Nussbaum POWER LIFT HF 4600 User manual

POWER LIFT HF 4600 HYMAX HF 4600
2.46 HLK
Serien Nr. / Serial No. / Nº d. serie:
Otto Nußbaum GmbH&Co. KG • Korker Str. 24 • D-77694 Kehl-Bodersweier
www.nussbaum-group.de • E-Mail: [email protected]
Service Hotline Germany: 0800-5288911
Service Hotline International: [phone]
OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.2-DE-EN-FR-ES-IT_122017
Made
in
Germany
ORIGINALBETRIEBSANLEITUNG OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
Betriebsanleitung | Prüfbuch
mit Ersatzteilliste
Operating manual | Inspection book
including spare parts list
Manuel d’exploitation | Carnet de contrôle
avec liste des pièces détachées
Instrucciones de servicio | Libro de inspección
con lista de piezas de recambio
Manuale operativo | Registro di controllo
con lista pezzi di ricambio

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 3
DEUTSCH
Einleitung.............................................................................. 7
AufstelIungsprotokolI........................................................... 8
Übergabeprotokoll ............................................................. 9
1 Allgemeine Information.................................10
1.1 Aufstellung und Prüfung der Hebebühne............ 10
1.2 Gefährdungshinweise ............................................ 10
2 Stammblatt der Anlage .................................11
2.1 Hersteller................................................................... 11
2.2 Verwendungszweck............................................... 11
2.3 Änderungen an der Konstruktion.......................... 11
2.4 Wechsel des Aufstellungsortes .............................. 11
2.5 Konformitätserklärungen........................................ 12
3 Technische Information .................................14
3.1 Technische Daten .................................................. 14
3.2 Sicherheitseinrichtungen........................................ 14
3.3 Datenblatt POWER LIFT HF 4600 ............................ 15
3.4 Dübelbohrbild ......................................................... 16
3.5 Hydraulikplan........................................................... 17
3.6 Elektroschaltplan..................................................... 18
4 Sicherheitsbestimmungen.............................30
5 Bedienungsanleitung.....................................30
5.1 Positionierung des Fahrzeugs................................. 30
5.2 Anheben des Fahrzeugs ........................................ 31
5.3 Gleichlaufregelung der Hebebühne.................... 31
5.4 Senken des Fahrzeugs............................................ 31
6 Verhalten im Störungsfall...............................31
6.1 Notablass bei Stromausfall..................................... 32
6.2 Auffahren auf ein Hindernis ................................... 32
7 WartungundPegederHebebühne ...........32
7.1 Wartungsplan.......................................................... 34
7.2 Reinigung der Hebebühne.................................... 38
7.3 Überprüfung der Standsicherheit der
Hebebühne ............................................................. 38
8 Montage und Inbetriebnahme .....................38
8.1 Aufstellungsrichtlinien ............................................. 38
8.2 Tragarmmontage ................................................... 41
8.3 Inbetriebnahme...................................................... 41
8.4 Wechsel des Aufstellungsortes .............................. 41
8.5 Auswahl der Dübel ................................................. 41
9 Sicherheitsüberprüfung..................................42
9.1 Einmalige Sicherheitsprüfung vor Inbetrieb-
nahme...................................................................... 43
9.2 Regelmäßige Sicherheitsprüfung und Wartung.. 44
9.3 Außerordentliche Sicherheitsprüfung................... 54
ENGLISH
Introduction ....................................................................... 55
Set up protocol.................................................................. 56
Transfer protocol ............................................................... 57
1 General information.......................................58
1.1 Set up and test the lift ............................................ 58
1.2 Hazard information................................................. 58
2 System master sheet......................................59
2.1 Manufacturer .......................................................... 59
2.2 Purpose .................................................................... 59
2.3 Changes to the design / construction ................. 59
2.4 Changing the assembly location ......................... 59
2.5 Declarations of conformity.................................... 60
3 Technical information ....................................62
3.1 Technical data ....................................................... 62
3.2 Safety devices......................................................... 62
3.3 Data sheet POWER LIFT HF 4600 ............................ 63
3.4 Anchor pin drilling template.................................. 64
3.5 Hydraulic plan......................................................... 65
3.6 Electrical circuit diagram....................................... 66
4 Safety regulations...........................................67
5 Operatingmanual..........................................67
5.1 Positioning the vehicle ........................................... 67
5.2 Lifting the vehicle.................................................... 67
5.3 Lift synchronization.................................................. 68
5.4 Lowering the vehicle.............................................. 68
6 Behaviour in cases of error............................68
6.1 Emergency discharge during blackout ............... 69
6.2 Moving onto an obstacle ...................................... 69
7 Maintenance and care of the lift..................69
7.1 Maintenance plan.................................................. 70
7.2 Cleaning the lift....................................................... 74
7.3 Checking the stability of the lift............................. 74
8 Assembly and commissioning......................74
8.1 Set up guidelines..................................................... 74
8.2 Lifting arm assembly ............................................... 76
8.3 Commissioning........................................................ 77
8.4 Changing the assembly location ......................... 77
8.5 Selecting the anchors ............................................ 77
9 Safetyinspection............................................78
9.1 Single safety inspection before commissioning .. 79
9.2 Regular safety inspection and maintenance ..... 80
9.3 Exceptional safety inspection ............................... 90

