Litex Industries SG52BNK5L User manual

PRINTED IN CHINA
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 6
Blade Assembly. pg. 7
Light Kit Assembly (Optional). pgs. 7- 8
Testing Your Fan. pg. 8
Troubleshooting. pg. 9
Parts Replacement. pg. 9
Warranty. pg. 9
net weight of fan: 16.31 lb (7.4 kg)
For Models:
SG52BNK5L
SG52EB5L
Installation Guide
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
4007498

SAFETY TIPS.
page 1
WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit
panel before you begin the fan installation or before servicing the fan or installing accessories.
1. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN
AND SAVE THESE INSTRUCTIONS.
CAUTION: To avoid personal injury, the use of gloves may be necessary while handling fan parts with sharp
edges.
2. Make sure all electrical connections comply with Local Codes or Ordinances, the National Electrical Code
and ANSI/NFPA 70-1999. If you are unfamiliar with electrical wiring or if the house/building wires are
different colors than those referred to in the instructions, please use a qualified electrician.
3. Make sure you have a location selected for your fan that allows clear space for the blades to rotate, and at
least seven (7) feet (2.13 meters) of clearance between the floor and the fan blade tips. The fan should
be mounted so that the tips of the blades are at least thirty (30) inches (76 centimeters) from walls or
other upright structures.
4. The outlet box and ceiling support joist used must be securely mounted, and capable of supporting at
least 35 pounds (16 kilograms).The outlet box must be supported directly by the building structure.
Use only ETL or UL listed outlet boxes marked "FOR FAN SUPPORT."
WARNING: To reduce the risk of fire, electrical shock, or personal injury, mount to the outlet box marked
"Acceptable for Fan Support of 15.9 kg (35 lb) or less," and use the mounting screws provided with the outlet
box. Most outlet boxes commonly used for the support of lighting fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified electrician if in doubt.
WARNING: To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this fan
are designed to accept only one 12 gauge house wire and two lead wires from the fan. If your house wire is
larger than 12 gauge or there is more than one house wire to connect to the corresponding fan lead wires,
consult an electrician for the proper size wire connectors to use.
5. Electrical diagrams are for reference only. Light kits that are not packed with the fan must be ETL or UL
listed and marked suitable for use with the model fan you are installing. Switches must be ETL or UL
general use switches. Refer to the instructions packaged with the light kits and switches for proper
assembly.
6. After installation is complete, check that all connections are absolutely secure.
7. After making electrical connections, spliced conductors should be turned upward and pushed carefully up
into the outlet box. The wires should be spread apart with the grounded conductor and the
equipment-grounding conductor on opposite sides of the outlet box.
WARNING: To reduce the risk of fire or electrical shock and fire, do not use this fan with any solid state speed
control device or control fan speed with a full range dimmer switch. [Using a full range dimmer switch to control
fan speed will cause a loud humming noise from fan.] (Note:This fan is suitable for use with remote control.)
8. Do not operate the reverse switch until the fan has come to a complete stop.
9. Do not insert anything between the fan blades while they are rotating.
WARNING: To reduce the risk of personal injury, do not bend the blade arms during assembly or after
installation. Do not insert objects into the path of the blades.
WARNING: To avoid personal injury or damage to the fan and other items, be cautious when working around or
cleaning the fan.
10. Do not use water or detergents when cleaning the fan or fan blades.A dry dust cloth or lightly dampened
cloth will be suitable for most cleaning.
WARNING: To reduce the risk of personal injury, use only parts provided with this fan. The use of parts OTHER
than those provided with this fan will void the warranty.
NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all
possible conditions and situations that may occur. It must be understood that common sense and caution are
necessary factors in the installation and operation of this fan.

