Nussbaum Sprinter NT Operator's manual

Sprinter NT
Automotive lift date: 12/99
Manual date: 20.12.99
Operating Instruction and Documentation
Serial number:...........................................
Nussbaum Hebetechnik GmbH & Co.KG//Korker Straße 24//D-77694 Kehl-Bodersweier//Tel: [phone]
Fax: [phone] / 87 87//E-mail: nussba[email protected]//http://www.nussbaum-lifts.de
Retailer address / phone

Operating Instruction and Documentation
Sprinter NT
- 2 -
Contents
Foreword....................................................................................................................... 3
Record of installation.................................................................................................... 5
Record of handing over................................................................................................ 6
1. Introduction.................................................................................................................. 7
1.1 Installation and check of the automotive lift.......................................................... 7
1.2 Information of Warning.......................................................................................... 7
2. Master of the document................................................................................................ 8
2.1 Lift-manufacturer.................................................................................................... 8
2.2 Application.............................................................................................................. 8
2.3 Changes at the construction.................................................................................... 8
2.4 Displacement of the automotive-lift....................................................................... 8
2.5 CE-Certificate/attestation of conformity................................................................ 9
3. Technische Information................................................................................................. 10
3.1 Technical ratings..................................................................................................... 10
3.2 Safety devices......................................................................................................... 10
3.3 Datasheet................................................................................................................. 11
3.4 Foundationplan........................................................................................................ 12
3.5 Hydraulic diagram.................................................................................................. 13
Hydraulic part list ................................................................................................... 13
3.6 Connection of the hydraulic tubes.......................................................................... 14
3.7 Electrical diagram drawing..................................................................................... 15
Electrical part list.................................................................................................... 15
4. Safety regulations......................................................................................................... 16
5. Operating instructions................................................................................................... 16
5.1 Lifting the vehicle.................................................................................................. 16
5.2 Lowering the vehicle.............................................................................................. 17
5.3 Deaerate the cylinder.............................................................................................. 18
5.4 Equalisation of the platform.................................................................................... 19
6. Troubleshooting............................................................................................................ 21
6.1 Driving on an obstacle........................................................................................... 21
6.2 Emergency lowering in case of power failure or defective valve......................... 21
7. Maintenance................................................................................................................. 23
7.1 Inspection and Maintenance of Nussbaum lifts.................................................... 23
7.2 Cleaning the automotive-lift.................................................................................. 24
8. Security check.............................................................................................................. 25
9. Installation and Initiation............................................................................................. 26
9.1 Installation of the automotive lift.......................................................................... 26
9.2 Regulations for the installation............................................................................. 26
9.3 Erection and doweling of the lift.......................................................................... 26
9.4 Extension of the hydraulic-hoses.......................................................................... 27
9.5 Initiation............................................................................................................... 28
9.6 Changing the installation place............................................................................ 28
Appendix
Selection of Dowels....................................................................................................... 29
Document "First security check before Installation".................................................... 31
Document "Regular security check"............................................................................. 32
Document "Extraordinary security check".................................................................... 40

Operating Instruction and Documentation
Sprinter NT
- 3 -
Foreword
Nussbaum-Lifts are a result of long-standing experiences.
The high quality and the superior concept guarantee them reliability, a long lift time and the
economic business.
To avoid unnecessary damages and dangers, read the operating instruction attentive and
observe the contents.
Another or the described purpose going out use is not valid when not as agreed.
This is valid particularly for climb and go.
Company Nussbaum is not liable for damages arising from this. The user carries the risk
alonely.
For the use belonged:
- to observe all the notice in the operating instruction and
- the following of the inspection and maintenance work and the prescribed tests.
-The instruction for use have to be observed by all persons working with the lift.
-Especially the chapter “Safety/accident Prevention“ has to be observed.
- In addition to the safety remarks of the instructions for use the regulations and
instructions being valid at the place of operation have to be considered.
Obligations of the operator:
The operator is obliged to allow only those persons complying to the following requirement to
work at the unit
- being well acquainted with the basic regulations concerning labour safety and accident
prevention and being trained to operate the unit.
- having read and understood the chapter concerning safety and warning instructions and
confirmed that by their signature.
Dangers when operating with the lift:
The Nußbaum-Lifts are designed and built according to technical standard and the approved
regulations for technical security. Yet, danger for body and life of the operator may turn up
when using the lift inexpertly.
The lift must only be operated :
-for its appropriate use
-in unobjectionable condition concerning technical security.