Introduction
Nussbaum products are a result of many years of
experience. A high quality standard and superior
concept guarantees you reliability, long lifetimes
and economical operation. To prevent unnec-
essary damage and hazards, read this operating
manual carefully and always comply with its con-
tents.
Any other use, or use beyond purpose is considered
improper.
!Otto Nußbaum GmbH & Co.KG is not liable for
anyresultingdamage.Theoperatingcompany
alonecarriestherisk.
Properusealsoincludes:
• Adherence to all instructions in this operating
manual and
• Compliance with inspection and maintenance
work and the inspections stipulated.
• The operating manual is to be followed by all per-
sonnel working on the lift. This is notably with re-
gards to Section 4 “Safety conditions”.
• In addition to safety information from the operat-
ing manual, comply with rules and regulations at
the location of use.
• Proper system handling.
Operatingcompanyobligations:
The operating company is obliged to only permit
personnel to work on the system who
• Understand the principle regulations about work
safety and accident prevention and who have
been trained in working with the lift.
• Have read the safety section and warning infor-
mation in this operating manual, have under-
stooditandconrmedlearningwithasignature.
Hazardsinworkingwiththesystem:
Nussbaum products have been designed and built
to state-of-the-art and to recognised safety stan-
dards. However, improper use may lead to hazards
to life and limb of the user or result in property dam-
age.
The system may only be operated
• For proper intended use.
• If it is technically in perfect condition.
Organisational measures
• The operating manual is always to be kept ready
at the location of use of the system.
• Supplemental to the operating manual, refer to
and comply with generally valid legal and other
binding regulations for accident prevention and
for environmental protection.
• Check occasionally that personnel have an
awareness of hazards and safe work in compli-
ance with the operating manual!
• Use personal protective equipment as needed or
required by regulations.
• All safety and hazard information on the system is
to be kept in a legible condition!
• Replacementpartsmustmeettechnicalspeci-
cations of the manufacturer. This is only guaran-
teed for original parts.
• Deadlines pre-set or given in the operating man-
ual for repeating tests / inspections must be fol-
lowed.
Maintenancework,errorremoval
Comply with pre-determined setting, maintenance
and inspection work and intervals in the operating
manual, including details for exchanging parts /
partttings!Theseactivitiesmayonlybedoneby
specialists who have participated in a special fac-
tory training.
Guarantee and liability
• In principle, our “General sales and supply condi-
tions” apply.
Guarantee and liability claims for personal and
property damage are excluded if due to one or
more of the following causes:
• Improper use of the system.
• Improper assembly, commissioning, operation
and maintenance of the system.
• Operating the system with defective safety de-
vices or improperly attached or non-functional
safety and protection devices.
• Non-compliance with information in the operat-
ing manual in terms of transport, storage, assem-
bly, commissioning, operation, maintenance and
ttingofthesystem.
• Independent construction changes to the system.
• Independent changes to ..... (e.g. drive ratios:
power, rotation speed, etc.).
• Improperly done repairs.
• Catastrophic cases due to foreign inuences or
force majeure.
ENGLISH OriginalOperatingManual

