NuAire Genie-DC Series Instruction Manual

Isolation - Before commencing work make sure that
the unit is electrically isolated from the mains and
switched live supply.
1
11. 06. 18. Leaflet Number 671504
Genie-DC and DCE
12V and 230V
Universal Surface Mounted Fans
Installation and Maintenance
superimposed on page 6.
Figure 2. Remove cover.
Cover screws.
NB. The discharge spigot is 98mm od.
The hole in the structure should therefore
be of a dimension to accomodate any
ducting or cavity lining used.
Press tabs to release cover.
The EMC Directive
2014/30/EU
The Low Voltage
Directive
2014/35/EU
Easy stretch fit removable filter.
System 3 – Continuous mechanical extract (MEV) requires
that fans be fitt ed in the kitchen and all other wet rooms
(bathroom, utility room, en-suite bathroom).
1.0 Genie-DC and DCE fans
Genie-DC and DCE are part of our established Genie range but
with low watt DC mot or s to save energy. The Genie range of
fans has been specifically designed to ventilate small rooms
such as kitchens, toilets, bathrooms, cloakrooms and similar
and can be surface or recessed mounted.
* An optional window mounting kit is available for this unit,
code ref: WINKIT
Air entering the unit passes through a washable filter fitted to the
front cover. Anti-backdraught shutters, retained in the closed
position when fan is not running, are fitted to the base plate
(S and H models only).
Motor has sealed, ball bearings and locked rotor protection.
All units are fitted with high efficiency 12V DC motors. The fan/
motor assembly is retained by spring clips to simplify maintenance.
Interchangeable plug in electronic control modules can incorporate:
■Run-on timer
■Humidistat
■Continuous low duty with boost.
Genie units are supplied with a finishing frame for use in
semi-recessed applications.
Warning: when installing Genie units for remote switching it
is important that the pull cord (if fitted) is removed.
It is recommended that the unit is switched of f (by the pull
cord) before cutting. Cut the pull cord inside the unit a little
way beyond the control module.
1.1 Coding
230V unit 12V unit Descr iption
GENIE-DC-S GENIE-DC-S12
With integral run-on
timer, operated by
remote switch* only.
GENIE-DC-H GENIE-DC-H12
With integral humidistat,
operated by pull cord
or remote switch*
GENIE-DC-X GENIE-DC-X12
Continuous low duty
with boost facility
operated by pull cord
or remote switch*
GENIE-DC-XH GENIE-DC-XH12
Continuous low duty
with boost facility
via internal humidistat
operated by pull cord
GENIE-DCE GENIE-DCE-12
See 1.2
GENIE-DCE-H GENIE-DCE-H12
See 1.2
*light switch or similar or remote switch (by others).
WINKIT = Optional window mounting kit.
1.2 GENIE-DCE
This model is designed to operate in accordance with the
requirements of building regulations 2000 Part F Means of
Ventilation, System 3. (2010 Edition).
They are designed to operate continuously at a low ventilation level.
Sanitary accommodation is not required to be fitted with a fan if it
contains an openable window. For set up instructions please refer
to section 4.
The Genie-DCE units are SAP appendix Q listed. Please refer to
www.sap-appendixq.org.uk for further details.
2.0 Fan Installation
Tobe carried out by qualified personnel only.
2.1 Surface Mounting
Not e. It is assumed that a solid mounting position has
been select ed and passages for ductwork fr om the
outlet spigot, as well as electrical connection prepared.
In addition that compatible ductwork has been installed.
Figure 1. Surface mounted, wall. NB. Base drill pattern
1. Remove cover/grille assembly by
removing cover screws. Depress the
top/bottom retaining tabs. (Fig. 2).
2. Unplug the wiring connector
(Fig 4a) from the electronic control
module, then remove the electronic
control module. (Fig. 3).
3. Remove the fan/motor assembly
by pulling aside the two spring clips
(see Fig. 3).
