Nussbaum 4.250 H SST Operator's manual

4.80 H SST - 4.300 H SST
Automotive lift date: 10/2003
Manual date: 24.10.2003
Operating Instruction and Documentation
Serial number: .....................................
Nußbaum Hebetechnik GmbH & Co.KG//Korker Straße 24//D-77694 Kehl-Bodersweier//Tel: [phone]
Fax: [phone]//E-mail: [e-mail]//http://www.nussbaum-lifts.de
retailer/ phone
4.80 H SST
-
4.300 H SST E 10
-
03.doc

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 2 -
Contents
Foreword.................................................................................................................................3
Record of installation..............................................................................................................5
Record of handing over...........................................................................................................6
1.Introduction.............................................................................................................................7
1.1 Installation and check of the automotive lift..................................................................... 7
1.2 Information of Warning....................................................................................................7
2.Master document of the automotive lift..................................................................................8
2.1 Lift–manufacturer .............................................................................................................8
2.2 Application........................................................................................................................8
2.3 Changes at the construction .............................................................................................. 8
2.4 Displacement of the automotive-lift .................................................................................8
2.5 CE-Certificate ...................................................................................................................9
3. Technical Information..........................................................................................................11
3.1 Technical ratings.............................................................................................................11
3.2 Safety device...................................................................................................................11
3.3 Data sheet........................................................................................................................13
3.4 Foundation diagram drawing..........................................................................................14
4. Safety regulations................................................................................................................. 15
5. Operating instructions..........................................................................................................16
5.1 Lifting the vehicle...........................................................................................................16
5.2 Lowering the vehicle.......................................................................................................16
5.3 Equalisation of the Lift ...................................................................................................17
5.4 Function Microprocessor / Display-advertisement.........................................................17
5.5 The lift is not in the rule-window ...................................................................................17
5.6 Function of the bypass-switch in case of unequal level of the platform........................17
6.Troubleshooting ....................................................................................................................18
6.1 Driving on an obstacle .................................................................................................... 18
6.1.1 Remove an obstacle..................................................................................................19
6.2 Emergency lowering....................................................................................................... 19
6.2.1 Procedure of the emergency lowering......................................................................19
6.3 Reset the lift after an emergency lowering.....................................................................21
7.Inspection and Maintenance of Nussbaum lifts ....................................................................22
7.1 Maintenance plan of the Mobile column lift...................................................................22
7.2 Cleaning of the Mobile column lift.................................................................................23
8.Security check.......................................................................................................................24
9.Handing over and Initiation...................................................................................................24
9.1 Regulations .....................................................................................................................24
9.3 Adjusting the rail.............................................................................................................26
9.4 Changing the installation place.......................................................................................26
9.5 Initiation..........................................................................................................................27
First security check before installation .................................................................................30
Hydraulic diagram drawing ..................................................................................................44
Electrical diagram drawing...................................................................................................46

