Numatic TTV-5565/200T Assembly instructions

233887 / 06/11 (A05) 2
Index
Machine overview
Control panel overview
Rating label / Personal Protective Equipment / Recycling
Safety Precautions
Before continuing, please refer to Quick Set Up Guide on Page 8
!!
Quick set-up guide
Machine set-up
Fitting the oor tool
Setting the width
Fitting the brushes
Filling the clean-water tank
Fill level indicator
Chemical dosing system
Pre-cleaning advice
Machine Operation
Lowering the oor tool
Lowering the brush-deck
Setting the cleaning controls
Brush pressure / load adjustment
Waste tank warning light
Emergency stop button
Breakaway oor-tool feature
Machine usage advice
Off-aisle cleaning kit ( optional )
Regular Maintenance
Tanks and Filters
Changing the Floor Tool Blades
Machine Charging
Motor brake disengage lever / Free-wheel function
Battery care
Specications
Trip sequences
Trouble shooting
Recommended spare parts
Wiring Diagrams
Declaration document
Company Addresses
Page 2
Page 3
Page 4
Page 5
Page 6 / 7
Page 8
Page 9
Page 10
Page 10
Page 11
Page 11
Page 12
Page 12
Page 13
Page 13
Page 14
Page 15
Page 15
Page 15
Page 16
Page 16
Page 17
Page 18
Page 19
Page 20
Page 21
Page 22
Page 23
Page 24 / 25
Page 26
Page 26
Page 28 / 29
Page 31
Back Cover

233887 / 06/11 (A05)
3
Machine Overview
1. Operator control panel ( see page 4 )
2. Charging socket
3. Clean water tank ll point
4. Floor tool raise / lower lever
5. Clean water tank emptying hose & ll level
6. Floor tool vacuum hose
7. Brush deck-lifting Pedal
8. Extra brush load Pedal
9. Semi parabolic oor-tool
10. Brush deck (aluminium)
11. Chemical dosing tank ( 5 litre )
12. Chemical dosing Pump
13. Water pump
14. Gel batteries
15. 40 Amp battery fuses x2
16. Clean Water Filter
17. Waste water emptying hose
18. Top tank hood release catches
19. Top tank (waste water)
20. Bottom tank (clean water)
21. Adjustable side skirt
22. Control handle (start / stop trigger)
23. Top tank hood
24. Basket Filter
3
45
678
10
12
13
14
15
16
17
18
19
20
21
11
2
1
22
12 13
9
23 18
24

233887 / 06/11 (A05) 4
1Control Panel Overview
1
2
3
4
7
Recovery Tank ‘Full’ Indicator
Main Control ON/OFF Key
Emergency Stop Button
For full easy to follow
Instructions on
control panel set up and use,
see machine operation
page 14 &15
Start / Stop Trigger
Speed Control
Forward / Reverse Switch
5
6
Water Flow Rate Adjustment
8
9
10
Chemical Mix Adjustment
11
12
Off Aisle Vacuum Button / Whisper mode
Battery Charge Level Indicator
Hours Meter toggle Button
Brush Pressure / Load Indicator
2
3
4
5
6
7
8
10
11
9
12

233887 / 06/11 (A05)
5
Rating Label
WEEE (Waste, Electrical and Electronic Equipment)
Scrubber Dryer Accessories and Packaging should be
sorted for Environmentally- Friendly recycling.
Only for EU countries.
Do not dispose of Scrubber drier into household waste.
According to the European directive 2002/96/EC on waste
electrical electronic equipment and its incorporation into
national law.
Scrubber dryers that are no longer suitable for use must be
separated collected and sent for recovery in an
Environmentally- friendly manner.
Safety Critical Component
Charging Lead: H05VV-F x 1.0 mm2x 3 core
Battery Charger: 220 / 240 Volt
PPE
(Personal protective equipment) that may be required for certian operations.
Ear Protection Safety Footwear Head Protection Safety Gloves
Dust/Allergens
Protection
Eye Protection Protective
Clothing
Hi Vis Jacket
About the Machine
Caution Floorsign
Machine Description
Company name and address
Voltage Frequency
Weight
WEEE Logo
Machine yr/ wk / serial number
Machine Description
Weight
Noise Level
Hand Arm Vibration
Note:
A risk assessment should be
conducted to determine which PPE should be worn.
CE Mark
Max Gradient