56 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
Setupprotocol
iAfter successful set up, complete this form fully, sign it, make a copy and send the original to the man-
ufacturer within a week. The copy remains in the inspection book.
Otto Nußbaum GmbH & Co.KG
Korker Straße 24
D-77694 Kehl-Bodersweier
The system with serial number _____________________ was set up on (date) ______________________________
at (company name) _____________________________ in (town, city) _____________________________________
checked for function and safety and put into operation.
The set up was done by the operating company / specialist (score out the one that does not apply).
After successful inspection of function and safety by a trained assembler, the lift is transferred without elec-
trical connection (e.g. plug) to on-site power supply An on-site electrical connection between the lift and
thepowersupplyistobedonebyaqualiedelectrician(seedetailsintheelectricalplan).
Theoperatingcompanyconrmsproperliftsetup,hasreadandwillcomplywithallinformationcontained
in this operating manual and inspection book, and will keep this document accessible to trained operators
at all times.
Thespecialistconrmsproperliftsetup,hasreadallinformationinthisoperatingmanualandinspection
book, and has transferred the documents to the operating company.
Onlylloutifthesystemhasaxedanchor.
Anchor used *) ___________________________________________________________
Type/ brand
Minimum anchor depth *) complied with: __________ mm
Tightening torque *) complied with: __________ Nm
_________________________ _____________________________________________ _________________________
Date Name, operating company and company stamp Operating company signature
_________________________ _____________________________________________ _________________________
Date Name, specialist Signature of specialist
Service partner: _________________________________________________________________________
Stamp
*) See enclosed anchor manufacturer sheet

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 57
Transferprotocol
The system with serial number _____________________ was set up on (date) ______________________________
at (company name) _____________________________ in (town, city) _____________________________________
checked for function and safety and put into operation.
The following listed people (operators) were trained to handle the lift after it was set up by a trained assem-
bler of the manufacturer or a contract partner (specialist).
(Date, name, signature, empty lines must have a scored out)
_________________________ _____________________________________________ _________________________
Date Name Signature
_________________________ _____________________________________________ _________________________
Date Name Signature
_________________________ _____________________________________________ _________________________
Date Name Signature
_________________________ _____________________________________________ _________________________
Date Name Signature
_________________________ _____________________________________________ _________________________
Date Name Signature
_________________________ _____________________________________________ _________________________
Date Name, specialist Signature of specialist
Service partner: _________________________________________________________________________
Stamp

58 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
1 General information
Technical documentation contains important infor-
mation for safe operation and for retaining func-
tional safety of the lift.
• To verify lift set up, the assembly protocol form is
to be completed, signed and sent to the manu-
facturer.
• Forms are available in this inspection book for use
in verifying single, regular and extraordinary safety
checks. Use the forms to document inspections and
leave the completed forms in the inspection book.
• The lift master forms must record changes to the
construction or changes to set up location.
1.1 Setupandtestthelift
Safety relevant work on the lift and safety inspec-
tions may only be done by personnel specically
trained to carry it out. They are designated in gen-
eral and in this documentation as technical experts
and specialists (competent people).
• Technical experts are people (freelance expert
engineers, TÜV specialists) that may inspect and
assess due to their education and experience
with lifts. They are knowledgeable in the appro-
priate work safety and accident prevention reg-
ulations.
• Specialists (competent people) are people who
havesufcientknowledgeandexperiencewithlifts
and have participated in a special factory training
by the lifts manufacturer.
1.2 Hazard information
To become aware of the hazardous points and im-
portant information, the following three symbols are
used with the descriptive meaning. Pay particular
attention to text positions that are labelled by these
symbols.
i Note! Labels information about a key function or
points to an important remark!
! Caution!identiesawarningofpossiblesystem
damageorotheroperatingcompanyproperty
damageifthehighlightedprocessisnotdone
properly!
Danger!Identiesadangertolifeand
limb,ifthehighlightedprocessisnot
doneproperlythereisamortaldan-
ger!