Operating Instruction and Documentation
Sprinter NT
- 4 -
Organising requirements
-The instructions for use are constantly to be kept at the place of operation being at hand
at any time.
- In addition to the instructions for use rules pertaining to other regulations i.e. accident
prevention and environmental rules are to be observed and directed.
- Safety- and danger alert operation of personal is occasionally and by observing the
instructions for use to be controlled.
-As far as required and ordered by regulations personal protective equipment is to be
used
- All safety- and danger-hints at the lift are to be observed!
- Spare parts must comply with technical requirements laid down by the manufacturer.
This is only warranted with original parts.
Consider time intervals given or fixed in instructions for use for repeated
tests/inspections.
Maintenanceworks, remedy of faults and disposal
-Fixed Adjusting-, maintenance- and inspectionworks and time intervals including
Details for exchange of parts/part components as mentioned in the instructions for use
are to be adhered.
These works must only be carried out by expert personal.
- After maintenance- and repair works loose screw connections must always be firmly
tightend!

Operating Instruction and Documentation
Sprinter NT
- 5 -
Filling out and undersigned and copying this sheet and send the original to the
lift manufacturer. The copy remains in the Manual.
Otto Nussbaum Hebetechnik GmbH & Co.KG
Korker Strasse. 24
77694 Kehl-Bodersweier
Germany
Record of installation
The automotive lift Sprinter NT with the
serial number:............................................ was installed on:...............................................
at the firm:................................................. at:.....................................................................
the safety was checked and the lift was started.
The installation was effected from the operating authority/competent (please delete as applicable).
The safety of the automotive lift was checked from the competent before the initial operation.
The operating authority attest the installation of the automotive lift, the competent attest the
correct initial operation.
............................................ ..................................................... ............................................
date name of the operating authority signature of the operating authority
............................................ ..................................................... ............................................
date name of the competent person signature of the competent person
Your customer service is the company:........................................................................................
.......................................................................................................................................................
Automotive lift date: 12/99 / Manual date: 20.12.1999

Operating Instruction and Documentation
Sprinter NT
- 6 -
Record of handing over
The automotive lift Sprinter NT with the
serial number:............................................ was installed on:...............................................
at the firm:................................................. at:.....................................................................
the safety was checked and the lift was started.
The persons below were introduced after the installation of the automotive lift. The
introduction was carried out from an erector of the lift-manufacturer or from a franchised
dealer (competent person).
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name signature
............................................ ..................................................... ............................................
date name of competent signature of the competent
Your customer service is the company:........................................................................................
....................................................................................................................................................

Operating Instruction and Documentation
Sprinter NT
- 7 -
1.Introduction
The document ”Operating Instructions and Documentation” contains important
information about installation, operation and maintenance of the Sprinter NT.
To furnish proof of installation of the automotive lift the form ”Record of Installation”
must be signed and returned to the manufacturer.
To furnish proof of the singular, felt this documentation contains forms. The forms should
be used to document the checks. They should not be removed from this documentation.
Every Changes to the construction and displacement of the automotive lift must be
registered in the ”Master document” of the lift.
1.1 Installation and check of the automotive lift
Only specialist staff is allowed to do work concerning safety and to do the safety checks of
the lift. They are called experts and competent person in this document.
Experts are persons (for example self-employed engineers, experts) which have
received instruction and have experience to check and to test automotive lifts.
They know the relevant labour and accidents prevention regulations.
Competent person are persons who have acquired adequate knowledge and experience
with automotive lifts. They took part in training from the lift-manufacturer
(servicing technicians of the manufacturer or dealer, are competent)
1.2 Information of Warning
To show danger and to show important information the three symbols below are used. Pay
attention to those passages, which are marked with these symbols
Danger! This sign indicates danger to life. Inexpert handling of the described
operation may be dangerous to life.
Caution! This sign cautions against possible damage to the automotive lift or other
material defects in case of inexpert handling .
Attention! This sign indicates for an important function or other important
notes.