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 3 -
Foreword
Nussbaum-Lifts are a result of long-standing experiences.
The high quality and the superior concept guarantee them reliability, a long lift time and the
economic business.
To avoid unnecessary damages and dangers, read the operating instruction attentive and
observe the contents.
Another or the described purpose going out use is not valid when not as agreed.
This is valid particularly for climb and go.
Company Nussbaum is not liable for damages arising from this. The user carries the risk
a lonely.
For the use belonged:
- to observe all the notice in the operating instruction and
- the following of the inspection and maintenance work and the prescribed tests.
- The instruction for use have to be observed by all persons working with the lift.
- Especially the chapter “Safety/accident Prevention“ has to be observed.
- In addition to the safety remarks of the instructions for use the regulations and
instructions being valid at the place of operation have to be considered.
Obligations of the operator:
The operator is obliged to allow only those persons complying to the following requirement to
work at the unit
- being well acquainted with the basic regulations concerning labour safety and accident
prevention and being trained to operate the unit.
- having read and understood the chapter concerning safety and warning instructions and
confirmed that by their signature.
Dangers when operating with the lift:
The Nussbaum-Lifts are designed and built according to technical standard and the approved
regulations for technical security. Yet, danger for body and life of the operator may turn up
when using the lift inexpertly.
The lift must only be operated :
- for its appropriate use
- in unobjectionable condition concerning technical security.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 4 -
Organising requirements
- The instructions for use are constantly to be kept at the place of operation being at hand
at any time.
- In addition to the instructions for use rules pertaining to other regulations i.e. accident
prevention and environmental rules are to be observed and directed.
- Safety- and danger alert operation of personal is occasionally and by observing the
instructions for use to be controlled.
- As far as required and ordered by regulations personal protective equipment is to be
used
- All safety- and danger-hints at the lift are to be observed!
- Spare parts must comply with technical requirements laid down by the manufacturer.
This is only warranted with original parts.
Consider time intervals given or fixed in instructions for use for repeated
tests/inspections.
Maintenance works, remedy of faults and disposal
- Fixed Adjusting-, maintenance- and inspection works and time intervals including
Details for exchange of parts/part components as mentioned in the instructions for use
are to be adhered.
These works must only be carried out by expert personal.
- After maintenance- and repair works loose screw connections must always be firmly
tightened!
Guarantee and liability
- Our “General conditions of selling and delivering” are in force.
There will be no guarantee or liability for incidents involving injuries or death or damage
to equipment if these incidents are the result of one or more of the following reasons.
- Inappropriate use of the lift
- Inappropriate installation, initiation, operation and maintenance of the lift.
- Use of the lift while one or several security devices do not work, do not work correctly or
are not installed correctly.
- Failure to follow the regulations of the operating instructions regarding transport, storage,
installation, initiation, operation and maintenance of the lift.
- Unauthorized changes to the structure of the lift without first asking the producer.
- Unauthorized changes of adjustments of important components of the lift (e.g. driving
elements, power rating, motor speed, etc)
- Wrong or incorrect maintenance practice.
- Catastrophes, acts of God or external reasons.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 5 -
Filling out and undersigned and copying this sheet and send the original to the
lift manufacturer. The copy remains in the Manual.
Otto Nussbaum Hebetechnik GmbH & Co. KG
Korker Straße 24
D-77694 Kehl-Bodersweier
Record of installation
The automotive lift 4.80 H SST – 4.300 H SST with the
serial number:............................................ was installed on:...............................................
at the firm:................................................. at:.....................................................................
the safety was checked and the lift was started.
The installation was effected from the operating authority/competent (please delete as applicable).
The safety of the automotive lift was checked from the competent before the initial operation.
The operating authority attest the installation of the automotive lift, the competent attest the
correct initial operation.
............................................ ..................................................... ............................................
date name of the operating authority signature of the operating authority
............................................ ..................................................... ............................................
date name of the competent person signature of the competent person
Service partner:............................................................................................................................
Automotive lift date: 10/03 / Manual date: 24.10.2003

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 6 -
Record of handing over
The automotive lift 4.80 H SST – 4.300 H SST with the
serial number:............................................ was installed on:...............................................
at the firm:................................................. at:.....................................................................
the safety was checked and the lift was started.
The persons below were introduced after the installation of the automotive lift. The
introduction was carried out from an erector of the lift-manufacturer or from a franchised
dealer (competent person).
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name of competent signature of the competent
Service partner:............................................................................................................................