233887 / 06/11 (A05) 6
Component Interval Inspect for
Mains Lead DAILY scufng, cracks, splits, conductors showing
Brushes DAILY bristle damage, wear, drive collar wear
Squeegee Blade BEFORE EACH USE wear, cracks, splits
Filters BEFORE EACH USE clogging and debris retention
Tanks AFTER EACH USE rinse dirty water tank after use
CAUTION:
Read the instruction manual before using the appliance.
This product meets the requirements of BS. EN 60335-2-72
WARNING:
As with all electrical equipment care and attention must be exercised at all times during its use, in addition to ensuring
that routine and preventative maintenance is carried out periodically in order to ensure its safe operation.
Failure to carry out maintenance as necessary, including the replacement of parts to the correct standard could render
this equipment unsafe and the manufacturer can accept no responsibility or liability in this respect.
When ordering spare parts always quote the Model Number / Serial Number specied on the Rating Plate.
Warning do not use on slopes exceeding 9%.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capa-
bilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
NOTE:
This machine is also suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and of-
ces for other than normal housekeeping purposes.
CAUTION:
This machine is not suitable for picking up hazardous dust.
Do not use on surfaces having a gradient exceeding that marked on the appliance.
The machine is not to be stored outdoors in wet conditions.
This machine is for indoor use only.
Do’s and Don’ts:
DO ensure only competent persons unpack/assemble the machine.
DO keep your machine clean.
DO keep your brushes in good condition.
DO replace any worn or damaged parts immediately.
DO regularly examine the power cord for damage, such as cracking or ageing. If damage is found, replace the cord
before further use.
DO only replace the power cord with the correct Numatic approved replacement parts.
DO ensure that the work area is clear of obstructions and / or people.
DO ensure that the working area is well illuminated.
DO pre-sweep the area to be cleaned.
DON’T use steam cleaners or pressure washers to clean the machine or use in the rain.
DON’T attempt machine maintenance or cleaning unless the power plug has been removed from the supply outlet.
DON’T allow any inexperienced repairs. Call the experts
DON’T strain cable or try to unplug by pulling on cable.
DON’T leave the brush pad on the machine when not in use.
DON’T allow the machine to be used by inexperienced or unauthorised operators or without appropriate training.
DON’T use the machine without the solution tanks properly positioned on the machine, as shown in the instructions.
DON’T expect the machine to provide trouble-free, reliable operation unless maintained correctly.
DON’T run the machine over power cable during operation.
DON’T lift or pull the machine by any of the operating triggers - Use the main handle.
DON’T remove the handle from the machine except for service and repair.
ORIGINAL INSTRUCTIONS
READ MANUAL BEFORE USE
Information for Scrubber Dryer

233887 / 06/11 (A05)
7
WARNING:
Only use brushes provided with the appliance or those specied in the instruction manual.
The use of other brushes may impair safety.
A full range of brushes and accessories are available for this product.
Only use brushes or pads which are suitable for the correct operation of the machine for the specic task being per-
formed.
It is essential that this equipment is correctly assembled and operated in accordance with current safety regulations.
When using the equipment always ensure that all necessary precautions are taken to guarantee the safety of the
operator and any other persons who may be affected.
Wear non-slip footwear when scrubbing. Use a respiratory mask in dusty environments.
The machine, while charging, must be positioned so that the mains plug is easily accessible.
When cleaning, servicing or maintaining the machine, replacing parts or converting to another function the power
source shall be switched off.
Mains operated machines shall be disconnected by removing the power plug, and battery operated machines shall be
disconnected by removing the isolating pin.
In order to prevent unauthorised use of the machine the power key must be removed after use.
Machines left unattended shall be secured against unintentional movement.
Operators shall be adequately instructed as to the correct use of the machine.
PRECAUTIONS WHEN WORKING WITH BATTERIES
1. Always wear protective clothing e.g. face visor, gloves and overalls when working with batteries
2. Whenever possible always use a properly designated and well-ventilated area for charging. Do not smoke or bring
naked ames into the charging area.
3. Remove any metallic items from hands, wrists and neck i.e. rings, chains etc. before working on a battery.
4. Never rest tools or metallic objects on top of the battery.
5. When charging is complete disconnect from the mains supply.
6. The batteries must be removed from the machine before it is scrapped.
7. The machine must be disconnected from the supply when removing the battery.
8. To remove the batteries:- Disconnect machine from the mains supply (if charging) and ensure batteries are switched
off with circuit disconnect switch (see page 17). Disconnect hoses from separator and tanks.
Remove separator and tanks . Unscrew battery strap xings and remove.
Undo battery terminals and remove. Remove batteries.
9. The batteries are to be disposed of safely and in accordance with the battery directive.
10. Only use genuine NUMATIC replacement batteries.
11. Do not allow the batteries to become fully discharged; it may not be possible to recharge them. Batteries should
not be discharged below 9.5 volts with 10 amps owing.
12.Do not allow one battery to be discharged separately to the other.
13.Do not mix batteries from different machines.
14. The batteries tted to this product are Valve Regulated Lead Acid (VRLA) gel electrolyte type. The tting of any
other type of battery may cause a safety hazard.
BATTERY CARE
1. Always recharge the batteries after use. This can be done at any time its not necessary to wait until they are fully
discharged; they do not develop a “memory”.
2. Leaving the charger to operate for a minimum of 4 hours after the green
light has come on, at least weekly, will prolong battery life.
3. Do not store the machine with the batteries discharged.