Operating Instruction and Documentation
Sprinter NT
- 8 -
2.Master document of the automotive lift
2.1 Lift –manufacturer Otto Nussbaum Hebetechnik GmbH & Co. KG
Korker Straße 24
D-77694 Kehl-Bodersweier
2.2 Application
The automotive lift Sprinter NT is a lifting mechanism for lifting motor vehicles
with a laden weight of up to 3000 kg. The max. load distributation is 3:2 in or against
drive-on direction. The automotive lift is only designed for servicing vehicles. It is not
allowed to carry persons with the lift.
It’s not allowed to install the standard-automotive lift in a hazardous location or
washing bays.
2.3 Changes at the construction
Changes at the construction, expert checking, resumption of work (date, kind of
change, signature of the expert)
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
..................................................................................................................................................
name, address of the expert
........................................................... ............................................................
place, date signature of the expert
2.4 Displacement of the automotive-lift
Displacement of the automotive-lift, expert checking, resumption of work (date, kind
of change, signature of the competent)
..................................................................................................................................................
..................................................................................................................................................
name, address of the competent
........................................................... ............................................................
place, date signature of the competent

Operating Instruction and Documentation
Sprinter NT
- 9 -
2.5 CE-Certificate/attestation of conformity
The automotive lift Sprinter NT with the serial number.........................................................
Is in accordance with the tested lift (CE-certificate-number 04-205-1440/00)
................................................ ...............................................................
place, date company stamp, signature

Operating Instruction and Documentation
Sprinter NT
- 10 -
3. Technical Information
3.1 Technical ratings
Capacity: 3000 kg
Load distributation: 3:2 in or against drive-on direction
Lifting time: approx. 7 sec.
Lowering time: approx. 6 sec.
Line voltage: 3 x 400 Volt , 50Hz
Power rating: 3 kW
Motor speed: 3000 rotation/min
Pump capacity: 3 ccm/revolution
Hydraulic pressure: approx. 270 bar
Pressure relief valve: approx. 300 bar
Oiltank: approx. 14 litre - viscosity 32 cst.
Sound level: ≤75 dBA
Connection by customer (standard) 3~/N+PE, 400V, 50 Hz
with fuse T16A
(Pay attention to the tension of your state)
3.2 Safety device
1. Pressure relief valve
Overprint-safety of the hydraulic system
2. Holding valve
safety device against unintentional lowering
3. Lockable main switch
safety device against unauthorized operation
4. Foot protector
safety device against squeeze
5. Two independent cylinder system (master and slavesystem)
Safety device against unintentional lowering

Operating Instruction and Documentation
Sprinter NT
- 11 -
3.3 Datasheet

Operating Instruction and Documentation
Sprinter NT
- 12 -
3.4 Foundationplan
Foundation plan: quality of the concrete minimum. B25
wide minimum 2166 mm
lenght minimum 1400 mm
thickness minimum 160 mm
If the concrete is available the quality B25 and the thickness minimum 160 mm must be
guaranteed.
Concrete plate
It is possible to
mount the
operating unit on
the left side or on
the right side of the
lift
rail