4. Place the unit in the mounting
position, connect the ductwork and
feed the cable through the cable
entry. Connect the wiring to the
terminal block (it may be easier to
temporarily remove the block to
facilitate wiring).
5. Drill and plug the mounting
surface if necessary and secure the
unit in position, using three No. 6
wood screws.
6. Re-fit the fan assembly to the
case, securing it with the two spring
clips. Install the electronic control module (Fig. 3) ensuring that it is
fully engaged in the internal socket then insert the plug-in wiring
connector into the electronic control module (Fig 4a).
If the pull-cord option is required it should be fed through the
aperture on the impeller housing before sliding the control module
into place. (see Fig 4b). If the pullcord option is not required it must
be removed. Replace the front cover.
7. Ensure two cover screws are fitted.
8. Fit the filter which is a push fit between the front cover and the
body of the unit (see Fig. 2).
9. Test run the unit noting that if a timer/humidistat option is
fitted, the unit may run-on for the duration of the control sequence.
Nuaire: A Trading Division of Polypipe Limited Western Industrial Estate Caerphilly United Kingdom CF83 1NA
T: 029 2088 5911 F: 029 2088 7033 E: [email protected] W: www.nuaire.co.uk

Mounting br acket for semi-
recessed applications.
Optional Extra Part
No. 7 70982
1. Prepare an opening 184mm x 213mm. This will allow sufficient
clearance (approx. 5 to 10mm) all around the unit to accept the
fixing bracket (optional). Note. Do not exceed these dimensions, as
an aperture larger than 208mm x 238mm will not be covered by
the finishing plate.
It is assumed that a solid, non-reverberant mounting position has
been selected and the necessary compatible ductwork is already
installed.
2. Position the mounting bracket
(Fig.7) in the previously prepared
aperture so that the ends of the
bracket are flush with the
surface of the wall. Secure the
bracket with suitable fixings
(by others) see Fig. 5.
Note: Fit finishing plate to fan
before securing to bracket.
Not e: the remaining installation
procedures for Semi-Recessed
Mounting are as Surface
Mounting description.
Plug-in
wiring
connector.
Installation and Maintenance Genie DC & DCE 12V & 230V Universal Surface Mounted Fans
2
11. 06. 18. Leaflet Number 671504
Remove the
fan/motor
assembly by
pulling aside
the two
spring clips.
Pullcord.
Figure 4a. Plug-in wiring connector fits into the
electronic control module.
Spring clip.
Figure 4b. The pull-cord should be fed through the aperture
on the impeller housing if required.
Rear casing.
"Warning: For EMC compliance the 12V cable should not
be fitted within 50mm of 230V or other cables or on the
same tr ay/trunking if made of metal. The earth connection
in the tr ansformer enclosure should not be used.
No earth connection should be made to the 12V fan unit."
Fixings by
others.
Finishing
Plate.
3 set
screw
(supplied).
Mounting
Plate.
2.2 Semi-Recessed Mounting
Not e: Remove the shutter s fr om the spigot if you are
mounting the Genie in the ceiling.
Figure 5. Semi-recessed mounted, ceiling. First cut an aperture for
the fan in the ceiling, cut and fit (A) timber supports (not supplied)
and fit fan as shown.
Figure 6. Semi-recessed mounted, wall.
A
AAA
Ceiling.
Mounting
Plate.
Ceiling.
Figure 7.
2.1 Surface Mounting cont.
Figure 3. Unit components.
Electronic control
module.
Fan/motor
assembly

3
11. 06. 18. Leaflet Number 671504
Installation and Maintenance Genie DC & DCE 12V & 230V Universal Surface Mounted Fans
Front view
10mm
70mm
.
Figure 9.
The window mounting kit is
designed for mounting the unit
into windows 4mm to 32mm
thick using a 125mm dia. hole
(see figure 9).
The hole in the glass should be
125mm dia. Centre 10mm to the
left of the unit centre line and
70mm from the top of the unit.
Pull cord
(when used)
Should the screws
foul on the back of
the shutters during
installation replace
with the next size
down.
Figure 8. Fitting the window kit.