233887 / 06/11 (A05) 8
Quick Set Up Guide
Please read before commencing any operation.
After the removal of all the packaging, carefully open and check the contents of the start up pack (g.1).
!!
1Contents:
1 x Operator Manual
1 x Battery charging lead
2 x Keys
3 x 40 amp fuses (1 x spare)
1 x Maxi fuse-puller
Note: Ensure that no metal objects come into contact with battery terminals while the batteries are exposed.
When inserting the rst fuse you may notice a spark, this is normal.
Lift top tank assembly to reveal battery compartment, ensuring you use the handle grip
provided (g.1).
Fit battery fuses (contained in start-up pack) into the battery fuse holders as illustrated (g.2).
Note: Wear suitable gloves when inserting fuses.
Fig.2
Ensure the Emergency Stop button is released (g.3).
Insert key into master control on/off and turn quarter-turn clockwise to the ‘ON’ position.
Ensure that the forward/reverse switch is set to forward position (g.4).
Select the slow speed setting.
Depress control handle with both hands and slowly drive machine off of the pallet (g.5).
When the machine is removed and in a safe position, turn key back to the off position (g.6). Fig.6
Fig.4 Fig.5
3
Fig.3
2
Fig.1
Use Handle Grip when
raising or lowering the
top waste tank.

233887 / 06/11 (A05)
9
Machine Set Up
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS
!!
Fitting the oor-tool
Lower the oor-tool arm by moving the release lever to the lower position (g. 7)
Push oor-tool onto the holder and secure with the easy-t securing pin (g 8)
Push waste collection pipe onto the oor-tool; ensure a tight t (g 9)
Note: Raise oor-tool again before driving to the cleaning area (g.9a)
!
Fig.8 Fig.9a
Fig.9
Fig.7
Owning the TTV-5565 scrubber dryer is like having 2 machines in one.
With two width-settings the operator can quickly adapt the machine to any cleaning situation;
without the need for any tools. The machine can be set to clean anything from a narrow corridor to
a large warehouse. The TTV-5565 is a totally versatile machine. (see Fig.10)
650mm 550mm
Fig.10

233887 / 06/11 (A05) 10
Machine Set Up
Fitting the brushes
Featuring the new OBS (Octagonal Brush System);
The brushes simply push-t up onto the chucks making tting and removal a simple process.
Ensure the Brush deck is set to the appropriate width for the brushes being used.(g 11a/11b).
Slide the brush under the brush deck (g 12).
Fit the brushes onto the OBS drive chuck (g.13)
Safety gloves are recommended for the changing of used brushes.
Note:
Check the deck width setting is correct with the selected brushes before use.
Fig.12
Fig.13
Setting the width adjustment
Adjustment of the Brush deck must take place with the deck in the raised position.
Lift the Deck locking knob located at the front of the machine. (see g.11), then pull the side pod at the handle position
to expand or close to contract the deck to the desired width - 650mm (see Fig.11a) or 550mm (see Fig 11b)
650mm 550mm
Fig.11 Fig.11a Fig.11b
Note: Use 2x 330mm Brush size for
650mm setting.
Note: Use 2x 280mm Brush size for
550mm setting.
2x 330mm Brush for 650 mm setting.
2x 280mm Brush for 550 mm setting.
Note: Remove the brushes before adjusting width!