Operating Instruction and Documentation
Sprinter NT
- 13 -
3.5 Hydraulic diagram
Hydraulic parts list
0.1 Oiltank
0.2 Suboilmotor
0.3 Gear pump
0.4 Filter
0.5 Oil level gauge
0.6 Pressure control valve
0.7 Holding valve
0.8 Electrical control valve
0.9 Emergency lowering screw
0.10 Equalisation screw
0.11 Flow control valve Ø1,5 mm
K1 commando cylinder 1
F1 slave cylinder 1
K2 commando cylinder 2
F2 slave cylinder 2

Operating Instruction and Documentation
Sprinter NT
- 14 -
3.6 Connection of the hydraulic tubes
Pos: Description piece/Lift
1 reduction 8 – 6 4x
2 T-piece NW8 2x
3 hydraulic tube 450 mm 4x
4 hydraulic tube 3400 mm 1x
5 hydraulic tube 3400 mm 1x
6 hydraulic tube 850 mm 2x
7 hydraulic tube 1500 mm 2x
8 hydraulic tube 2100 mm 1x
9 hydraulic tube 2700 mm 1x
KO master cylinder
FO slave cylinder
It is possible to mount the operating unit on the left side or on the right side of
the lift. Observe the cylinder pair, which is nearer to the operating unit, they
have the designation K1 and F1. The designation of the tubes becomes taken
over, indifferent where the operating unit stands.

Operating Instruction and Documentation
Sprinter NT
- 15 -
3.7 Electrical diagram drawing
Electrical part list
Pos. designation part number
A1 main switch 990129
KM1 up contactor 990214
T1 button „lifting“ 990334
T2 button „lowering“ 990334
y1 coil + plug 981393 + 981392
y2 coil + plug 981393 + 981392
F1 fuse 500 mA 990649
TR1 transformer 990659
M1 motor 990445

Operating Instruction and Documentation
Sprinter NT
- 16 -
4. Safety regulations
Using automotive lifts for working the regulations of accident EN1493/Aug.98 (CEN/TC
98 „ Automotive lifts”) must be observed.
Especially the following regulations are very important:
• During working with the lift the operating instructions must be followed.
• The laden weight of the lifted vehicle mustn’t be more than 3000 kg for automotive lift
• Only trained personnel over the age of 18 years old are to operate this lift.
• During lifting or lowering the vehicle it must be observed from the operator.
• Position the polymer supports as described of the vehicle manufacturer under the
vehicle.
• If necessary use the ramps.
• It’s not allowed to stay under the lifted or lowered vehicle (except for the operator).
• It’s not allowed to transport passengers on the lift or in the vehicle.
• It’s not allowed to climb onto the lift or onto a lifted vehicle.
• The automotive lift must be checked from an expert after changes in construction or
after repairing carrying pads.
• It’s not allowed to start with operations at the lift before the main switch is switched off.
• It’s not allowed to install the standard-automotive lift in hazardous location.
5. Operating instructions
The Safety Regulations must be observed during working with the automotive lift.
Read the safety regulations in chapter 4 carefully before working with the lift!
5.1 Lifting the vehicle
• Drive vehicle over the lift, longitudinal axes on line of the lift.
If necessary use the ramps for the safe position of the vehicle. If the wheelbase is
too short and the wheels are standing on the ramps, remove the ramps.
• Block the vehicle against rolling, put into gear.
• Position elastomer-supports under the pick-up points of the vehicle as prescribed
by the vehicle-manufacturer.

Operating Instruction and Documentation
Sprinter NT
- 17 -
The vehicle must be positioned on the elastomer supports in a safe way, otherwise
there’s a danger that the vehicle might fall down.
• Check the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift
• Switch on the control system; main switch on position ”1” (see pic.1)
• Lift vehicle until the wheels are free. Press button ”lifting”. Check that the vehicle
is safety positioned.
• Lift the vehicle on the working height. Press the button „lifting“ .
• Observe the complete process.
Pic 1: Operating unit
1 main switch
2 button „lifting“
3 button „lowering“
5.2 Lowering the vehicle
• Control the dangerous places of the lift and be sure that there are no objects or
people in the immediate area of the lift or on the lift
• Lower the vehicle to the working height or until the platform reaches the lowest
point; press the button “lowering“
• Observe the complete process.
• If the lift is in the lowest position, remove the polymer-supports.
• Drive the vehicle out of the lift.