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 7 -
1.Introduction
The document ”Operating Instructions and Documentation” contains important
information about installation, operation and maintenance of the automotive lift.
To furnish proof of installation of the automotive lift the form ”Record of Installation”
must be signed and returned to the manufacturer.
To furnish proof of the singular, felt this documentation contains forms. The forms should
be used to document the checks. They should not be removed from this documentation.
Every Changes to the construction and displacement of the automotive lift must be
registered in the ”Master document” of the lift.
1.1 Installation and check of the automotive lift
Only specialist staff is allowed to do work concerning safety and to do the safety checks of
the lift. They are called experts and competent person in this document.
Experts are persons (for example self-employed engineers, experts) which have
received instruction and have experience to check and to test automotive lifts.
They know the relevant labour and accidents prevention regulations.
Competent person are persons who have acquired adequate knowledge and experience
with automotive lifts. They took part in training from the lift-manufacturer
(servicing technicians of the manufacturer or dealer, are competent)
1.2 Information of Warning
To show danger and to show important information the three symbols below are used. Pay
attention to those passages, which are marked with these symbols
Danger! This sign indicates danger to life. Inexpert handling of the described
operation may be dangerous to life.
Caution! This sign cautions against possible damage to the automotive lift or other
material defects in case of inexpert handling .
Attention! This sign indicates for an important function or other important
notes.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 8 -
2.Master document of the automotive lift
2.1 Lift–manufacturer
Otto Nußbaum Hebetechnik GmbH & Co. KG
Korker Straße 24
D-77694 Kehl-Bodersweier
Germany
2.2 Application
The automotive lift 4.80 H SST – 4.300 H SST is a lifting mechanism for lifting motor
vehicles with a laden weight of up to 8000 kg – 30.000 kg. The max. load distribution
2:1 in or against drive-on direction. The automotive lift is only designed for service at
the vehicles. It is not allowed to carry persons with the lift.
It’s not allowed to install the standard-automotive lift in a hazardous location or
washing bays.
2.3 Changes at the construction
Changes at the construction, expert checking, resumption of work (date, kind of
change, signature of the expert)
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
name, address of the expert
........................................................... ............................................................
place, date signature of the expert
2.4 Displacement of the automotive-lift
Displacement of the automotive-lift, expert checking, resumption of work (date, kind
of change, signature of the competent)
..................................................................................................................................................
..................................................................................................................................................
name, address of the competent
........................................................... ............................................................
place, date signature of the competent

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 9 -
2.5 CE-Certificate

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 10 -

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 11 -
3. Technical Information
3.1 Technical ratings
Capacity: *after implementation
8000 kg - 30.000 kg
Lifting time approx. 100 sec. with load (*)
Lowering time approx. 55 sec. with load
Line voltage 3 x 400 Volt , 50Hz
Control voltage 24 V
Power rating 1,5 kW
Motor speed 1400 rotation/min
Pump capacity 3 cm3
Hydraulic pressure approx. 220 bar with load
Pressure relief valve approx. 250 bar with load
Pressure relief valve (safety device) max. 35 bar
Oil tank approx. 17 L per hydraulic unit
Sound level ≤75 dB(A)
Connection by customer (standard) 3~/N+PE, 400V, 50 Hz
with fuse T16A
(Pay attention to the tension of your state)
3.2 Safety device
1. Pressure relief valve
Overprint-safety of the hydraulic system
2. Holding valve
safety device against unintentional lowering
3. Lockable main switch
safety device against unauthorised operation
4. CE-STOP
safety device against squeeze
5. Hydraulically unlocking safety-system at the cylinder
Safety device against unintentional lowering
6. Safety Star System (SST)
• The SST observed the complete Process of the Lift during „Lifting“ and
„Lowering“.
• The lift will be lowering during the normal work with 0,05 Meter per sec.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 12 -
If the lift descends noticeable faster there may be a problem with the hydraulic
system. The computer-control-system recognizes the problem and switch off the
hydraulic supply for the cylinder.
The Safety-star system locks and the lift stopped.
- Switch off the main switch.
- Check the complete hydraulic system. If the system is defective, call the service of
your retailer.
• The lift can be repaired by an expert, the satisfactory knowledge and experiences
with hydraulic ramps has.
CE-STOP (main lift and wheel free lift)
• The automotive lift stops automatically approx. 320 mm before the lowest position.
- Check the dangerous places of the lift and be sure that there are no objects or people
in the immediate area of the lift or on the lift.
- An acoustic signal is heard until the lift is in the lowest position
Top-Limit
• The Computer-control-system recognizes the top-height position of the lift and
switch off.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 13 -
3.3 Data sheet