Window 4mm to 32mm thick.
Cut 125mm hole for fan.
Electrical cable passed through
the inner gasket and fed into case.
Unit case.
Spacers where
required.
Approximately
150mm of cable
for final wiring.
Inner gasket, spigot
moulding locates in
window aperture.
Top three shutter blades
temporarily removed during
installation.
Outer shutter frame.
Outer gasket, spigot
moulding locates in
window aperture.
2.3 Window Mounting
WINKIT Parts checklist
The WINKIT contains the following parts. Make sure you have all
the parts present before commencing installation.
1 of f Outer Shutter frame assembly 011372 and 040547
540846
540845
050149
680268
680087
680264
1 off Outer gasket
1 off Inner gasket
3 off 5mm spacers
3 off M4 x 12 Screws
3 off M4 x 20 Screws
3 off M4 x 30 Screws
3 off M4 x 40 Screws 680265
1. Employ a qualified glazier to cut a hole 125mm dia in the glass or,
alternatively, replace your window with new glass incorporating a
precut hole (Fig. 9).
2. The outer assembly consists a four bladed outlet shutter
complete with clamping plate and an outer rubber gasket moulding.
The gasket incorporates a moulded spigot which is designed to
locate inside the 125mm dia hole in the glass.
Pop-out the top three plastic shutter blades from the frame and
retain for replacement later. Position the assembly on the outside
of the glass. If only one person is installing the fan it may be helpful
to tape the assembly to the outside glass at this stage during
installation as all fixings and assembly are completed from inside
3. Working from inside the room with the inner gasket and unit
casing. Run suitable cable through the inner gasket (Holes are
provided top and bottom). Feed the cable through the access hole
in the back of the case. Allow approximately 150mm of cable to
protrude into the case (See Fig.8). Position this inner gasket and
case assembly over the hole in the glass and locate the inner
gasket moulded spigot in the aperture.
4. Select appropriate screws and spacers from the four sets of
screws and three spacers supplied for mounting into different
thicknesses of glass, see table below.
Table 1 Glass/Screw selection
Window thickness
4mm - 6mm
Screw size
M4 x 12
7mm - 11mm
12mm - 16mm
17mm - 21mm
22mm - 26mm
27mm - 32mm
M4 x 20
M4 x 30 + spacer
M4 x 30
M4 x 40 + spacer
M4 x 40
5. Using the three screws (and spacers fitting under the screw
heads if required) locating with the threaded inserts in the outer
assembly, draw the inner and outer assemblies together. Remove
any tape supporting the outer assembly and continue to draw the
units together until the rubber gaskets positively locate the unit
on the window.
Not e: do not over tight en the fixing screws as this may distort
the assembly. Replace the shutters in the outer frame assembly.
6. Wire unit in accordance with the appropriate wiring diagram. A
cable clamp is provided inside the case.
Not e: the remaining installation procedures for Window
Mounting are as Surface Mounting description.

Ensure boost speed is set higher
than trickle speed setting
12V fan units must be installed in accor dance with
these instructions and IEE Wiring Regulations BS7 6 7 1
for SEL V installations.
Isolation - Before commencing work mak e sure the unit is
electrically isolated fr om the mains and switched live supply.
Means for double pole disconnection must be incorporated in
the fixed wiring in accordance with the wiring regulations.
3.0 Genie-DC Commissioning
a) Run-on-timer
When installing a unit with
run-on timer the adjuster
should initially be turned
fully anti-clockwise. (This
equates to a run-on of
approximately 1 minute).
Isolate unit from supply
and remove front cover.
Locate the electronic
control module situated to
the right of the fan/motor
assembly. Using a small
screwdriver, turn the
adjuster to the fully anti-
clockwise position.
Adjustment to the timer can
subsequently be made to
suit individual preferences.