Operating Instruction and Documentation
Sprinter NT
- 18 -
5.3 Deaerate the cylinder
• The automotive lift is complete assembled. The connection of the tubes and pipes
are right associated. Only the right power supply , the right oil and the right
portion of the oil and the closeness of the hydraulic parts have to be checked.
If the hydraulic connections be open (prolongation the tubes), air can penetrate in
the tubes.
• If you have an unequal run of the lift. You must check the lift. Check the
coordination of the hoses.
• If necessary a dearing of the cylinder must be carried out at these symptoms:
abruptly lifting from the lowest position, unequal platform with load, not
complete lowering of a platform in the lowest position.
Right dearing:
Checks whether 14 litres are in the oil tank. Oil level = between the upper and the
lower marker.
• Raise the lift – without load – in the highest endposition.
• Open the both equalisation screw A1 and A2 at the hydraulic block.
Remove before the plastic covers.
Pic.4
Position X = the bore hole is for the equalisation screw
• Loose the locknut of the equalisation screws A1 and A2 with a suitable tool.
Unscrew one turn the equalisation screws with a suitable tool.
• Press the button “lifting” approx. 1 sec. The automotive lift can incline.
• Open the vent screw at one cylinder. (easily opening)

Operating Instruction and Documentation
Sprinter NT
- 19 -
Pic.5
Position X = the vent screw at the cylinder
Attention: The lift sinks constantly to below. You can interrupt this process if you
close the vent screw.
• Open the vent screw so long, until only oil comes out of the bore hole. After this
close the screw.
• After this, open the vent screw from the other cylinder and deaerate as described.
Close the vent screw, otherwise a malfunction of the lift may occur.
• Raise the lift in the upper endposition. Press the button „lifting“ . If necessary repeat
the aeration.
• Check the vent screw. These must be closed.
• Lower the lift in the lowest position. Press the button „lowering“and hold it.
• If the lift reached the lowest position, close the equalisation screws (A1 and A2) and
secure it with the locknuts.
• Raise and lower the lift several times without load.
• Check the cylinder lever at the scissor again. (see pic.3)
•To ensure the equalisation of the lift, the chapter 5.4 must be observed
5.4 Equalisation the platforms
• During the normal work of the automotive lift it is almost impossible to get an
unequal run of the platform, by the two independent hydraulic systems.
• If you have an unequal run of the lift. Check the lift.
• If it is sure there is no leak in the hydraulics system and no other external fault, a
compensation may be carried out
• Lower the lift in the lowest position.
• Drive the vehicle from the lift.
• If necessary a compensation must be carried out at these symptoms:

Operating Instruction and Documentation
Sprinter NT
- 20 -
abruptly lifting from the lowest position, unequal platform with load, not
complete lowering of a platform in the lowest position.
Right equalisation:
Assumption: One platform is higher than the other platform.
Measure:
• Lower the lift in the lowest position. Press the button “lowering”.
Equalize the lift without load, otherwise the vehicle can mighty fall down.
• Remove on the right side and the left side the covers of the operating unit.
pic. 2
Position X =
The bore hole in the cover is for the equalisation screw.
• Loose the locknuts (SW17) of the equalisation screws A1 and A2 with a suitable
tool.
• Open slowly the screw A1 and A2. Press the button “lowering” until both
platforms are on the lowest position.
• During this process both platforms get balanced.
Further measure:
• Close the equalisation screw A1 and A2 and safe it with the locknut.
Close after equalisation the screws A1 and A2 and the locknuts. Otherwise a
malfunction of the lift may occur.
• Raise the lift in the upper end position. Press the button “lifting”
• Open the screws A1 and A2.
• Press the button "lowering". Lower the lift approx. 50 mm
