the burner is mounted to the furnace front withdrawal distance equal to the overall length of the
burner including inner assembly should always be allowed at the rear of the burner unit.
Gas pipework into the burner should be such as to include an elbow and union connection to ensure
freedom of removal of internal parts of the burner for service. Care should be exercised in assembly of the
gas pipework to ensure electrode extensions are not damaged. Care should be taken to ensure that it
seats evenly and squarely to the chamber. A gasket, gasket rope or furnace cement should be used to
prevent leakage.
2. CONTROLS
Typical scheme showing the use of the Nu-way double diaphragm proporti9nator. This arrangement ensures
that the correct gas-air ratio is maintained over the turndown range of the burner at both hot and cold furnace
conditions.
The control system and components used in conjunction with the Multiplex burner should be in accordance with
recommendation and codes of practice set out by British Gas Corporation where the equipment is for use in the
UK, and to the relevant authority in other countries. The instructions given by Nu-way assume that these
conditions have been met by the plant manufacturers and/or installers.
page 2
1. Burner unit
2. Eductor
3. Double diaphragm
proportionator
4. Gas adjusting tee
5. Orifice plate
6. Air inlet
7. Gas inlet

3. GAS AND ELECTRICAL CONNECTIONS
When connecting a gas supply it is desirable to install a manual shut-off valve together with a suitable pipe
union at or near the burner. The burner assembly should not be used to support the incoming gas supply,
suitable brackets or hangers should be used for this purpose. Care should be taken to ensure that the
incoming gas piping is sized correctly to prevent excessive drops, also that gas connections are pressure
tight and gas line purged and pressure tested in accordance with local gas authority requirements or
legislation.
Wiring of the burner should be in accordance with the appropriate wiring standards. A suitable mains
isolator should be placed in a convenient location, and the final electrical connections to the burner should
be in flexible conduits. It is vital that the live and neutral wires are connected to their appropriate terminal
as reversal could present a hazard, also the earth bonding must be checked to ensure a good earth
connection (poor earth connections are often the cause of faulty burner operation when using the flame
probe detection).
Note: Gas piping must not be used for earthing.
The burners are all of the ‘expanding flame’ type pilot system and can use ‘intermittent’, interrupted’, or
‘semi-automatic’ flame failure control boxes.
4. ELECTRICAL SEQUENCE – FULLY AUTOMATIC SYSTEM
1. Switch panel isolator ON.
2. “Programme” Time Switch as required.
3. Reset “Excess Temp” on control panel.
4. Turn “OFF/AUTO” switch to “AUTO” for automatic start-up when time switch is in the ON state.
5. Air pressure switch must prove “no air”.
6. Start burners. Action of time switch switches burners on.
7. Burner controller (LFL1.335) starts light-up sequence.
8. Air control valve drives OPEN.
9. Air control valve must prove OPEN throughout pre-purge period.
10. Air control valve drives CLOSED.
11. Air control valve must prove CLOSED.
12. Ignition transformers are energised.
13. Gas pilot valves are energised.
14. Ignition transformers are de-energised.
15. Flame must be proved on burner.
16. Main gas valves are energised.
17. “Release to modulation” relay energised.
18. Air control valve comes under control of temperature controller.
19. Burners shut down via time switch, or excess temp., or OFF/AUTO switch.
20. Air control valve drives CLOSED.
5. LOW FIRE (PILOT START GAS AND AIR SETTINGS) (minimum input rate)
Set air butterfly valve to give approximately 15mm (0.6 ins) wg air pressure at inlet to burner (above
combustion chamber pressure/suction).
Slightly ‘crack’ open gas flow control valve.
Initiate start sequence, if burner fails to ignite, slightly increase gas flow at butterfly valve and reset
sequence controller and initiate a new start sequence, repeating as many times as necessary to give a
smooth start (the burner should not light with an ignition shock or noise) – if this is the case the gas flow is
generally too high for a safe start-up.
N.B: It is recommended that the start gas rate should never exceed 10% of burner rating.
page 3

6. FULL FIRE
With servomotor linkages still disconnected and flame established manually increase flow rate of air and
gas to achieve required output. This will be FULL FIRE position.
N.B: Always move air valve first on increasing flame, and gas valve on decreasing flame size. it is
dangerous to produce gas rich flames.
Reconnect control linkages and drive motor and ensure they are free to travel over full firing range.
Check firing range and if necessary adjust characteristics of control valve system for best operation of
combustion and turndown required.
7. With burner firing ensure air pressure switch is set for correct burner operation. It should be set to break
electrical continuity if the air pressure fails.
8. Observe flame at different firing rates and re-check allied safety control and all process interlocks and
controls.
OPERATING INSTRUCTIONS
TO START (Fully Automatic – Previously Commissioned System)
1. Open PILOT GAS COCK and MAIN GAS COCK.
2. Press START or IGNITION BUTTON.
TO START (Manual - Previously Commissioned System)
1. Make sure MAIN GAS COCK is closed.
2. Make sure the burner firing rate is at predetermined low fire position.
3. Start any process circulating and exhaust fans.
4. Energise system control panel (if applicable).
5. Start BURNER FAN BLOWER MOTOR.
6. Press IGNITION BUTTON or apply external ignition source.
7. Open MAIN GAS COCK slowly until burner ignites.
TO STOP (Either Manual or Automatic System)
1. Close MAIN and PILOT GAS COCK.
2. Allow burner to continue operating until flame goes out (as seen through observation port on rear of
burner).
3. De-energise system control panel and BURNER FAN BLOWER MOTOR.
4. If the combustion chamber is under positive pressure allow BURNER BLOWER to run while cooling down
system.
page 4