Turn timer clockwise to
increase run on time -
maximum run on time is 60 mins. Not e: for units fitted with
humidistat control (H variants) run-on timer is fixed at
15 minutes.
b) Genie humidistat set up instructions
Set humidistat to mid position (3 o’clock) when viewed as figure 10
(approximately 60% RH). Switch mains power ON (note, switched
live e.g. light switch, should be off and the pull cord should not be
pulled). Under normal conditions the fan should be OFF. If the fan
is ON and the green LED is on, turn adjustment clockwise until the
light goes out.
Not e the green light is ON when humidity is being sensed or
the switched live/pull cord is activated. If the fan is running
and the green light is OFF the fan is in its run-on period.
c) Speed control
All variants are fully speed controllable. ‘S and H’ variants are
equipped with speed control for the boost function only. ‘X and XH’
variants are equipped with control of both trickle and boost speed.
4.0 Genie-DCE Commissioning
Install unit as per previous instructions.
Depending on where the unit has been installed
it will need to be set to the required
continuous trickle duty.
Referring to Fig. 11 the unit has two set points:
B – setting for bathrooms, en-suit es,
utility room.
K – Kitchens.
See 3b set up instructions for ‘H’ variants.
P ower Consump tion 230V 12V
12 16
.14 .085
Unit input power (watts)
Full load current (amps)
Starting Current (amps) .14 .085
5.0 Wiring details
4
11. 06. 18. Leaflet Number 671504
Installation and Maintenance Genie DC & DCE 12V & 230V Universal Surface Mounted Fans
L
N
3
1
2
N
L
E
Fuse 2 amp
230V units via Remote Switch
GENIE-DC-S
GENIE-DC-H
GENIE-DC-X
GENIE-DC-XH
GENIE-DCE
GENIE-DCE-H
230V units via Pullcord
GENIE-DC-H
GENIE-DC-X
GENIE-DC-XH
GENIE-DCE
GENIE-DCE-H
L
N
3
1
2
E
N
L
Fan
Fuse 2 amp
Transformer
230V 12V
N
L
N
L
GENIE-DC-X12
GENIE-DC-H12
GENIE-DC-XH12
GENIE-DCE-12
GENIE-DCE-H12
As wiring for remote switch
above, excluding switch.
Transformer Installation notes for wiring sizes
It is important to note that the size of wire used between the
transformer and the fan unit can have an adverse effect on the
units performance if the following table is not adherred to.
Mains Supply : (230V) 0.5mm sq.
Transformer to fan (12V units only)
Cable run (max. 10 metr es) Cable size
Up to 2m 0.75mm sq.
1.00mm sq.
1.50mm sq.
Up to 4m
Up to 6m
Up to 10m 2.50mm sq.
L
N
3
1
2
Fuse 2 amp E
N
L
12V units via Remot e Switch
GENIE-DC-S12
GENIE-DC-X12
GENIE-DC-H12
GENIE-DC-XH12
GENIE-DCE-12
GENIE-DCE-H12
12V units via Pullcord
The switched Live signal to terminal 2 must be at 230V to
enable the fan and at 0V to st op the fan after the
adjustable timed over run period. Induced voltages in the
switched live field wiring can keep the unit running.
Run-on
timer / Humidity
BK
Min
Trickle
Max
Min
Boost
Max
Min
Max
Run-on
timer / Humidity
Min
Boost
Max
Min
Max
Max
Airflow %
L
N
3
1
2
N
L
E
Fuse 2 amp Fan
230V 12V
N
L
N
L
SL 2
Transformer
Run-on
timer / Humidity
BK
Min
Trickle
Max
Min
Boost
Max
Min
Max
Figure 10a.
(X & XH variants)
Figure 11.
(DCE variants)
Green LED
Figure 10b.
(S & H variants)
Green LED

147mm 85mm
64mm
32mm
85mm
End view
Plan view
Cover fixings
View inside with cover remo ved
12V OUTPUT N L 2
FAN
SWL N L 230V SUPPLY
12V supply
to fan
Mains supply
230V 1ph 50Hz
12V fan units must be installed in accordance with these
instructions and IEE Wiring Regulations BS7 67 1
for SELV installations.