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 59
2 System master sheet
2.1 Manufacturer
Otto Nußbaum GmbH & Co.KG
Korker Straße 24
D-77694 Kehl-Bodersweier
2.2 Purpose
The lift is a lifting tool for raising vehicles with a total weight of 4600 kg in normal workshop operation, for a
maximum lift distribution of 1:3 in the drive-in or against the drive-in direction. A single load from only one or
two lifting arms may not happen.
Set up of the standard lift in explosion endangered workshops and humid spaces (e.g. washing halls) is
prohibited.
Lift operation is done directly on the operating column (see Data sheet).
After construction and maintenance changes on load carrying parts the lift must be inspected afterwards
by a specialist who approves the changes. If the set up location is changed, the lift must be checked
again by a specialist and changed approved.
Load carrying capacity of the POWER LIFT HF 4600:
POWER LIFT HF 4600=4,600 kg
2.3 Changes to the design / construction
Inspections by a technical expert are required before recommissioning (date, type of change, technical
expert signature).
______________________________________________________________________________________________________
______________________________________________________________________________________________________
Name, address of technical expert
_________________________________________________ _________________________________________________
Location, date Technical expert signature
2.4 Changing the assembly location
Inspections by a technical expert are required before recommissioning (date, type of change, specialist
signature).
______________________________________________________________________________________________________
______________________________________________________________________________________________________
Name, address of technical expert
_________________________________________________ _________________________________________________
Location, date Signature of Technical Expert of Safety inspections

60 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
2.5 Declarations of conformity
2.5.1 POWER LIFT HF 4600

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 61
2.5.2 HYMAX HF 4600

62 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
3 Technical information
3.1 Technical data
Load carrying capacity: POWER LIFT HF 4600=
4600 kg
Loading a lifting arm: A single load from only
one lifting arm may not
happen
Load distribution: POWER LIFT HF 4600
max. 1:3 or 3:1 mm or
against the drive- in
direction
POWER LIFT HF 4600: Lift / lowering time:
approx. 35 s/seamless 0 –
max 24 s with 1750 kg
Standard operating
voltage:
3 ~/N+PE,400 volt, 50 Hz
Motor capacity POWER
LIFT HF 4600:
3 kW
Motor speed: 2880 rpm
Hydraulic pump: 2.7 cm³
Lifting pressure: 120 bar
Pressure relief valve: 250 bar
Oil volume: Approx. 10 litres (HLP32)
Noise level LpA: ≤70dB
On-site connection: 3~/N+PE, 400 V, 50 hz
with 16 A fuses, slow,
according to
VDE regulations
3.2 Safety devices
• Over-pressurevalve
Hydraulic system fuse against over-pressure.
• Checkvalve
Secure the vehicle against unauthorised lower-
ing.
• Mainswitchwithcurtainlockdevice
Fuse to prevent unauthorised use.
• Commandfollowsystemwithlatch
Secure against unauthorised lowering of the lift.
• Deadman controls
Lift movement stops when the operating lever is
released.
• Footbumpersontheliftingarms
Secure against shear and crushing points in the
foot area.
• Liftingarmblock
Secures the lifting arm against horizontal move-
ment in a lifted condition.
• Operatingleverwithcurtainlockdevice
Fuse to prevent unauthorised use.

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 63
3.3 Data sheet POWER LIFT HF 4600

64 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
3.4 Anchorpindrillingtemplate
Nr Aenderung Datum
Name
Urspr. Ersatz fuer: Ersatz durch:
Zeichnungsnummer
Norm Gepr. Bearb.
Datum Name
27.03.17
mh
8564_NB
HF4600 Duebelbohrbild
-
-
-
-
246hlk00010
(nur fuer interne Verwendung)
t=18

