NURZVIY DISCOVER 100 User manual

DISCOVER 100



What’s in the Box
Product Info
Technical Specifications
How to Recharge Discover 100
Operation Guidance
LCD Display
Safety Guidelines
Warranty and Contact
1
2
4
6
7
8
9
11
CONTENTS

For your safety and benefit, please keep this
manual handy for future reference.
If there is any question, please contact us at
[e-mail].
1
Discover 100 User Manual
What's in the Box

USB A1 Output USB A2 Output
Type-C1
Input/Output Type-C2
Input/Output
Power Button
2
Product Info

Product Info
LED Light
3

What’s in the Box
Product Info
Technical Specifications
How to Recharge Discover 100
Operation Guidance
LCD Display
Safety Guidelines
Warranty and Contact
1
2
4
6
7
8
9
11
Net Weight
Dimensions
Type-C1 Input
Type-C2 Input
General
Battery Type
Capacity
Charging Time
Life Cycle
Lithium Polymer Battery
106.56 Wh (22.2V/4.8Ah)
7.5 Hours
＞500 Cycles
About 1.2 lbs. (0.5 Kg)
4.4 x 3.1 x 2 inch (11.3 x 8 x 5.1cm)
PD 60W 5V/3A, 9V/2A, 12V/3A, 20V/3A
PD 100W 5V/3A, 9V/2A, 12V/3A, 20V/5A
4
Battery Info
Technical Specifications

LED Flashlight
Pass-through Charging
Operating Temperature
Charging Temperature
Storage Temperature
Output
USB1/USB2:
5V/4.5A, 9V/2A, 12V/1.88A (22.5W)
Type-C1:
PD 60W 5V/3A, 9V/2A, 12V/3A, 20V/3A
Type-C2:
PD 100W 5V/3A, 9V/2A, 12V/3A, 20V/5A
MAX 2W (3 Brightness Level
+ SOS Mode)
Yes
14℉-104℉
32℉-104℉
32℉-104℉
5
Technical Specifications

By USB Type-C Cable
·Use a USB Type-C cable to plug in the USB Type-C1 port.
6
How to Recharge Discover 100

How to charge USB digital appliances
with Discover 100?
Connect the standard USB cable of digital appliance to
any port of Discover 100, and the product will start to
charge your device. Please press the power button in
case that the product does not start to charge your
device automatically.
Notice:
·Discover 100 supports fast charging by using single
Type-C port. There will be a power reduction to 5V/2A
if double ports are used at the same time.
·Discover 100 supports two-way fast charging.
·Discover 100 allows for pass-through charging.
7
Operation Guidance

How to use the LED flashlight?
This product is equipped with LED flashlight.
·Long press the power button for 3 seconds to turn on
the LED flashlight, then press the power button to
change the LED flashlight mode – weak, medium,
strong or SOS.
·Long press the power button for 3 seconds to turn off
the LED flashlight.
Warning: Do not direct the dazzling light to people’s
eyes to avoid any hurt.
·The LCD screen will display current battery level
as percentage.
·The LCD screen will display current voltage and current.
Operation Guidance
LCD Display
8

·Do not short-circuit the product. Keep it away from metal
objects (e.g., coins, hairpins, keys, etc.).
·Do not expose the product to fire or excessive temperature,
othewise, it may cause an explosion. Keep it away from
high temperature environment and avoid direct sunlight.
·Do not water it. Keep it away from high humidity
environment.
·Do not cover the product. Keep it and use it in
well-ventilated environment.
·Do not drop or place heavy objects on the product.
·Do not dismantle the product. Take it to a qualified service
person if service or repair is required.
·To avoid any injury, close supervision is required when the
product is used near children.
·Do not use damaged or incompatible wires, plugs or output
cables to connect the product, otherwise, it may cause
electric shock.
·Do not charge the product over the required time.
·Disconnect the product after it is fully charged.
Safety Guidelines
9

Notice:
·The product is only used for emergency. It cannot replace
the standard DC or AC power of household appliances or
digital products.
·Always return your used electronic products, batteries, and
packaging materials to dedicated collection points, so as
not to cause explosion or pollution.
10
·Pull the power plug out of the product port when the
product is not in use.
·This product has built-in high quality original polymer
battery, It has no memory effect, but it is durable and with
high capacity. We recommend you to apply in the range of
50℉~86℉, so as to obtain the optimal charging capacity.
·When charging, please stay away from TV, radio or other
equipment to avoid any interference.
·If the product is switched on, but not in use, it will automati
cally shut down in 60s.
Safety Guidelines

Nurzviy warrants that the Nurzviy products will be free from
defects in workmanship and materials under normal used
during the applicable warranty period identified in the
Warranty Period section below.
This warranty statement sets forth Nurzviy’s full and exclu-
sive warranty obligations. Nurzviy will not assign or authorize
anyone to assume for us any other liability with respect to the
products we sell.
Warranty Period
The warranty period for Discover 100 is 24 months. In each
case, the warranty period is with effect from the date of
purchase by the original consumer purchaser. The sales
receipt from the first consumer purchase or other reasonable
documentary proof is required in order to establish the start
date of the warranty period.
How to get warranty service
To get warranty service, please contact our customer
service through [e-mail]
or call [phone], thank you!
Warranty and Contact
11

Disclaimer
·The company shall not be liable for any damage
caused by force majeure such as fire, typhoon, flood,
earthquake or customer's intentional negligence,
misuse or use under other abnormal conditions.
·The company shall not be liable for any damage
caused by non-standard connectors.
·The company shall not be liable for any damage
caused by not operating the product in accordance with
the instructions in the operating instructions.
·This product is not suitable for atomic energy equip
ment, aerospace equipment, transportation equipment,
medical equipment, etc., which are related with
personal safety, or equipment relying heavily on unin
terrupted electricity. The company shall not be liable for
any personal accidents, fire accidents, or malfunctions
if the product is used on the above equipment or
machines.

Nurzviy Energy, Inc.
4555 GREAT AMERICA PKWY 5TH FL SANTA CL
ARA, CA 95054 UNITED STATES
[phone]
www.nurzviy.com
[e-mail]
