NURZVIY DISCOVER 600 User manual

DISCOVER 600



CONTENTS
What’s in the Box
Product Info
Technical Specifications
How to Recharge Discover 600
Operation Guidance
LCD Display
What It Powers
General Safety
Troubleshooting
Storage and Maintenance
FAQs
Warranty and Contact
1
2
4
6
8
9
10
11
12
12
13
14

For your safety and benefit, please keep this manual handy for
future reference.
If there are some problems with the portable power station,
please contact us at [e-mail]
1
What's in the Box
Discover 600 AC Power Adapter
Shoulder Strap User Manual

Product Info
Capacity status indicator on LCD
(power query/reset button)
1
2
3DC1/DC2 button
4LED light
5LED light button
6PV input
2
Car output
LCD display switch button
7
8
9Type-C output
10 USB-A output
11 Type-C and USB-A button
12
2
DC input
2
DC1/DC2 output
1
2
3
4
5
6
7
8
9
10
1112

·Capacity status indicator on LCD:
Check the capacity left at current output before use. If the power
capacity is low, please recharge the product in time.
·DC1/DC2 output: 12V/4A
·Car output: 12V/8A
·DC1/DC2 button: Car port /DC output
·Type-C output: 60W (PD) 5V/3A,9V/3A, 12V/3A, 15V/3A, 20V/3A
·USB-A output: 18W
·AC output: 110V/60Hz 600W
·PV input: 12.5V-30V/4.75A MAX
·DC input: 26V/4.75A
3
AC output
AC output button
Product Info

What’s in the Box
Product Info
Technical Specifications
How to Recharge Discover 600
Operation Guidance
LCD Display
What It Powers
General Safety
Troubleshooting
Storage and Maintenance
FAQs
Warranty and Contact
1
2
4
6
8
9
10
11
12
12
13
14
4
Charging Hours
Battery Type
Capacity
Life Span
Battery Management System
About 5 hours with the original
power adapter
Temperature control, surge protection,
sine wave, short circuit protection
Lithium-ion battery
540Wh
1000 times
PV Input
DC Input
USB-A Output
Type-C Output
DC1 and DC2 Output
AC Output
Car Output
Input
Output
26V/4.75A
12.5V-30V/4.75A MAX
18W
60W (PD) 5V/3A, 9V/3A
12V/3A, 15V/3A, 20V/3A
12V/4A
12V/8A
110V/60Hz 600W
Technical Specifications

5
Dimension
Weight
Operating Temperature
Charging Temperature
Warranty
General
12.3 lbs (5.6 Kg)
11.2 x 5.2 x 11.7 inch (28.4 x 13.2 x 29.7 cm)
32~104℉(0~40℃)
14~104℉(-10~40℃)
24 Months
Technical Specifications
60W (PD) 5V/3A, 9V/3A
12V/3A, 15V/3A, 20V/3A

Charging from AC Adapter
·Please charge the product with the AC power adapter when you see
the remaining power indicator on the LCD display showing low
capacity. The LCD display shows the current charging proportion and
charging power.
·When the LCD indicator shows 100%, it means the product is fully
charged. The charging process takes about 5 hours. Please use the
original charger to charge this product.
6
How to Recharge Discover 600

·Capacity status indicator on LCD:
Check the capacity left at current output before use. If the power
capacity is low, please recharge the product in time.
·DC1/DC2 output: 12V/4A
·Car output: 12V/8A
·DC1/DC2 button: Car port /DC output
·Type-C output: 60W (PD) 5V/3A,9V/3A, 12V/3A, 15V/3A, 20V/3A
·USB-A output: 18W
·AC output: 110V/60Hz 600W
·PV input: 12.5V-30V/4.75A MAX
·DC input: 26V/4.75A
7
Charging from Solar Panel [Sold Separately]
Please charge the product through the PV input port with the solar
photovoltaic panel.
·Place your solar panel where it can get as much direct
sunlight as possible.
·Solar charging time depends on weather conditions.
How to Recharge Discover 600

