Nuova Simonelli MYTHOS Plus BE Series User manual

©McDonald’s Corporation · Planned Maintenance Manual · Revised December 2012
Hazards
These icons alert you to a possible risk of personal injury.
Equipment alerts
Look for this icon to find information about how to avoid damaging the
equipment while doing a procedure.
Tips
Look for this icon to find helpful tips about how to do a procedure.
EQUIPMENT CATEGORY
BE XX
Nuova Simonelli
MYTHOS Plus
Cross reference (optional)
50.000 cycles maintenance tasks
BE XX S01 Minor preventive
maintenance
100.000 cycles maintenance tasks
BE XX A01 Major preventive
maintenance
Model MYTHOS
1 Holder lid, 2 Dynamometric presser lever, 3 Frontal door, 4 Dynamometric presser, 5 Pouring lip, 6
Drawer, 7 Fork, 8 Start-up micro-switch, 9 Switch, 10 Control panel, 11 Body machines, 12 Coffee
bean hopper
Nuova Simonelli MYTHOS Plus BE XX

Technicians Service 50.000 Cycles BE XX S1-T
©McDonald’s Corporation · Planned Maintenance Manual · Revised December 2012 Page 1 of 4
Nuova Simonelli MYTHOS Plus QUALIFIED TECHNICIANS ONLY 50.000 Cycles BE XX S1-T
Why
To ensure the machine is producing gold standard quality coffee.
Time required
10 minutes to prepare 1,25 hours to complete
Time of day
Time of day. For 24-hour restaurants: XXX
Hazard icons
Tools and supplies
Tools supplied by
technician
Procedure
QUALIFIED TECHNICIANS ONLY
1
Check for any damaged wires
or caballing.
2
Check for noisy motor.
3
Check for cracks on beans
hopper.
4
Check all moving parts on
grinder lever.
5
Replace grinder lever spring.

Technicians Service (continued)
©McDonald’s Corporation · Planned Maintenance Manual · Revised December 2012 Page 2 of 4
Nuova Simonelli MYTHOS Plus QUALIFIED TECHNICIANS ONLY 50.000 Cycles BE XX S1-T
.
6
Replace white discharge
coffee flap.
7
Check for wear on product
button selection.
8
Check on/off switch.
9
Check LCD display.

Technicians Service 100.000 Cycles BE XX A1-T
©McDonald’s Corporation · Planned Maintenance Manual · Revised December 2012 Page 3 of 4
Nuova Simonelli MYTHOS Plus QUALIFIED TECHNICIANS ONLY 100.000 Cycles BE XX A1-T
Why
To ensure the machine is producing gold standard quality coffee.
Time required
10 minutes to prepare 1,75 hours to complete
Time of day
Time of day. For 24-hour restaurants: XXX
Hazard icons
Tools and supplies
Tools supplied by
technician
Procedure
QUALIFIED TECHNICIANS ONLY
1
Check for any damaged wires
or caballing.
2
Check for noisy motor.
3
Check for cracks on beans
hopper.
4
Replace grinder blades.

Technicians Service (continued)
©McDonald’s Corporation · Planned Maintenance Manual · Revised December 2012 Page 4 of 4
Nuova Simonelli MYTHOS Plus QUALIFIED TECHNICIANS ONLY 100.000 Cycles BE XX A1-T
5
Replace white discharge
coffee flap.
6
Replace grinder lever
mechanism.
.
7
Check for wear on product
button selection.
8
Check on/off switch.
9
Check LCD display.