233887 / 06/11 (A05)
11
Machine Set Up
Filling the clean water tank
The TTV-5565 is equipped with a large capacity 85 litre clean-water tank allowing, for large areas to be covered in
a single ll.
To ll the clean-water tank, extend the hose located to the rear of the machine in the centre of the removable ller cap,
see Fig 14. Pull out hose, Fig 15. Open the stopper Fig 16 and place hose under water tap, or use a hose to com-
mence lling, Fig 17.
Or the tank can be lled by unscrewing the ller cap and using a bucket or similar container Fig 17a.
Note: Great care must be taken to ensure that contaminants (leaves, hair, dirt, etc.) are not allowed to enter the
clean-water tank during the lling process. If using a bucket or similar, ensure it is always clean and free from debris.
Fig.17
Fig.14
Fig.16
Fig.15
Fig.17a
The water level in the clean water
tank can be measured using the
scale on the rear of the machine
(g.17b).
The clean water bottom tank
holds 85 litres.
Fig.17b
Fill-level indicator

233887 / 06/11 (A05) 12
When handling and mixing chemicals.
Always ensure that chemical manufacturers safety guidelines are followed.
Only use chemicals recommended for use in auto scrubber-driers.
Important
Do not operate machine unless the Operator Manual has been read and fully understood.
After use, ensure the chemical dosing tank is emptied, cleaned and relled with clean water.
The dosing pipes also need to be cleaned and ushed through with clean water for at least 60 seconds after use.
!
!
!
!
Chemical dosing System
Note: always ensure that the waste-water tank is empty before lifting.
The TTV-5565 scrubber dryer has an optional automatic chemical-dosing system.
Simply ll the 5 litre chemical dosing bottle and the machine will deliver the correct mix ratio as set by the operator,
depending on the oor and cleaning conditions.
To ll the chemical-dosing bottle, rst make sure the top waste tank is fully drained then, lift up the waste-water tank
(g. 18), remove the dosing bottle, unscrew the bottle cap (g.19) and ll with appropriate cleaning chemical, or t your
own chemical container, reusing the original Numatic container cap. Ret dosing bottle (g.19a) and replace bottle cap,
and carefully lower waste-water tank.
Note: The top (waste) tank is tted with a pressure sensor that disables the machine until the top tank is closed.
The machine is now ready to be moved to the cleaning site.
Before performing the cleaning operation, place-out appropriate warning signs and sweep or dust-mop the oor
Fig.18
Fig.19 Fig.19a

233887 / 06/11 (A05)
13
Machine Operation
Lowering the brush deck
Lowering the oor tool
Fig.20
Fig.22
After preparing the oor (see previous section), we are now ready to set the controls to suit the cleaning conditions.
Before any settings can be applied, ensure the brush deck is lowered. (see g 23)
Move the Floor tool lever (see g.20), to it’s lower position (see g.21).
Note: The machine will still reverse with the Floor tool in the lowered position, this could possibly damage the
blades. Raise the oor tool before selecting reverse.
The control for lowering the brush deck can be found to the rear right of the machine (g 22).
Lower the brush deck by moving the left hand release lever to the upper position (see g. 23).
Note: If the brush width has not been set, see ‘Setting the width adjustment’ on page 10 before proceeding.
Fig.23
Fig.21

233887 / 06/11 (A05) 14
Set automatic Chemical Dosing Mix as required, depending on oor type and level of soiling.
Set desired traction Speed as required, depending on oor type and level of soiling.
Middle speed is the optimum cleaning speed.
Set Water Flow Rate as required, depending on oor type and level of soiling
Setting the cleaning controls
Insert the key into the master control on/off and quarter-turn it clockwise to the ‘ON’ position.
The battery charge-level indicator will illuminate for 5 seconds.
1L 2L 3L 4L
1 L / Min
2 L / Min
3 L / Min
4 L / Min
100:1 75:1 50:1 25:1
100 : 1
75 : 1
50 : 1
25 : 1
The TTV-5565 has been tted with a whisper mode, this reduces the
noise produced by the vacuum motor by 3dB.
To operate the Whisper mode start the machine in the normal way.
When the machine is running normally the off aisle light will show a
constant green. This means the Vacuum motor is running at 100%.
With the machine running press the off aisle button once the Vacuum
motor will reduce speed to 75% of capacity and the off aisle light will
FLASH green.