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 65
3.5 Hydraulicplan
Zeichnungsnummer
HF 4600 (246HLK)
1
Nr. Version
Name
Datum
von
Bearb.
Datum Name Benennung
Blatt
1
14.09.17 SBr
V00
230SLNT41150
F1
K1
A
RV1
DBV
B
RV2
1.4
SB
Stückliste:
0.1 Ölbehälter 240slh01013
0.2 Saugfilter 980012
0.5 Unterölmotor 3,0 kW 2Pol. 992658
0.4 Zahnradpumpe 2,7 cm³ 980340
0.5 Ölpeilstab 980011
1.0 Block kpl. 230SLNT41150
1.1 Druckbegrenzungsventil 155211
1.2 Kugelhahn 974820
1.3 Rückschlagventil 130053
1.4 Senkbremse 983629
2.1 Kommandozylinder 246HLK02041
2.2 Folgezylinder 246HLK02121
1.0
1.3 1.3
1.1
MeA
1.12
P
T1 T2
0.1
0.5
0.2
M
0.3
0.4
MeB
MeP
230SLNT41150_1 14.09.2017
0.1 240SLH01013 OIL CONTAINER
0.2 980012 SUCTION FILTER
0.5 992658 LOWEROILMOTOR3.0KW2POLE
0.4 980340 MECHANICAL PUMP 2.7 CM³
0.5 980011 OIL DIPSTICK
1.0 230SLNT41150 BLOCK ASSY.
1.1 155211 PRESSURE RELIEF VALVE
1.2 974820 BALL VALVE
1.3 130053 CHECK VALVE
1.4 983629 LOWERING BRAKE
2.1 246HLK02041 COMMAND CYLINDER
2.2 246HLK02121 DOWNSTREAM CYLINDER

66 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
3.6 Electrical circuit diagram
Grounding according to local regulations
Before commissioning check whether the nominal
motor current matches the motor protection relay.
Check all terminal points for proper connection
and that all contact screws are tight.
Before commissioning, check all wiring and controls
for proper function. Do not permit commissioning
from the unauthorised side.
These plans were generated on a CAD system. To
keep plans to the current state, we ask that you re-
quest Nussbaum to make the changes.
These circuit diagrams are intellectual property.
They may not be given to third parties or repro-
duced without our permission!
Rights to make changes are retained.
Circuitdiagramandswitchdocuments
Circuit diagrams were made to the best of our
knowledge.
No guarantee is made for the accuracy of enclosed
circuit diagrams and switch plans contained in this
document. This is particularly relevant for switches
that were completed by us according to third party
plans. This was done by us from purchaser provided
manufacturer documentation.
Functionaltestofswitchsystems
Circuit diagrams are not standard documents.
When checking the control cabinet at the facto-
ry, eld devices such as sensors, thermostats and
motors cannot be included. For this reason, even
with careful inspection, functional and switch errors
cannot always be prevented.
Decienciesareremovedwithinthescopeofguar-
antee during commissioning. During commission-
ing,ifourservicesarenotused,thennodeciency
liability is accepted. Rework, including informing
of circuit diagrams of switch systems not commis-
sioned by us are therefore only done to an invoice
according to our service terms and conditions.
Costs for rework by third parties cannot be hon-
oured.
Safetyinspectionandsafetymeasures
The control cabinet has been produced, set up
and inspected according to recognised technolo-
gy rules according to VDE0100/0113 and accident
prevention regulation VBG4 (electrical systems and
equipment)
The following tests were done:
• Voltage test and/or insulation test of the control
cabinet according to VDE0100/5.73
• Inspection of effectiveness of the safety mea-
sures used for indirect contact according to
VDE0100g/7.75 para. 22
• Functional test and part test according to
VDE560/11.87
Implemented safety measures:
• Protection against direct contact according to
VDE0100/5.73. Para. 4
• Protection against indirect contact according to
VDE0100/5.73. Para. 5
i See chapter 3.6 in the german
version for the diagrams.