page 2
1. Unpacking Your Fan.
Carefully open the packaging. Remove items
from Styrofoam inserts. Remove motor housing
and place on carpet or Styrofoam to avoid
damage to finish. Do not discard fan carton or
Styrofoam inserts should this fan need to be
returned for repairs.
Check against parts inventory that all parts have
been included.
2. Parts Inventory.
a. canopy. 1 piece
b. hanging bracket. 1 piece
c. downrod and hanging ball (with pin and clip).
1 piece
d. motor housing. 1 piece
e. yoke cover. 1 piece
f. blade arm. 5 pieces
g. switch housing cap. 1 piece
h. blade. 5 pieces
i. light kit fitter. 1 piece
j. glass shade. 1 piece
k. finial plate (pre-attached to light kit fitter).
1 piece
l. finial (pre-attached to light kit fitter). 1 piece
m. hardware packs
a
IMPORTANT REMINDER: You must
use the parts provided with this fan for
proper installation and safety.
b
cd
e
h
g
ij
m
k
l
f
bulbs required:
3 x 6.5 watt medium base LED bulbs
(included)

3. Installation Preparation.
4. Hanging Bracket Installation.
page 3
Vaulted ceiling
angle is not to
exceed 20 degrees.
downrod
installation
ON
OFF
ON
OFF
blade edge
7 feet
(2.13m)
(76cm)
30
inches
flushmount
installation
12ft. - 20ft.
12ft. - 20ft.
(3.66m - 6.1m)
(3.66m - 6.1m)
Turn off circuit breakers to current fixture from
breaker panel and be sure operating light switch is
turned to the OFF position.
WARNING: Failure to disconnect power supply prior
to installation may result in serious injury.
Remove existing fixture.
WARNING: When using an existing outlet box, be
sure the outlet box is securely attached to the
building structure and can support the full weight of
the fan. Ensure outlet box is clearly marked "Suitable
for Fan Support." If not, it must be replaced with an
approved outlet box. Failure to do so can result in
serious injury.
CAUTION: Be sure outlet box is grounded properly
and that a ground wire (GREEN or bare) is present.
Install hanging bracket to outlet box using original
screws, spring washers and flat washers provided
with new or original outlet box.*If installing on a
vaulted ceiling, face opening of hanging bracket
towards high point of ceiling. Arrange electrical
wiring around the back of the hanging bracket and
away from the hanging bracket opening.
*Note: It is very important that you use the proper
hardware when installing the hanging bracket as this
will support the fan.
To prevent personal injury and damage, ensure that
the hanging location allows the blades a clearance
of 7ft. (2.13m) from the floor and 30in. (76cm) from
any wall or obstruction.
This fan is suitable for room sizes up to 400 square
feet (37.2 square meters).
This fan can be mounted with a downrod on a
regular (no-slope) or vaulted ceiling.The hanging
length can be extended by purchasing a longer
downrod (0.5in./1.27cm diameter). After installing
hanging bracket, continue to Section 5 on page 4 for
those instructions. This fan can also be mounted as a
flushmount on a regular (no-slope) ceiling. After
installing hanging bracket,continue to Section 6 on
page 5 for those instructions.
Installation requires these tools:
Phillips screwdriver, flat-head screwdriver,
adjustable pliers or wrench, stepladder, wire cutters,
and rated electrical tape.
hanging bracket
spring washers
outlet box screws
flat washers

page 4
NOTE:The important safety precautions and
instructions appearing in the manual are not
meant to cover all possible conditions and
situations that may occur. It must be understood
that common sense and caution are necessary
factors in the installation and operation of this fan.
5. Fan Assembly (with downrod).
downrod
electrical wiring
pin
clip
canopy
yoke cover
motor
housing
yoke set screw
If you wish to extend the hanging length of your
fan, you must remove the hanging ball from the
downrod provided to use with an extended
downrod (sold separately). [If you wish to use the
downrod provided,please proceed to instructions
following the dotted line below.]
To remove hanging ball, loosen set screw on
hanging ball and remove pin and clip. Lower
hanging ball and remove stop pin. Slide hanging
ball off the original downrod, A, and slide it down
the longer downrod, B (the top of the downrod
should be noted as having a set screw hole; use
this hole when setting the set screw). Insert stop
pin into top of extended downrod and raise
hanging ball. Be sure stop pin aligns with slots on
the inside of the hanging ball.Tighten set screw
securely.
WARNING: Failure to tighten set screw (on
hanging ball) completely could result in the fan
becoming loose and possibly falling.
Tip: To prepare for threading electrical wires
through downrod, apply a small piece of electrical
tape to the ends of the electrical wires--this will
keep the wires together when threading them
through the downrod.
Loosen yoke set screws and nut at top of motor
housing. Remove pin and clip from downrod (if
you have not already done so). Slide downrod
through canopy and yoke cover.
Thread electrical wires through downrod and pull
extra wire slack from the upper end of the
downrod.
Place downrod into the motor housing yoke and
re-insert pin and clip that were previously
removed. Tighten yoke set screws and nut
securely. Lower yoke cover to motor housing.
["Fan Assembly" continued on next page.]
pin clip
set screw hole
set screw
hanging ball
stop pin
A
B