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 14 -
3.4 Foundation diagram drawing
B
ei Erstellun
g
des Fundamentes ist die unbedin
g
t die Schienenlän
g
e zu prü
f
en.
Check the length before construction the foundation.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 15 -
4. Safety regulations
Using automotive lifts for working the regulations of accident EN1493/Aug.98 (CEN/TC
98 „ Automotive lifts”) must be observed.
Especially the following regulations are very important:
• During working with the lift the operating instructions must be followed.
• The laden weight of the lifted vehicle mustn’t be more than 8000 kg – 30.000 kg
for automotive lift
• Only trained personnel over the age of 18 years old are to operate this lift.
• During lifting or lowering the vehicle it must be observed from the operator.
• It’s not allowed to stay under the lifted or lowered vehicle (except for the
operator).
• It’s not allowed to transport passengers on the lift or in the vehicle.
• It’s not allowed to climb onto the lift or onto a lifted vehicle.
• The automotive lift must be checked from an expert after changes in construction.
• At vehicles with low under body-freedom or with optional equipment’s, it is to be
tested previously whether damages can appear.
• It’s not allowed to start with operations at the lift before the main switch is
switched off.
• It’s not allowed to install the standard-automotive lift in hazardous location.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 16 -
5. Operating instructions
The Safety Regulations must be observed during working with the automotive lift.
Read the safety regulations in chapter 4 carefully before working with the lift!
5.1 Lifting the vehicle
• Drive vehicle over the lift, longitudinal axes on line of the lift.
• Block the vehicle against rolling, put into gear.
• Check the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift.
• Switch on the control system; main switch on position ”1” (see pic.1)
• Raise the lift. Press the button „lifting“.
• Lift the vehicle on the working height
• In the display of the operating unit, the momentary height of the platform can be
read.
• Observe the complete process.
Pic 1: Operating unit
1 Button „Lifting“
2 Button „Lowering“
3 Button „equalization the platform“
4 Lighting switch
5 Keyboard and Display
6 Main switch
5.2 Lowering the vehicle
• Check the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift.
• Lower the vehicle to the working height or until the platform reaches the lowest
point; press the button „lowering“ .
The lift is raising a few millimetre before the lift lowered (the safety device is
unlocking).
• Observe the complete process.
The lift stops before reaching the lowest position CE-Stop).