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 67
4 Safety regulations
When working with lifts comply with legal acci-
dent prevention regulations according to BGG945:
Comply with inspection of lifts; BGR500, operation
of lifts; (VBG14).
Particularattentionisdrawntocompliancewith
thefollowingregulations:
• The max. load carrying capacity for lifts may not
be exceeded. For this, see details on the model
plate.
• Always follow the operating manual when using
the lift.
• The lift must be completely lowered before the
vehicle is driven on, and it may only be done in
the intended direction.
• Vehicles with low oor clearance or tted with
custom devices are to be checked to see wheth-
er damage could occur before positioning the
lifting arm and raising the vehicle.
• Only personnel aged 18 or over may operate
the lift independently, they must be trained in
liftoperationandhavetheirworkveriedbythe
company. You must be explicitly tasked with the
operation of the lift. (excerpt from BGR500) (see
transfer protocol).
• The proper positioning of the carrier plate below
the vehicle is to be checked again after the vehi-
cle has been raised slightly.
• After each set down of the vehicle, check the lift-
ing arm positions below the xture points again
and adjust as required.
• When disassembling heavy, consider any possible
centre of mass shifts. The vehicle is to be appro-
priately secured using suitable materials (e.g. ten-
sioning belts, beams, etc.) against falling.
• During lifting or lowering, the work area of the lift
should be clear or people.
• It is prohibited from moving people with the lift.
• Climbing onto the lift and onto a lifted vehicle is
prohibited.
• After design and maintenance on load bearing
parts the lift must be inspected by a technical ex-
pert.
• Vehiclesmayonly be attached atxturepoints
approved by the vehicle manufacturer.
• The entire lifting and lowering process is to be
continuously observed.
• It is prohibited to set up a standard lift in explosion
endangered workshops and humid spaces (E.g.
washing halls).
• Initial access to the lift is only permitted after the
main switch has been turned off and secured,
and the operating lever is additionally secured
against unauthorised use.
5 Operatingmanual
Whenhandlingthelift,itmustabso-
lutelycomplywithsafetyregulations.
Carefully read the safety regulations
inSection4beforerstoperation!
5.1 Positioning the vehicle
Drive the vehicle onto the lift according to the following
images,untiltheliftingarmreceivesit(gureAandB).
Figure. A) The lift column must be located between the steering
wheel and the car door hinges!
Figure. B) Drive in the middle of the lift.
Swivel in the lifting arms and extend out to the de-
sired position The adjustable receiving plates are to
be placed at the pointed prescribed by the vehicle
manufacturer.
5.2 Lifting the vehicle
• Lift the vehicle until the wheels are off the ground.
Push the operating lever forwards v"Lift" (see
gure4).
• If the wheels are not blocked, interrupt the lifting
process and check for proper seating of the car-
rier plate. Similarly check whether the lifting arm
blocks are ratcheted in. Otherwise, lower the lift
and reposition the vehicle.
• After each set down of the vehicle, check the lift-
ing arm positions below the xture points again
and adjust as required.

68 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
• Check that there are no people or objects in the
hazardous area of the lift.
• Afterwards, lift the vehicle to the desired working
height.
Ensuresecurevehicleplacementon
thecarrierplate,otherwisethereisa
dangerofthevehicledropping.
i See to it that the lifting arm blocks are ratcheted
in after the vehicle has been accepted.
Main switch
Lower into catches
Operating lever
Lift: Lift lever and push
Lower: Lift lever and pull
5.3 Lift synchronization
• Uneven running of the lift is not possible in proper
operation.
• For this, raise the lift to its uppermost end posi-
tion. Push the operating lever for 2 more seconds.
During this procedure the lift rails are equalised to
each other as hydraulic oil ows to the tank as
anoverowfromthecommandcylinderviathe
downstream cylinder to the tank.
• Release the operating lever. The lift rails then
lower some millimetres and thereby block the
overowopeningofthecylinder.
• Both lift rails are now at the same height.
5.4 Loweringthevehicle
• Check that there are no people or objects in the
hazardous area of the lift.
• Lower the vehicle to the desired working height
or to its lowest position; pull the operating lever
slowly v"Lower".
• For heavier vehicles, lift it slightly before lowering
to prevent an "sticking" and any corresponding
jolt during lowering.
• The lowering speed can be varied seamlessly.
• Once the lift is in the lowest position, push the lift-
ing arms to the start position.
Auffahrrichtung drive in direction
Lifting arm start position
Once the lift is in the lowest position, swing out the lifting arms to
the start position.
• Move the vehicle out of the lift.
6 Behaviour in cases of error
Defective operational readiness of the lift may be
due to a simple error. Check the system for the list-
ed sources of error.
If the error cannot be removed after an inspection
to the named causes, then inform customer service
or your dealer.
Independentrepairstothelift,espe-
ciallyonthesafetydevices,aswellas
inspectionsandrepairstoelectrical
systemsareprohibited.
Workonelectricalsystemsmayonly
be done by electricians.