MAINTENANCE AND SPARES
The following should be carried six-monthly or every 1000 hours, whichever is the shorter:-
Turn off gas and electricity supplies.
Clean the burner, a clean burner looks better and works better.
Check the electrodes, make sure they are clean and set correctly.
Check gas pipes and electrical connections. Bearings of electric motors provided with oilers should be
lubricated with six drops of light machine oil. Ball bearing motors are normally grease packed for life.
Connect a manometer to the test point between the manual gas cock and the safety shut-off valve. Turn
the manual gas cock on and then off. Mains gas pressure is then between the valves and this pressure will
be indicated on the manometer. Any leakage of gas past the main or pilot safety shut-off valves, or from a
pipe joint will reduce the pressure. If this pressure remains constant over a period of not less than one
minute, no leakage is taking place. Should gas pressure not remain constant – please call a Service
Engineer to properly check, clean and test the gas valve system.
Turn on the gas and electricity and start the burner.
Check the flame signal.
Restrict the air inlet to the combustion air fan. The burner should shut down under the action of the air
pressure switch.
The burner running, close the manual gas cock. The burner will go to lockout and any alarms fitted should
operate. Reset the control box.
ELECTRODE GAPS
Spark Electrode
These are pre-bent at the factory and should be set
with the internals of the burner removed (withdraw
the burner by removing four or eight screws in the
back plate casting), after disconnecting the gas
supply at the burner union. Gap should be
nominally 2.5mm.
Replacement of end section can be achieved by
unscrewing the final bent section with insulation from the front (nozzle end) of the burner.
Flame Failure Electrode (if fitted)
These are pre-bent at the factory as is the spark electrode
and are replaced in the same way.
page 5

For Spares requirements the main burner components are as follows:-
Spark and flame failure electrodes are built up as follows:-
page 6
1. Back Insulator
2. Compression Fitting
3. Brass Connector Sleeve
4. Washer
5. Internal Insulator (Ignition)
6. Internal Insulator (Flame Probe)
7. Kanthol Ignition & Flame Probes.
Note:
All enquiries should quote details off burner
nameplate.

COMBUSTION AIR REQUIREMENTS
SELF RECUPERATIVE SYSTEM
Typical control scheme showing the use of a double diaphragm proportionator. This arrangement ensures that
the correct gas-air ratio is maintained over the turndown range of the burner at both hot and cold furnaces
conditions.
EDUCTOR AIR SHOULD BE 100% OF COMBUSTION AIR
MPSR ‘A’ ‘B’ Hot Cap. ‘C’ Hot Cap. ‘D’ ‘E’
6 28” wg 16” wg 20” wg 26” wg
10 28” wg 16” wg 20” wg 26” wg
15 28” wg 16” wg 20” wg 26” wg
25 28” wg 16” wg 20” wg 26” wg
These pressures can be used on the MPHA and MP2 systems when used in conjunction.
page 7
1. Burner unit
2. Eductor
3. Double diaphragm
proportionator
4. Gas adjusting tee
5. Orifice plate
6. Air inlet
7. Gas Inlet

COMBUSTION AIR REQUIREMENTS
RECUPERATIVE SYSTEM
Typical control scheme showing the use of a double diaphragm proportionator. This arrangement ensures that
the correct gas-air ratio is maintained over the turndown range of the burner at both hot and cold furnaces
conditions.
EDUCTOR AIR SHOULD BE SAME VOLUME AS COMBUSTION AIR
MPSR ‘A’ ‘B’ Hot Cap. ‘C’ Hot Cap. ‘D’ ‘E’
6 28” wg 16” wg 20” wg 26” wg
10 28” wg 16” wg 20” wg 26” wg
15 28” wg 16” wg 20” wg 26” wg
25 28” wg 16” wg 20” wg 26” wg
GAS PRESSURE REQUIREMENTS
Gas pressures at burner (whether self-recuperative burner, or separate recuperator and MPHA burner) should be 4” wg for
design rating of burner.
1. Burner unit
2. Eductor
3. Double diaphragm
proportionator
4. Gas adjusting tee
5. Orifice plate
6. Air inlet
7. Gas Inlet
Enertech Limited, P O Box 1, Vines Lane
Droitwich, Worcestershire, WR9 8NA
tel: [phone] • fax:[phone]
email: [email protected] • web: www.nu-way.co.uk