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 17 -
Control the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift. Press the button
“Lowering” until the lift again. You hear an acoustic signal until the lift is
reaching the lowest position.
• Drive the vehicle out of the lift if the lift is in the lowest position.
5.3 Equalisation of the Lift
• Press the button „Equalization the platform“ at the operation unit. The Platform of
the lift equalize.
5.4 Function Microprocessor / Display-advertisement
• The automotive lift is equipped with a microprocessor. This system recognizes an
unequal of the lift and regulate the hydraulic valves until the lift has the same
height.
• The processor recognizes the present position of the cylinder. The lift switched off
if the automotive lift reaches the top end position or the bottom end position or the
position of the CE-Stop.
• The display shows the present position of the cylinder.
• this display is required also for the service-business, over a foil-keyboard.
5.5 The lift is not in the rule-window
• The lift switched off, if the lift is not in the rule-window of ± 50 mm.
• Read the chapter 5.6 step B to put the lift in the normal Function.
5.6 Function of the bypass-switch in case of unequal level of the platform
Pic 2: Position of the bypass switch
A) Do not press the button „lifting“ shortly consecutively before the lift was lowered 50
mm. Otherwise the lift will raising over the top limit position. After, it is not possible
to lower the lift again with the button „lowering“.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 18 -
B) In this case it is possible to lower the lift with the button „lowering and the bypass
switch. Press both buttons simultaneously (see pic 2, arrow) until the lift has the
normal function again.
Take careful, otherwise a malfunction can occur.
6.Troubleshooting
If the lift does not work properly, the reason for this might be quite simple. Please check
the lift for the potential reasons mentioned on the following pages. If the cause of
trouble cannot be found, please call the technical service
Problem: Motor does not start!
Potential causes: solution:
- no power supply Check the power supply
- main switch is not engaged Check the main switch
- fuse defective Check the fuse
- the feed line is cut Check the feed line
- Button „lifting“ defective Check the button
- Thermo fuse active Let it cool down
- Out of the rule-window ± 50 mm Read chapter 5.5
Problem: Motor starts, lift does not lifting!
Potential causes: solution:
- The vehicle is too heavy Unload the vehicle
- Level of the oil is too low Fill in new hydraulic oil
- The hydraulic valve is defective Call the lift service
Problem: The lift does not lowered!
Potential causes: solution:
- The lift is standing on a obstacle Read chapter 6.1
- The hydraulic valve is defective Call the lift service
- fuse defective Check the fuse
- button „lowering“ is not pressed or defective Check the button
- the holding valve is defective Call the lift service
- the safety device is locked Call the lift service
6.1 Driving on an obstacle
If the Safety-Star-System recognizes a difference of ± 50 mm between the platforms
then it switches off the lift.

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 19 -
6.1.1 Remove an obstacle
Only trained and authorized staff is allowed to work with the DIP-switches! The
main-switch has to be switched off!
• Remove the cover of the operating unit and the control box.
• Press the button “lifting” and the bypass switch simultaneously. (pic 3, arrow).
Raise the lift until the object can be removed.
After it, lower the lift in the lowest position and enforce a reset.
Take careful, otherwise a malfunction can occur.
6.2 Emergency lowering
A emergency lowering is an intervention into the control of the lift and can be
done only by experienced expert.
The emergency lowering must be carried in this order. Otherwise a malfunction
can lead it to damages or lead to danger for body and lives.
Every kind of external leakage has to be removed. This is necessary in particular
before an emergency lowering.
The emergency lowering may only be done by persons which are trained in using
the lift.
Reasons, that can make an emergency lowering necessary, are a defect of the electric
system or disturbances of the valves, etc.
In case of power-failure or defective Valves there is the possibility through suitable
tools to lower the lift in the lowest position, so that the vehicle can be driven off.
6.2.1 Procedure of the emergency lowering
• Switch off the main switch an d safe it. (lock it)
• Remove the covers of hydraulic unit.
• Secure the dangerous place around the lift.
Pic 6:
Loosen and remove the 2 lock nuts with a suitable
tool in arrow direction. Carry out this process at
both columns. (Key 41)

Operating Instruction and Documentation
4.80 H SST- 4.300 H SST
- 20 -
Pic 7:
The piston rod can be stuck through the dirty
deposit at the top of the hole. Use the solvent and
lubricating stuff (for an example WD40) to
loosen the connection. The WD40 is sprayed
generously between the screw thread and the
bore hole (see arrow). The time of the effect
follows the contamination-degree.
Pic 8:
Loosen the cap of the Minimess connection and the
cap of the tank. Fasten the Minimess hydraulic tube
at the screw fitting and put the other end into the
tank.
Pic 9:
Use the long screw thread-bushing and
turns with a suitable tool (key-wideness 24,
available with your dealer,), clockwise.
Lower the lifting carriage only approx. 5cm
– 10 cm. Repeat the process at the next
column. Lower always 5 cm-10 cm until all
lift are in the lowest position.
Repair the defective lift. After it create a
Reset which is described in the operating
instruction.
Attention!! Lower the automotive-lift only approx. 5cm – 10 cm.
Observe the complete emergency lowering process.
Do not work with the lift until the defective parts are changed.