233887 / 06/11 (A05) 15
Brush pressure / Load adjustment
The brush load lever is located to the right hand side of the machine.
This option is for hard to clean patches, adding 10 kg extra pressure to the brushes.
The brush load indicator on the control display shows the pressure applied, when the
machine is being operated.
Load increases from 40 Kg (g 24) to 50Kg When the lever is in the up position. (g 24a)
NOTE: It is recommended this option is NOT used all the time and is for spot cleaning only.
Fig.24
Fig.24 a
NOTE: The run-time of the machine may decrease
if the load on the brushes is increased
Machine Operation
Waste water tank ll level warning light
When the waste water-tank becomes full, a red warning light will
illuminate on the operator control panel (as illustrated).
The vacuum motor will stop automatically after 5 seconds .
The waste-water tank requires emptying (see page 17).
Emergency-stop button
The TTV - 5565 is equipped with an electronic braking system.
Simply release the hand operated start / stop trigger and the machine will stop.
In an emergency, strike the emergency-stop button.
The machine will be disabled.
To reset, turn Emergency Stop button clockwise (see g.25).
After re-setting the emergency stop button, to restart the machine, turn the
master control on/off key to the ‘OFF’ and then ‘ON’ position.
Fig.25

233887 / 06/11 (A05)
16
Breakaway oor-tool
Fig.26
The oor-tool design incorporates a breakaway feature.
Allowing it to safely disengage from its mounting should it
become caught on an obstruction, during forward machine
movement
(See g.26)
Fig.27
To re-attach the blade to its holder.
First loosen the retaining knobs on the oor-tool body and slide
onto the holding bracket.
Tighten retaining knobs to nger tight.
(See g.27)
Machine Operation
Machine in use
ALWAYS ENSURE THAT THE FLOOR IS PRE-SWEPT
AND RELEVANT SAFETY SIGNS ARE DISPLAYED.
NOTE: Care must be taken to reduce speed when
cornering or when manoeuvring around obstacles
! !
To operate, turn the master control on/off key to the ‘ON’ position,
select water ow rate, chemical mix (see page 14), lower the oor
tool (see page 13) and select forward (see page 8: g 4), press
the start / stop trigger.
Vacuum pick-up, water-ow and chemical-dose will turn on
automatically and the machine will move forward.
Adjust the speed to suit the conditions using the variable speed
control (see page 8).
The clean water / chemical mix is dispersed evenly via
‘THRU- FEED’ scrubbing brushes.
The waste water is then retrieved by the suction oor-tool
(see page 9).
Overlap each scrubbing path by 10cm to ensure
an even clean.
Do not operate the machine on inclines that exceed (9%), when
full.
If streaking occurs wipe oor-tool blades clean (see g.29).
On heavily soiled oors use a ‘double scrub’ technique.
First pre-scrub the oor with the oor-tool in the raised position,
allow the chemical time to work then scrub the area a second
time with the oor-tool lowered.
Fig.28
Fig.29

233887 / 06/11 (A05) 17
Fig.30
Off-Aisle Cleaning Kit (Optional Extra Accessory)606182
The optional off-aisle cleaning kit gives added exibility to the operator.
The kit can be used to clean hard to reach / inaccessible areas.
The TTV-5565 has been tted with a whisper mode, this reduces the noise produced by the vacuum motor by 3dB.
Press the off aisle button on the control panel (see g.30) to turn on the off aisle function, the vacuum motor will run at
100% and the off aisle light will show a constant green.
This will disable all the machine functions accept for the vacuum allowing for the use of the off aisle accessory kit.
Remove the vacuum hose from the oor tool and attach to the off aisle kit (g 30a).
Press the off aisle button again to enter whisper mode and the off aisle light will ash. allowing the vacuum motor to
run at 75% of capacity.
Press the off aisle button once more to stop the off aisle function.
Return the hose to the oor tool once nished using the off aisle facility.
The machine will need to be reset for normal use, when nished using the off aisle kit.
By simply operating the control handle or pressing the off aisle button on the control panel.
Fig.30a
Off-Aisle Accessory Kit
(Optional) (606182)