5
11. 06. 18. Leaflet Number 671504
Installation and Maintenance Genie DC & DCE 12V & 230V Universal Surface Mounted Fans
Isolation - Before commencing work make sure
that the unit is electrically isolated from the mains
and switched live supply.
Figure 12. 12V Transformer details.
Side view
7.0 Maintenance
General
A washable filter is fitted to protect the fan/motor assembly from
towel lint, talc etc. and to prolong the life of the unit.
However, some fine dustmay find its way through the filter
and could build up on the motor and/or impeller. It is therefore
strongly recommended that all units are inspected and cleaned at
least every six months.
Procedure
At all times take care not to damage, distort or disturb the balance
of the impeller. Remove the filter and the electronic control module.
Spring aside the two clips and remove the fan module Inspect and
replace any damaged items.
Using a soft brush or dry cloth remove dust and dirt from the fan
module. Wash front cover in warm soapy water and dry
thoroughly. Re-fit fan and electronic control module, replace front
cover and secure with screws. Wash filter on tepid water to which
a little mild detergent has been added. Shake out excess water and
allow to dry naturally. Replace filter. Refit the retaining screws
(Fig 3). Test run the unit.
8.0 Replacement of Parts
Should any component need replacing Nuaire keep extensive stocks
for quick delivery. Ensure that the unit is electrically isolated,
before carrying out any work.
When ordering spare parts, please quote the serial number of the
unit and the ARC number of the purchase if possible.
(This information will be available on the fan label).
9.0 Warranty
The 5 year warranty starts from the day of delivery and includes
parts and labour for the first year. The remaining period covers
replacement parts only.
This warranty is void if the equipment is modified without
authorisation, is incorrectly applied, misused, disassembled, or not
installed, commissioned and maintained in accordance with the
details contained in this manual and general good practice.
The product warranty applies to the UK mainland and in
accordance with Clause 14 of our Conditions of Sale. Customers
purchasing from outside of the UK should contact Nuaire
International Sales office for further details.
10.0 After Sales Enquiries
For technical assistance or further product information, please
contact the After Sales Department.
Telephone [phone]
Technical or commercial considerations may, from time to time, make it necessary to alter the design, performance and
dimensions of equipment and the right is reserved to make such changes without prior notice.
Not e to installing
electrician:
To a void cable
insulation contact with
hot transformer, always
use the knockout at
PCB end.
12V cables should not be fitt ed within
50mm of 230V cables or on the same metal
cable tr ay/conduit.
6.0 Installation of Transformer
Enclosure (12 Volt units only)
The enclosure containing the transformer is intended
to be mounted out of sight (e.g. in a loft, cupboard,
under floorboards etc.). However, if this is not
possible the transformer enclosure should be mounted
as close to the ceiling, or as far from the "splash zone"
as possible (see below for definition of the splash
zone). As can be seen from the table of wiring sizes, it
is advisable to place the enclosure as close to the fan
as possible to reduce the costs of wiring and assist in
installation.
‘Splash zone’
The ‘Splash Zone’ can be considered to be an area
within a bathroom or shower room where a person
using the bath or shower can effectively reach.
An arms reach is defined as 0.6 metres from the edge
of the bath or shower up to a height of 2.25 metres.
Procedure
1. Remove two screws securing the cover and
remove the cover.
2. Position the base enclosure on mounting
surface and route cables through knockouts.
Mark the fixing points on the mounting surface
and secure using suitable fixings (by others).
3. Connect wiring as shown.
4. Replace cover.
Keep vents clear of obstruction.
Not e: No earth is to be connected
between tr ansformer and fan.

6
11. 06. 18. Leaflet Number 671504
Installation and Maintenance Genie DC & DCE 12V & 230V Universal Surface Mounted Fans
Western Industrial Estate
Caerphilly United Kingdom
CF83 1NA
T: 029 2088 5911
F: 029 2088 7033
E: [email protected]
W: www.nuaire.co.uk
Figure 13. Genie-DC and DCE base drill pattern.