page 5
5. Fan Assembly (with downrod). (cont.)
hanging ball slot
hanging bracket tab
With the hanging bracket secured to the
outlet box and able to support the fan, you are
now ready to hang your fan. Grab the fan
firmly with two hands. Slide downrod through
opening in hanging bracket and let hanging
ball rest on the hanging bracket.Turn the
hanging ball slot until it lines up with the
hanging bracket tab.
WARNING: Failure to align slot in hanging ball
with tab in hanging bracket may result in
serious injury or death.
Tip: Seek the help of another person to hold
the stepladder in place and to help lift the fan
up to you once you are set on the ladder.
Continue to "Wiring" section on page 6 for
wiring diagram.
6. Fan Assembly (flushmount).
Remove and set aside canopy cover to
reveal 6 holes. [Refer to diagram 1.]Notice
that 3 of these holes are larger.
Locate 6 screws in top of motor housing
yoke. Observe that 3 of the screw heads
are almost flush with the yoke plate
surface and remove these 3 screws/lock
washers. [Leave the other 3 screws intact.]
Thread wiring through canopy. Place
canopy over yoke, aligning larger holes in
canopy with the 3 existing screws in top of
motor housing. Re-insert the 3 screws/lock
washers that were previously removed
into the remaining holes. Securely tighten
these screws. [Refer to diagram 2.]
To prepare the fan for wiring, hang fan
onto hanging bracket by sliding the
canopy over the hanging bracket tab.(Use
one of the non-slotted holes on the rim of
the canopy to do so.) [Refer to diagram 3.]
canopy
canopy cover
canopy
motor
housing
yoke
yoke
flush
screw
raised
screw
flush screw/
lock washer
diagram 1
motor
housing
diagram 2
canopy
motor housing
diagram 3
hanging
bracket tab

page 6
7.Wiring.
WARNING:Turn off circuit breakers to current
fixture from breaker panel and be sure switch is
turned to the OFF position.
CAUTION: Be sure outlet box is properly grounded
and that a ground wire (GREEN or Bare) is present.
Make sure all electrical connections comply with
Local Codes or Ordinances and the National
Electrical Code. If you are unfamiliar with electrical
wiring or if the house/building wires are different
colors than those referred to below, please use a
qualified electrician.
Note: Excess lead wire length from the fan can be
cut to the desired length and then stripped.
When downrod is secured in place on the
hanging bracket, electrical wiring can be made
as follows:
Connect BLACK and BLUE wires from fan to
BLACK wire from ceiling with wire connector
provided.
Connect WHITE wire from fan to WHITE wire
from ceiling with wire connector provided.
Connect all GROUND (GREEN) wires together
from fan to BARE/GREEN wire from ceiling with
wire connector provided.
If you intend to control the fan light with a
separate light switch, connect BLUE wire from
fan to the BLACK (or RED) supply from the
independent switch.
* Wrap each wire connector separately with
electrical tape as an extra safety measure.
This fan is remote control adaptable (remote
control sold separately).
8. Canopy Assembly.
Temporarily raise canopy to hanging bracket to
determine which 2 screws in hanging bracket
align with slotted holes in canopy, and then lower
canopy and partially loosen these 2 screws.
Remove the other 2 screws/lock washers and set
aside.
Now, lift canopy to hanging bracket again,
aligning slotted holes in canopy with loosened
screws in hanging bracket.Twist canopy to lock.
Re-insert the other 2 screws/lock washers and
secure all screws with a Phillips screwdriver.
blue
black
black
white
white
black supply wire
white supply wire
from
ceiling
ground
(green or bare)
ground
(green
or bare)
from fan
hanging bracket
canopy