8
The initial charging is crucial to the battery performance
of the product.
When charging for the first time, plug your new Discover 600
into an AC outlet until fully charged.
How to use the product:
·Cold temperatures can impact both the battery capacity and the
output power.
·If the battery temperature is higher or lower than the standard range,
the warning indicator on the LCD will light up.
·It can power your devices at temperatures
ranging from 14℉~104℉(-10℃~ 40℃).
·If the product is charged at a temperature below 32℉(0℃),
we suggest it be placed in a dry and insulated environment.
Working Temperature Range
Press the Power Button to start up corresponding output.
You will know the output is turned on when the corresponding LED
indicator lights up in red. Attention: When not using certain ports,
make sure to turn them off to conserve power.
The rated power of the AC output is 600W. Power over 600W will
cause the product to cut off automatically for overload protection.
When the AC output power reaches 600W, the 12V DC output will
be cut off to prioritize the power supply to the AC output.
Operation Guidance

9
·The LCD: charging/discharging mode.
·The remaining power indicator on the left: 5 segments and
each one represents 20% of the capacity.
·Input on the right: the amount of power (watts) going into the
product while charging.
·Output on the right: the amount of power (watts) your devices
are using while plugged into the product.
·The overheating icon on the screen: the unit is over-heating.
In: 0W
0WOut:
Power Display Input Power
Output Power
LCD Display

·USB Output:
Smartphones, digital cameras, tablet computers, etc.
·12V Car Power Output:
Lamps, automobile adapters, etc.
·AC Output:
Laptop, display screens, household appliances, etc.
Laptop 50W
About 12 Hours
Digital cameras
40-60 Rechargers
MINI refrigerator 60W
About 10 Hours
Respiratory 40W
About 16 Hours
UAV
About 10 Rechargers
Smart phones
40-60 Rechargers
32 inch TV 60W
About 10 Hours
Tablet 15W
About 40 Rechargers
10
What It Powers

11
When using this product, basic precautions should always be followed,
including the following: Read all the instructions before using the product.
The company takes no responsibilities for any damages caused by
customers’ failure to follow instructions. Any operation against the
instructions will void the warranty.
·To reduce the risk of injury, close supervision is required when this
product is used near children.
·The use of accessories recommended or sold by nonprofessional
product manufacturers may result in a risk of electric shock.
·Please pull the power plug out of the product socket when
the product is not in use.
·Do not use the product with incompatible components or dismantle the
product in any way. Take it to a qualified service person when service or
repair is required. Incorrect reassembly may result in a risk of fire or
injury to persons.
·Do not use damaged wires or plugs or output cables to connect the
product, which may result in a risk of electric shock.
·Please charge the product in a well-ventilated place. Do not restrict the
ventilation of the product in any way.
·Please put the product in a ventilated and dry place to avoid the rain.
Water inflow may result in a risk of electric shock.
·Do not expose the product to fire or excessive temperature. Exposure to
fire or temperature above 284℉(140 ℃) may cause an explosion.
General Safety