233887 / 06/11 (A05)
18
Next remove oor-tool vacuum hose and ush-out
with clean water.
Next empty clean water tank, using emptying hose
and again ush-out with clean water.
Regular Maintenance
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF PRIOR TO ANY
MAINTENANCE USING THE MASTER CONTROL ON/OFF KEY.
REMOVE THE KEY PRIOR TO ANY MAINTENANCE OPERATION.
! !
After use, empty waste-water tank using emptying
hose and ush-out with clean water.
AA
B
C
B
C
Whilst pressing in the top tank hood toggles, remove the hood (g 31)
The hood also has a sealing-rubber which should be examined at
every clean-down.
Rinse using clean water , avoiding the vac lter (31a)
IMPORTANT:
Remove white vac lter and clean if required (keep dry) (g 31a).
Never use the machine without the recommended lter as it may cause damage to
the machine.(g 31 a)
Remove debris basket lter and rinse using clean water, and ret.
IMPORTANT:
If the debris basket is allowed to become clogged, vacuum performance can deteriorate.
(g 31b)
The clean-water tank lter is located to the rear of the battery compartment,
and should be checked at regular intervals.
Unscrew the cap check the lter condition (g 31 c), rinse and ret.
Ensure tank has been emptied and care is taken when working in the vicinity of
batteries.
Fig.31 c
Fig.31
Fig.31 a
Fig.31 b
NOTE:
ANY SPILLS SHOULD BE WIPED-UP BEFORE THE TOP TANK IS
LOWERED.

233887 / 06/11 (A05) 19
! !
Changing the Floor Tool Blades
The oor-tool
Fig.32
Fig.34 Fig.35
Fig.33
To clean the oor-tool, remove securing-pin and pull-free from the holder (see g.32).
Rinse the oor-tool assembly with clean water and ret.
Periodically the oor-tool blades should be examined and checked for wear and damage.
The blade removal is easy. Simply start by removing the four retaining pins (see g.33), turn the
oor-tool over and separate the blade carrier from the body (see g.34).Peel away the blades from their locating lugs
(see g.35) and examine or renew as required.
Replacement is a reversal of the removal process.
Floor-tool overview
1. Floor-tool main body
2. Rear blade
3. Blade carrier
4. Front blade (slotted)
5. Retaining pins x 4
1
2
3
4
5
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF PRIOR TO ANY
MAINTENANCE USING THE MASTER CONTROL ON/OFF KEY.
REMOVE THE KEY PRIOR TO ANY MAINTENCANCE OPERATION.

233887 / 06/11 (A05)
20
Machine Charging
ALWAYS ENSURE THAT THE MACHINE IS
SWITCHED OFF PRIOR TO CHARGING.
! !
The battery meter displays the charge level of the batteries; when fully charged,
all meter lights are illuminated (see g 36).
As the machine is used and the batteries are discharged, the meter lights will go out from
right to left.
If the battery-charge level is allowed to discharge to the point that only the red light remains
illuminated, the operator must consider charging the machine.
If the battery-charge level is allowed to discharge to the point that only one red light remains
illuminated (and begins to ash), all cleaning functions will automatically be disabled and
the operator should drive the machine straight to a suitable charge point.
The large capacity gel batteries are sealed for life and are totally maintenance free.
The on-board charger automatically monitors the charging process and will switch off
when the batteries are fully charged.
Insert the charging lead required for your country(g 36a for UK, Fig 36b for Europe) into
the charging point.
The machine charging point is located to the rear of the machine under the control panel.
(see g.37).
Connect to a suitable power supply (see g.38).
Once mains power is connected the red charging indicator will illuminate.
To ensure a full charge, the machine should be left for a period of 8-12hrs.
Once fully charged, disconnect the charging lead from both the power supply and
the machine.
Fig.36a
Fig.36
Fig.37
Fig.38
Fig.39
Fig.36b
