Nukeproof MEGAWATT 297 User manual

How to remove and install your Nukeproof Megawatt battery
ITEMs required
• 4mm hex key
removal
1. Set your bike upright somewhere safe and look
under the downtube
2. Loosen the bottom left hand bolt on the battery door
1 full turn using your 4mm hex key
3. Loosen the bottom right hand bolt on the battery
door 1 full turn using your 4mm hex key
4. Fully remove the top battery door bolt

5. Slide the battery door upwards to remove 6. Using your 4mm hex key, carefully turn the silver
battery release bolt CLOCKWISE
7. The battery should slide forwards and stop as per
8. Push the silver clip down to fully release the battery
9. Lift the battery out of the frame

Installation
10. Check the battery holder to ensure it is in good condition and there is no damage to any part of it
11. Rotate the battery so that the locating plastic part on
the mount lines up to the hole in the battery casing
12. Line the battery up and push into the frame
13. The battery should be fully seated after you hear
two clicks
14. Slide your battery door back into place

15. Tighten the top bolt rst using your 4mm hex key 16. Tighten the lower left bolt using your 4mm hex key
17. Tighten the lower right bolt using your 4mm hex key
Your battery has now been retted and you are ready to ride