page 7
9. Blade Assembly.
Time Saver:Washers for blade screws can be set
on each blade screw prior to installing blades.
Locate 15 blade attachment screws and washers
in one of the hardware packs. Hold blade arm up
to blade and align holes. Insert 3 blade
attachment screws (along with washers) with
fingers first and then tighten screws securely
with a Phillips screwdriver. Repeat for the
remaining blades.
Remove blade arm screws and lock washers
from underside of motor. If plastic motor locks
are installed with blade arm screws, discard
plastic motor locks (save blade arm screws and
lock washers to secure blade arms). Align blade
arm holes with motor screw holes and attach
blade arm with lock washers and blade arm
screws. Before securing screws permanently,
repeat with remaining blade arms. Securely
tighten all screws.
NOTE: Tighten blade arm screws twice a year.
switch housing cap
light kit fitter
switch
housing
motor
housing
switch housing
cap
hex nut
lock washer
10. Light Kit Assembly.
Remove 3 screws from switch housing cap.
If you wish to use fan WITHOUT the light kit,
align holes in switch housing cap with holes in
switch housing. (Note:The gap on the top edge
of the switch housing cap must align with the
reverse switch on the switch housing for the
proper fit.) Secure switch housing cap with
3 screws that were just removed.
Please proceed to Section 11 on the next page to
complete installation WITHOUT the light kit.
If you wish to use fan WITH the light kit, locate
BLUE (or BLACK) and WHITE wires in switch
housing labeled LIGHT.
Remove hex nut and lock washer from threaded
rod on light kit fitter. Punch center cap out of
switch housing cap with a screwdriver. Feed
wires from light kit fitter through center hole in
switch housing cap.Then, screw switch housing
cap onto threaded rod followed by lock washer
and hex nut.Tighten hex nut over lock washer
for a secure fit.
["Light Kit Assembly" continued on next
page.]
black (or blue)
wire
blade arm
blade
blade attachment
screws and washers
lock
washers
blade arm screws
motor housing
plastic
motor lock
center cap
white wire
switch housing cap

page 8
10. Light Kit Assembly (Optional). (cont.)
It is recommended that you test fan before finalizing
installation. Restore power from circuit box and light switch (if
applicable).Test fan speeds with the pull chain on the switch
housing. Start at the OFF position (no blade movement). First
pull will set the fan to HI. Second pull will set the fan to
MEDIUM.Third pull will set the fan to LOW. Fourth pull will
again set the fan to the OFF setting.Test light with the pull
chain in the middle. (diagram 1) If fan and/or light do (does)
not function, please refer to "Troubleshooting" section to
solve any issues before contacting Customer Service.
Turn fan completely off before moving the reverse switch. Set
reverse switch to recirculate air depending on the season:
- DOWN position in summer (diagram 2)
- UP position in winter (diagram 3)
A ceiling fan will allow you to raise your thermostat setting in
summer and lower your thermostat setting in winter without
feeling a difference in your comfort.
Important: Reverse switch must be set either completely UP or
completely DOWN for fan to function. If the reverse switch is
set in the middle position (diagram 4), fan will not operate.
Attach pull chain extensions supplied or custom pull chain
extensions (sold separately) to ends of the pull chains
11.Testing Your Fan.
Connect WHITE wire from switch housing to WHITE wire
from light kit fitter. Connect BLUE (or BLACK) wire from
switch housing to BLACK wire from light kit fitter. Be sure
molex connections snap together completely.
Align holes in light kit fitter with holes in switch housing.
(Note:The gap on the top edge of the switch housing cap
must align with the reverse switch on the switch housing
for the proper fit.) Attach light kit fitter with screws that
were removed on previous page. Securely tighten all
3 screws with a Phillips screwdriver.
Install 3 medium base 6.5 watt LED bulbs (included).
IMPORTANT:When you need to replace bulbs, please allow
bulbs and glass shade to cool down before touching.
Remove finial, finial plate, hex nut, flat washer and rubber
washer from threaded rod at bottom of light kit fitter.
Place rubber washer inside glass shade over center hole.
Raise glass shade in order to guide pull chains through
corresponding holes in glass shade. Align threaded rod on
light kit fitter with hole in middle of glass shade and push
up gently, allowing threaded rod to come through hole.
(Be sure pull chain for fan operation does not rub against
bulb during operation.)
Replace flat washer and hex nut on threaded rod.Tighten
hex nut to secure glass shade, but DO NOT OVERTIGHTEN
hex nut as glass may crack or break.Align hole in center of
finial plate with threaded rod, allowing pull chains to come
through corresponding holes in finial plate, and push up.
Thread center pull chain through hole in finial and secure
glass shade to light kit fitter by tightening finial. DO NOT
OVERTIGHTEN finial as glass may crack or break.
glass
shade
finial
bulb light kit fitter
switch
housing
reverse
switch
finial plate
black wire
blue
(or black)
wire
white
wire
molex
connections
white wire
flat washer
hex nut
rubber washer
diagram 2 diagram 3 diagram 4
diagram 1
light
pull chain
extension
fan
pull chain
extension
motor housing