If the product cannot charge or power other devices,
please check according to the following steps:
·Make sure the output port is on and the LED indicator above the power
button lights up in red.
·Please check the remaining power indicator on the LCD. If it is at 20%
or below, please recharge the product as soon as possible.
·Please check your electronic device’s required power to see whether
it exceeds the maximum output power of the product.
·Please check your electronic device connection to see whether it is
well connected.
·If the screen cannot display well, such as blank or with garbled code,
please press and hold the screen switch for about 5 seconds to reboot.
Note: If there are some problems with your Discover 600,
please contact us at [e-mail].
·Full charge the unit before storage and switch off all power buttons.
·Keep it in a cool, dry place for long-term storage. Temperature within
32~104℉(0~40℃)，avoid direct sunlight.
·Keep the battery lying flat during recharging, charging or storing.
·Clean the unit with a dry cloth gently and carefully.
·DO NOT stack anything on top of the unit either in storage or in use.
·Full charge the unit at least once every 3 months.
12
When using this product, basic precautions should always be followed,
including the following: Read all the instructions before using the product.
The company takes no responsibilities for any damages caused by
customers’ failure to follow instructions. Any operation against the
instructions will void the warranty.
·To reduce the risk of injury, close supervision is required when this
product is used near children.
·The use of accessories recommended or sold by nonprofessional
product manufacturers may result in a risk of electric shock.
·Please pull the power plug out of the product socket when
the product is not in use.
·Do not use the product with incompatible components or dismantle the
product in any way. Take it to a qualified service person when service or
repair is required. Incorrect reassembly may result in a risk of fire or
injury to persons.
·Do not use damaged wires or plugs or output cables to connect the
product, which may result in a risk of electric shock.
·Please charge the product in a well-ventilated place. Do not restrict the
ventilation of the product in any way.
·Please put the product in a ventilated and dry place to avoid the rain.
Water inflow may result in a risk of electric shock.
·Do not expose the product to fire or excessive temperature. Exposure to
fire or temperature above 284℉(140 ℃) may cause an explosion.
Troubleshooting
Storage and Maintenance

13
Q1: What type of battery is in the product?
A: This product uses a power cylindrical 18650 lithium-ion battery.
Q2: How do I know whether the product is well charged?
A: Check the battery level by pressing the capacity button on the LCD.
Q3: Can it charge and discharge simultaneously?
A: Yes, but it is not recommended to charge and discharge at the same time in
order to protect the battery life. It is OK to use the product even when it’s not
fully charged.
Q4: Can l take the product onto a plane?
A: No. Since the product contains a large volume of lithium-ion batteries with a
maximum power capacity of 540Wh, it is deemed as a dangerous article and
not allowed on planes under FAA regulations.
Q5: How long will the product run my device?
A: 540Wh*0.8/operating power of your device=the actual working time.
The calculation formula is:
the maximum power capacity of the product the conversion efficiency of the
product /operating power of your device. For example, the output of the product
with a maximum power capacity of 540Wh, and your electronic device with a
rated power of 100W, the product can continuously run for 4.3 hours.
Note: 0.8 represents the conversion efficiency of the product,
because the product will lose a small amount of energy during
discharge.
*
FAQs

Nurzviy warrants to the original consumer purchaser that the Nurzviy
product will be free from defects in workmanship and material under
normal consumer use during the applicable warranty period identified in
the “Warranty Period” section below. This warranty statement sets forth
Nurzviy’s total and exclusive warranty obligation. We will not assume, nor
authorize any person to assume for us any other liability in connection with
the sale of our products.
Warranty Period
The warranty period for Discover 600 is 24 months. In each case, the
warranty period is measured starting on thedate of purchase by the
original consumer purchaser. The sales receipt from the first consumer
purchase, or other reasonable documentary proof, is required in order to
establish the start date of the warranty period.
How to Get Warranty Service
To get warranty service, please contact our customer service through
[e-mail] or call [phone], thank you!
14
Warranty and Contact

Nurzviy Energy, Inc.
4555 GREAT AMERICA PKWY 5TH FL SANTA CLARA,
CA 95054 UNITED STATES
[phone]
www.nurzviy.com
[e-mail]
·The company shall not be liable for any damage caused by force
majeure such as fire, typhoon, flood, earthquake or customers'
intentional negligence, misuse or use under other abnormal conditions.
·Defect caused by the non-standard connectors is not compensable.
·The company does not assume any responsibility for damage caused
by not operating the product in accordance with the instructions in the
operating instructions.
·This product is not suitable for atomic energy equipment, aerospace
equipment, transportation equipment, medical equipment, etc. which
are related with personal safety or equipment relies heavily on
uninterrupted electricity must be guaranteed. It is assumed that the
product is used on the above equipment or machine, the company is
not liable for any personal accidents, fire accidents, or malfunctions
caused by the malfunction of the product.
Disclaimer