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 69
Problem:Theliftcannotberaised
Possible causes: Remedy:
No power supply pres-
ent
Check power supply
The main switch is not
switched on, or is de-
fective
Check main switch
Operating lever defec-
tive
Check function
Defective fuse Check fuses
Power line interrupted Check power lines
Motor has overheated Let motor cool (cooling
time dependent on am-
bient temperature)
Motor defective Do an emergency dis-
charge (see Section 6.1)
Only 2 phases active Do an on-site check with
aqualiedelectrician
Insufcienthydraulicoil
available
Rellnewhydraulicoil
Problem:Theliftcannotbelowered
Possible causes: Remedy:
The lifting arm has
moved onto an obsta-
cle
Raise the lift and remove
the obstacle.
Operating lever defec-
tive
Notify customer service
Perform emergency dis-
charge. Slowly pull lever
6.1 Emergencydischargeduringblackout
There is the option of placing the lift into the lowest
position with a simple operation.
An emergency discharge can only be
donebypersonnelwhoaretrainedto
operatethelift.Followtheconditions
to"Lower".
Emergencydischargeprocedure
• People may not stand in the hazardous area
around the lift.
• Restrain latches.
• Slowly pull the operating lever. The lowering pro-
cedure begins immediately. Lowering speed can
be varied by the lever position.
• Always observe the lowering process.
• Lower the lift to the lowest position.
• Ifrequired,rstlyinformcustomerservice.
• Only operate the lift if it is in seamless condition
from a safety point of view again.
6.2 Moving onto an obstacle
If the lifting rails or lifting arms move onto an ob-
stacle due to operator inattention, the lift stops
in place. To remove the object, raise the lift to a
height where the object can be removed.
7 Maintenance and care of the lift
iBefore maintenance, do all preparation work
so there is no danger to life or limb or object
damage during maintenance and repair work.
Value is placed on long lifetimes and safety in
the development and production of Nussbaum
products. To guarantee the safety of the oper-
ator, product reliability, low running costs, keep
the warranty and also the long-lifetime of the
product, proper set up and operation is just as
important as regular maintenance and suf-
cient care.
iLegal principles: BSV (operating equipment
regulation) + BGR500 (Operation of work equip-
ment).
Ourplatformsfullorexceedallsafetystandardsof
the countries we supply to. For example, Europe-
anregulationsrequireaservicebyqualiedexperts
every 12 months of work of the platform. To guar-
antee the largest possible availability and function-
al capacity of the lift system, ensure the list of any
cleaning, care and maintenance work is done.
Afterrstcommissioningtheliftistobeservicedat
regular intervals of a maximum of one year by an
authorised person according to the following plan.
For intensive operation and higher degree of con-
tamination shorten the service interval.
The complete function of the lift is to be observed
during daily use. Customer service must be in-
formed of any malfunctions.

70 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
7.1 Maintenanceplan
iBefore beginning service, disconnect from power. The work area around the lift is to be secured against
unauthorised use.
Visual
inspection
Spray Oil Lubricate Cleanwith
compressed
air
Clean Inspect
Time frame Position
Typeof
maintenance
Maintenanceplan
As required
The lift cylinder can sweat and small oil droplets can form on the base
plate, this is however, not a leak.
Daily
1
12
11
10
9
8
7
6
5
4
3
2
365 x / 12
Model and information signs, labels, brief operating instructions,
safety stickers and warning information are to be cleaned and ex-
changed if damaged.
Daily
1
12
11
10
9
8
7
6
5
4
3
2
365 x / 12 Check the foot bumper for condition and function. Exchange if dam-
aged.
Daily
1
12
11
10
9
8
7
6
5
4
3
2
365 x / 12 The rubber acceptance plate is to be checked for wear and replaced
if necessary.
Every 3 months
Check the tracks and the lift rail equalization parts for wear. After
cleaning, grease with multi-purpose grease. We exclusively recom-
mend that MO-2 high performance lubricating grease is used. (avail-
able for purchase directly from Oest).
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12 Check the lifting arm block and gear for wear. Exchange if there is
visible damage.

OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT 71
Time frame Position
Typeof
maintenance
Maintenanceplan
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12
Lifting arm booms, lifting arm bolts, carrier plate threaded bolts are
to be checked for ease of running. If required, lightly grease with
multi-purpose grease. Do not over-lubricate.
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12
Check all fastening screws and anchors with a torque wrench.
Fastening class 8.8
0.08* 0.12** 0.14***
M8 17.9 23.1 25.3
M10 36 46 51
M12 61 80 87
M16 147 194 214
M20 297 391 430
M24 512 675 743
Fastening class 10.9
0.08* 0.12** 0.14***
M8 26.2 34 37.2
M10 53 68 75
M12 90 117 128
M16 216 285 314
M20 423 557 615
M24 730 960 1060
* Lubricated slide friction number 0.8 MoS2
** Lightly oiled slide friction number 0.12
*** Ensured slide friction number 0.14 screw with micro-encapsulated plastic
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12 All weld seams must have a visual inspection. Stop the system and
contact the manufacturer if there are cracks or breaks in weld seams
of the lift.
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12
Check electrical components for function and condition.
• Plug.
• Operating lever with button switch.
• During assembly and maintenance always check the condition of
electrical lines. All cables and lines must be secured so they cannot
be crushed, kinked or contact any moving assembly.
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12
Optional energy set:
• Electrical socket
• Pneumatic connection
Check for condition and function.

72 OPI-POWER LIFT HF 4600-HYMAX HF 4600-V2.3-DE-EN-FR-ES-IT
Time frame Position
Typeof
maintenance
Maintenanceplan
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12
Checkthepaint:
• Check the powder coating and improve if required.
Damageby external inuences istobe treated immediately after
detection.Ifthesepointsarenottreated,inltrationofdepositsofall
kinds can cause wide-ranging and permanent damage.
These points are to be lightly sanded (120 grit), cleaned and
degreased. Afterwards, rework with a suitable touch up paint (note
the RAL No.).
• Check galvanised surfaces, touch up as needed.
White rust is fostered by permanent humidity, poor ventilation. The
affected areas can be treated by using a sanding cloth (A 280 grit).
If required, the parts are to be treated with a suitable, resistant mate-
rial (paint etc.). Check the RAL colour selection.
• Rust is brought out by mechanical damage, wear, aggressive de-
posits (de-icing salt, leaking operating uids) cleaning that is not
done or incomplete.
The affected areas can be treated by using a sanding cloth (A 280
grit). If required, post-treat the areas with a resistant material (paint
etc.).
Annually
1
12
11
10
9
8
7
6
5
4
3
2
1 x / 12
According to manufacturer instructions, the hydraulic oil should be
changed every two years in normal operations. Various environmen-
tal inuences e.g. location, temperature swings, intensive operation
etc.,canhaveaninuenceonthequalityofthehydraulicoil.Forthis
reason, the oil must be checked during annual safety inspections and
maintenance.
The oil is used if it has a milky colour or if the hydraulic oil smells unpleas-
antly.
To change oil, lower the lift is to its lowest position then suction the oil
out of the oil container and replace the contents.
The manufacturer recommends high-quality clean hydraulic oil. The
required oil volume and type is to be taken from the technical data.
Afterlling,thehydraulic oil must bebetweentheupperand lower
markingontheoildipstick,orapprox.2.5cmbelowtheoilllingopen-
ing.
Dispose of the old oil according to regulations to the intended location
(districtofces,environmentalprotectionofceorcommercialregula-
toryofcehastheobligationtodiscloseaboutdisposalpoints).