page 9
Troubleshooting.
Problem: Fan fails to operate.
Solutions:
1. Check wall switch to fan.
2.Verify that reverse switch is set completely in
either direction.
3. Check to be sure fan is wired properly.
Problem: Light kit (optional) not lighting.
Solutions:
1. Check wall switch to fan.
2. Check that bulbs are installed correctly.
3. Check to be sure wires in canopy are wired
properly.
4.Verify that molex connections are connected
properly in switch housing.
Problem: Fan operates but light fails (if applicable).
Solutions:
1. Check that bulbs are installed correctly.
2. Check to be sure wires in canopy are wired
properly.
3.Verify that molex connections are connected
properly in switch housing.
4. Replace defective bulbs with same type of bulb.
Problem: Fan wobbles.
Solutions:
1. Use the balancing kit in one of the hardware
packs. If no blade balancing kit is provided, please
call Customer Support, at 1-800-527-1292, to request
one.
2. Check to be sure set screw(s) on motor housing
yoke is (are) tightened securely.
3. Check to be sure set screw on hanging ball is
tightened securely.
Warranty.
Parts Replacement.
For parts and information, please refer to
"Parts Inventory" on page 2.
Litex Customer Support:
1-800-527-1292
KHLI1801
LITEX 30-YEAR LIMITED WARRANTY:
LITEX INDUSTRIES, LTD. warrants this fan to the original
household purchaser for indoor use under the following
provisions:
1-YEAR WARRANTY: LITEX INDUSTRIES, LTD. will replace or
repair any fan which has faulty performance due to a
defect in material or workmanship.Contact Litex Customer
Service at 1-800-527-1292 to arrange for return of fan.
Return fan, shipping prepaid, to Litex Industries, Ltd.We will
repair or ship you a replacement fan, and we will pay the
return shipping cost.
5-YEAR WARRANTY: LITEX INDUSTRIES, LTD. will repair or
replace, at no charge to the original purchaser, any fan
motor that fails to operate satisfactorily when failure
results from normal use.
RETURN FAN MOTOR ONLY, shipping prepaid, to Litex
Industries.We will repair or ship purchaser a replacement
motor and Litex will pay the return shipping cost.
6-YEAR to 30-YEAR LIMITED WARRANTY: LITEX INDUSTRIES,
LTD. will repair the fan, at no charge to the original
purchaser for labor only, if the fan motor fails to operate
satisfactorily when failure results from normal use.Parts
used in the repair will be billed to the purchaser at
prevailing prices at time of repair.
The purchaser shall be responsible for all costs incurred
in the removal, reinstallation and shipping of the product
for repairs.
This warranty does not apply when damage from
mechanical, physical, electrical or water abuse results in
causing the malfunction. Deterioration of finishes or other
parts due to time or exposure to salt air is specifically
exempted under this warranty.
Neither Litex Industries nor the manufacturer will
assume any liability resulting from improper installation or
use of this product. In no case shall the company be liable
for any consequential damages for breach of this, or any
other warranty expressed or implied whatsoever.This
limitation as to consequential damages shall not apply in
states where prohibited.
